cellVolumeWeightMethod Class Reference

Cell-volume-weighted mesh-to-mesh interpolation class. More...

Inheritance diagram for cellVolumeWeightMethod:

Collaboration diagram for cellVolumeWeightMethod:

Public Member Functions
	TypeName ("cellVolumeWeight")
	cellVolumeWeightMethod (const polyMesh &src, const polyMesh &tgt)
virtual	~cellVolumeWeightMethod ()
virtual void	calculate (labelListList &srcToTgtAddr, scalarListList &srcToTgtWght, pointListList &srcToTgtVec, labelListList &tgtToSrcAddr, scalarListList &tgtToSrcWght, pointListList &tgtToSrcVec)
Public Member Functions inherited from meshToMeshMethod
	TypeName ("meshToMeshMethod")
	declareRunTimeSelectionTable (autoPtr, meshToMeshMethod, components,(const polyMesh &src, const polyMesh &tgt),(src, tgt))
	meshToMeshMethod (const polyMesh &src, const polyMesh &tgt)
virtual	~meshToMeshMethod ()
const polyMesh &	src () const
const polyMesh &	tgt () const
scalar	V () const
void	writeConnectivity (const polyMesh &mesh1, const polyMesh &mesh2, const labelListList &mesh1ToMesh2Addr) const

Protected Member Functions
bool	findInitialSeeds (const labelList &srcCellIDs, const boolList &mapFlag, const label startSeedI, label &srcSeedI, label &tgtSeedI) const
void	calculateAddressing (labelListList &srcToTgtCellAddr, scalarListList &srcToTgtCellWght, labelListList &tgtToSrcCellAddr, scalarListList &tgtToSrcCellWght, const label srcSeedI, const label tgtSeedI, const labelList &srcCellIDs, boolList &mapFlag, label &startSeedI)
void	setNextCells (label &startSeedI, label &srcCelli, label &tgtCelli, const labelList &srcCellIDs, const boolList &mapFlag, const DynamicList< label > &visitedCells, labelList &seedCells) const
Protected Member Functions inherited from meshToMeshMethod
labelList	maskCells () const
virtual bool	intersect (const label srcCelli, const label tgtCelli) const
virtual scalar	interVol (const label srcCelli, const label tgtCelli) const
virtual Tuple2< scalar, point >	interVolAndCentroid (const label srcCellI, const label tgtCellI)
virtual void	appendNbrCells (const label tgtCelli, const polyMesh &mesh, const DynamicList< label > &visitedTgtCells, DynamicList< label > &nbrTgtCellIDs) const
virtual bool	initialise (labelListList &srcToTgtAddr, scalarListList &srcToTgtWght, labelListList &tgtToTgtAddr, scalarListList &tgtToTgtWght) const

Additional Inherited Members
Static Public Member Functions inherited from meshToMeshMethod
static autoPtr< meshToMeshMethod >	New (const word &methodName, const polyMesh &src, const polyMesh &tgt)
Protected Attributes inherited from meshToMeshMethod
const polyMesh &	src_
const polyMesh &	tgt_
scalar	V_
Static Protected Attributes inherited from meshToMeshMethod
static scalar	tolerance_ = 1e-6

Detailed Description

Cell-volume-weighted mesh-to-mesh interpolation class.

Volume conservative.

Source files

• cellVolumeWeightMethod.H
• cellVolumeWeightMethod.C

Definition at line 48 of file cellVolumeWeightMethod.H.

Constructor & Destructor Documentation

cellVolumeWeightMethod()

cellVolumeWeightMethod	(	const polyMesh &	src,
		const polyMesh &	tgt
	)

Definition at line 329 of file cellVolumeWeightMethod.C.

~cellVolumeWeightMethod()

~cellVolumeWeightMethod ( )

virtual

Definition at line 340 of file cellVolumeWeightMethod.C.

Member Function Documentation

findInitialSeeds()

bool findInitialSeeds ( const labelList &  srcCellIDs, const boolList &  mapFlag, const label  startSeedI, label &  srcSeedI, label &  tgtSeedI  ) const

protected

Definition at line 43 of file cellVolumeWeightMethod.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), points, and Foam::Pout.

Here is the call graph for this function:

calculateAddressing()

void calculateAddressing ( labelListList &  srcToTgtCellAddr, scalarListList &  srcToTgtCellWght, labelListList &  tgtToSrcCellAddr, scalarListList &  tgtToSrcCellWght, const label  srcSeedI, const label  tgtSeedI, const labelList &  srcCellIDs, boolList &  mapFlag, label &  startSeedI  )

protected

Definition at line 88 of file cellVolumeWeightMethod.C.

References List::append(), DynamicList::append(), DynamicList::clear(), Foam::expressions::patchExpr::debug, Foam::constant::electromagnetic::e, Foam::endl(), forAll, Foam::mag(), DynamicList::remove(), Foam::sum(), List::transfer(), and WarningInFunction.

Here is the call graph for this function:

setNextCells()

void setNextCells ( label &  startSeedI, label &  srcCelli, label &  tgtCelli, const labelList &  srcCellIDs, const boolList &  mapFlag, const DynamicList< label > &  visitedCells, labelList &  seedCells  ) const

protected

Definition at line 225 of file cellVolumeWeightMethod.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), forAll, and Foam::Pout.

Here is the call graph for this function:

TypeName()

TypeName

(

"cellVolumeWeight"

)

calculate()

void calculate ( labelListList &  srcToTgtAddr, scalarListList &  srcToTgtWght, pointListList &  srcToTgtVec, labelListList &  tgtToSrcAddr, scalarListList &  tgtToSrcWght, pointListList &  tgtToSrcVec  )

virtual

Implements meshToMeshMethod.

Reimplemented in correctedCellVolumeWeightMethod.

Definition at line 347 of file cellVolumeWeightMethod.C.

---

The documentation for this class was generated from the following files:

• src/sampling/meshToMesh/calcMethod/cellVolumeWeight/cellVolumeWeightMethod.H
• src/sampling/meshToMesh/calcMethod/cellVolumeWeight/cellVolumeWeightMethod.C
