Takes the description of the block and the list of curved edges and creates a list of points on edges together with the weighting factors. More...

Inheritance diagram for blockDescriptor:

[legend]

Collaboration diagram for blockDescriptor:

[legend]

Public Member Functions
	blockDescriptor (const blockDescriptor &)=default

void	operator= (const blockDescriptor &)=delete

	blockDescriptor (const cellShape &bshape, const pointField &vertices, const blockEdgeList &edges, const blockFaceList &faces, const labelVector &density, const UList< gradingDescriptors > &expand=UList< gradingDescriptors >::null(), const word &zoneName=word::null)

	blockDescriptor (const dictionary &dict, const label blockIndex, const pointField &vertices, const blockEdgeList &edges, const blockFaceList &faces, Istream &is)

const pointField &	vertices () const noexcept

const blockFaceList &	blockFaces () const noexcept

const cellShape &	blockShape () const noexcept

const labelVector &	density () const noexcept

const List< gradingDescriptors > &	grading () const noexcept

const word &	zoneName () const noexcept

const FixedList< label, 6 > &	curvedFaces () const noexcept

label	nCurvedFaces () const noexcept

const point &	blockPoint (const label i) const

label	facePointLabel (const direction facei, const label i, const label j) const

bool	vertex (const label i, const label j, const label k) const

bool	edge (const label i, const label j, const label k) const

int	edgesPointsWeights (pointField(&edgesPoints)[12], scalarList(&edgesWeights)[12]) const

bool	edgePointsWeights (const label edgei, pointField &edgePoints, scalarList &edgeWeights, const label nDiv, const gradingDescriptors &gd=gradingDescriptors()) const

bool	edgePointsWeights (const label edgei, pointField &edgePoints, scalarList &edgeWeights) const

bool	flatFaceOrEdge (const label i, const label j, const label k) const

FixedList< pointField, 6 >	facePoints (const pointField &points) const

void	correctFacePoints (FixedList< pointField, 6 > &) const

InfoProxy< blockDescriptor >	info () const

Public Member Functions inherited from ijkMesh
	ijkMesh ()

	ijkMesh (const labelVector &ijk)

	ijkMesh (const label nx, const label ny, const label nz)

label	nPoints () const

label	nCells () const

label	nFaces () const

label	nInternalFaces () const

label	nBoundaryFaces () const

label	nBoundaryFaces (const direction shapeFacei) const

label	cellLabel (const label i, const label j, const label k) const

label	cellLabel (const labelVector &ijk) const

label	pointLabel (const label i, const label j, const label k) const

label	pointLabel (const labelVector &ijk) const

hexCell	vertLabels (const label i, const label j, const label k) const

hexCell	vertLabels (const labelVector &ijk) const

Public Member Functions inherited from ijkAddressing
	ijkAddressing ()

	ijkAddressing (const labelVector &ijk)

	ijkAddressing (const label ni, const label nj, const label nk)

bool	empty () const

const labelVector &	sizes () const

labelVector &	sizes ()

label	size () const

const label &	size (const vector::components cmpt) const

void	clear ()

void	reset (const label ni, const label nj, const label nk)

void	reset (const labelVector &newSizes)

label	index (const label i, const label j, const label k) const

label	index (const labelVector &ijk) const

labelVector	index (const label idx) const

void	checkIndex (const label i, const label j, const label k, const bool allowExtra=false) const

void	checkIndex (const labelVector &ijk, const bool allowExtra=false) const

void	checkSizes () const

void	checkSizes (const labelVector &other) const

void	checkSizes (const label nTotal) const

Static Public Member Functions
static void	write (Ostream &, const label blocki, const dictionary &)

Detailed Description

Takes the description of the block and the list of curved edges and creates a list of points on edges together with the weighting factors.

For a given block, the correspondence between the ordering of vertex labels and face labels is shown below. For vertex numbering in the sequence 0 to 7 (block, centre): faces 0 (f0) and 1 are left and right, respectively; faces 2 and 3 are front and back; and faces 4 and 5 are bottom and top:

                7 ---- 6
          f5    |\     :\    f3
           |    | 4 ---- 5    \
           |    3.|....2 |     \
           |     \|     \|     f2
          f4      0 ---- 1
  Y  Z
   \ |          f0 ------ f1
    \|
     o--- X

Source files

Definition at line 74 of file blockDescriptor.H.

Constructor & Destructor Documentation

◆ blockDescriptor() [1/3]

blockDescriptor ( const blockDescriptor & )

default

◆ blockDescriptor() [2/3]

blockDescriptor	(	const cellShape &	bshape,
		const pointField &	vertices,
		const blockEdgeList &	edges,
		const blockFaceList &	faces,
		const labelVector &	density,
		const UList< gradingDescriptors > &	expand = `UList<gradingDescriptors>::null()`,
		const word &	zoneName = `word::null`
	)

Definition at line 190 of file blockDescriptor.C.

References Foam::exit(), Foam::stringOps::expand(), Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

◆ blockDescriptor() [3/3]

blockDescriptor	(	const dictionary &	dict,
		const label	blockIndex,
		const pointField &	vertices,
		const blockEdgeList &	edges,
		const blockFaceList &	faces,
		Istream &	is
	)

Definition at line 223 of file blockDescriptor.C.

References token::BEGIN_LIST, Foam::check(), dict, Foam::endl(), Foam::exit(), Foam::stringOps::expand(), Foam::FatalError, FatalErrorInFunction, Foam::FatalIOError, FatalIOErrorInFunction, token::info(), IOWarningInFunction, token::isPunctuation(), token::isWord(), token::pToken(), Istream::putBack(), ijkAddressing::sizes(), dictionary::subOrEmptyDict(), token::wordToken(), Vector< Cmpt >::x(), Vector< Cmpt >::y(), and Vector< Cmpt >::z().

Here is the call graph for this function:

Member Function Documentation

◆ operator=()

void operator= ( const blockDescriptor & )

delete

◆ vertices()

const Foam::pointField & vertices ( ) const

inlinenoexcept

Definition at line 25 of file blockDescriptorI.H.

Referenced by projectFace::project().

Here is the caller graph for this function:

◆ blockFaces()

const Foam::blockFaceList & blockFaces ( ) const

inlinenoexcept

Definition at line 32 of file blockDescriptorI.H.

◆ blockShape()

const Foam::cellShape & blockShape ( ) const

inlinenoexcept

Definition at line 39 of file blockDescriptorI.H.

Referenced by Foam::operator<<(), and projectFace::project().

Here is the caller graph for this function:

◆ density()

const Foam::labelVector & density ( ) const

inlinenoexcept

Definition at line 46 of file blockDescriptorI.H.

References ijkAddressing::sizes().

Referenced by Foam::faceNij(), Foam::facePoint(), Foam::facePointN(), Foam::operator<<(), and projectFace::project().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ grading()

const Foam::List< Foam::gradingDescriptors > & grading ( ) const

inlinenoexcept

Definition at line 53 of file blockDescriptorI.H.

Referenced by Foam::operator<<().

Here is the caller graph for this function:

◆ zoneName()

const Foam::word & zoneName ( ) const

inlinenoexcept

Definition at line 59 of file blockDescriptorI.H.

Referenced by Foam::operator<<().

Here is the caller graph for this function:

◆ curvedFaces()

const Foam::FixedList< Foam::label, 6 > & curvedFaces ( ) const

inlinenoexcept

Definition at line 66 of file blockDescriptorI.H.

◆ nCurvedFaces()

Foam::label nCurvedFaces ( ) const

inlinenoexcept

Definition at line 72 of file blockDescriptorI.H.

◆ blockPoint()

const Foam::point & blockPoint ( const label i ) const

inline

Definition at line 78 of file blockDescriptorI.H.

◆ facePointLabel()

Foam::label facePointLabel	(	const direction	facei,
		const label	i,
		const label	j
	)		const

inline

Definition at line 85 of file blockDescriptorI.H.

References x, and y.

◆ vertex()

bool vertex	(	const label	i,
		const label	j,
		const label	k
	)		const

inline

Definition at line 122 of file blockDescriptorI.H.

References k.

◆ edge()

bool edge	(	const label	i,
		const label	j,
		const label	k
	)		const

inline

Definition at line 135 of file blockDescriptorI.H.

References k.

◆ edgesPointsWeights()

int edgesPointsWeights	(	pointField(&)	edgesPoints[12],
		scalarList(&)	edgesWeights[12]
	)		const

Definition at line 122 of file blockDescriptorEdges.C.

References hexCell::modelEdges().

Here is the call graph for this function:

◆ edgePointsWeights() [1/2]

bool edgePointsWeights	(	const label	edgei,
		pointField &	edgePoints,
		scalarList &	edgeWeights,
		const label	nDiv,
		const gradingDescriptors &	gd = `gradingDescriptors()`
	)		const

Definition at line 147 of file blockDescriptorEdges.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, and hexCell::modelEdges().

Here is the call graph for this function:

◆ edgePointsWeights() [2/2]

bool edgePointsWeights	(	const label	edgei,
		pointField &	edgePoints,
		scalarList &	edgeWeights
	)		const

Definition at line 178 of file blockDescriptorEdges.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, and hexCell::modelEdges().

Here is the call graph for this function:

◆ flatFaceOrEdge()

bool flatFaceOrEdge	(	const label	i,
		const label	j,
		const label	k
	)		const

inline

Definition at line 148 of file blockDescriptorI.H.

References k, x, and y.

◆ facePoints()

Foam::FixedList< Foam::pointField, 6 > facePoints ( const pointField & points ) const

Definition at line 319 of file blockDescriptor.C.

References k, points, and FixedList::setSize().

Here is the call graph for this function:

◆ correctFacePoints()

void correctFacePoints ( FixedList< pointField, 6 > & facePoints ) const

Definition at line 375 of file blockDescriptor.C.

References forAll.

◆ write()

void write	(	Ostream &	os,
		const label	blocki,
		const dictionary &	d
	)

static

Definition at line 395 of file blockDescriptor.C.

References dictionary::findDict(), os(), and Foam::blockMeshTools::write().

Here is the call graph for this function:

◆ info()

InfoProxy<blockDescriptor> info ( ) const

inline

Definition at line 260 of file blockDescriptor.H.

The documentation for this class was generated from the following files:

src/mesh/blockMesh/blockDescriptor/blockDescriptor.H
src/mesh/blockMesh/blockDescriptor/blockDescriptor.C
src/mesh/blockMesh/blockDescriptor/blockDescriptorEdges.C
src/mesh/blockMesh/blockDescriptor/blockDescriptorI.H
