This boundary condition provides a wall constraint on the specific dissipation rate (i.e. omega) and the turbulent kinetic energy production contribution (i.e. G) for atmospheric boundary layer modelling. More...

Inheritance diagram for atmOmegaWallFunctionFvPatchScalarField:

[legend]

Collaboration diagram for atmOmegaWallFunctionFvPatchScalarField:

[legend]

Public Member Functions
	TypeName ("atmOmegaWallFunction")

	atmOmegaWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)

	atmOmegaWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)

	atmOmegaWallFunctionFvPatchScalarField (const atmOmegaWallFunctionFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)

	atmOmegaWallFunctionFvPatchScalarField (const atmOmegaWallFunctionFvPatchScalarField &)

virtual tmp< fvPatchScalarField >	clone () const

	atmOmegaWallFunctionFvPatchScalarField (const atmOmegaWallFunctionFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)

virtual tmp< fvPatchScalarField >	clone (const DimensionedField< scalar, volMesh > &iF) const

virtual	~atmOmegaWallFunctionFvPatchScalarField ()=default

virtual void	autoMap (const fvPatchFieldMapper &)

virtual void	rmap (const fvPatchScalarField &, const labelList &)

virtual void	write (Ostream &) const

Public Member Functions inherited from omegaWallFunctionFvPatchScalarField
	TypeName ("omegaWallFunction")

	omegaWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)

	omegaWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)

	omegaWallFunctionFvPatchScalarField (const omegaWallFunctionFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)

	omegaWallFunctionFvPatchScalarField (const omegaWallFunctionFvPatchScalarField &)

	omegaWallFunctionFvPatchScalarField (const omegaWallFunctionFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)

virtual	~omegaWallFunctionFvPatchScalarField ()=default

scalarField &	G (bool init=false)

scalarField &	omega (bool init=false)

virtual void	updateCoeffs ()

virtual void	updateWeightedCoeffs (const scalarField &weights)

virtual void	manipulateMatrix (fvMatrix< scalar > &matrix)

virtual void	manipulateMatrix (fvMatrix< scalar > &matrix, const scalarField &weights)

Public Member Functions inherited from fixedValueFvPatchField< scalar >
	TypeName ("fixedValue")

	fixedValueFvPatchField (const fvPatch &, const DimensionedField< scalar, volMesh > &)

	fixedValueFvPatchField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const scalar &value)

	fixedValueFvPatchField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &, const bool valueRequired=true)

	fixedValueFvPatchField (const fixedValueFvPatchField< scalar > &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)

	fixedValueFvPatchField (const fixedValueFvPatchField< scalar > &)

	fixedValueFvPatchField (const fixedValueFvPatchField< scalar > &, const DimensionedField< scalar, volMesh > &)

virtual tmp< fvPatchField< scalar > >	clone () const

virtual bool	fixesValue () const

virtual bool	assignable () const

virtual tmp< Field< scalar > >	valueInternalCoeffs (const tmp< scalarField > &) const

virtual tmp< Field< scalar > >	valueBoundaryCoeffs (const tmp< scalarField > &) const

virtual tmp< Field< scalar > >	gradientInternalCoeffs () const

virtual tmp< Field< scalar > >	gradientBoundaryCoeffs () const

virtual void	operator= (const UList< scalar > &)

virtual void	operator= (const fvPatchField< scalar > &)

virtual void	operator= (const scalar &)

virtual void	operator+= (const fvPatchField< scalar > &)

virtual void	operator+= (const Field< scalar > &)

virtual void	operator+= (const scalar &)

virtual void	operator-= (const fvPatchField< scalar > &)

virtual void	operator-= (const Field< scalar > &)

virtual void	operator-= (const scalar &)

virtual void	operator*= (const fvPatchField< scalar > &)

virtual void	operator*= (const Field< scalar > &)

virtual void	operator*= (const scalar)

virtual void	operator/= (const fvPatchField< scalar > &)

virtual void	operator/= (const Field< scalar > &)

virtual void	operator/= (const scalar)

Public Member Functions inherited from fvPatchField< scalar >
	TypeName ("fvPatchField")

	declareRunTimeSelectionTable (tmp, fvPatchField, patch,(const fvPatch &p, const DimensionedField< Type, volMesh > &iF),(p, iF))

	declareRunTimeSelectionTable (tmp, fvPatchField, patchMapper,(const fvPatchField< Type > &ptf, const fvPatch &p, const DimensionedField< Type, volMesh > &iF, const fvPatchFieldMapper &m),(dynamic_cast< const fvPatchFieldType & >(ptf), p, iF, m))

	declareRunTimeSelectionTable (tmp, fvPatchField, dictionary,(const fvPatch &p, const DimensionedField< Type, volMesh > &iF, const dictionary &dict),(p, iF, dict))

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const Type &value)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const word &patchType)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const Field< Type > &)

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &, const bool valueRequired=true)

	fvPatchField (const fvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

	fvPatchField (const fvPatchField< Type > &)

	fvPatchField (const fvPatchField< Type > &, const DimensionedField< Type, volMesh > &)

virtual tmp< fvPatchField< Type > >	clone (const DimensionedField< Type, volMesh > &iF) const

Foam::tmp< Foam::fvPatchField< Type > >	NewCalculatedType (const fvPatch &p)

Foam::tmp< Foam::fvPatchField< Type > >	NewCalculatedType (const fvPatchField< Type2 > &pf)

virtual	~fvPatchField ()=default

bool	useImplicit () const noexcept

bool	useImplicit (bool on) noexcept

virtual bool	coupled () const

const objectRegistry &	db () const

const fvPatch &	patch () const

const DimensionedField< Type, volMesh > &	internalField () const

const Field< Type > &	primitiveField () const

const word &	patchType () const

word &	patchType ()

bool	updated () const

bool	manipulatedMatrix () const

virtual void	rmap (const fvPatchField< Type > &, const labelList &)

virtual tmp< Field< Type > >	snGrad () const

virtual tmp< Field< Type > >	snGrad (const scalarField &deltaCoeffs) const

virtual tmp< Field< Type > >	patchInternalField () const

virtual void	patchInternalField (Field< Type > &) const

virtual tmp< Field< Type > >	patchNeighbourField () const

virtual void	initEvaluate (const Pstream::commsTypes commsType=Pstream::commsTypes::blocking)

virtual void	evaluate (const Pstream::commsTypes commsType=Pstream::commsTypes::blocking)

virtual tmp< Field< Type > >	valueInternalCoeffs (const tmp< Field< scalar >> &) const

virtual tmp< Field< Type > >	valueBoundaryCoeffs (const tmp< Field< scalar >> &) const

virtual tmp< Field< Type > >	gradientInternalCoeffs (const scalarField &deltaCoeffs) const

virtual tmp< Field< Type > >	gradientBoundaryCoeffs (const scalarField &deltaCoeffs) const

virtual void	manipulateMatrix (fvMatrix< Type > &matrix)

virtual void	manipulateMatrix (fvMatrix< Type > &matrix, const scalarField &weights)

virtual void	manipulateMatrix (fvMatrix< Type > &matrix, const label iMatrix, const direction cmp)

void	check (const fvPatchField< Type > &) const

virtual void	operator= (const UList< Type > &)

virtual void	operator= (const fvPatchField< Type > &)

virtual void	operator= (const Type &)

virtual void	operator+= (const fvPatchField< Type > &)

virtual void	operator+= (const Field< Type > &)

virtual void	operator+= (const Type &)

virtual void	operator-= (const fvPatchField< Type > &)

virtual void	operator-= (const Field< Type > &)

virtual void	operator-= (const Type &)

virtual void	operator== (const fvPatchField< Type > &)

virtual void	operator== (const Field< Type > &)

virtual void	operator== (const Type &)

Protected Member Functions
virtual void	calculate (const turbulenceModel &turbulence, const List< scalar > &cornerWeights, const fvPatch &patch, scalarField &G, scalarField &omega)

Protected Member Functions inherited from omegaWallFunctionFvPatchScalarField
virtual void	setMaster ()

virtual void	createAveragingWeights ()

virtual omegaWallFunctionFvPatchScalarField &	omegaPatch (const label patchi)

virtual void	calculateTurbulenceFields (const turbulenceModel &turbulence, scalarField &G0, scalarField &omega0)

virtual label &	master ()

Protected Attributes
autoPtr< PatchFunction1< scalar > >	z0_

Protected Attributes inherited from omegaWallFunctionFvPatchScalarField
bool	blended_

bool	initialised_

label	master_

scalar	beta1_

scalarField	G_

scalarField	omega_

List< List< scalar > >	cornerWeights_

Additional Inherited Members
Public Types inherited from fvPatchField< scalar >
typedef fvPatch	Patch

typedef calculatedFvPatchField< Type >	Calculated

Static Public Member Functions inherited from fvPatchField< scalar >
static tmp< fvPatchField< Type > >	New (const word &, const fvPatch &, const DimensionedField< Type, volMesh > &)

static tmp< fvPatchField< Type > >	New (const word &, const word &actualPatchType, const fvPatch &, const DimensionedField< Type, volMesh > &)

static tmp< fvPatchField< Type > >	New (const fvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)

static tmp< fvPatchField< Type > >	New (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &)

static tmp< fvPatchField< Type > >	NewCalculatedType (const fvPatch &)

static tmp< fvPatchField< Type > >	NewCalculatedType (const fvPatchField< Type2 > &)

static const word &	calculatedType ()

Static Public Attributes inherited from fvPatchField< scalar >
static int	disallowGenericFvPatchField

Static Protected Attributes inherited from omegaWallFunctionFvPatchScalarField
static scalar	tolerance_ = 1e-5

Detailed Description

This boundary condition provides a wall constraint on the specific dissipation rate (i.e. omega) and the turbulent kinetic energy production contribution (i.e. G) for atmospheric boundary layer modelling.

References:

    Theoretical expressions (tags:PGVB, B):
        Parente, A., Gorlé, C., Van Beeck, J., & Benocci, C. (2011).
        Improved k–ε model and wall function formulation
        for the RANS simulation of ABL flows.
        J. of wind engineering and industrial aerodynamics, 99(4), 267-278.
        DOI:10.1016/j.jweia.2010.12.017

        Bredberg, J. (2000).
        On the wall boundary condition for turbulence models.
        Chalmers University of Technology, Depart. of Thermo and Fluid Dyn.
        Internal Report 00/4. Sweden: Göteborg.

Required fields:

  omega    | Specific dissipation rate    [1/s]

Usage

Example of the boundary condition specification:

<patchName>
{
    // Mandatory entries (unmodifiable)
    type            atmOmegaWallFunction;

    // Mandatory entries (runtime modifiable)
    z0              uniform 0.001;

    // Optional (inherited) entries
    ...
}

where the entries mean:

Property	Description	Type	Reqd	Dflt
`type`	Type name: atmOmegaWallFunction	word	yes	-
`z0`	Surface roughness length [m]	PatchFunction1<scalar>	yes	-

The inherited entries are elaborated in:

See also

Foam::omegaWallFunctionFvPatchScalarField

Source files

Definition at line 122 of file atmOmegaWallFunctionFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ atmOmegaWallFunctionFvPatchScalarField() [1/5]

atmOmegaWallFunctionFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF
	)

Definition at line 100 of file atmOmegaWallFunctionFvPatchScalarField.C.

Referenced by atmOmegaWallFunctionFvPatchScalarField::clone().

Here is the caller graph for this function:

◆ atmOmegaWallFunctionFvPatchScalarField() [2/5]

atmOmegaWallFunctionFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 126 of file atmOmegaWallFunctionFvPatchScalarField.C.

◆ atmOmegaWallFunctionFvPatchScalarField() [3/5]

atmOmegaWallFunctionFvPatchScalarField	(	const atmOmegaWallFunctionFvPatchScalarField &	ptf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 112 of file atmOmegaWallFunctionFvPatchScalarField.C.

◆ atmOmegaWallFunctionFvPatchScalarField() [4/5]

atmOmegaWallFunctionFvPatchScalarField ( const atmOmegaWallFunctionFvPatchScalarField & owfpsf )

Definition at line 139 of file atmOmegaWallFunctionFvPatchScalarField.C.

◆ atmOmegaWallFunctionFvPatchScalarField() [5/5]

atmOmegaWallFunctionFvPatchScalarField	(	const atmOmegaWallFunctionFvPatchScalarField &	owfpsf,
		const DimensionedField< scalar, volMesh > &	iF
	)

Definition at line 150 of file atmOmegaWallFunctionFvPatchScalarField.C.

◆ ~atmOmegaWallFunctionFvPatchScalarField()

virtual ~atmOmegaWallFunctionFvPatchScalarField ( )

virtualdefault

Member Function Documentation

◆ calculate()

void calculate	(	const turbulenceModel &	turbulence,
		const List< scalar > &	cornerWeights,
		const fvPatch &	patch,
		scalarField &	G,
		scalarField &	omega
	)

protectedvirtual

Reimplemented from omegaWallFunctionFvPatchScalarField.

Definition at line 31 of file atmOmegaWallFunctionFvPatchScalarField.C.

References GeometricField::boundaryField(), nutWallFunctionFvPatchScalarField::Cmu(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::constant::electromagnetic::G0, k, turbulenceModel::k(), nutWallFunctionFvPatchScalarField::kappa(), Foam::mag(), turbulenceModel::nu(), Foam::foamVersion::patch, Foam::pow025(), fvPatchField::snGrad(), Foam::sqrt(), turbulenceModel::U(), y, and turbulenceModel::y().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "atmOmegaWallFunction" )

◆ clone() [1/2]

virtual tmp<fvPatchScalarField> clone ( ) const

inlinevirtual

Reimplemented from omegaWallFunctionFvPatchScalarField.

Definition at line 188 of file atmOmegaWallFunctionFvPatchScalarField.H.

References atmOmegaWallFunctionFvPatchScalarField::atmOmegaWallFunctionFvPatchScalarField().

Here is the call graph for this function:

◆ clone() [2/2]

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > & iF ) const

inlinevirtual

Reimplemented from omegaWallFunctionFvPatchScalarField.

Definition at line 205 of file atmOmegaWallFunctionFvPatchScalarField.H.

References atmOmegaWallFunctionFvPatchScalarField::atmOmegaWallFunctionFvPatchScalarField().

Here is the call graph for this function:

◆ autoMap()

void autoMap ( const fvPatchFieldMapper & m )

virtual

Reimplemented from fvPatchField< scalar >.

Definition at line 163 of file atmOmegaWallFunctionFvPatchScalarField.C.

◆ rmap()

void rmap	(	const fvPatchScalarField &	ptf,
		const labelList &	addr
	)

virtual

Definition at line 173 of file atmOmegaWallFunctionFvPatchScalarField.C.

References atmOmegaWallFunctionFvPatchScalarField::z0_.

◆ write()

void write ( Ostream & os ) const

virtual

Reimplemented from omegaWallFunctionFvPatchScalarField.

Definition at line 188 of file atmOmegaWallFunctionFvPatchScalarField.C.

References os(), and Foam::vtk::write().

Here is the call graph for this function:

Member Data Documentation

◆ z0_

autoPtr<PatchFunction1<scalar> > z0_

protected

Definition at line 131 of file atmOmegaWallFunctionFvPatchScalarField.H.

Referenced by atmOmegaWallFunctionFvPatchScalarField::rmap().

The documentation for this class was generated from the following files:

src/atmosphericModels/derivedFvPatchFields/wallFunctions/atmOmegaWallFunction/atmOmegaWallFunctionFvPatchScalarField.H
src/atmosphericModels/derivedFvPatchFields/wallFunctions/atmOmegaWallFunction/atmOmegaWallFunctionFvPatchScalarField.C

Public Member Functions

Protected Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ atmOmegaWallFunctionFvPatchScalarField() [1/5]

◆ atmOmegaWallFunctionFvPatchScalarField() [2/5]

◆ atmOmegaWallFunctionFvPatchScalarField() [3/5]

◆ atmOmegaWallFunctionFvPatchScalarField() [4/5]

◆ atmOmegaWallFunctionFvPatchScalarField() [5/5]

◆ ~atmOmegaWallFunctionFvPatchScalarField()

Member Function Documentation

◆ calculate()

◆ TypeName()

◆ clone() [1/2]

◆ clone() [2/2]

◆ autoMap()

◆ rmap()

◆ write()

Member Data Documentation

◆ z0_
