alphatWallFunctionFvPatchScalarField Class Reference

This boundary condition provides a turbulent thermal diffusivity condition when using wall functions. More...

Inheritance diagram for alphatWallFunctionFvPatchScalarField:

Collaboration diagram for alphatWallFunctionFvPatchScalarField:

Public Member Functions
	TypeName ("compressible::alphatWallFunction")
	alphatWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)
	alphatWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	alphatWallFunctionFvPatchScalarField (const alphatWallFunctionFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)
	alphatWallFunctionFvPatchScalarField (const alphatWallFunctionFvPatchScalarField &)
virtual tmp< fvPatchScalarField >	clone () const
	alphatWallFunctionFvPatchScalarField (const alphatWallFunctionFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
virtual tmp< fvPatchScalarField >	clone (const DimensionedField< scalar, volMesh > &iF) const
virtual void	updateCoeffs ()
virtual void	write (Ostream &) const

Detailed Description

This boundary condition provides a turbulent thermal diffusivity condition when using wall functions.

• replicates OpenFOAM v1.5 (and earlier) behaviour

The turbulent thermal diffusivity calculated using:

where

	=	turblence thermal diffusivity
	=	turblence viscosity
	=	turblent Prandtl number

Usage

Property	Description	Required	Default value
nut	turbulence viscosity field name	no	nut
Prt	turbulent Prandtl number	no	0.85

Example of the boundary condition specification:

    <patchName>
    {
        type            alphatWallFunction;
        nut             nut;
        Prt             0.85;
        value           uniform 0; // optional value entry
    }

See also

Foam::fixedValueFvPatchField

Source files

• alphatWallFunctionFvPatchScalarField.H
• alphatWallFunctionFvPatchScalarField.C

Definition at line 115 of file alphatWallFunctionFvPatchScalarField.H.

Constructor & Destructor Documentation

alphatWallFunctionFvPatchScalarField() [1/5]

alphatWallFunctionFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF
	)

Definition at line 38 of file alphatWallFunctionFvPatchScalarField.C.

Referenced by alphatWallFunctionFvPatchScalarField::clone().

Here is the caller graph for this function:

alphatWallFunctionFvPatchScalarField() [2/5]

alphatWallFunctionFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 62 of file alphatWallFunctionFvPatchScalarField.C.

alphatWallFunctionFvPatchScalarField() [3/5]

alphatWallFunctionFvPatchScalarField	(	const alphatWallFunctionFvPatchScalarField &	ptf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 49 of file alphatWallFunctionFvPatchScalarField.C.

alphatWallFunctionFvPatchScalarField() [4/5]

alphatWallFunctionFvPatchScalarField

(

const alphatWallFunctionFvPatchScalarField &

awfpsf

)

Definition at line 74 of file alphatWallFunctionFvPatchScalarField.C.

alphatWallFunctionFvPatchScalarField() [5/5]

alphatWallFunctionFvPatchScalarField	(	const alphatWallFunctionFvPatchScalarField &	awfpsf,
		const DimensionedField< scalar, volMesh > &	iF
	)

Definition at line 84 of file alphatWallFunctionFvPatchScalarField.C.

Member Function Documentation

TypeName()

TypeName

(

"compressible::alphatWallFunction"

)

clone() [1/2]

virtual tmp<fvPatchScalarField> clone ( ) const

inlinevirtual

Definition at line 166 of file alphatWallFunctionFvPatchScalarField.H.

References alphatWallFunctionFvPatchScalarField::alphatWallFunctionFvPatchScalarField().

Here is the call graph for this function:

clone() [2/2]

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > &  iF ) const

inlinevirtual

Definition at line 183 of file alphatWallFunctionFvPatchScalarField.H.

References alphatWallFunctionFvPatchScalarField::alphatWallFunctionFvPatchScalarField().

Here is the call graph for this function:

updateCoeffs()

void updateCoeffs ( )

virtual

Definition at line 96 of file alphatWallFunctionFvPatchScalarField.C.

References GeometricField::boundaryField(), Foam::constant::atomic::group, IOobject::groupName(), turbulenceModel::nut(), Foam::operator==(), Foam::foamVersion::patch, turbulenceModel::propertiesName, and compressibleTurbulenceModel::rho().

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Definition at line 125 of file alphatWallFunctionFvPatchScalarField.C.

References os(), and fvPatchField::write().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/TurbulenceModels/compressible/turbulentFluidThermoModels/derivedFvPatchFields/wallFunctions/alphatWallFunctions/alphatWallFunction/alphatWallFunctionFvPatchScalarField.H
• src/TurbulenceModels/compressible/turbulentFluidThermoModels/derivedFvPatchFields/wallFunctions/alphatWallFunctions/alphatWallFunction/alphatWallFunctionFvPatchScalarField.C
