Two-scheme cell-based Courant number based blending differencing scheme. More...

Inheritance diagram for cellCoBlended< Type >:

Collaboration diagram for cellCoBlended< Type >:

Public Member Functions
	TypeName ("cellCoBlended")

	cellCoBlended (const fvMesh &mesh, Istream &is)

	cellCoBlended (const fvMesh &mesh, const surfaceScalarField &faceFlux, Istream &is)

virtual tmp< surfaceScalarField >	blendingFactor (const GeometricField< Type, fvPatchField, volMesh > &vf) const

tmp< surfaceScalarField >	weights (const GeometricField< Type, fvPatchField, volMesh > &vf) const

tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	interpolate (const GeometricField< Type, fvPatchField, volMesh > &vf) const

virtual bool	corrected () const

virtual tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	correction (const GeometricField< Type, fvPatchField, volMesh > &vf) const

Public Member Functions inherited from surfaceInterpolationScheme< Type >
	TypeName ("surfaceInterpolationScheme")

	declareRunTimeSelectionTable (tmp, surfaceInterpolationScheme, Mesh,(const fvMesh &mesh, Istream &schemeData),(mesh, schemeData))

	declareRunTimeSelectionTable (tmp, surfaceInterpolationScheme, MeshFlux,(const fvMesh &mesh, const surfaceScalarField &faceFlux, Istream &schemeData),(mesh, faceFlux, schemeData))

	surfaceInterpolationScheme (const fvMesh &mesh)

virtual	~surfaceInterpolationScheme ()=default

const fvMesh &	mesh () const

virtual tmp< GeometricField< typename innerProduct< vector, Type >::type, fvsPatchField, surfaceMesh > >	dotInterpolate (const surfaceVectorField &Sf, const GeometricField< Type, fvPatchField, volMesh > &vf) const

tmp< GeometricField< typename innerProduct< vector, Type >::type, fvsPatchField, surfaceMesh > >	dotInterpolate (const surfaceVectorField &Sf, const tmp< GeometricField< Type, fvPatchField, volMesh >> &) const

tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	interpolate (const tmp< GeometricField< Type, fvPatchField, volMesh >> &) const

Public Member Functions inherited from refCount
constexpr	refCount () noexcept

int	count () const noexcept

bool	unique () const noexcept

void	operator++ () noexcept

void	operator++ (int) noexcept

void	operator-- () noexcept

void	operator-- (int) noexcept

Public Member Functions inherited from blendedSchemeBase< Type >
	blendedSchemeBase ()

virtual	~blendedSchemeBase ()=default

Additional Inherited Members
Static Public Member Functions inherited from surfaceInterpolationScheme< Type >
static tmp< surfaceInterpolationScheme< Type > >	New (const fvMesh &mesh, Istream &schemeData)

static tmp< surfaceInterpolationScheme< Type > >	New (const fvMesh &mesh, const surfaceScalarField &faceFlux, Istream &schemeData)

static tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	interpolate (const GeometricField< Type, fvPatchField, volMesh > &, const tmp< surfaceScalarField > &, const tmp< surfaceScalarField > &)

template<class SFType >
static tmp< GeometricField< typename innerProduct< typename SFType::value_type, Type >::type, fvsPatchField, surfaceMesh > >	dotInterpolate (const SFType &Sf, const GeometricField< Type, fvPatchField, volMesh > &vf, const tmp< surfaceScalarField > &tlambdas)

static tmp< GeometricField< Type, fvsPatchField, surfaceMesh > >	interpolate (const GeometricField< Type, fvPatchField, volMesh > &, const tmp< surfaceScalarField > &)

Detailed Description

template<class Type>
class Foam::cellCoBlended< Type >

Two-scheme cell-based Courant number based blending differencing scheme.

This scheme is equivalent to the CoBlended scheme except that the Courant number is evaluated for cells using the same approach as use in the finite-volume solvers and then interpolated to the faces rather than being estimated directly at the faces based on the flux. This is a more consistent method for evaluating the Courant number but suffers from the need to interpolate which introduces a degree of freedom. However, the interpolation scheme for "Co" is run-time selected and may be specified in "interpolationSchemes" and "localMax" might be most appropriate.

Example of the cellCoBlended scheme specification using LUST for Courant numbers less than 1 and linearUpwind for Courant numbers greater than 10:

divSchemes
{
    .
    .
    div(phi,U)  Gauss cellCoBlended 1 LUST grad(U) 10 linearUpwind grad(U);
    .
    .
}

interpolationSchemes
{
    .
    .
    interpolate(Co) localMax;
    .
    .
}
