Attach/detach boundary mesh modifier. This modifier takes a set of internal faces and converts them into boundary faces and vice versa based on the given activation switch. More...

Inheritance diagram for attachDetach:

[legend]

Collaboration diagram for attachDetach:

[legend]

Public Member Functions
	TypeName ("attachDetach")

	attachDetach (const word &name, const label index, const polyTopoChanger &mme, const word &faceZoneName, const word &masterPatchName, const word &slavePatchName, const scalarField &triggerTimes, const bool manualTrigger=false)

	attachDetach (const word &name, const dictionary &dict, const label index, const polyTopoChanger &mesh)

virtual	~attachDetach ()=default

const polyPatchID &	masterPatchID () const

const polyPatchID &	slavePatchID () const

bool	attached () const

bool	manualTrigger () const

bool	setAttach () const

bool	setDetach () const

virtual bool	changeTopology () const

virtual void	setRefinement (polyTopoChange &) const

virtual void	modifyMotionPoints (pointField &motionPoints) const

virtual void	updateMesh (const mapPolyMesh &)

const scalarField &	triggerTimes () const

virtual void	write (Ostream &) const

virtual void	writeDict (Ostream &) const

Public Member Functions inherited from polyMeshModifier
	TypeName ("meshModifier")

	declareRunTimeSelectionTable (autoPtr, polyMeshModifier, dictionary,(const word &name, const dictionary &dict, const label index, const polyTopoChanger &mme),(name, dict, index, mme))

	polyMeshModifier (const word &name, const label index, const polyTopoChanger &mme, const bool act)

virtual	~polyMeshModifier ()=default

const word &	name () const

label	index () const

const polyTopoChanger &	topoChanger () const

Switch	active () const

void	enable () const

void	disable () const

Additional Inherited Members
Static Public Member Functions inherited from polyMeshModifier
static autoPtr< polyMeshModifier >	New (const word &name, const dictionary &dict, const label index, const polyTopoChanger &mme)

Detailed Description

Attach/detach boundary mesh modifier. This modifier takes a set of internal faces and converts them into boundary faces and vice versa based on the given activation switch.

The patch is oriented using the flip map in the face zone. The oriented faces are put into the master patch and their mirror images into the slave.

Source files

Definition at line 58 of file attachDetach.H.

Constructor & Destructor Documentation

◆ attachDetach() [1/2]

attachDetach	(	const word &	name,
		const label	index,
		const polyTopoChanger &	mme,
		const word &	faceZoneName,
		const word &	masterPatchName,
		const word &	slavePatchName,
		const scalarField &	triggerTimes,
		const bool	manualTrigger = `false`
	)
