atmBoundaryLayerInletEpsilonFvPatchScalarField Class Reference
Turbulence models » RAS turbulence » Boundary conditionsBoundary conditions » | Inlet

This boundary condition provides a log-law type ground-normal inlet boundary condition for the turbulent kinetic energy dissipation rate (i.e. epsilon) for homogeneous, two-dimensional, dry-air, equilibrium and neutral atmospheric boundary layer modelling. More...

Inheritance diagram for atmBoundaryLayerInletEpsilonFvPatchScalarField:
Inheritance graph
[legend]
Collaboration diagram for atmBoundaryLayerInletEpsilonFvPatchScalarField:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("atmBoundaryLayerInletEpsilon")

 atmBoundaryLayerInletEpsilonFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)

 atmBoundaryLayerInletEpsilonFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)

 atmBoundaryLayerInletEpsilonFvPatchScalarField (const atmBoundaryLayerInletEpsilonFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)

virtual tmp< fvPatchScalarField > clone () const

 atmBoundaryLayerInletEpsilonFvPatchScalarField (const atmBoundaryLayerInletEpsilonFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)

virtual tmp< fvPatchScalarField > clone (const DimensionedField< scalar, volMesh > &iF) const

virtual void updateCoeffs ()

virtual void autoMap (const fvPatchFieldMapper &)

virtual void rmap (const fvPatchScalarField &, const labelList &)

virtual void write (Ostream &) const

- Public Member Functions inherited from atmBoundaryLayer
 atmBoundaryLayer (const Time &time, const polyPatch &pp)

 atmBoundaryLayer (const Time &time, const polyPatch &pp, const dictionary &dict)

 atmBoundaryLayer (const atmBoundaryLayer &abl, const fvPatch &patch, const fvPatchFieldMapper &mapper)

 atmBoundaryLayer (const atmBoundaryLayer &)

vector flowDir () const

vector zDir () const

tmp< scalarField > Ustar (const scalarField &z0) const

void autoMap (const fvPatchFieldMapper &)

void rmap (const atmBoundaryLayer &, const labelList &)

tmp< vectorField > U (const vectorField &pCf) const

tmp< scalarField > k (const vectorField &pCf) const

tmp< scalarField > epsilon (const vectorField &pCf) const

tmp< scalarField > omega (const vectorField &pCf) const

void write (Ostream &) const


Additional Inherited Members

- Protected Attributes inherited from atmBoundaryLayer
bool initABL_


Detailed Description

This boundary condition provides a log-law type ground-normal inlet boundary condition for the turbulent kinetic energy dissipation rate (i.e. epsilon) for homogeneous, two-dimensional, dry-air, equilibrium and neutral atmospheric boundary layer modelling.

The ground-normal epsilon profile expression:

\[ \epsilon = \frac{(u^*)^3}{\kappa (z - d + z_0)} \sqrt{C_1 \ln \left( \frac{z - d + z_0}{z_0} \right) + C_2} \]

where

$ \epsilon $ = Ground-normal TKE dissipation rate profile [m^2/s^3]
$ u^* $ = Friction velocity [m/s]
$ \kappa $ = von Kármán constant [-]
$ z $ = Ground-normal coordinate component [m]
$ z_0 $ = Aerodynamic roughness length [m]
$ d $ = Ground-normal displacement height [m]
$ C_1 $ = Curve-fitting coefficient for YGCJ profiles [-]
$ C_2 $ = Curve-fitting coefficient for YGCJ profiles [-]

Required fields:

        epsilon   | Turbulent kinetic energy dissipation rate   [m2/s3]
Usage
Example of the boundary condition specification:
inlet
{
    // Mandatory entries (unmodifiable)
    type            atmBoundaryLayerInletEpsilon;

    // Mandatory/Optional (inherited) entries (unmodifiable)
    ...
}

where the entries mean:

Property Description Type Reqd Deflt
type Type name: atmBoundaryLayerInletEpsilon word yes -

The inherited entries are elaborated in:

See also
Source files

Definition at line 152 of file atmBoundaryLayerInletEpsilonFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ atmBoundaryLayerInletEpsilonFvPatchScalarField() [1/4]

atmBoundaryLayerInletEpsilonFvPatchScalarField ( const fvPatch &  p,
const DimensionedField< scalar, volMesh > &  iF
)

Definition at line 38 of file atmBoundaryLayerInletEpsilonFvPatchScalarField.C.

Referenced by atmBoundaryLayerInletEpsilonFvPatchScalarField::clone().

Here is the caller graph for this function:

◆ atmBoundaryLayerInletEpsilonFvPatchScalarField() [2/4]

atmBoundaryLayerInletEpsilonFvPatchScalarField ( const fvPatch &  p,
const DimensionedField< scalar, volMesh > &  iF,
const dictionary &  dict
)

Definition at line 50 of file atmBoundaryLayerInletEpsilonFvPatchScalarField.C.

References dict, epsilon, dictionary::getOrDefault(), Field::operator=(), p, and Foam::foamVersion::patch.

Here is the call graph for this function:

◆ atmBoundaryLayerInletEpsilonFvPatchScalarField() [3/4]

atmBoundaryLayerInletEpsilonFvPatchScalarField ( const atmBoundaryLayerInletEpsilonFvPatchScalarField &  psf,
const fvPatch &  p,
const DimensionedField< scalar, volMesh > &  iF,
const fvPatchFieldMapper &  mapper
)

Definition at line 79 of file atmBoundaryLayerInletEpsilonFvPatchScalarField.C.

◆ atmBoundaryLayerInletEpsilonFvPatchScalarField() [4/4]

atmBoundaryLayerInletEpsilonFvPatchScalarField ( const atmBoundaryLayerInletEpsilonFvPatchScalarField &  psf,
const DimensionedField< scalar, volMesh > &  iF
)

Definition at line 93 of file atmBoundaryLayerInletEpsilonFvPatchScalarField.C.

Member Function Documentation

◆ TypeName()

TypeName ( "atmBoundaryLayerInletEpsilon"  )

◆ clone() [1/2]

virtual tmp<fvPatchScalarField> clone ( ) const
inlinevirtual

Definition at line 192 of file atmBoundaryLayerInletEpsilonFvPatchScalarField.H.

References atmBoundaryLayerInletEpsilonFvPatchScalarField::atmBoundaryLayerInletEpsilonFvPatchScalarField().

Here is the call graph for this function:

◆ clone() [2/2]

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > &  iF) const
inlinevirtual

Definition at line 209 of file atmBoundaryLayerInletEpsilonFvPatchScalarField.H.

References atmBoundaryLayerInletEpsilonFvPatchScalarField::atmBoundaryLayerInletEpsilonFvPatchScalarField().

Here is the call graph for this function:

◆ updateCoeffs()

void updateCoeffs ( )
virtual

Definition at line 105 of file atmBoundaryLayerInletEpsilonFvPatchScalarField.C.

References atmBoundaryLayer::epsilon(), and Foam::foamVersion::patch.

Here is the call graph for this function:

◆ autoMap()

void autoMap ( const fvPatchFieldMapper &  m)
virtual

Definition at line 119 of file atmBoundaryLayerInletEpsilonFvPatchScalarField.C.

References atmBoundaryLayer::autoMap().

Here is the call graph for this function:

◆ rmap()

void rmap ( const fvPatchScalarField &  psf,
const labelList &  addr
)
virtual

Definition at line 129 of file atmBoundaryLayerInletEpsilonFvPatchScalarField.C.

References atmBoundaryLayer::rmap().

Here is the call graph for this function:

◆ write()

void write ( Ostream &  os) const
virtual

Definition at line 143 of file atmBoundaryLayerInletEpsilonFvPatchScalarField.C.

References os(), atmBoundaryLayer::write(), and fvPatchField::write().

Here is the call graph for this function:
The documentation for this class was generated from the following files:
