cellDistFuncs Class Reference

Collection of functions used in wall distance calculation. More...

Inheritance diagram for cellDistFuncs:

Public Member Functions
	ClassName ("cellDistFuncs")
	cellDistFuncs (const polyMesh &mesh)
const polyMesh &	mesh () const
labelHashSet	getPatchIDs (const UList< wordRe > &patchNames) const
template<class Type >
labelHashSet	getPatchIDs () const
scalar	smallestDist (const point &p, const polyPatch &patch, const labelUList &wallFaces, label &meshFacei) const
void	getPointNeighbours (const primitivePatch &, const label patchFacei, DynamicList< label > &) const
label	maxPatchSize (const labelHashSet &patchIDs) const
label	sumPatchSize (const labelHashSet &patchIDs) const
void	correctBoundaryFaceCells (const labelHashSet &patchIDs, scalarField &wallDistCorrected, Map< label > &nearestFace) const
void	correctBoundaryPointCells (const labelHashSet &patchIDs, scalarField &wallDistCorrected, Map< label > &nearestFace) const
template<class Type >
Foam::labelHashSet	getPatchIDs () const

Detailed Description

Collection of functions used in wall distance calculation.

Source files

• cellDistFuncs.H
• cellDistFuncs.C
• cellDistFuncsTemplates.C

Definition at line 59 of file cellDistFuncs.H.

Constructor & Destructor Documentation

cellDistFuncs()

cellDistFuncs

(

const polyMesh &

mesh

)

Definition at line 35 of file cellDistFuncs.C.

Member Function Documentation

ClassName()

ClassName

(

"cellDistFuncs"

)

mesh()

const polyMesh& mesh ( ) const

inline

Definition at line 88 of file cellDistFuncs.H.

Referenced by cellDistFuncs::getPatchIDs().

Here is the caller graph for this function:

getPatchIDs() [1/3]

Foam::labelHashSet getPatchIDs

(

const UList< wordRe > &

patchNames

)

const

Definition at line 44 of file cellDistFuncs.C.

References polyMesh::boundaryMesh(), mesh, patchNames(), and polyBoundaryMesh::patchSet().

Here is the call graph for this function:

getPatchIDs() [2/3]

labelHashSet getPatchIDs

(

)

const

smallestDist()

Foam::scalar smallestDist	(	const point &	p,
		const polyPatch &	patch,
		const labelUList &	wallFaces,
		label &	meshFacei
	)		const

Definition at line 56 of file cellDistFuncs.C.

References PointHit< PointType >::distance(), p, Foam::foamVersion::patch, and points.

Here is the call graph for this function:

getPointNeighbours()

void getPointNeighbours	(	const primitivePatch &	patch,
		const label	patchFacei,
		DynamicList< label > &	neighbours
	)		const

Definition at line 87 of file cellDistFuncs.C.

References Foam::abort(), DynamicList::append(), DynamicList::appendUniq(), DynamicList::clear(), Foam::expressions::patchExpr::debug, Foam::endl(), f(), Foam::FatalError, FatalErrorInFunction, forAll, HashSet::insert(), Foam::foamVersion::patch, and SeriousErrorInFunction.

Here is the call graph for this function:

maxPatchSize()

Foam::label maxPatchSize

(

const labelHashSet &

patchIDs

)

const

Definition at line 182 of file cellDistFuncs.C.

References polyMesh::boundaryMesh(), forAll, Foam::max(), mesh, and Foam::foamVersion::patch.

Here is the call graph for this function:

sumPatchSize()

Foam::label sumPatchSize

(

const labelHashSet &

patchIDs

)

const

Definition at line 203 of file cellDistFuncs.C.

References polyMesh::boundaryMesh(), forAll, mesh, Foam::foamVersion::patch, and Foam::sum().

Here is the call graph for this function:

correctBoundaryFaceCells()

void correctBoundaryFaceCells	(	const labelHashSet &	patchIDs,
		scalarField &	wallDistCorrected,
		Map< label > &	nearestFace
	)		const

Definition at line 225 of file cellDistFuncs.C.

References polyMesh::boundaryMesh(), primitiveMesh::cellCentres(), polyMesh::faceOwner(), forAll, mesh, and Foam::foamVersion::patch.

Here is the call graph for this function:

correctBoundaryPointCells()

void correctBoundaryPointCells	(	const labelHashSet &	patchIDs,
		scalarField &	wallDistCorrected,
		Map< label > &	nearestFace
	)		const

Definition at line 271 of file cellDistFuncs.C.

References polyMesh::boundaryMesh(), primitiveMesh::cellCentres(), forAll, mesh, Foam::foamVersion::patch, and primitiveMesh::pointCells().

Here is the call graph for this function:

getPatchIDs() [3/3]

Foam::labelHashSet getPatchIDs

(

)

const

Definition at line 29 of file cellDistFuncsTemplates.C.

References polyMesh::boundaryMesh(), forAll, HashSet::insert(), and cellDistFuncs::mesh().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/meshTools/cellDist/cellDistFuncs.H
• src/meshTools/cellDist/cellDistFuncs.C
• src/meshTools/cellDist/cellDistFuncsTemplates.C
