arcEdge Class Reference

A blockEdge defined as an arc of a circle. More...

Inheritance diagram for arcEdge:

Collaboration diagram for arcEdge:

Public Member Functions
	TypeName ("arc")
	arcEdge (const pointField &points, const point &origin, const edge &fromTo)
	arcEdge (const pointField &points, const edge &fromTo, const point &midPoint)
	arcEdge (const pointField &points, const point &origin, const label from, const label to)
	arcEdge (const pointField &points, const label from, const label to, const point &midPoint)
	arcEdge (const dictionary &dict, const label index, const searchableSurfaces &, const pointField &points, Istream &is)
virtual	~arcEdge ()=default
point	position (const scalar lambda) const
scalar	length () const noexcept
Public Member Functions inherited from blockEdge
	TypeName ("blockEdge")
	declareRunTimeSelectionTable (autoPtr, blockEdge, Istream,(const dictionary &dict, const label index, const searchableSurfaces &geometry, const pointField &points, Istream &is),(dict, index, geometry, points, is))
	blockEdge (const pointField &points, const edge &fromTo)
	blockEdge (const dictionary &dict, const label index, const pointField &points, Istream &is)
virtual autoPtr< blockEdge >	clone () const
virtual	~blockEdge ()=default
bool	valid () const noexcept
label	start () const noexcept
label	end () const noexcept
const point &	firstPoint () const
const point &	lastPoint () const
int	compare (const blockEdge &e) const
int	compare (const edge &e) const
int	compare (const label start, const label end) const
point	linearPosition (const scalar lambda) const
virtual tmp< pointField >	position (const scalarList &lambdas) const
void	write (Ostream &os, const dictionary &dict) const

Additional Inherited Members
Static Public Member Functions inherited from blockEdge
static autoPtr< blockEdge >	New (const dictionary &dict, const label index, const searchableSurfaces &geometry, const pointField &points, Istream &is)
Protected Member Functions inherited from blockEdge
	blockEdge (const pointField &points, const label from, const label to)
Static Protected Member Functions inherited from blockEdge
static pointField	appendEndPoints (const pointField &p, const label from, const label to, const pointField &intermediate)
Protected Attributes inherited from blockEdge
const pointField &	points_
const label	start_
const label	end_

Detailed Description

A blockEdge defined as an arc of a circle.

The arc is normally defined by its endpoints and a point on its circumference, typically a midpoint. For example,

points ((1 0 0) (0 1 0));

arc 0 1 (0.707107 0.707107 0);

The arc can enclose an angle greater than 0 and less than 360 degrees.

The arc will frequently enclose an angle less than 180 degrees. For the case, it is possible to define the arc by its endpoints and its centre (origin) point. For example,

arc 0 1 origin (0 0 0);

When defined in the way, any discrepancy in the arc radius for the endpoints is resolved by adjusting the origin to ensure that the average radius is satisfied.

It is also possible to define a flatness factor as a multiplier of the calculated radius. For example,

arc 0 1 origin 1.1 (0 0 0);

Source files

• arcEdge.H
• arcEdge.C

Definition at line 75 of file arcEdge.H.

Constructor & Destructor Documentation

arcEdge() [1/5]

arcEdge	(	const pointField &	points,
		const point &	origin,
		const edge &	fromTo
	)

Parameters

points	Referenced point field
origin	The origin of the circle
fromTo	Start/end in point field

Definition at line 186 of file arcEdge.C.

arcEdge() [2/5]

arcEdge	(	const pointField &	points,
		const edge &	fromTo,
		const point &	midPoint
	)

Parameters

points	Referenced point field
fromTo	Start/end in point field
midPoint	A point on the circumference

Definition at line 202 of file arcEdge.C.

arcEdge() [3/5]

arcEdge	(	const pointField &	points,
		const point &	origin,
		const label	from,
		const label	to
	)

Parameters

points	Referenced point field
origin	The origin of the circle
from	Start point in point field
to	End point in point field

Definition at line 218 of file arcEdge.C.

arcEdge() [4/5]

arcEdge	(	const pointField &	points,
		const label	from,
		const label	to,
		const point &	midPoint
	)

Parameters

points	Referenced point field
from	Start point in point field
to	End point in point field
midPoint	A point on the circumference

Definition at line 230 of file arcEdge.C.

arcEdge() [5/5]

arcEdge	(	const dictionary &	dict,
		const label	index,
		const searchableSurfaces &	,
		const pointField &	points,
		Istream &	is
	)

Parameters

points

Referenced point field

Definition at line 242 of file arcEdge.C.

References Foam::expressions::patchExpr::debug, Foam::Info, token::isWord(), Foam::nl, token::number(), p, and Istream::putBack().

Here is the call graph for this function:

~arcEdge()

virtual ~arcEdge ( )

virtualdefault

Member Function Documentation

TypeName()

TypeName

(

"arc"

)

position()

Foam::point position ( const scalar  lambda ) const

virtual

Implements blockEdge.

Definition at line 301 of file arcEdge.C.

References InfoInFunction, lambda(), and Foam::nl.

Here is the call graph for this function:

length()

Foam::scalar length ( ) const

virtualnoexcept

Implements blockEdge.

Definition at line 324 of file arcEdge.C.

---

The documentation for this class was generated from the following files:

• src/mesh/blockMesh/blockEdges/arcEdge/arcEdge.H
• src/mesh/blockMesh/blockEdges/arcEdge/arcEdge.C
