Templated 3D Vector derived from VectorSpace adding construction from 3 components, element access using x(), y() and z() member functions and the inner-product (dot-product) and cross product operators. More...

Inheritance diagram for Vector< Cmpt >:

[legend]

Collaboration diagram for Vector< Cmpt >:

[legend]

Public Types
enum	components { X, Y, Z }

typedef Vector< label >	labelType

Public Types inherited from VectorSpace< Vector< Cmpt >, Cmpt, 3 >
typedef VectorSpace< Form, Cmpt, Ncmpts >	vsType

typedef Cmpt	cmptType

typedef Cmpt	magType

typedef Cmpt *	iterator

Public Member Functions
	Vector ()=default

	Vector (const Vector &)=default

Vector &	operator= (const Vector &)=default

	Vector (const Foam::zero)

template<class Cmpt2 >
	Vector (const VectorSpace< Vector< Cmpt2 >, Cmpt2, 3 > &vs)

	Vector (const Cmpt &vx, const Cmpt &vy, const Cmpt &vz)

	Vector (Istream &is)

const Cmpt &	x () const

const Cmpt &	y () const

const Cmpt &	z () const

Cmpt &	x ()

Cmpt &	y ()

Cmpt &	z ()

Vector< Cmpt > &	normalise ()

const Vector< Cmpt > &	centre (const Foam::List< Vector< Cmpt >> &) const

Public Member Functions inherited from VectorSpace< Vector< Cmpt >, Cmpt, 3 >
	VectorSpace ()=default

	VectorSpace (const Foam::zero)

	VectorSpace (const VectorSpace< Form, Cmpt, Ncmpts > &vs)

	VectorSpace (const VectorSpace< Form2, Cmpt2, Ncmpts > &)

	VectorSpace (Istream &is)

const Cmpt &	component (const direction) const

Cmpt &	component (const direction)

void	component (Cmpt &, const direction) const

void	replace (const direction, const Cmpt &)

const Cmpt *	cdata () const noexcept

Cmpt *	data () noexcept

const ConstBlock< SubVector, BStart >	block () const

const Foam::VectorSpace< Form, Cmpt, Ncmpts >::template ConstBlock< SubVector, BStart >	block () const

const Cmpt &	operator[] (const direction) const

Cmpt &	operator[] (const direction)

void	operator= (const VectorSpace< Form, Cmpt, Ncmpts > &)

void	operator= (const Foam::zero)

void	operator+= (const VectorSpace< Form, Cmpt, Ncmpts > &)

void	operator-= (const VectorSpace< Form, Cmpt, Ncmpts > &)

void	operator*= (const scalar)

void	operator/= (const scalar)

iterator	begin () noexcept

const_iterator	begin () const noexcept

iterator	end () noexcept

const_iterator	end () const noexcept

const_iterator	cbegin () const noexcept

const_iterator	cend () const noexcept

Static Public Attributes
static constexpr direction	rank = 1

Static Public Attributes inherited from VectorSpace< Vector< Cmpt >, Cmpt, 3 >
static constexpr direction	dim

static constexpr direction	nComponents

static constexpr direction	mRows

static constexpr direction	nCols

static const char *const	typeName

static const char *const	componentNames []

static const Form	zero

static const Form	one

static const Form	max

static const Form	min

static const Form	rootMax

static const Form	rootMin

Additional Inherited Members
Static Public Member Functions inherited from VectorSpace< Vector< Cmpt >, Cmpt, 3 >
static constexpr direction	size () noexcept

static Form	uniform (const Cmpt &s)

Public Attributes inherited from VectorSpace< Vector< Cmpt >, Cmpt, 3 >
const typedef Cmpt *	const_iterator

Cmpt	v_ [Ncmpts]

Detailed Description

template<class Cmpt>
class Foam::Vector< Cmpt >

Templated 3D Vector derived from VectorSpace adding construction from 3 components, element access using x(), y() and z() member functions and the inner-product (dot-product) and cross product operators.

A centre() member function which returns the Vector for which it is called is defined so that point which is a typedef to Vector<scalar> behaves as other shapes in the shape hierarchy.

Source files

Definition at line 58 of file Vector.H.

Member Typedef Documentation

◆ labelType

typedef Vector<label> labelType

Definition at line 67 of file Vector.H.

Member Enumeration Documentation

◆ components

enum components

Enumerator
X
Y
Z

Definition at line 77 of file Vector.H.

Constructor & Destructor Documentation

◆ Vector() [1/6]

Vector ( )

default

◆ Vector() [2/6]

Vector ( const Vector< Cmpt > & )

default

◆ Vector() [3/6]

Vector ( const Foam::zero )

inline

Definition at line 25 of file VectorI.H.

◆ Vector() [4/6]

Vector ( const VectorSpace< Vector< Cmpt2 >, Cmpt2, 3 > & vs )

inline

Definition at line 34 of file VectorI.H.

◆ Vector() [5/6]

Vector	(	const Cmpt &	vx,
		const Cmpt &	vy,
		const Cmpt &	vz
	)

inline

Definition at line 44 of file VectorI.H.

◆ Vector() [6/6]

Vector ( Istream & is )

inlineexplicit

Definition at line 57 of file VectorI.H.

Member Function Documentation

◆ operator=()

Vector& operator= ( const Vector< Cmpt > & )

default

Referenced by triad::operator=().

Here is the caller graph for this function:

◆ x() [1/2]

Cmpt & x

inline

Definition at line 66 of file VectorI.H.

Referenced by biLinearFitPolynomial::addCoeffs(), cubicUpwindFitPolynomial::addCoeffs(), linearFitPolynomial::addCoeffs(), quadraticFitPolynomial::addCoeffs(), quadraticLinearUpwindFitPolynomial::addCoeffs(), quadraticUpwindFitPolynomial::addCoeffs(), quadraticLinearFitPolynomial::addCoeffs(), triad::align(), BarycentricTensor< Cmpt >::BarycentricTensor(), blockDescriptor::blockDescriptor(), PDRblock::blockMeshDict(), NURBS3DVolume::bound(), PDRblock::C(), energySpectrum::calcAndWriteSpectrum(), CentredFitSnGradData< Polynomial >::calcFit(), FitData< CentredFitSnGradData< Polynomial >, extendedCentredCellToFaceStencil, Polynomial >::calcFit(), wedgePolyPatch::calcGeometry(), rotorDiskSource::calculate(), ijkAddressing::checkIndex(), Tensor< scalar >::col(), Tensor< scalar >::cols(), axisAligned::computeControlPoints(), transformBox::computeControlPoints(), boundBox::contains(), boundBox::containsInside(), NURBS3DVolume::coordinates(), cyclicPolyPatch::coupledEdges(), cyclicPolyPatch::coupledPoints(), SymmTensor< scalar >::diag(), Tensor< scalar >::diag(), treeBoundBox::distanceCmp(), PDRblock::dx(), adjointRotatingWallVelocityFvPatchVectorField::dxdbMult(), Foam::eigenVector(), Foam::eigenVectors(), pitchForkRing::energy(), treeBoundBox::faceBits(), boundBox::faceCentre(), Foam::faceNij(), Foam::facePoint(), Foam::facePointN(), dynamicTreeDataPoint::findNearest(), NURBS3DVolume::findPointsInBox(), pitchForkRing::force(), rigidBodyModel::forwardDynamics(), Foam::fromCartesian(), FIRECore::getFirePoint(), boundaryMesh::getNearest(), ellipsoidImplicitFunction::grad(), PDRblock::grid(), ijkAddressing::index(), voxelMeshSearch::index(), voxelMeshSearch::index3(), waveModel::initialiseGeometry(), waveMakerPointPatchVectorField::initialiseGeometry(), cellShapeControlMesh::insert(), cellShapeControlMesh::insertFar(), treeBoundBox::intersects(), Foam::inv(), NURBS3DVolume::JacobianUVW(), Rzyx::jcalc(), Rxyz::jcalc(), Ryxz::jcalc(), cellMDLimitedGrad< Type >::limitFace(), momentOfInertia::massPropertiesSolid(), boundBox::nearest(), twoDPointCorrector::normalDir(), NURBS3DCurve::nrm2D(), voxelMeshSearch::offset(), Foam::operator&(), treeDataPoint::findNearestOp::operator()(), treeDataEdge::findNearestOp::operator()(), Foam::operator*(), Foam::operator/(), Foam::operator^(), boundBox::overlaps(), plane::planeIntersect(), ijkMesh::pointLabel(), polyTopoChange::pointRemoved(), tetrahedron::pointToBarycentric(), treeBoundBox::posBits(), triad::primaryDirection(), projectFace::project(), FIRECore::putFirePoint(), quaternion::quaternion(), Foam::Ra(), AC3DsurfaceFormat< Face >::read(), energySpectrum::read(), IjkField< Foam::Vector< bool > >::resize(), linearSpringDamper::restrain(), Tensor< scalar >::row(), Tensor< scalar >::rows(), treeBoundBox::searchOrder(), NURBS3DCurve::setNrm2DOrientation(), ReactingLookupTableInjection< CloudType >::setPositionAndCell(), ThermoLookupTableInjection< CloudType >::setPositionAndCell(), ReactingMultiphaseLookupTableInjection< CloudType >::setPositionAndCell(), KinematicLookupTableInjection< CloudType >::setPositionAndCell(), snappyVoxelMeshDriver::snappyVoxelMeshDriver(), SpatialVector< scalar >::SpatialVector(), Foam::sqr(), leastSquares::stencilWeights(), treeBoundBox::subBbox(), treeBoundBox::subOctant(), Foam::toCartesian(), NURBS3DVolumeCylindrical::transformationTensorDxDb(), controlPointsDefinition::transformControlPoints(), NURBS3DVolumeCylindrical::transformPointToCartesian(), Foam::transformPrincipal_vector(), pointConstraint::unconstrainedDirections(), joint::unitQuaternion(), objectiveForce::update_dxdbMultiplier(), NURBS3DVolumeCylindrical::updateLocalCoordinateSystem(), PDRblock::V(), paraboloidImplicitFunction::value(), ellipsoidImplicitFunction::value(), ijkMesh::vertLabels(), NURBS3DVolume::volumeDerivativeCP(), wallLayerCells::wallLayerCells(), SMESHsurfaceFormat< Face >::write(), nastranSetWriter< Type >::write(), STLtriangle::write(), OBJstream::write(), sixDoFRigidBodyState::write(), meshToMeshMethod::writeConnectivity(), Foam::meshTools::writeOBJ(), coupledPolyPatch::writeOBJ(), triSurfaceTools::writeOBJ(), cellCuts::writeOBJ(), Foam::writeObjPoints(), Cloud< passivePositionParticle >::writePositions(), moleculeCloud::writeXYZ(), PDRobstacle::x(), Foam::Xinterpolate(), and Foam::XstepForwardsToNextPoint().

◆ y() [1/2]

Cmpt & y

inline

Definition at line 72 of file VectorI.H.

Referenced by biLinearFitPolynomial::addCoeffs(), cubicUpwindFitPolynomial::addCoeffs(), linearFitPolynomial::addCoeffs(), quadraticFitPolynomial::addCoeffs(), quadraticLinearUpwindFitPolynomial::addCoeffs(), quadraticUpwindFitPolynomial::addCoeffs(), quadraticLinearFitPolynomial::addCoeffs(), triad::align(), BarycentricTensor< Cmpt >::BarycentricTensor(), blockDescriptor::blockDescriptor(), PDRblock::blockMeshDict(), NURBS3DVolume::bound(), PDRblock::C(), energySpectrum::calcAndWriteSpectrum(), CentredFitSnGradData< Polynomial >::calcFit(), FitData< CentredFitSnGradData< Polynomial >, extendedCentredCellToFaceStencil, Polynomial >::calcFit(), wedgePolyPatch::calcGeometry(), rotorDiskSource::calculate(), ijkAddressing::checkIndex(), Tensor< scalar >::col(), Tensor< scalar >::cols(), axisAligned::computeControlPoints(), transformBox::computeControlPoints(), boundBox::contains(), boundBox::containsInside(), NURBS3DVolume::coordinates(), cyclicPolyPatch::coupledEdges(), cyclicPolyPatch::coupledPoints(), SymmTensor< scalar >::diag(), Tensor< scalar >::diag(), treeBoundBox::distanceCmp(), adjointRotatingWallVelocityFvPatchVectorField::dxdbMult(), PDRblock::dy(), Foam::eigenVector(), Foam::eigenVectors(), pitchForkRing::energy(), treeBoundBox::faceBits(), boundBox::faceCentre(), Foam::faceNij(), Foam::facePoint(), Foam::facePointN(), dynamicTreeDataPoint::findNearest(), NURBS3DVolume::findPointsInBox(), pitchForkRing::force(), rigidBodyModel::forwardDynamics(), Foam::fromCartesian(), FIRECore::getFirePoint(), boundaryMesh::getNearest(), ellipsoidImplicitFunction::grad(), PDRblock::grid(), ijkAddressing::index(), voxelMeshSearch::index(), voxelMeshSearch::index3(), waveModel::initialiseGeometry(), waveMakerPointPatchVectorField::initialiseGeometry(), cellShapeControlMesh::insert(), cellShapeControlMesh::insertFar(), treeBoundBox::intersects(), Foam::inv(), NURBS3DVolume::JacobianUVW(), Rzyx::jcalc(), Rxyz::jcalc(), Ryxz::jcalc(), cellMDLimitedGrad< Type >::limitFace(), momentOfInertia::massPropertiesSolid(), boundBox::nearest(), twoDPointCorrector::normalDir(), NURBS3DCurve::nrm2D(), voxelMeshSearch::offset(), Foam::operator&(), treeDataPoint::findNearestOp::operator()(), treeDataEdge::findNearestOp::operator()(), Foam::operator*(), Foam::operator/(), Foam::operator^(), boundBox::overlaps(), plane::planeIntersect(), ijkMesh::pointLabel(), polyTopoChange::pointRemoved(), tetrahedron::pointToBarycentric(), treeBoundBox::posBits(), triad::primaryDirection(), projectFace::project(), FIRECore::putFirePoint(), quaternion::quaternion(), Foam::Ra(), AC3DsurfaceFormat< Face >::read(), energySpectrum::read(), IjkField< Foam::Vector< bool > >::resize(), linearSpringDamper::restrain(), Tensor< scalar >::row(), Tensor< scalar >::rows(), treeBoundBox::searchOrder(), NURBS3DCurve::setNrm2DOrientation(), snappyVoxelMeshDriver::snappyVoxelMeshDriver(), SpatialVector< scalar >::SpatialVector(), Foam::sqr(), leastSquares::stencilWeights(), treeBoundBox::subBbox(), treeBoundBox::subOctant(), Foam::toCartesian(), NURBS3DVolumeCylindrical::transformationTensorDxDb(), controlPointsDefinition::transformControlPoints(), NURBS3DVolumeCylindrical::transformPointToCartesian(), Foam::transformPrincipal_vector(), pointConstraint::unconstrainedDirections(), joint::unitQuaternion(), objectiveForce::update_dxdbMultiplier(), NURBS3DVolumeCylindrical::updateLocalCoordinateSystem(), PDRblock::V(), paraboloidImplicitFunction::value(), ellipsoidImplicitFunction::value(), ijkMesh::vertLabels(), NURBS3DVolume::volumeDerivativeCP(), wallLayerCells::wallLayerCells(), SMESHsurfaceFormat< Face >::write(), nastranSetWriter< Type >::write(), STLtriangle::write(), OBJstream::write(), sixDoFRigidBodyState::write(), meshToMeshMethod::writeConnectivity(), Foam::meshTools::writeOBJ(), coupledPolyPatch::writeOBJ(), triSurfaceTools::writeOBJ(), cellCuts::writeOBJ(), Foam::writeObjPoints(), Cloud< passivePositionParticle >::writePositions(), moleculeCloud::writeXYZ(), and PDRobstacle::y().

◆ z() [1/2]

Cmpt & z

inline

Definition at line 78 of file VectorI.H.

Referenced by biLinearFitPolynomial::addCoeffs(), cubicUpwindFitPolynomial::addCoeffs(), linearFitPolynomial::addCoeffs(), quadraticFitPolynomial::addCoeffs(), quadraticLinearUpwindFitPolynomial::addCoeffs(), quadraticUpwindFitPolynomial::addCoeffs(), quadraticLinearFitPolynomial::addCoeffs(), triad::align(), BarycentricTensor< Cmpt >::BarycentricTensor(), blockDescriptor::blockDescriptor(), PDRblock::blockMeshDict(), NURBS3DVolume::bound(), PDRblock::C(), energySpectrum::calcAndWriteSpectrum(), CentredFitSnGradData< Polynomial >::calcFit(), FitData< CentredFitSnGradData< Polynomial >, extendedCentredCellToFaceStencil, Polynomial >::calcFit(), wedgePolyPatch::calcGeometry(), rotorDiskSource::calculate(), ijkAddressing::checkIndex(), Tensor< scalar >::col(), Tensor< scalar >::cols(), axisAligned::computeControlPoints(), transformBox::computeControlPoints(), boundBox::contains(), boundBox::containsInside(), NURBS3DVolume::coordinates(), cyclicPolyPatch::coupledEdges(), cyclicPolyPatch::coupledPoints(), SymmTensor< scalar >::diag(), Tensor< scalar >::diag(), treeBoundBox::distanceCmp(), adjointRotatingWallVelocityFvPatchVectorField::dxdbMult(), PDRblock::dz(), Foam::eigenVector(), Foam::eigenVectors(), pitchForkRing::energy(), treeBoundBox::faceBits(), boundBox::faceCentre(), Foam::faceNij(), Foam::facePoint(), Foam::facePointN(), dynamicTreeDataPoint::findNearest(), NURBS3DVolume::findPointsInBox(), pitchForkRing::force(), rigidBodyModel::forwardDynamics(), Foam::fromCartesian(), FIRECore::getFirePoint(), boundaryMesh::getNearest(), ellipsoidImplicitFunction::grad(), PDRblock::grid(), ijkAddressing::index(), voxelMeshSearch::index(), voxelMeshSearch::index3(), waveModel::initialiseGeometry(), waveMakerPointPatchVectorField::initialiseGeometry(), cellShapeControlMesh::insert(), cellShapeControlMesh::insertFar(), treeBoundBox::intersects(), Foam::inv(), NURBS3DVolume::JacobianUVW(), Rzyx::jcalc(), Ryxz::jcalc(), Rxyz::jcalc(), cellMDLimitedGrad< Type >::limitFace(), momentOfInertia::massPropertiesSolid(), boundBox::nearest(), twoDPointCorrector::normalDir(), NURBS3DCurve::nrm2D(), Foam::operator&(), treeDataPoint::findNearestOp::operator()(), treeDataEdge::findNearestOp::operator()(), Foam::operator*(), Foam::operator/(), Foam::operator^(), boundBox::overlaps(), plane::planeIntersect(), ijkMesh::pointLabel(), polyTopoChange::pointRemoved(), tetrahedron::pointToBarycentric(), treeBoundBox::posBits(), triad::primaryDirection(), projectFace::project(), FIRECore::putFirePoint(), quaternion::quaternion(), Foam::Ra(), AC3DsurfaceFormat< Face >::read(), energySpectrum::read(), IjkField< Foam::Vector< bool > >::resize(), linearSpringDamper::restrain(), Tensor< scalar >::row(), Tensor< scalar >::rows(), treeBoundBox::searchOrder(), NURBS3DCurve::setNrm2DOrientation(), snappyVoxelMeshDriver::snappyVoxelMeshDriver(), SpatialVector< scalar >::SpatialVector(), Foam::sqr(), leastSquares::stencilWeights(), treeBoundBox::subBbox(), treeBoundBox::subOctant(), Foam::toCartesian(), controlPointsDefinition::transformControlPoints(), NURBS3DVolumeCylindrical::transformPointToCartesian(), Foam::transformPrincipal_vector(), joint::unitQuaternion(), objectiveForce::update_dxdbMultiplier(), NURBS3DVolumeCylindrical::updateLocalCoordinateSystem(), PDRblock::V(), paraboloidImplicitFunction::value(), ellipsoidImplicitFunction::value(), ijkMesh::vertLabels(), NURBS3DVolume::volumeDerivativeCP(), wallLayerCells::wallLayerCells(), SMESHsurfaceFormat< Face >::write(), nastranSetWriter< Type >::write(), STLtriangle::write(), OBJstream::write(), sixDoFRigidBodyState::write(), meshToMeshMethod::writeConnectivity(), Foam::meshTools::writeOBJ(), coupledPolyPatch::writeOBJ(), triSurfaceTools::writeOBJ(), cellCuts::writeOBJ(), Foam::writeObjPoints(), Cloud< passivePositionParticle >::writePositions(), moleculeCloud::writeXYZ(), and PDRobstacle::z().

◆ x() [2/2]

Cmpt& x ( )

inline

◆ y() [2/2]

Cmpt& y ( )

inline

◆ z() [2/2]

Cmpt& z ( )

inline

◆ normalise()

Foam::Vector< Cmpt > & normalise

inline

Definition at line 116 of file VectorI.H.

Referenced by wedgePolyPatch::calcGeometry(), cutCell::calcIsoFacePointsFromEdges(), ConeInjection< CloudType >::ConeInjection(), rotorDiskSource::createCoordinateSystem(), Foam::meshTools::edgeToCutDir(), searchableExtrudedCircle::findParametricNearest(), NURBS3DCurve::nrm3D(), surfaceFieldValue::processValues(), setFlow::read(), forces::read(), propellerInfo::setCoordinateSystem(), ConeInjection< CloudType >::setProperties(), ConeNozzleInjection< CloudType >::setProperties(), searchableSphere::surfaceNormal(), wallBoundedParticle::trackFaceTri(), triSurfaceTools::vertexNormals(), and surfaceIteratorPLIC::vofCutCell().

Here is the caller graph for this function:

◆ centre()

const Foam::Vector< Cmpt > & centre ( const Foam::List< Vector< Cmpt >> & ) const

inline

Definition at line 107 of file VectorI.H.

Referenced by cellShape::centre(), cyclicPolyPatch::coupledEdges(), and extendedEdgeMesh::sortPointsAndEdges().

Here is the caller graph for this function:

Member Data Documentation

◆ rank

constexpr direction rank = 1

staticconstexpr

Definition at line 73 of file Vector.H.

The documentation for this class was generated from the following files:

src/OpenFOAM/primitives/Vector/Vector.H
src/OpenFOAM/primitives/Vector/VectorI.H
