binaryTree< CompType, ThermoType > Class Template Reference

Data storage of the chemistryOnLineLibrary according to a binary tree structure. More...

Public Types
typedef binaryNode< CompType, ThermoType >	node
typedef chemPointISAT< CompType, ThermoType >	chemPoint

Public Member Functions
	binaryTree (TDACChemistryModel< CompType, ThermoType > &chemistry, dictionary coeffsDict)
label	size ()
label	depth (node *subTreeRoot)
label	depth ()
node *	root ()
label	maxNLeafs ()
void	insertNewLeaf (const scalarField &phiq, const scalarField &Rphiq, const scalarSquareMatrix &A, const scalarField &scaleFactor, const scalar &epsTol, const label nCols, chemPoint *&phi0)
void	binaryTreeSearch (const scalarField &phiq, node *node, chemPoint *&nearest)
bool	secondaryBTSearch (const scalarField &phiq, chemPoint *&x)
void	deleteLeaf (chemPoint *&phi0)
void	balance ()
void	deleteAllNode ()
chemPoint *	treeMin (node *subTreeRoot)
chemPoint *	treeMin ()
chemPoint *	treeSuccessor (chemPoint *x)
void	clear ()
bool	isFull ()
void	resetNumRetrieve ()

Detailed Description

template<class CompType, class ThermoType>
class Foam::binaryTree< CompType, ThermoType >

Data storage of the chemistryOnLineLibrary according to a binary tree structure.

0 (root node) / \ 0 0 / \ / \ L R L 0 / \ L R

L: leafLeft_ R: leafRight_

Definition at line 53 of file binaryTree.H.

Member Typedef Documentation

node

typedef binaryNode<CompType, ThermoType> node

Definition at line 58 of file binaryTree.H.

chemPoint

typedef chemPointISAT<CompType, ThermoType> chemPoint

Definition at line 59 of file binaryTree.H.

Constructor & Destructor Documentation

binaryTree()

binaryTree	(	TDACChemistryModel< CompType, ThermoType > &	chemistry,
		dictionary	coeffsDict
	)

Definition at line 337 of file binaryTree.C.

Member Function Documentation

size()

label size ( )

inline

Definition at line 134 of file binaryTree.H.

Referenced by ISAT< CompType, ThermoType >::size().

Here is the caller graph for this function:

depth() [1/2]

Foam::label depth

(

node *

subTreeRoot

)

Definition at line 354 of file binaryTree.C.

References Foam::max(), binaryNode< CompType, ThermoType >::nodeLeft(), and binaryNode< CompType, ThermoType >::nodeRight().

Here is the call graph for this function:

depth() [2/2]

label depth ( )

inline

Definition at line 142 of file binaryTree.H.

root()

node* root ( )

inline

Definition at line 147 of file binaryTree.H.

maxNLeafs()

label maxNLeafs ( )

inline

Definition at line 152 of file binaryTree.H.

insertNewLeaf()

void insertNewLeaf	(	const scalarField &	phiq,
		const scalarField &	Rphiq,
		const scalarSquareMatrix &	A,
		const scalarField &	scaleFactor,
		const scalar &	epsTol,
		const label	nCols,
		chemPoint *&	phi0
	)

Definition at line 376 of file binaryTree.C.

References A, Foam::deleteDemandDrivenData(), chemPointISAT< CompType, ThermoType >::node(), and Foam::constant::electromagnetic::phi0.

Here is the call graph for this function:

binaryTreeSearch()

void binaryTreeSearch	(	const scalarField &	phiq,
		node *	node,
		chemPoint *&	nearest
	)

Definition at line 460 of file binaryTree.C.

References binaryNode< CompType, ThermoType >::a(), binaryNode< CompType, ThermoType >::leafLeft(), binaryNode< CompType, ThermoType >::leafRight(), binaryNode< CompType, ThermoType >::nodeLeft(), binaryNode< CompType, ThermoType >::nodeRight(), and binaryNode< CompType, ThermoType >::v().

Here is the call graph for this function:

secondaryBTSearch()

bool secondaryBTSearch	(	const scalarField &	phiq,
		chemPoint *&	x
	)

Definition at line 517 of file binaryTree.C.

References chemPointISAT< CompType, ThermoType >::inEOA(), x, and y.

Here is the call graph for this function:

deleteLeaf()

void deleteLeaf

(

chemPoint *&

phi0

)

Definition at line 574 of file binaryTree.C.

References Foam::deleteDemandDrivenData(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, chemPointISAT< CompType, ThermoType >::node(), binaryNode< CompType, ThermoType >::parent(), Foam::constant::electromagnetic::phi0, and x.

Here is the call graph for this function:

balance()

void balance

Definition at line 638 of file binaryTree.C.

References forAll, SortableList::indices(), n, Foam::constant::electromagnetic::phi0, SortableList::sort(), Foam::sqr(), x, and Foam::Zero.

Here is the call graph for this function:

deleteAllNode()

void deleteAllNode ( )

inline

Definition at line 215 of file binaryTree.H.

treeMin() [1/2]

Foam::chemPointISAT< CompType, ThermoType > * treeMin

(

node *

subTreeRoot

)

Definition at line 730 of file binaryTree.C.

References binaryNode< CompType, ThermoType >::leafLeft(), and binaryNode< CompType, ThermoType >::nodeLeft().

Here is the call graph for this function:

treeMin() [2/2]

chemPoint* treeMin ( )

inline

Definition at line 222 of file binaryTree.H.

treeSuccessor()

Foam::chemPointISAT< CompType, ThermoType > * treeSuccessor

(

chemPoint *

x

)

Definition at line 747 of file binaryTree.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, x, and y.

Here is the call graph for this function:

clear()

void clear

Definition at line 797 of file binaryTree.C.

isFull()

bool isFull

Definition at line 811 of file binaryTree.C.

resetNumRetrieve()

void resetNumRetrieve

Definition at line 818 of file binaryTree.C.

References chemPointISAT< CompType, ThermoType >::resetNumRetrieve().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/thermophysicalModels/chemistryModel/chemistryModel/TDACChemistryModel/tabulation/ISAT/binaryTree/binaryTree.H
• src/thermophysicalModels/chemistryModel/chemistryModel/TDACChemistryModel/tabulation/ISAT/binaryTree/binaryTree.C
