Define a curved edge that is parameterized for 0<lambda<1 between the start/end points. More...

Inheritance diagram for blockEdge:

[legend]

Collaboration diagram for blockEdge:

Classes
class	iNew

Public Member Functions
	TypeName ("blockEdge")

	declareRunTimeSelectionTable (autoPtr, blockEdge, Istream,(const dictionary &dict, const label index, const searchableSurfaces &geometry, const pointField &points, Istream &is),(dict, index, geometry, points, is))

	blockEdge (const pointField &points, const edge &fromTo)

	blockEdge (const dictionary &dict, const label index, const pointField &points, Istream &is)

virtual autoPtr< blockEdge >	clone () const

virtual	~blockEdge ()=default

bool	valid () const noexcept

label	start () const noexcept

label	end () const noexcept

const point &	firstPoint () const

const point &	lastPoint () const

int	compare (const blockEdge &e) const

int	compare (const edge &e) const

int	compare (const label start, const label end) const

point	linearPosition (const scalar lambda) const

virtual point	position (const scalar lambda) const =0

virtual tmp< pointField >	position (const scalarList &lambdas) const

virtual scalar	length () const =0

void	write (Ostream &os, const dictionary &dict) const

Static Public Member Functions
static autoPtr< blockEdge >	New (const dictionary &dict, const label index, const searchableSurfaces &geometry, const pointField &points, Istream &is)

Protected Member Functions
	blockEdge (const pointField &points, const label from, const label to)

Static Protected Member Functions
static pointField	appendEndPoints (const pointField &p, const label from, const label to, const pointField &intermediate)

Protected Attributes
const pointField &	points_

const label	start_

const label	end_

Friends
Ostream &	operator<< (Ostream &os, const blockEdge &e)

Detailed Description

Define a curved edge that is parameterized for 0<lambda<1 between the start/end points.

Source files

Definition at line 60 of file blockEdge.H.

Constructor & Destructor Documentation

◆ blockEdge() [1/3]

blockEdge	(	const pointField &	points,
		const label	from,
		const label	to
	)

inlineprotected

Parameters

points	Referenced point field
from	Start point in point field
to	End point in point field

Definition at line 94 of file blockEdge.H.

◆ blockEdge() [2/3]

blockEdge	(	const pointField &	points,
		const edge &	fromTo
	)

Parameters

points	Referenced point field
fromTo	Start/end in point field

Definition at line 38 of file blockEdge.C.

◆ blockEdge() [3/3]

blockEdge	(	const dictionary &	dict,
		const label	index,
		const pointField &	points,
		Istream &	is
	)

Parameters

points Referenced point field

Definition at line 50 of file blockEdge.C.

◆ ~blockEdge()

virtual ~blockEdge ( )

virtualdefault

Member Function Documentation

◆ appendEndPoints()

Foam::pointField appendEndPoints	(	const pointField &	p,
		const label	from,
		const label	to,
		const pointField &	intermediate
	)

staticprotected

Parameters

p	Referenced point field
from	Start point in point field
to	End point in point field
intermediate	Intermediate points (knots)

Definition at line 103 of file blockEdge.C.

References polyLine::concat(), and p.

Here is the call graph for this function:

◆ TypeName()

TypeName ( "blockEdge" )

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		blockEdge	,
		Istream	,
		(const dictionary &dict, const label index, const searchableSurfaces &geometry, const pointField &points, Istream &is)	,
		(dict, index, geometry, points, is)
	)

◆ clone()

Foam::autoPtr< Foam::blockEdge > clone ( ) const

virtual

Definition at line 63 of file blockEdge.C.

References NotImplemented.

◆ New()

Foam::autoPtr< Foam::blockEdge > New	(	const dictionary &	dict,
		const label	index,
		const searchableSurfaces &	geometry,
		const pointField &	points,
		Istream &	is
	)
