This boundary condition provides a log-law type ground-normal inlet boundary condition for the streamwise component of wind velocity (i.e. u) for homogeneous, two-dimensional, dry-air, equilibrium and neutral atmospheric boundary layer modelling. More...

Inheritance diagram for atmBoundaryLayerInletVelocityFvPatchVectorField:

[legend]

Collaboration diagram for atmBoundaryLayerInletVelocityFvPatchVectorField:

[legend]

Public Member Functions
	TypeName ("atmBoundaryLayerInletVelocity")

	atmBoundaryLayerInletVelocityFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &)

	atmBoundaryLayerInletVelocityFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &, const dictionary &)

	atmBoundaryLayerInletVelocityFvPatchVectorField (const atmBoundaryLayerInletVelocityFvPatchVectorField &, const fvPatch &, const DimensionedField< vector, volMesh > &, const fvPatchFieldMapper &)

virtual tmp< fvPatchVectorField >	clone () const

	atmBoundaryLayerInletVelocityFvPatchVectorField (const atmBoundaryLayerInletVelocityFvPatchVectorField &, const DimensionedField< vector, volMesh > &)

virtual tmp< fvPatchVectorField >	clone (const DimensionedField< vector, volMesh > &iF) const

virtual void	updateCoeffs ()

virtual void	autoMap (const fvPatchFieldMapper &)

virtual void	rmap (const fvPatchVectorField &, const labelList &)

virtual void	write (Ostream &) const

Public Member Functions inherited from atmBoundaryLayer
	atmBoundaryLayer (const Time &time, const polyPatch &pp)

	atmBoundaryLayer (const Time &time, const polyPatch &pp, const dictionary &dict)

	atmBoundaryLayer (const atmBoundaryLayer &abl, const fvPatch &patch, const fvPatchFieldMapper &mapper)

	atmBoundaryLayer (const atmBoundaryLayer &)

vector	flowDir () const

vector	zDir () const

tmp< scalarField >	Ustar (const scalarField &z0) const

void	autoMap (const fvPatchFieldMapper &)

void	rmap (const atmBoundaryLayer &, const labelList &)

tmp< vectorField >	U (const vectorField &pCf) const

tmp< scalarField >	k (const vectorField &pCf) const

tmp< scalarField >	epsilon (const vectorField &pCf) const

tmp< scalarField >	omega (const vectorField &pCf) const

void	write (Ostream &) const

Additional Inherited Members
Protected Attributes inherited from atmBoundaryLayer
bool	initABL_

Detailed Description

This boundary condition provides a log-law type ground-normal inlet boundary condition for the streamwise component of wind velocity (i.e. u) for homogeneous, two-dimensional, dry-air, equilibrium and neutral atmospheric boundary layer modelling.

The ground-normal streamwise flow speed profile expression:

$u = \frac{u^*}{\kappa} \ln \left( \frac{z - d + z_0}{z_0} \right)$

$v = w = 0$

where

	=	Ground-normal streamwise flow speed profile [m/s]
	=	Spanwise flow speed [m/s]
	=	Ground-normal flow speed [m/s]
	=	Friction velocity [m/s]
$\kappa$	=	von Kármán constant [-]
	=	Ground-normal coordinate component [m]
	=	Ground-normal displacement height [m]
	=	Aerodynamic roughness length [m]

Required fields:

        U   | Velocity                                          [m/s]

Usage

Example of the boundary condition specification:

inlet
{
    // Mandatory entries (unmodifiable)
    type            atmBoundaryLayerInletVelocity;

    // Mandatory/Optional (inherited) entries (unmodifiable)
    ...
}

where the entries mean:

Property	Description	Type	Reqd	Deflt
`type`	Type name: atmBoundaryLayerInletVelocity	word	yes	-

The inherited entries are elaborated in:

See also

Source files

Definition at line 155 of file atmBoundaryLayerInletVelocityFvPatchVectorField.H.

Constructor & Destructor Documentation

◆ atmBoundaryLayerInletVelocityFvPatchVectorField() [1/4]

atmBoundaryLayerInletVelocityFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 37 of file atmBoundaryLayerInletVelocityFvPatchVectorField.C.

Referenced by atmBoundaryLayerInletVelocityFvPatchVectorField::clone().

Here is the caller graph for this function:

◆ atmBoundaryLayerInletVelocityFvPatchVectorField() [2/4]

atmBoundaryLayerInletVelocityFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 49 of file atmBoundaryLayerInletVelocityFvPatchVectorField.C.

References dict, dictionary::getOrDefault(), Field::operator=(), p, Foam::foamVersion::patch, U, and Foam::Zero.

Here is the call graph for this function:

◆ atmBoundaryLayerInletVelocityFvPatchVectorField() [3/4]

atmBoundaryLayerInletVelocityFvPatchVectorField	(	const atmBoundaryLayerInletVelocityFvPatchVectorField &	pvf,
		const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 78 of file atmBoundaryLayerInletVelocityFvPatchVectorField.C.

◆ atmBoundaryLayerInletVelocityFvPatchVectorField() [4/4]

atmBoundaryLayerInletVelocityFvPatchVectorField	(	const atmBoundaryLayerInletVelocityFvPatchVectorField &	pvf,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 92 of file atmBoundaryLayerInletVelocityFvPatchVectorField.C.

Member Function Documentation

◆ TypeName()

TypeName ( "atmBoundaryLayerInletVelocity" )

◆ clone() [1/2]

virtual tmp<fvPatchVectorField> clone ( ) const

inlinevirtual

Definition at line 195 of file atmBoundaryLayerInletVelocityFvPatchVectorField.H.

References atmBoundaryLayerInletVelocityFvPatchVectorField::atmBoundaryLayerInletVelocityFvPatchVectorField().

Here is the call graph for this function:

◆ clone() [2/2]

virtual tmp<fvPatchVectorField> clone ( const DimensionedField< vector, volMesh > & iF ) const

inlinevirtual

Definition at line 212 of file atmBoundaryLayerInletVelocityFvPatchVectorField.H.

References atmBoundaryLayerInletVelocityFvPatchVectorField::atmBoundaryLayerInletVelocityFvPatchVectorField().

Here is the call graph for this function:

◆ updateCoeffs()

void updateCoeffs ( )

virtual

Definition at line 104 of file atmBoundaryLayerInletVelocityFvPatchVectorField.C.

References Foam::foamVersion::patch, and atmBoundaryLayer::U().

Here is the call graph for this function:

◆ autoMap()

void autoMap ( const fvPatchFieldMapper & m )

virtual

Definition at line 118 of file atmBoundaryLayerInletVelocityFvPatchVectorField.C.

References atmBoundaryLayer::autoMap().

Here is the call graph for this function:

◆ rmap()

void rmap	(	const fvPatchVectorField &	pvf,
		const labelList &	addr
	)

virtual

Definition at line 128 of file atmBoundaryLayerInletVelocityFvPatchVectorField.C.

References atmBoundaryLayer::rmap().

Here is the call graph for this function:

◆ write()

void write ( Ostream & os ) const

virtual

Definition at line 142 of file atmBoundaryLayerInletVelocityFvPatchVectorField.C.

References os(), atmBoundaryLayer::write(), and fvPatchField::write().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/atmosphericModels/derivedFvPatchFields/atmBoundaryLayerInletVelocity/atmBoundaryLayerInletVelocityFvPatchVectorField.H
src/atmosphericModels/derivedFvPatchFields/atmBoundaryLayerInletVelocity/atmBoundaryLayerInletVelocityFvPatchVectorField.C
