Constructs on-the-fly a new boundary condition (derived from mixedFvPatchField) which is then used to evaluate. More...

Inheritance diagram for codedMixedFvPatchField< Type >:

Collaboration diagram for codedMixedFvPatchField< Type >:

Public Member Functions
	TypeName ("codedMixed")

	codedMixedFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &)

	codedMixedFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &)

	codedMixedFvPatchField (const codedMixedFvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

	codedMixedFvPatchField (const codedMixedFvPatchField< Type > &)

virtual tmp< fvPatchField< Type > >	clone () const

	codedMixedFvPatchField (const codedMixedFvPatchField< Type > &, const DimensionedField< Type, volMesh > &)

virtual tmp< fvPatchField< Type > >	clone (const DimensionedField< Type, volMesh > &iF) const

const mixedFvPatchField< Type > &	redirectPatchField () const

virtual void	updateCoeffs ()

virtual void	evaluate (const Pstream::commsTypes commsType=Pstream::commsTypes::blocking)

virtual void	write (Ostream &) const

Public Member Functions inherited from mixedFvPatchField< Type >
	TypeName ("mixed")

	mixedFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &)

	mixedFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &)

	mixedFvPatchField (const mixedFvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

	mixedFvPatchField (const mixedFvPatchField< Type > &)

	mixedFvPatchField (const mixedFvPatchField< Type > &, const DimensionedField< Type, volMesh > &)

virtual bool	fixesValue () const

virtual bool	assignable () const

virtual Field< Type > &	refValue ()

virtual const Field< Type > &	refValue () const

virtual Field< Type > &	refGrad ()

virtual const Field< Type > &	refGrad () const

virtual scalarField &	valueFraction ()

virtual const scalarField &	valueFraction () const

virtual Field< Type > &	source ()

virtual const Field< Type > &	source () const

virtual void	autoMap (const fvPatchFieldMapper &)

virtual void	rmap (const fvPatchField< Type > &, const labelList &)

virtual tmp< Field< Type > >	snGrad () const

virtual tmp< Field< Type > >	valueInternalCoeffs (const tmp< scalarField > &) const

virtual tmp< Field< Type > >	valueBoundaryCoeffs (const tmp< scalarField > &) const

virtual tmp< Field< Type > >	gradientInternalCoeffs () const

virtual tmp< Field< Type > >	gradientBoundaryCoeffs () const

virtual void	operator= (const UList< Type > &)

virtual void	operator= (const fvPatchField< Type > &)

virtual void	operator+= (const fvPatchField< Type > &)

virtual void	operator-= (const fvPatchField< Type > &)

virtual void	operator*= (const fvPatchField< scalar > &)

virtual void	operator/= (const fvPatchField< scalar > &)

virtual void	operator+= (const Field< Type > &)

virtual void	operator-= (const Field< Type > &)

virtual void	operator*= (const Field< scalar > &)

virtual void	operator/= (const Field< scalar > &)

virtual void	operator= (const Type &)

virtual void	operator+= (const Type &)

virtual void	operator-= (const Type &)

virtual void	operator*= (const scalar)

virtual void	operator/= (const scalar)

Public Member Functions inherited from fvPatchField< Type >
	TypeName ("fvPatchField")

	declareRunTimeSelectionTable (tmp, fvPatchField, patch,(const fvPatch &p, const DimensionedField< Type, volMesh > &iF),(p, iF))

	declareRunTimeSelectionTable (tmp, fvPatchField, patchMapper,(const fvPatchField< Type > &ptf, const fvPatch &p, const DimensionedField< Type, volMesh > &iF, const fvPatchFieldMapper &m),(dynamic_cast< const fvPatchFieldType & >(ptf), p, iF, m))

	declareRunTimeSelectionTable (tmp, fvPatchField, dictionary,(const fvPatch &p, const DimensionedField< Type, volMesh > &iF, const dictionary &dict),(p, iF, dict))

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const Type &value)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const word &patchType)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const Field< Type > &)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &, const bool valueRequired=true)

	fvPatchField (const fvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

	fvPatchField (const fvPatchField< Type > &)

	fvPatchField (const fvPatchField< Type > &, const DimensionedField< Type, volMesh > &)

virtual tmp< fvPatchField< Type > >	clone () const

Foam::tmp< Foam::fvPatchField< Type > >	NewCalculatedType (const fvPatch &p)

Foam::tmp< Foam::fvPatchField< Type > >	NewCalculatedType (const fvPatchField< Type2 > &pf)

virtual	~fvPatchField ()=default

bool	useImplicit () const noexcept

bool	useImplicit (bool on) noexcept

virtual bool	fixesValue () const

virtual bool	assignable () const

virtual bool	coupled () const

const objectRegistry &	db () const

const fvPatch &	patch () const

const DimensionedField< Type, volMesh > &	internalField () const

const Field< Type > &	primitiveField () const

const word &	patchType () const

word &	patchType ()

bool	updated () const

bool	manipulatedMatrix () const

virtual tmp< Field< Type > >	snGrad () const

virtual tmp< Field< Type > >	snGrad (const scalarField &deltaCoeffs) const

virtual void	updateWeightedCoeffs (const scalarField &weights)

virtual tmp< Field< Type > >	patchInternalField () const

virtual void	patchInternalField (Field< Type > &) const

virtual tmp< Field< Type > >	patchNeighbourField () const

virtual void	initEvaluate (const Pstream::commsTypes commsType=Pstream::commsTypes::blocking)

virtual tmp< Field< Type > >	valueInternalCoeffs (const tmp< Field< scalar >> &) const

virtual tmp< Field< Type > >	valueBoundaryCoeffs (const tmp< Field< scalar >> &) const

virtual tmp< Field< Type > >	gradientInternalCoeffs () const

virtual tmp< Field< Type > >	gradientInternalCoeffs (const scalarField &deltaCoeffs) const

virtual tmp< Field< Type > >	gradientBoundaryCoeffs () const

virtual tmp< Field< Type > >	gradientBoundaryCoeffs (const scalarField &deltaCoeffs) const

virtual void	manipulateMatrix (fvMatrix< Type > &matrix)

virtual void	manipulateMatrix (fvMatrix< Type > &matrix, const scalarField &weights)

virtual void	manipulateMatrix (fvMatrix< Type > &matrix, const label iMatrix, const direction cmp)

void	check (const fvPatchField< Type > &) const

virtual void	operator== (const fvPatchField< Type > &)

virtual void	operator== (const Field< Type > &)

virtual void	operator== (const Type &)

Public Member Functions inherited from codedBase
	ClassName ("codedBase")

	codedBase ()=default

virtual	~codedBase ()=default

Static Public Attributes
static constexpr const char *const	codeTemplateC = "mixedFvPatchFieldTemplate.C"

static constexpr const char *const	codeTemplateH = "mixedFvPatchFieldTemplate.H"

Static Public Attributes inherited from fvPatchField< Type >
static int	disallowGenericFvPatchField

Protected Member Functions
virtual dlLibraryTable &	libs () const

virtual string	description () const

virtual void	clearRedirect () const

virtual const dictionary &	codeContext () const

virtual const dictionary &	codeDict () const

virtual void	prepare (dynamicCode &, const dynamicCodeContext &) const

Protected Member Functions inherited from codedBase
dynamicCodeContext &	codeContext ()

void	setCodeContext (const dictionary &dict)

void	append (const std::string &str)

void	updateLibrary (const word &name, const dynamicCodeContext &context) const

void	updateLibrary (const word &name, const dictionary &dict) const

void	updateLibrary (const word &name) const

	codedBase (const codedBase &)=delete

void	operator= (const codedBase &)=delete

Additional Inherited Members
Public Types inherited from fvPatchField< Type >
typedef fvPatch	Patch

typedef calculatedFvPatchField< Type >	Calculated

Static Public Member Functions inherited from fvPatchField< Type >
static tmp< fvPatchField< Type > >	New (const word &, const fvPatch &, const DimensionedField< Type, volMesh > &)

static tmp< fvPatchField< Type > >	New (const word &, const word &actualPatchType, const fvPatch &, const DimensionedField< Type, volMesh > &)

static tmp< fvPatchField< Type > >	New (const fvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

static tmp< fvPatchField< Type > >	New (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &)

static tmp< fvPatchField< Type > >	NewCalculatedType (const fvPatch &)

static tmp< fvPatchField< Type > >	NewCalculatedType (const fvPatchField< Type2 > &)

static const word &	calculatedType ()

Static Protected Member Functions inherited from codedBase
static void	writeCodeDict (Ostream &os, const dictionary &dict)

static const dictionary &	codeDict (const objectRegistry &obr, const word &dictName="codeDict")

Detailed Description

template<class Type>
class Foam::codedMixedFvPatchField< Type >

Constructs on-the-fly a new boundary condition (derived from mixedFvPatchField) which is then used to evaluate.

The code entries:

codeInclude	:	include files
codeOptions	:	compiler line: added to EXE_INC (Make/options)
codeLibs	:	linker line: added to LIB_LIBS (Make/options)
localCode	:	c++; local static functions;
code	:	c++; patch value assignment
codeContext	:	additional dictionary context for the code

Usage

Example:

<patchName>
{
    type            codedMixed;

    refValue        uniform (0 0 0);
    refGradient     uniform (0 0 0);
    valueFraction   uniform 1;

    name    rampedMixed;   // name of generated BC

    code
    #{
        this->refValue() =
            vector(1, 0, 0)
           *min(10, 0.1*this->db().time().value());
        this->refGrad() = Zero;
        this->valueFraction() = 1.0;
    #};

    //codeInclude
    //#{
    //    #include "fvCFD.H"
    //#};

    //codeOptions
    //#{
    //    -I$(LIB_SRC)/finiteVolume/lnInclude
    //#};
}

A special form is if the 'code' section is not supplied. In this case the code gets read from a (runTimeModifiable!) dictionary system/codeDict which would have a corresponding entry

<patchName>
{
    code
    #{
        this->refValue() = min(10, 0.1*this->db().time().value());
        this->refGrad() = Zero;
        this->valueFraction() = 1.0;
    #};
}

Note: The code context dictionary can be supplied separately as the codeContext entry.

See also: Foam::dynamicCode Foam::functionEntries::codeStream

Source files

Definition at line 145 of file codedMixedFvPatchField.H.

Constructor & Destructor Documentation

◆ codedMixedFvPatchField() [1/5]

codedMixedFvPatchField	(	const fvPatch &	p,
		const DimensionedField< Type, volMesh > &	iF
	)

Definition at line 124 of file codedMixedFvPatchField.C.

◆ codedMixedFvPatchField() [2/5]

codedMixedFvPatchField	(	const fvPatch &	p,
		const DimensionedField< Type, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 154 of file codedMixedFvPatchField.C.

◆ codedMixedFvPatchField() [3/5]

codedMixedFvPatchField	(	const codedMixedFvPatchField< Type > &	rhs,
		const fvPatch &	p,
		const DimensionedField< Type, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 137 of file codedMixedFvPatchField.C.

◆ codedMixedFvPatchField() [4/5]

codedMixedFvPatchField ( const codedMixedFvPatchField< Type > & rhs )

Definition at line 185 of file codedMixedFvPatchField.C.

◆ codedMixedFvPatchField() [5/5]

codedMixedFvPatchField	(	const codedMixedFvPatchField< Type > &	rhs,
		const DimensionedField< Type, volMesh > &	iF
	)

Definition at line 199 of file codedMixedFvPatchField.C.

Member Function Documentation

◆ libs()

Foam::dlLibraryTable & libs

protectedvirtual

Implements codedBase.

Definition at line 32 of file codedMixedFvPatchField.C.

References dlLibraryTable::libs().

Here is the call graph for this function:

◆ description()

Foam::string description

protectedvirtual

Implements codedBase.

Definition at line 39 of file codedMixedFvPatchField.C.

References Foam::foamVersion::patch.

◆ clearRedirect()

void clearRedirect

protectedvirtual

Implements codedBase.

Definition at line 50 of file codedMixedFvPatchField.C.

◆ codeContext()

const Foam::dictionary & codeContext

protectedvirtual

Definition at line 58 of file codedMixedFvPatchField.C.

References dictionary::findDict().

Here is the call graph for this function:

◆ codeDict()

const Foam::dictionary & codeDict

protectedvirtual

Implements codedBase.

Definition at line 67 of file codedMixedFvPatchField.C.

◆ prepare()

void prepare	(	dynamicCode &	dynCode,
		const dynamicCodeContext &	context
	)		const

protectedvirtual

Implements codedBase.

Definition at line 81 of file codedMixedFvPatchField.C.

References dynamicCode::addCompileFile(), dynamicCode::addCopyFile(), DetailInfo, Foam::endl(), dynamicCodeContext::libs(), dynamicCodeContext::options(), dynamicCode::setFieldTemplates(), dynamicCode::setFilterVariable(), dynamicCode::setMakeOptions(), and dynamicCodeContext::sha1().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "codedMixed" )

◆ clone() [1/2]

virtual tmp<fvPatchField<Type> > clone ( ) const

inlinevirtual

Reimplemented from mixedFvPatchField< Type >.

Definition at line 238 of file codedMixedFvPatchField.H.

◆ clone() [2/2]

virtual tmp<fvPatchField<Type> > clone ( const DimensionedField< Type, volMesh > & iF ) const

inlinevirtual

Reimplemented from mixedFvPatchField< Type >.

Definition at line 255 of file codedMixedFvPatchField.H.

◆ redirectPatchField()

const Foam::mixedFvPatchField< Type > & redirectPatchField

Definition at line 216 of file codedMixedFvPatchField.C.

References dictionaryContent::dict(), Foam::nl, os(), Foam::foamVersion::patch, dictionary::set(), WarningInFunction, and Foam::vtk::write().

Here is the call graph for this function:

◆ updateCoeffs()

void updateCoeffs

virtual

Reimplemented from fvPatchField< Type >.

Definition at line 266 of file codedMixedFvPatchField.C.

References mixedFvPatchField< Type >::refGrad(), mixedFvPatchField< Type >::refValue(), and mixedFvPatchField< Type >::valueFraction().

Here is the call graph for this function:

◆ evaluate()

void evaluate ( const Pstream::commsTypes commsType = Pstream::commsTypes::blocking )

virtual

Reimplemented from mixedFvPatchField< Type >.

Definition at line 290 of file codedMixedFvPatchField.C.

References Foam::stringOps::evaluate().

Here is the call graph for this function:

◆ write()

void write ( Ostream & os ) const

virtual

Reimplemented from mixedFvPatchField< Type >.

Definition at line 309 of file codedMixedFvPatchField.C.

References os(), and Foam::vtk::write().

Here is the call graph for this function:

Member Data Documentation

◆ codeTemplateC

constexpr const char* const codeTemplateC = "mixedFvPatchFieldTemplate.C"

staticconstexpr

Definition at line 193 of file codedMixedFvPatchField.H.

◆ codeTemplateH

constexpr const char* const codeTemplateH = "mixedFvPatchFieldTemplate.H"

staticconstexpr

Definition at line 197 of file codedMixedFvPatchField.H.

The documentation for this class was generated from the following files:

src/finiteVolume/fields/fvPatchFields/derived/codedMixed/codedMixedFvPatchField.H
src/finiteVolume/fields/fvPatchFields/derived/codedMixed/codedMixedFvPatchField.C

Public Member Functions

Static Public Attributes

Protected Member Functions

Additional Inherited Members

Detailed Description

template<class Type> class Foam::codedMixedFvPatchField< Type >

Constructor & Destructor Documentation

◆ codedMixedFvPatchField() [1/5]

◆ codedMixedFvPatchField() [2/5]

◆ codedMixedFvPatchField() [3/5]

◆ codedMixedFvPatchField() [4/5]

◆ codedMixedFvPatchField() [5/5]

Member Function Documentation

◆ libs()

◆ description()

◆ clearRedirect()

◆ codeContext()

◆ codeDict()

◆ prepare()

◆ TypeName()

◆ clone() [1/2]

◆ clone() [2/2]

◆ redirectPatchField()

◆ updateCoeffs()

◆ evaluate()

◆ write()

Member Data Documentation

◆ codeTemplateC

◆ codeTemplateH

template<class Type>
class Foam::codedMixedFvPatchField< Type >
