Maps a geometry to a set of cell primitives. More...

Collaboration diagram for cellModel:

Public Types
enum	modelType { UNKNOWN = 0, HEX = 3, WEDGE = 4, PRISM = 5, PYR = 6, TET = 7, SPLITHEX = 8, TETWEDGE = 9 }

Public Member Functions
	cellModel (Istream &is)

autoPtr< cellModel >	clone () const

const word &	name () const noexcept

label	index () const noexcept

label	nPoints () const noexcept

label	nEdges () const noexcept

label	nFaces () const noexcept

const edgeList &	modelEdges () const noexcept

const faceList &	modelFaces () const noexcept

edgeList	edges (const labelUList &pointLabels) const

faceList	faces (const labelUList &pointLabels) const

Foam::edge	edge (const label modelEdgei, const labelUList &pointLabels) const

Foam::face	face (const label modelFacei, const labelUList &pointLabels) const

vector	centre (const labelList &pointLabels, const UList< point > &points) const

scalar	mag (const labelList &pointLabels, const UList< point > &points) const

InfoProxy< cellModel >	info () const

bool	writeData (Ostream &os) const

Static Public Member Functions
static const cellModel *	ptr (const modelType model)

static const cellModel *	ptr (const word &modelName)

static const cellModel *	ptr (const label modelIndex)

static const cellModel &	ref (const modelType model)

static const cellModel &	ref (const word &modelName)

static const cellModel &	ref (const label modelIndex)

static autoPtr< cellModel >	New (Istream &is)

Static Public Attributes
static const Enum< modelType >	modelNames

Friends
Ostream &	operator<< (Ostream &os, const cellModel &cm)

Detailed Description

Maps a geometry to a set of cell primitives.

This enables geometric cell data to be calculated without access to the primitive geometric level. This means mapping a 3D geometry to a set of pyramids which are each described by a cell face and the cell centre point.

Also includes a static collection of cell models (normally loaded from etc/cellModels), and a means of looking them up.

Source files

Definition at line 68 of file cellModel.H.

Member Enumeration Documentation

◆ modelType

enum modelType

Enumerator
UNKNOWN	unknown
HEX	hex
WEDGE	wedge
PRISM	prism
PYR	pyr
TET	tet
SPLITHEX	splitHex
TETWEDGE	tetWedge

Definition at line 74 of file cellModel.H.

Constructor & Destructor Documentation

◆ cellModel()

cellModel ( Istream & is )

explicit

Definition at line 27 of file cellModelIO.C.

References dict, dictionaryEntry::dict(), entry::keyword(), and dictionary::null.

Here is the call graph for this function:

Member Function Documentation

◆ ptr() [1/3]

const Foam::cellModel * ptr ( const modelType model )

static

Definition at line 113 of file cellModels.C.

Referenced by cellModeller::lookup(), cellMatcher::model(), STARCDMeshReader::readCells(), hexCell::shape(), tetCell::shape(), and shapeToCell::shapeToCell().

Here is the caller graph for this function:

◆ ptr() [2/3]

const Foam::cellModel * ptr ( const word & modelName )

static

Definition at line 119 of file cellModels.C.

References n, and Foam::name().

Here is the call graph for this function:

◆ ptr() [3/3]

const Foam::cellModel * ptr ( const label modelIndex )

static

Definition at line 139 of file cellModels.C.

◆ ref() [1/3]

const Foam::cellModel & ref ( const modelType model )

static

Definition at line 150 of file cellModels.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, and p.

Referenced by voxelMeshSearch::makeMesh(), STARCDMeshReader::readBoundary(), STARCDMeshReader::readCells(), ABAQUSCore::readHelper::readSurfaceElements(), vtuSizing::reset(), vtuSizing::resetShapes(), and writer::writer().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ ref() [2/3]

const Foam::cellModel & ref ( const word & modelName )

static

Definition at line 165 of file cellModels.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, and p.

Here is the call graph for this function:

◆ ref() [3/3]

const Foam::cellModel & ref ( const label modelIndex )

static

Definition at line 180 of file cellModels.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, and p.

Here is the call graph for this function:

◆ New()

static autoPtr<cellModel> New ( Istream & is )

inlinestatic

Definition at line 156 of file cellModel.H.

References autoPtr::New().

Here is the call graph for this function:

◆ clone()

autoPtr<cellModel> clone ( ) const

inline

Definition at line 162 of file cellModel.H.

References autoPtr::New().

Here is the call graph for this function:

◆ name()

const Foam::word & name ( ) const

inlinenoexcept

Definition at line 24 of file cellModelI.H.

Referenced by Foam::operator<<().

Here is the caller graph for this function:

◆ index()

Foam::label index ( ) const

inlinenoexcept

Definition at line 30 of file cellModelI.H.

Referenced by Foam::operator<<(), STARCDMeshReader::readBoundary(), and writer::writer().

Here is the caller graph for this function:

◆ nPoints()

Foam::label nPoints ( ) const

inlinenoexcept

Definition at line 36 of file cellModelI.H.

Referenced by Foam::operator<<().

Here is the caller graph for this function:

◆ nEdges()

Foam::label nEdges ( ) const

inlinenoexcept

Definition at line 42 of file cellModelI.H.

Referenced by Foam::operator<<().

Here is the caller graph for this function:

◆ nFaces()

Foam::label nFaces ( ) const

inlinenoexcept

Definition at line 48 of file cellModelI.H.

Referenced by Foam::operator<<().

Here is the caller graph for this function:

◆ modelEdges()

const Foam::edgeList & modelEdges ( ) const

inlinenoexcept

Definition at line 54 of file cellModelI.H.

Referenced by Foam::operator<<().

Here is the caller graph for this function:

◆ modelFaces()

const Foam::faceList & modelFaces ( ) const

inlinenoexcept

Definition at line 60 of file cellModelI.H.

Referenced by Foam::operator<<(), and ABAQUSCore::readHelper::readSurfaceElements().

Here is the caller graph for this function:

◆ edges()

Foam::edgeList edges ( const labelUList & pointLabels ) const

inline

Definition at line 67 of file cellModelI.H.

References forAll, and pointLabels().

Here is the call graph for this function:

◆ faces()

Foam::faceList faces ( const labelUList & pointLabels ) const

inline

Definition at line 95 of file cellModelI.H.

References forAll, and pointLabels().

Here is the call graph for this function:

◆ edge()

Foam::edge edge	(	const label	modelEdgei,
		const labelUList &	pointLabels
	)		const

inline

Definition at line 84 of file cellModelI.H.

References pointLabels().

Here is the call graph for this function:

◆ face()

Foam::face face	(	const label	modelFacei,
		const labelUList &	pointLabels
	)		const

inline

Definition at line 112 of file cellModelI.H.

References pointLabels().

Here is the call graph for this function:

◆ centre()

Foam::vector centre	(	const labelList &	pointLabels,
		const UList< point > &	points
	)		const

Definition at line 28 of file cellModel.C.

References Foam::endl(), f(), forAll, pointLabels(), points, WarningInFunction, and Foam::Zero.

Here is the call graph for this function:

◆ mag()

Foam::scalar mag	(	const labelList &	pointLabels,
		const UList< point > &	points
	)		const

Definition at line 71 of file cellModel.C.

References Foam::endl(), f(), forAll, pointLabels(), points, WarningInFunction, and Foam::Zero.

Here is the call graph for this function:

◆ info()

InfoProxy<cellModel> info ( ) const

inline

Definition at line 228 of file cellModel.H.

Referenced by Foam::operator<<().

Here is the caller graph for this function:

◆ writeData()

bool writeData ( Ostream & os ) const

inline

Definition at line 234 of file cellModel.H.

References os().

Here is the call graph for this function:

Friends And Related Function Documentation

◆ operator<<

Ostream& operator<<	(	Ostream &	os,
		const cellModel &	cm
	)

friend

Member Data Documentation

◆ modelNames

const Foam::Enum< Foam::cellModel::modelType > modelNames

static

Definition at line 88 of file cellModel.H.

Referenced by Foam::serializeHex().

The documentation for this class was generated from the following files:

src/OpenFOAM/meshes/meshShapes/cellModel/cellModel.H
src/OpenFOAM/meshes/meshShapes/cellModel/cellModel.C
src/OpenFOAM/meshes/meshShapes/cellModel/cellModelI.H
src/OpenFOAM/meshes/meshShapes/cellModel/cellModelIO.C
src/OpenFOAM/meshes/meshShapes/cellModel/cellModels.C
