chemistryTabulationMethod< CompType, ThermoType > Class Template Reference

An abstract class for chemistry tabulation. More...

Inheritance diagram for chemistryTabulationMethod< CompType, ThermoType >:

Collaboration diagram for chemistryTabulationMethod< CompType, ThermoType >:

Public Member Functions
	TypeName ("chemistryTabulationMethod")
	declareRunTimeSelectionTable (autoPtr, chemistryTabulationMethod, dictionary,(const dictionary &dict, TDACChemistryModel< CompType, ThermoType > &chemistry),(dict, chemistry))
	chemistryTabulationMethod (const dictionary &dict, TDACChemistryModel< CompType, ThermoType > &chemistry)
virtual	~chemistryTabulationMethod ()
bool	active ()
bool	log ()
bool	variableTimeStep ()
scalar	tolerance () const
virtual label	size ()=0
virtual void	writePerformance ()=0
virtual bool	retrieve (const scalarField &phiQ, scalarField &RphiQ)=0
virtual label	add (const scalarField &phiQ, const scalarField &RphiQ, const scalar rho, const scalar deltaT)=0
virtual bool	update ()=0

Static Public Member Functions
static autoPtr< chemistryTabulationMethod >	New (const IOdictionary &dict, TDACChemistryModel< CompType, ThermoType > &chemistry)

Protected Attributes
const dictionary &	dict_
const dictionary	coeffsDict_
Switch	active_
Switch	log_
TDACChemistryModel< CompType, ThermoType > &	chemistry_
scalar	tolerance_

Detailed Description

template<class CompType, class ThermoType>
class Foam::chemistryTabulationMethod< CompType, ThermoType >

An abstract class for chemistry tabulation.

Source files

• chemistryTabulationMethod.H
• chemistryTabulationMethod.C

Definition at line 55 of file chemistryTabulationMethod.H.

Constructor & Destructor Documentation

chemistryTabulationMethod()

chemistryTabulationMethod	(	const dictionary &	dict,
		TDACChemistryModel< CompType, ThermoType > &	chemistry
	)

Definition at line 29 of file chemistryTabulationMethod.C.

~chemistryTabulationMethod()

~chemistryTabulationMethod

virtual

Definition at line 47 of file chemistryTabulationMethod.C.

Member Function Documentation

TypeName()

TypeName

(

"chemistryTabulationMethod< CompType, ThermoType >"

)

declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		chemistryTabulationMethod< CompType, ThermoType >	,
		dictionary	,
		(const dictionary &dict, TDACChemistryModel< CompType, ThermoType > &chemistry)	,
		(dict, chemistry)
	)

New()

Foam::autoPtr< Foam::chemistryTabulationMethod< CompType, ThermoType > > New ( const IOdictionary &  dict, TDACChemistryModel< CompType, ThermoType > &  chemistry  )

static

DynamicList<word> thisCmpts(6); thisCmpts.append(CompType::typeName); thisCmpts.append ( basicThermo::splitThermoName(ThermoType::typeName(), 5) );

DynamicList<word> validNames;

if (thisCmpts == SubList<word>(cmpts, 6, 1)) { validNames.append(cmpts[0]); }

Definition at line 30 of file chemistryTabulationMethodNew.C.

References DynamicList::append(), chemistry, dict, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInLookup, dictionary::get(), Foam::Info, Foam::PtrListOps::names(), Foam::nl, and Foam::printTable().

Here is the call graph for this function:

active()

bool active ( )

inline

Definition at line 120 of file chemistryTabulationMethod.H.

References chemistryTabulationMethod< CompType, ThermoType >::active_.

log()

bool log ( )

inline

Definition at line 125 of file chemistryTabulationMethod.H.

References chemistryTabulationMethod< CompType, ThermoType >::active_, and chemistryTabulationMethod< CompType, ThermoType >::log_.

variableTimeStep()

bool variableTimeStep ( )

inline

Definition at line 130 of file chemistryTabulationMethod.H.

References chemistryTabulationMethod< CompType, ThermoType >::chemistry_, and TDACChemistryModel::variableTimeStep().

Here is the call graph for this function:

tolerance()

scalar tolerance ( ) const

inline

Definition at line 135 of file chemistryTabulationMethod.H.

References chemistryTabulationMethod< CompType, ThermoType >::tolerance_.

size()

virtual label size ( )

pure virtual

Implemented in ISAT< CompType, ThermoType >, and none< CompType, ThermoType >.

writePerformance()

virtual void writePerformance ( )

pure virtual

Implemented in ISAT< CompType, ThermoType >, and none< CompType, ThermoType >.

retrieve()

virtual bool retrieve ( const scalarField &  phiQ, scalarField &  RphiQ  )

pure virtual

Implemented in ISAT< CompType, ThermoType >, and none< CompType, ThermoType >.

add()

virtual label add ( const scalarField &  phiQ, const scalarField &  RphiQ, const scalar  rho, const scalar  deltaT  )

pure virtual

Implemented in ISAT< CompType, ThermoType >, and none< CompType, ThermoType >.

update()

virtual bool update ( )

pure virtual

Implemented in ISAT< CompType, ThermoType >, and none< CompType, ThermoType >.

Member Data Documentation

dict_

const dictionary& dict_

protected

Definition at line 60 of file chemistryTabulationMethod.H.

coeffsDict_

const dictionary coeffsDict_

protected

Definition at line 62 of file chemistryTabulationMethod.H.

active_

Switch active_

protected

Definition at line 65 of file chemistryTabulationMethod.H.

Referenced by chemistryTabulationMethod< CompType, ThermoType >::active(), and chemistryTabulationMethod< CompType, ThermoType >::log().

log_

Switch log_

protected

Definition at line 68 of file chemistryTabulationMethod.H.

Referenced by chemistryTabulationMethod< CompType, ThermoType >::log().

chemistry_

TDACChemistryModel<CompType, ThermoType>& chemistry_

protected

Definition at line 70 of file chemistryTabulationMethod.H.

Referenced by chemistryTabulationMethod< CompType, ThermoType >::variableTimeStep().

tolerance_

scalar tolerance_

protected

Definition at line 72 of file chemistryTabulationMethod.H.

Referenced by chemistryTabulationMethod< CompType, ThermoType >::tolerance().

---

The documentation for this class was generated from the following files:

• src/thermophysicalModels/chemistryModel/chemistryModel/TDACChemistryModel/tabulation/chemistryTabulationMethod/chemistryTabulationMethod.H
• src/thermophysicalModels/chemistryModel/chemistryModel/TDACChemistryModel/tabulation/chemistryTabulationMethod/chemistryTabulationMethod.C
• src/thermophysicalModels/chemistryModel/chemistryModel/TDACChemistryModel/tabulation/chemistryTabulationMethod/chemistryTabulationMethodNew.C
