Container to encapsulate various operations for cubic equation of the forms with real coefficients: More...

Inheritance diagram for cubicEqn:

Collaboration diagram for cubicEqn:

Public Types
enum	components { A, B, C, D }

Public Types inherited from VectorSpace< cubicEqn, scalar, 4 >
typedef VectorSpace< Form, Cmpt, Ncmpts >	vsType

typedef Cmpt	cmptType

typedef Cmpt	magType

typedef Cmpt *	iterator

Public Member Functions
	cubicEqn ()

	cubicEqn (const Foam::zero)

	cubicEqn (const scalar a, const scalar b, const scalar c, const scalar d)

scalar	a () const

scalar	b () const

scalar	c () const

scalar	d () const

scalar &	a ()

scalar &	b ()

scalar &	c ()

scalar &	d ()

scalar	value (const scalar x) const

scalar	derivative (const scalar x) const

scalar	error (const scalar x) const

Roots< 3 >	roots () const

Public Member Functions inherited from VectorSpace< cubicEqn, scalar, 4 >
	VectorSpace ()=default

	VectorSpace (const Foam::zero)

	VectorSpace (const VectorSpace< Form, Cmpt, Ncmpts > &vs)

	VectorSpace (const VectorSpace< Form2, Cmpt2, Ncmpts > &)

	VectorSpace (Istream &is)

const Cmpt &	component (const direction) const

Cmpt &	component (const direction)

void	component (Cmpt &, const direction) const

void	replace (const direction, const Cmpt &)

const Cmpt *	cdata () const noexcept

Cmpt *	data () noexcept

const ConstBlock< SubVector, BStart >	block () const

const Foam::VectorSpace< Form, Cmpt, Ncmpts >::template ConstBlock< SubVector, BStart >	block () const

const Cmpt &	operator[] (const direction) const

Cmpt &	operator[] (const direction)

void	operator= (const VectorSpace< Form, Cmpt, Ncmpts > &)

void	operator= (const Foam::zero)

void	operator+= (const VectorSpace< Form, Cmpt, Ncmpts > &)

void	operator-= (const VectorSpace< Form, Cmpt, Ncmpts > &)

void	operator*= (const scalar)

void	operator/= (const scalar)

iterator	begin () noexcept

const_iterator	begin () const noexcept

iterator	end () noexcept

const_iterator	end () const noexcept

const_iterator	cbegin () const noexcept

const_iterator	cend () const noexcept

Additional Inherited Members
Static Public Member Functions inherited from VectorSpace< cubicEqn, scalar, 4 >
static constexpr direction	size () noexcept

static Form	uniform (const Cmpt &s)

Public Attributes inherited from VectorSpace< cubicEqn, scalar, 4 >
const typedef Cmpt *	const_iterator

Cmpt	v_ [Ncmpts]

Static Public Attributes inherited from VectorSpace< cubicEqn, scalar, 4 >
static constexpr direction	dim

static constexpr direction	nComponents

static constexpr direction	mRows

static constexpr direction	nCols

static const char *const	typeName

static const char *const	componentNames []

static const Form	zero

static const Form	one

static const Form	max

static const Form	min

static const Form	rootMax

static const Form	rootMin

Detailed Description

Container to encapsulate various operations for cubic equation of the forms with real coefficients:

$a*x^3 + b*x^2 + c*x + d = 0 x^3 + B*x^2 + C*x + D = 0$

The following two substitutions into the above forms are used:

$x = t - B/3 t = w - P/3/w$

This reduces the problem to a quadratic in w^3:

$w^6 + Q*w^3 - P = 0$

where Q and P are given in the code.

The properties of the cubic can be related to the properties of this quadratic in w^3.

If the quadratic eqn has two identical real roots at zero, three identical real roots exist in the cubic eqn.

If the quadratic eqn has two identical real roots at non-zero, two identical and one distinct real roots exist in the cubic eqn.

If the quadratic eqn has two complex roots (a complex conjugate pair), three distinct real roots exist in the cubic eqn.

If the quadratic eqn has two distinct real roots, one real root and two complex roots (a complex conjugate pair) exist in the cubic eqn.

The quadratic eqn is solved for the most numerically accurate value of w^3. See the quadraticEqn.H for details on how to pick a value. This single value of w^3 can yield up to three cube roots for w, which relate to the three solutions for x.

Only a single root, or pair of conjugate roots, is directly evaluated; the one, or ones with the lowest relative numerical error. Root identities are then used to recover the remaining roots, possibly utilising a quadratic and/or linear solution. This seems to be a good way of maintaining the accuracy of roots at very different magnitudes.

Reference:

    Kahan's algo. to compute 'p' using fused multiply-adds (tag:JML):
        Jeannerod, C. P., Louvet, N., & Muller, J. M. (2013).
        Further analysis of Kahan's algorithm for the accurate
        computation of 2× 2 determinants.
        Mathematics of Computation, 82(284), 2245-2264.
        DOI:10.1090/S0025-5718-2013-02679-8
