ZoneMesh Class Reference

A list of mesh zones. More...

Inheritance diagram for ZoneMesh:

Public Member Functions
	ZoneMesh (const IOobject &io, const MeshType &mesh)
	ZoneMesh (const IOobject &io, const MeshType &mesh, const label size)
	ZoneMesh (const IOobject &io, const MeshType &mesh, const PtrList< ZoneType > &pzm)
	~ZoneMesh ()
const MeshType &	mesh () const noexcept
const Map< label > &	zoneMap () const
label	whichZone (const label objectIndex) const
wordList	types () const
wordList	names () const
wordList	names (const wordRe &matcher) const
wordList	names (const wordRes &matcher) const
wordList	sortedNames () const
wordList	sortedNames (const wordRe &matcher) const
wordList	sortedNames (const wordRes &matcher) const
labelList	indices (const wordRe &matcher, const bool useGroups=true) const
labelList	indices (const wordRes &matcher, const bool useGroups=true) const
label	findIndex (const wordRe &key) const
label	findIndex (const wordRes &matcher) const
label	findZoneID (const word &zoneName) const
const ZoneType *	cfindZone (const word &zoneName) const
ZoneType *	findZone (const word &zoneName)
bitSet	selection (const labelUList &zoneIds) const
bitSet	selection (const wordRe &matcher, const bool useGroups=true) const
bitSet	selection (const wordRes &matcher, const bool useGroups=true) const
const HashTable< labelList > &	groupZoneIDs () const
void	setGroup (const word &groupName, const labelUList &zoneIDs)
bool	checkDefinition (const bool report=false) const
bool	checkParallelSync (const bool report=false) const
void	movePoints (const pointField &pts)
void	clearAddressing ()
void	clear ()
bool	hasFaceAreas () const
const ZoneType &	operator[] (const word &zoneName) const
ZoneType &	operator[] (const word &zoneName)
ZoneType &	operator() (const word &zoneName, const bool verbose=false)
void	updateMetaData ()
bool	writeData (Ostream &os) const
labelList	findIndices (const wordRes &key) const

Static Public Attributes
static int	disallowGenericZones

Friends
Ostream &	operator (Ostream &os, const ZoneMesh< ZoneType, MeshType > &zones)

Detailed Description

A list of mesh zones.

Source files

• ZoneMesh.H
• ZoneMesh.C

Definition at line 38 of file cellZoneMeshFwd.H.

Constructor & Destructor Documentation

ZoneMesh() [1/3]

ZoneMesh	(	const IOobject &	io,
		const MeshType &	mesh
	)

Definition at line 200 of file ZoneMesh.C.

ZoneMesh() [2/3]

ZoneMesh	(	const IOobject &	io,
		const MeshType &	mesh,
		const label	size
	)

Definition at line 215 of file ZoneMesh.C.

ZoneMesh() [3/3]

ZoneMesh	(	const IOobject &	io,
		const MeshType &	mesh,
		const PtrList< ZoneType > &	pzm
	)

Definition at line 232 of file ZoneMesh.C.

~ZoneMesh()

~ZoneMesh

(

)

Definition at line 259 of file ZoneMesh.C.

Member Function Documentation

mesh()

const MeshType& mesh ( ) const

inlinenoexcept

Definition at line 138 of file ZoneMesh.H.

zoneMap()

const Foam::Map< Foam::label > & zoneMap

(

)

const

Definition at line 269 of file ZoneMesh.C.

whichZone()

Foam::label whichZone

(

const label

objectIndex

)

const

Definition at line 282 of file ZoneMesh.C.

Referenced by cyclicAMIPolyPatch::addAMIFaces(), meshRefinement::mergeBaffles(), polyMeshAdder::mergePoints(), removeCells::setRefinement(), perfectInterface::setRefinement(), and edgeCollapser::setRefinement().

Here is the caller graph for this function:

types()

Foam::wordList types

(

)

const

Definition at line 291 of file ZoneMesh.C.

names() [1/3]

Foam::wordList names

(

)

const

Definition at line 298 of file ZoneMesh.C.

Referenced by preserveFaceZones::add(), surfaceZonesInfo::addCellZonesToMesh(), surfaceZonesInfo::addFaceZonesToMesh(), preserveFaceZones::apply(), meshRefinement::checkCoupledFaceZones(), extractEulerianParticles::checkFaceZone(), dynamicMultiMotionSolverFvMesh::init(), fvMeshTools::newMesh(), cellTable::operator=(), multiphaseMangrovesTurbulenceModel::read(), sizeDistribution::setCellZoneCells(), and displacementLayeredMotionMotionSolver::solve().

Here is the caller graph for this function:

names() [2/3]

Foam::wordList names

(

const wordRe &

matcher

)

const

Definition at line 306 of file ZoneMesh.C.

names() [3/3]

Foam::wordList names

(

const wordRes &

matcher

)

const

Definition at line 316 of file ZoneMesh.C.

sortedNames() [1/3]

Foam::wordList sortedNames

(

)

const

Definition at line 326 of file ZoneMesh.C.

sortedNames() [2/3]

Foam::wordList sortedNames

(

const wordRe &

matcher

)

const

Definition at line 337 of file ZoneMesh.C.

sortedNames() [3/3]

Foam::wordList sortedNames

(

const wordRes &

matcher

)

const

Definition at line 350 of file ZoneMesh.C.

indices() [1/2]

labelList indices	(	const wordRe &	matcher,
		const bool	useGroups = true
	)		const

Referenced by ZoneMesh< cellZone, polyMesh >::findIndices(), multiphaseMangrovesTurbulenceModel::read(), and sampledFaceZone::zoneIDs().

Here is the caller graph for this function:

indices() [2/2]

labelList indices	(	const wordRes &	matcher,
		const bool	useGroups = true
	)		const

findIndex() [1/2]

Foam::label findIndex

(

const wordRe &

key

)

const

Definition at line 484 of file ZoneMesh.C.

Referenced by sampledCuttingPlane::sampledCuttingPlane(), sampledInterface::sampledInterface(), sampledIsoSurface::sampledIsoSurface(), and sampledPlane::sampledPlane().

Here is the caller graph for this function:

findIndex() [2/2]

Foam::label findIndex

(

const wordRes &

matcher

)

const

Definition at line 498 of file ZoneMesh.C.

findZoneID()

Foam::label findZoneID

(

const word &

zoneName

)

const

Definition at line 512 of file ZoneMesh.C.

Referenced by surfaceZonesInfo::addCellZone(), surfaceZonesInfo::addFaceZone(), cellZoneSet::cellZoneSet(), extractEulerianParticles::checkFaceZone(), FaceInteraction< CloudType >::FaceInteraction(), FacePostProcessing< CloudType >::FacePostProcessing(), faceZoneSet::faceZoneSet(), dynamicMultiMotionSolverFvMesh::init(), pointZoneSet::pointZoneSet(), powerLawLopesdaCostaZone::powerLawLopesdaCostaZone(), RemoveParcels< CloudType >::RemoveParcels(), sizeDistribution::setCellZoneCells(), displacementLayeredMotionMotionSolver::solve(), cellZoneSet::writeObject(), pointZoneSet::writeObject(), faceZoneSet::writeObject(), zeroATCcells::zeroATCcells(), and meshRefinement::zonify().

Here is the caller graph for this function:

cfindZone()

const ZoneType * cfindZone

(

const word &

zoneName

)

const

Definition at line 546 of file ZoneMesh.C.

findZone()

ZoneType * findZone

(

const word &

zoneName

)

Definition at line 582 of file ZoneMesh.C.

selection() [1/3]

Foam::bitSet selection

(

const labelUList &

zoneIds

)

const

Definition at line 592 of file ZoneMesh.C.

selection() [2/3]

bitSet selection	(	const wordRe &	matcher,
		const bool	useGroups = true
	)		const

selection() [3/3]

bitSet selection	(	const wordRes &	matcher,
		const bool	useGroups = true
	)		const

groupZoneIDs()

const Foam::HashTable< Foam::labelList > & groupZoneIDs

(

)

const

Definition at line 646 of file ZoneMesh.C.

setGroup()

void setGroup	(	const word &	groupName,
		const labelUList &	zoneIDs
	)

Definition at line 659 of file ZoneMesh.C.

checkDefinition()

bool checkDefinition

(

const bool

report = false

)

const

Definition at line 726 of file ZoneMesh.C.

checkParallelSync()

bool checkParallelSync

(

const bool

report = false

)

const

Definition at line 745 of file ZoneMesh.C.

movePoints()

void movePoints

(

const pointField &

pts

)

Definition at line 821 of file ZoneMesh.C.

clearAddressing()

void clearAddressing

(

)

Definition at line 702 of file ZoneMesh.C.

Referenced by interRegionExplicitPorositySource::initialise(), polyMesh::updateMesh(), cellZoneSet::writeObject(), pointZoneSet::writeObject(), and faceZoneSet::writeObject().

Here is the caller graph for this function:

clear()

void clear

(

)

Definition at line 717 of file ZoneMesh.C.

Referenced by polyMeshAdder::add(), cellTable::addCellZones(), blockMesh::mesh(), and fvMeshTools::newMesh().

Here is the caller graph for this function:

hasFaceAreas()

bool hasFaceAreas ( ) const

inline

Definition at line 266 of file ZoneMesh.H.

operator[]() [1/2]

const ZoneType & operator[]

(

const word &

zoneName

)

const

Definition at line 860 of file ZoneMesh.C.

operator[]() [2/2]

ZoneType & operator[]

(

const word &

zoneName

)

Definition at line 880 of file ZoneMesh.C.

operator()()

ZoneType & operator()	(	const word &	zoneName,
		const bool	verbose = false
	)

Definition at line 900 of file ZoneMesh.C.

updateMetaData()

void updateMetaData

(

)

Definition at line 833 of file ZoneMesh.C.

writeData()

bool writeData

(

Ostream &

os

)

const

Definition at line 849 of file ZoneMesh.C.

findIndices()

labelList findIndices ( const wordRes &  key ) const

inline

Definition at line 324 of file ZoneMesh.H.

Friends And Related Function Documentation

operator

Ostream& operator ( Ostream &  os, const ZoneMesh< ZoneType, MeshType > &  zones  )

friend

Member Data Documentation

disallowGenericZones

int disallowGenericZones

static

Definition at line 102 of file ZoneMesh.H.

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/meshes/polyMesh/zones/ZoneMesh/cellZoneMeshFwd.H
• src/OpenFOAM/meshes/polyMesh/zones/ZoneMesh/ZoneMesh.H
• src/OpenFOAM/meshes/polyMesh/zones/ZoneMesh/ZoneMesh.C
