OpenFOAM: cellTable Class Reference

The open source CFD toolbox

The cellTable persistent data saved as a Map<dictionary>. More...

Inheritance diagram for cellTable:

Inheritance graph

[legend]

Collaboration diagram for cellTable:

Collaboration graph

[legend]

Public Member Functions
	cellTable ()

	cellTable (const objectRegistry &, const word &name="cellTable", const fileName &instance="constant")

	~cellTable ()=default

label	append (const dictionary &)

label	findIndex (const word &name) const

word	name (const label id) const

Map< word >	names () const

Map< word >	names (const wordRes &patterns) const

Map< word >	selectType (const word &materialType) const

Map< word >	fluids () const

Map< word >	shells () const

Map< word >	solids () const

Map< word >	materialTypes () const

void	setMaterial (const label, const word &)

void	setName (const label, const word &)

void	setName (const label)

void	readDict (const objectRegistry &, const word &name="cellTable", const fileName &instance="constant")

void	writeDict (const objectRegistry &, const word &name="cellTable", const fileName &instance="constant") const

void	operator= (const cellTable &)

void	operator= (const Map< dictionary > &)

void	operator= (const polyMesh &)

void	addCellZones (polyMesh &, const labelList &tableIds) const

void	combine (const dictionary &mapDict, labelList &tableIds)

Public Member Functions inherited from Map< dictionary >
	Map ()

	Map (const label size)

	Map (Istream &is)

	Map (const this_type &map)

	Map (this_type &&map)

	Map (std::initializer_list< std::pair< label, T >> map)

void	operator= (const this_type &rhs)

void	operator= (this_type &&rhs)

void	operator= (const this_type &rhs)

void	operator= (std::initializer_list< std::pair< Key, T >> rhs)

void	operator= (this_type &&rhs)

Additional Inherited Members
Public Types inherited from Map< dictionary >
typedef Map< T >	this_type

typedef HashTable< T, label, Hash< label > >	parent_type

using	iterator = typename parent_type::iterator

using	const_iterator = typename parent_type::const_iterator

Detailed Description

The cellTable persistent data saved as a Map<dictionary>.

The meshReader supports cellTable information.

The constant/cellTable file is an IOMap<dictionary> that is used to save the information persistently. It contains the cellTable information of the following form:

    (
        ID
        {
            Label           WORD;
            MaterialType    WORD;
            MaterialId      INT;
            PorosityId      INT;
            ColorIdx        INT;
            ...
        }
    ...
    )

If the Label is missing, a value cellTable_{ID} will be inferred. If the MaterialType is missing, the value fluid will be inferred.

Source files

Definition at line 76 of file cellTable.H.

Constructor & Destructor Documentation

◆ cellTable() [1/2]

cellTable ( )

Definition at line 98 of file cellTable.C.

◆ cellTable() [2/2]

cellTable	(	const objectRegistry &	registry,
		const word &	name = `"cellTable"`,
		const fileName &	instance = `"constant"`
	)

Definition at line 105 of file cellTable.C.

References Foam::name().

Here is the call graph for this function:

◆ ~cellTable()

~cellTable ( )

default

Member Function Documentation

◆ append()

Foam::label append ( const dictionary & dict )

Definition at line 119 of file cellTable.C.

References dict, forAllConstIters(), and insert().

Here is the call graph for this function:

◆ findIndex()

Foam::label findIndex ( const word & name ) const

Definition at line 195 of file cellTable.C.

References forAllConstIters(), Foam::name(), and word::null.

Here is the call graph for this function:

◆ name()

Foam::word name ( const label id ) const

Definition at line 181 of file cellTable.C.

References Foam::name().

Here is the call graph for this function:

◆ names() [1/2]

Foam::Map< Foam::word > names ( ) const

Definition at line 135 of file cellTable.C.

References forAllConstIters(), and Foam::name().

Here is the call graph for this function:

◆ names() [2/2]

Foam::Map< Foam::word > names ( const wordRes & patterns ) const

Definition at line 157 of file cellTable.C.

References forAllConstIters(), wordRes::match(), and Foam::name().

Here is the call graph for this function:

◆ selectType()

Foam::Map< Foam::word > selectType ( const word & materialType ) const

Definition at line 231 of file cellTable.C.

References dict, forAllConstIters(), dictionary::getOrDefault(), and Foam::name().

Here is the call graph for this function:

◆ fluids()

Foam::Map< Foam::word > fluids ( ) const

Definition at line 262 of file cellTable.C.

Referenced by reader::fluids().

Here is the caller graph for this function:

◆ shells()

Foam::Map< Foam::word > shells ( ) const

Definition at line 274 of file cellTable.C.

◆ solids()

Foam::Map< Foam::word > solids ( ) const

Definition at line 268 of file cellTable.C.

Referenced by reader::solids().

Here is the caller graph for this function:

◆ materialTypes()

Foam::Map< Foam::word > materialTypes ( ) const

Definition at line 214 of file cellTable.C.

References forAllConstIters().

Here is the call graph for this function:

◆ setMaterial()

void setMaterial	(	const label	id,
		const word &	matlType
	)

Definition at line 281 of file cellTable.C.

Referenced by STARCDMeshReader::readCells().

Here is the caller graph for this function:

◆ setName() [1/2]

void setName	(	const label	id,
		const word &	name
	)

Definition at line 287 of file cellTable.C.

References Foam::name().

Referenced by STARCDMeshReader::readCells().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ setName() [2/2]

void setName ( const label id )

Definition at line 293 of file cellTable.C.

References Foam::ListOps::find(), found, and Foam::name().

Here is the call graph for this function:

◆ readDict()

void readDict	(	const objectRegistry &	registry,
		const word &	name = `"cellTable"`,
		const fileName &	instance = `"constant"`
	)

Definition at line 305 of file cellTable.C.

References clear(), Foam::endl(), regIOobject::headerOk(), Foam::Info, Foam::name(), IOobject::NO_WRITE, and IOobject::READ_IF_PRESENT.

Here is the call graph for this function:

◆ writeDict()

void writeDict	(	const objectRegistry &	registry,
		const word &	name = `"cellTable"`,
		const fileName &	instance = `"constant"`
	)		const

Definition at line 340 of file cellTable.C.

References Foam::endl(), Foam::Info, Foam::name(), IOobject::name(), IOobject::NO_READ, IOobject::NO_WRITE, IOobject::note(), IOobject::objectPath(), os(), and IOobject::writeHeader().

Here is the call graph for this function:

◆ operator=() [1/3]

void operator= ( const cellTable & rhs )

Definition at line 373 of file cellTable.C.

References Map::operator=().

Here is the call graph for this function:

◆ operator=() [2/3]

void operator= ( const Map< dictionary > & rhs )

Definition at line 380 of file cellTable.C.

References Map::operator=().

Here is the call graph for this function:

◆ operator=() [3/3]

void operator= ( const polyMesh & mesh )

Definition at line 387 of file cellTable.C.

References dictionary::add(), polyMesh::cellZones(), dict, forAll, mesh, ZoneMesh::names(), primitiveMesh::nCells(), and Map::operator=().

Here is the call graph for this function:

◆ addCellZones()

void addCellZones	(	polyMesh &	mesh,
		const labelList &	tableIds
	)		const

Definition at line 433 of file cellTable.C.

References List::append(), IOobject::AUTO_WRITE, polyMesh::cellZones(), ZoneMesh::clear(), Foam::endl(), forAll, Foam::Info, mesh, and List::setSize().

Here is the call graph for this function:

◆ combine()

void combine	(	const dictionary &	mapDict,
		labelList &	tableIds
	)

Definition at line 499 of file cellTable.C.

References Foam::endl(), erase(), Foam::findIndex(), forAllConstIters(), Foam::identity(), Foam::Info, Foam::inplaceRenumber(), wordRes::match(), Foam::max(), Foam::min(), and Foam::PtrListOps::names().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/conversion/common/tables/cellTable.H
src/conversion/common/tables/cellTable.C
