UPstream Class Reference

Inter-processor communications stream. More...

Inheritance diagram for UPstream:

Collaboration diagram for UPstream:

Classes
class	commsStruct
class	communicator
struct	listEq

Public Types
enum	commsTypes : char { blocking, scheduled, nonBlocking }
typedef IntRange< int >	rangeType

Public Member Functions
	ClassName ("UPstream")
	UPstream (const commsTypes commsType)
commsTypes	commsType () const noexcept
commsTypes	commsType (const commsTypes ct) noexcept
template<class T >
Foam::List< T >	listGatherValues (const T &localValue, const label comm)

Static Public Member Functions
static label	allocateCommunicator (const label parent, const labelList &subRanks, const bool doPstream=true)
static void	freeCommunicator (const label communicator, const bool doPstream=true)
static void	freeCommunicators (const bool doPstream)
static int	baseProcNo (const label myComm, const int procID)
static label	procNo (const label comm, const int baseProcID)
static label	procNo (const label myComm, const label currentComm, const int currentProcID)
static void	addValidParOptions (HashTable< string > &validParOptions)
static bool	init (int &argc, char **&argv, const bool needsThread)
static bool	initNull ()
static label	nRequests ()
static void	resetRequests (const label sz)
static void	waitRequests (const label start=0)
static void	waitRequest (const label i)
static bool	finishedRequest (const label i)
static int	allocateTag (const char *)
static int	allocateTag (const word &)
static void	freeTag (const char *, const int tag)
static void	freeTag (const word &, const int tag)
static bool	parRun (const bool on) noexcept
static bool &	parRun () noexcept
static bool	haveThreads () noexcept
static label	nProcs (const label communicator=worldComm)
static constexpr int	masterNo () noexcept
static bool	master (const label communicator=worldComm)
static int	myProcNo (const label communicator=worldComm)
static label	parent (const label communicator)
static List< int > &	procID (label communicator)
static const wordList &	allWorlds () noexcept
static const labelList &	worldIDs () noexcept
static label	myWorldID ()
static const word &	myWorld ()
static rangeType	allProcs (const label communicator=worldComm)
static rangeType	subProcs (const label communicator=worldComm)
static const List< commsStruct > &	linearCommunication (const label communicator=worldComm)
static const List< commsStruct > &	treeCommunication (const label communicator=worldComm)
static int &	msgType () noexcept
static void	shutdown (int errNo=0)
static void	abort ()
static void	exit (int errNo=1)
static void	allToAll (const labelUList &sendData, labelUList &recvData, const label communicator=worldComm)
static void	allToAll (const char *sendData, const UList< int > &sendSizes, const UList< int > &sendOffsets, char *recvData, const UList< int > &recvSizes, const UList< int > &recvOffsets, const label communicator=worldComm)
static void	mpiGather (const char *sendData, int sendSize, char *recvData, int recvSize, const label communicator=worldComm)
static void	mpiScatter (const char *sendData, int sendSize, char *recvData, int recvSize, const label communicator=worldComm)
static void	gather (const char *sendData, int sendSize, char *recvData, const UList< int > &recvSizes, const UList< int > &recvOffsets, const label communicator=worldComm)
static void	scatter (const char *sendData, const UList< int > &sendSizes, const UList< int > &sendOffsets, char *recvData, int recvSize, const label communicator=worldComm)
template<class T >
static List< T >	listGatherValues (const T &localValue, const label communicator=worldComm)
template<class T >
static T	listScatterValues (const UList< T > &allValues, const label communicator=worldComm)
static constexpr int	firstSlave () noexcept
static int	lastSlave (const label communicator=worldComm)

Static Public Attributes
static const Enum< commsTypes >	commsTypeNames
static bool	floatTransfer
static int	nProcsSimpleSum
static commsTypes	defaultCommsType
static int	nPollProcInterfaces
static int	maxCommsSize
static const int	mpiBufferSize
static label	worldComm
static label	warnComm

Protected Attributes
commsTypes	commsType_

Detailed Description

Inter-processor communications stream.

Source files

• UPstream.H
• UPstream.C
• UPstreamCommsStruct.C
• UPstreamTemplates.C
• combineGatherScatter.C
• gatherScatter.C
• gatherScatterList.C

Definition at line 57 of file UPstream.H.

Member Typedef Documentation

rangeType

typedef IntRange<int> rangeType

Definition at line 62 of file UPstream.H.

Member Enumeration Documentation

commsTypes

enum commsTypes : char

strong

Enumerator
blocking
scheduled
nonBlocking

Definition at line 65 of file UPstream.H.

Constructor & Destructor Documentation

UPstream()

UPstream ( const commsTypes  commsType )

inlineexplicit

Definition at line 298 of file UPstream.H.

Member Function Documentation

ClassName()

ClassName

(

"UPstream"

)

allocateCommunicator()

Foam::label allocateCommunicator ( const label  parent, const labelList &  subRanks, const bool  doPstream = true  )

static

Definition at line 101 of file UPstream.C.

References Foam::abort(), Foam::expressions::patchExpr::debug, Foam::endl(), Foam::FatalError, FatalErrorInFunction, forAll, and Foam::Pout.

Referenced by masterCoarsestGAMGProcAgglomeration::agglomerate(), eagerGAMGProcAgglomeration::agglomerate(), procFacesGAMGProcAgglomeration::agglomerate(), manualGAMGProcAgglomeration::agglomerate(), and globalMeshData::updateMesh().

Here is the call graph for this function:

Here is the caller graph for this function:

freeCommunicator()

void freeCommunicator ( const label  communicator, const bool  doPstream = true  )

static

Definition at line 167 of file UPstream.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), and Foam::Pout.

Referenced by globalMeshData::updateMesh(), collatedFileOperation::~collatedFileOperation(), UPstream::communicator::~communicator(), eagerGAMGProcAgglomeration::~eagerGAMGProcAgglomeration(), hostCollatedFileOperation::~hostCollatedFileOperation(), manualGAMGProcAgglomeration::~manualGAMGProcAgglomeration(), masterCoarsestGAMGProcAgglomeration::~masterCoarsestGAMGProcAgglomeration(), masterUncollatedFileOperation::~masterUncollatedFileOperation(), OFstreamCollator::~OFstreamCollator(), and procFacesGAMGProcAgglomeration::~procFacesGAMGProcAgglomeration().

Here is the call graph for this function:

Here is the caller graph for this function:

freeCommunicators()

void freeCommunicators ( const bool  doPstream )

static

Definition at line 194 of file UPstream.C.

References forAll.

baseProcNo()

int baseProcNo ( const label  myComm, const int  procID  )

static

Definition at line 206 of file UPstream.C.

References UPstream::parent(), and UPstream::procID().

Referenced by UPstream::procNo().

Here is the call graph for this function:

Here is the caller graph for this function:

procNo() [1/2]

Foam::label procNo ( const label  comm, const int  baseProcID  )

static

Definition at line 222 of file UPstream.C.

procNo() [2/2]

Foam::label procNo ( const label  myComm, const label  currentComm, const int  currentProcID  )

static

Definition at line 240 of file UPstream.C.

References UPstream::baseProcNo().

Here is the call graph for this function:

addValidParOptions()

void addValidParOptions ( HashTable< string > &  validParOptions )

static

Definition at line 27 of file UPstream.C.

init()

bool init ( int &  argc, char **&  argv, const bool  needsThread  )

static

Definition at line 41 of file UPstream.C.

References Foam::endl(), Foam::exit(), Foam::FatalError, and FatalErrorInFunction.

Referenced by ParRunControl::runPar().

Here is the call graph for this function:

Here is the caller graph for this function:

initNull()

bool initNull ( )

static

Definition at line 31 of file UPstream.C.

References Foam::endl(), and WarningInFunction.

Here is the call graph for this function:

nRequests()

Foam::label nRequests ( )

static

Definition at line 245 of file UPstream.C.

Referenced by mapDistributeBase::compact(), dynamicOversetFvMesh::correctBoundaryConditions(), dynamicOversetFvMesh::correctCoupledBoundaryConditions(), GeometricField::Boundary::evaluate(), Foam::evaluateConstraintTypes(), syncTools::syncBoundaryFaceList(), syncTools::syncFaceList(), and OFstreamCollator::write().

Here is the caller graph for this function:

resetRequests()

void resetRequests ( const label  sz )

static

Definition at line 251 of file UPstream.C.

waitRequests()

void waitRequests ( const label  start = 0 )

static

Definition at line 255 of file UPstream.C.

Referenced by mapDistributeBase::compact(), dynamicOversetFvMesh::correctBoundaryConditions(), dynamicOversetFvMesh::correctCoupledBoundaryConditions(), GeometricField::Boundary::evaluate(), Foam::evaluateConstraintTypes(), syncTools::syncBoundaryFaceList(), syncTools::syncFaceList(), and OFstreamCollator::write().

Here is the caller graph for this function:

waitRequest()

void waitRequest ( const label  i )

static

Definition at line 259 of file UPstream.C.

Referenced by PPCG::scalarSolveCG().

Here is the caller graph for this function:

finishedRequest()

bool finishedRequest ( const label  i )

static

Definition at line 263 of file UPstream.C.

References NotImplemented.

allocateTag() [1/2]

int allocateTag ( const char *  s )

static

Definition at line 1419 of file UPstream.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), Foam::PstreamGlobals::freedTags_, Foam::PstreamGlobals::nTags_, Foam::Pout, DynamicList::remove(), and s.

Here is the call graph for this function:

allocateTag() [2/2]

int allocateTag ( const word &  s )

static

Definition at line 1448 of file UPstream.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), Foam::PstreamGlobals::freedTags_, Foam::PstreamGlobals::nTags_, Foam::Pout, DynamicList::remove(), and s.

Here is the call graph for this function:

freeTag() [1/2]

void freeTag ( const char *  s, const int  tag  )

static

Definition at line 1477 of file UPstream.C.

References DynamicList::append(), Foam::expressions::patchExpr::debug, Foam::endl(), Foam::PstreamGlobals::freedTags_, Foam::Pout, and s.

Here is the call graph for this function:

freeTag() [2/2]

void freeTag ( const word &  s, const int  tag  )

static

Definition at line 1493 of file UPstream.C.

References DynamicList::append(), Foam::expressions::patchExpr::debug, Foam::endl(), Foam::PstreamGlobals::freedTags_, Foam::Pout, and s.

Here is the call graph for this function:

parRun() [1/2]

static bool parRun ( const bool  on )

inlinestaticnoexcept

Definition at line 420 of file UPstream.H.

parRun() [2/2]

static bool& parRun ( )

inlinestaticnoexcept

Definition at line 429 of file UPstream.H.

Referenced by snappyLayerDriver::addLayers(), unwatchedIOdictionary::addWatch(), regIOobject::addWatch(), UPstream::allToAll(), meshRefinement::balance(), addPatchCellLayer::calcExtrudeInfo(), processorCyclicPolyPatch::calcGeometry(), processorFaPatch::calcGeometry(), processorPolyPatch::calcGeometry(), surfaceNoise::calculate(), cyclicAMIPolyPatch::canResetAMI(), IOobjectList::checkNames(), polyBoundaryMesh::checkParallelSync(), AMIInterpolation::checkSymmetricWeights(), fieldValue::combineFields(), mapDistributeBase::compact(), dynamicOversetFvMesh::correctBoundaryConditions(), dynamicOversetFvMesh::correctCoupledBoundaryConditions(), processorFvPatch::coupled(), cyclicAMIPointPatch::coupled(), processorPointPatchField< Type >::coupled(), processorCyclicPointPatchField< Type >::coupled(), processorFvsPatchField< Type >::coupled(), processorCyclicFvsPatchField< Type >::coupled(), processorFaePatchField< Type >::coupled(), processorFaPatchField< Type >::coupled(), processorFvPatchField< Type >::coupled(), cyclicACMIFvPatch::coupled(), processorFaPatch::coupled(), cyclicAMIFvPatch::coupled(), calculatedProcessorFvPatchField< Type >::coupled(), processorPolyPatch::coupled(), multiWorldConnections::createComms(), simpleGeomDecomp::decompose(), decompositionMethod::decompose(), conformalVoronoiMesh::decomposition(), processorFvPatch::delta(), processorFaPatch::delta(), masterUncollatedFileOperation::dirPath(), refinementHistory::distribute(), fvMeshDistribute::distribute(), distributedTriSurfaceMesh::distribute(), distributedTriSurfaceMesh::distributedTriSurfaceMesh(), snappyLayerDriver::doLayers(), snappyRefineDriver::doRefine(), GeometricField::Boundary::evaluate(), Foam::evaluateConstraintTypes(), Pstream::exchange(), Foam::exitNow(), faMesh::faMesh(), faMeshReconstructor::faMeshReconstructor(), masterUncollatedFileOperation::filePath(), polyMesh::findCell(), masterUncollatedFileOperation::findInstance(), distributedTriSurfaceMesh::findLine(), distributedTriSurfaceMesh::findLineAll(), distributedTriSurfaceMesh::findLineAny(), distributedTriSurfaceMesh::findNearest(), masterUncollatedFileOperation::findTimes(), Pstream::gather(), Pstream::gatherList(), zoneDistribute::getDatafromOtherProc(), distributedTriSurfaceMesh::getField(), distributedTriSurfaceMesh::getNormal(), distributedTriSurfaceMesh::getRegion(), distributedTriSurfaceMesh::getVolumeType(), faMeshBoundaryHalo::haloSize(), InflationInjection< CloudType >::InflationInjection(), processorFaPatch::initGeometry(), processorPolyPatch::initGeometry(), InjectedParticleInjection< CloudType >::initialise(), InjectedParticleDistributionInjection< CloudType >::initialise(), extractEulerianParticles::initialiseBins(), processorPolyPatch::initOrder(), processorFaPatch::initUpdateMesh(), processorPolyPatch::initUpdateMesh(), fileOperation::lookupAndCacheProcessorsPath(), LUscalarMatrix::LUscalarMatrix(), processorFaPatch::makeDeltaCoeffs(), processorFaPatch::makeNonGlobalPatchPoints(), processorFvPatch::makeWeights(), processorFaPatch::makeWeights(), error::master(), surfaceWriter::merge(), surfaceWriter::mergeFieldTemplate(), Cloud< passivePositionParticle >::move(), polyBoundaryMesh::neighbourEdges(), masterUncollatedFileOperation::NewIFstream(), fvMeshTools::newMesh(), fileWriter::open(), processorPolyPatch::order(), InflationInjection< CloudType >::parcelsToInject(), argList::parse(), pointHistory::pointHistory(), collatedFileOperation::processorsDir(), masterUncollatedFileOperation::read(), lumpedPointState::readData(), Time::readModifiedObjects(), masterUncollatedFileOperation::readObjects(), masterUncollatedFileOperation::readStream(), surfaceNoise::readSurfaceData(), AMIWeights::reportPatch(), faMeshBoundaryHalo::reset(), PPCG::scalarSolveCG(), Pstream::scatter(), Pstream::scatterList(), fvMeshSubset::setCellSubset(), Time::setControls(), surfaceWriter::setSurface(), zoneDistribute::setUpCommforZone(), shortestPathSet::shortestPathSet(), error::simpleExit(), messageStream::stream(), surfaceWriter::surface(), surfaceNoise::surfaceAverage(), syncObjects::sync(), syncTools::syncEdgeMap(), syncTools::syncPointMap(), triSurfaceMesh::triSurfaceMesh(), turbulentDFSEMInletFvPatchVectorField::updateCoeffs(), processorFaPatch::updateMesh(), processorPolyPatch::updateMesh(), faMesh::updateMesh(), fileOperation::updateStates(), mergedSurf::use(), energySpectrum::write(), ensightCells::write(), areaWrite::write(), vtkWrite::write(), meshToMeshMethod::writeConnectivity(), AMIWeights::writeFileHeader(), fieldMinMax::writeFileHeader(), isoAdvection::writeIsoFaces(), faMeshReconstructor::writeMesh(), patchMeshWriter::writeNeighIDs(), collatedFileOperation::writeObject(), fileWriter::writeProcIDs(), surfaceNoise::writeSurfaceData(), and streamLineBase::writeToFile().

haveThreads()

static bool haveThreads ( )

inlinestaticnoexcept

Definition at line 435 of file UPstream.H.

Referenced by OFstreamCollator::write().

Here is the caller graph for this function:

nProcs()

static label nProcs ( const label  communicator = worldComm )

inlinestatic

Definition at line 441 of file UPstream.H.

Referenced by surfaceZonesInfo::addCellZonesToMesh(), surfaceZonesInfo::addFaceZonesToMesh(), masterCoarsestGAMGProcAgglomeration::agglomerate(), eagerGAMGProcAgglomeration::agglomerate(), procFacesGAMGProcAgglomeration::agglomerate(), manualGAMGProcAgglomeration::agglomerate(), UPstream::allProcs(), sensitivitySurfacePoints::assembleSensitivities(), meshRefinement::balanceAndRefine(), faPatch::boundaryProcs(), faMesh::boundaryProcs(), faPatch::boundaryProcSizes(), faMesh::boundaryProcSizes(), mapDistributeBase::calcCompactAddressing(), surfaceNoise::calculate(), meshRefinement::checkCoupledFaceZones(), polyBoundaryMesh::checkParallelSync(), mappedPatchBase::collectSamples(), fieldValue::combineFields(), sizeDistribution::combineFields(), Foam::combineReduce(), UPstream::commsStruct::commsStruct(), mapDistributeBase::compact(), GAMGAgglomeration::continueAgglomerating(), fvMeshDistribute::countCells(), meshRefinement::directionalRefineCandidates(), fvMeshDistribute::distribute(), distributedTriSurfaceMesh::distribute(), distributedTriSurfaceMesh::distributedTriSurfaceMesh(), Pstream::exchange(), mapDistributeBase::exchangeAddressing(), Pstream::exchangeSizes(), extendedUpwindCellToFaceStencil::extendedUpwindCellToFaceStencil(), distributedTriSurfaceMesh::findNearest(), meshRefinement::findRegions(), mappedPatchBase::findSamples(), Pstream::gather(), externalCoupled::gatherAndCombine(), Pstream::gatherList(), zoneDistribute::getDatafromOtherProc(), distributedTriSurfaceMesh::getVolumeType(), processorPolyPatch::initGeometry(), InjectedParticleInjection< CloudType >::initialise(), viewFactor::initialise(), InjectedParticleDistributionInjection< CloudType >::initialise(), processorPolyPatch::initUpdateMesh(), UPstream::lastSlave(), distributedTriSurfaceMesh::localQueries(), LUscalarMatrix::LUscalarMatrix(), mapDistributeBase::mapDistributeBase(), Cloud< passivePositionParticle >::move(), masterUncollatedFileOperation::NewIFstream(), InflationInjection< CloudType >::parcelsToInject(), argList::parse(), pointHistory::pointHistory(), mapDistributeBase::printLayout(), collatedFileOperation::processorsDir(), masterUncollatedFileOperation::read(), lumpedPointState::readData(), masterUncollatedFileOperation::readHeader(), masterUncollatedFileOperation::readStream(), Foam::reduce(), meshRefinement::refineAndBalance(), meshRefinement::refineCandidates(), meshRefinement::removeGapCells(), parProfiling::report(), faMeshBoundaryHalo::reset(), globalIndex::reset(), Foam::returnReduce(), Pstream::scatter(), Pstream::scatterList(), fvMeshSubset::setCellSubset(), Time::setControls(), zoneDistribute::setUpCommforZone(), ParSortableList< Type >::sort(), UPstream::subProcs(), syncObjects::sync(), trackingInverseDistance::update(), inverseDistance::update(), dynamicOversetFvMesh::updateAddressing(), turbulentDFSEMInletFvPatchVectorField::updateCoeffs(), globalMeshData::updateMesh(), externalCoupled::writeGeometry(), isoAdvection::writeIsoFaces(), and streamLineBase::writeToFile().

masterNo()

static constexpr int masterNo ( )

inlinestaticconstexprnoexcept

Definition at line 447 of file UPstream.H.

Referenced by simpleGeomDecomp::decompose(), LUscalarMatrix::LUscalarMatrix(), UPstream::master(), masterUncollatedFileOperation::NewIFstream(), fvMeshTools::newMesh(), argList::parse(), globalMeshData::sharedPoints(), syncTools::syncEdgeMap(), syncTools::syncPointMap(), patchMeshWriter::writeNeighIDs(), patchMeshWriter::writePatchIDs(), and patchMeshWriter::writePoints().

Here is the caller graph for this function:

master()

static bool master ( const label  communicator = worldComm )

inlinestatic

Definition at line 453 of file UPstream.H.

References UPstream::masterNo().

Referenced by regIOobject::addWatch(), masterUncollatedFileOperation::addWatch(), mappedPatchBase::calcMapping(), pointNoise::calculate(), viewFactor::calculate(), surfaceNoise::calculate(), argList::check(), fileWriter::checkFormatterValidity(), polyBoundaryMesh::checkParallelSync(), argList::checkRootCase(), extractEulerianParticles::collectParticle(), sizeDistribution::combineFields(), commSchedule::commSchedule(), writeFile::createFile(), logFiles::createFiles(), simpleGeomDecomp::decompose(), masterUncollatedFileOperation::dirPath(), systemCall::dispatch(), snappyVoxelMeshDriver::doRefine(), abort::end(), abort::execute(), wallHeatFlux::execute(), Curle::execute(), momentum::execute(), forces::execute(), externalFileCoupler::externalFileCoupler(), masterUncollatedFileOperation::filePath(), logFiles::files(), probes::findElements(), masterUncollatedFileOperation::findInstance(), meshRefinement::findRegions(), masterUncollatedFileOperation::findTimes(), masterUncollatedFileOperation::findWatch(), STDMD::fit(), sampledSet::gather(), externalCoupled::gatherAndCombine(), masterUncollatedFileOperation::getFile(), masterUncollatedFileOperation::getState(), Random::globalGaussNormal(), Random::globalPosition(), Random::globalRandomise01(), Random::globalSample01(), viewFactor::initialise(), surfaceNoise::initialise(), JobInfo::JobInfo(), fileOperation::lookupAndCacheProcessorsPath(), LUscalarMatrix::LUscalarMatrix(), NURBS3DVolume::makeFolders(), error::master(), messageStream::masterStream(), surfaceWriter::mergeFieldTemplate(), ensightCase::newCloud(), ensightCase::newGeometry(), masterUncollatedFileOperation::NewIFstream(), fvMeshTools::newMesh(), fileOperation::nProcs(), objectiveManager::objectiveManager(), fileWriter::open(), InflationInjection< CloudType >::parcelsToInject(), argList::parse(), pointHistory::pointHistory(), porosityModel::porosityModel(), probes::prepare(), decomposedBlockData::read(), writeFile::read(), sampledSets::read(), externalCoupled::read(), sampledSurfaces::read(), masterUncollatedFileOperation::read(), baseIOdictionary::readData(), lumpedPointState::readData(), masterUncollatedFileOperation::readHeader(), masterUncollatedFileOperation::readObjects(), masterUncollatedFileOperation::readStream(), surfaceNoise::readSurfaceData(), externalCoupled::removeDataMaster(), externalCoupled::removeDataSlave(), masterUncollatedFileOperation::removeWatch(), parProfiling::report(), logFiles::resetNames(), ensightCase::setTime(), masterUncollatedFileOperation::setUnmodified(), globalMeshData::sharedPoints(), shortestPathSet::shortestPathSet(), externalFileCoupler::shutdown(), snappyVoxelMeshDriver::snappyVoxelMeshDriver(), rigidBodyMeshMotionSolver::solve(), rigidBodyMeshMotion::solve(), rigidBodyMotion::solve(), ParSortableList< Type >::sort(), SQP::SQP(), messageStream::stream(), surfaceNoise::surfaceAverage(), hexRef8Data::sync(), syncTools::syncEdgeMap(), syncTools::syncPointMap(), triSurfaceMesh::triSurfaceMesh(), sixDoFRigidBodyMotion::update(), lumpedPointDisplacementPointPatchVectorField::updateCoeffs(), activePressureForceBaffleVelocityFvPatchVectorField::updateCoeffs(), electrostaticDepositionFvPatchScalarField::updateCoeffs(), turbulentDigitalFilterInletFvPatchVectorField::updateCoeffs(), updateMethod::updateMethod(), fileMonitor::updateStates(), masterUncollatedFileOperation::updateStates(), solution::upgradeSolverDict(), externalFileCoupler::useMaster(), externalFileCoupler::useSlave(), OFstreamCollator::waitAll(), externalFileCoupler::waitForMaster(), externalFileCoupler::waitForSlave(), sensitivityBezier::write(), sensitivityVolBSplines::write(), sensitivityVolBSplinesFI::write(), proxyWriter::write(), sensitivityBezierFI::write(), timeInfo::write(), x3dWriter::write(), SQP::write(), energySpectrum::write(), starcdWriter::write(), OFstreamCollator::write(), foamWriter::write(), rawWriter::write(), yPlus::write(), vtkWriter::write(), wallShearStress::write(), abaqusWriter::write(), boundaryDataWriter::write(), histogram::write(), sampledSets::write(), nastranWriter::write(), sizeDistribution::write(), vtkCloud::write(), NURBS3DCurve::write(), objective::write(), vtkWrite::write(), volFieldValue::write(), regionSizeDistribution::write(), NURBS3DSurface::write(), turbulentDigitalFilterInletFvPatchVectorField::write(), surfaceFieldValue::write(), propellerInfo::writeAxialWake(), ensightWriter::writeCollated(), updateMethod::writeCorrection(), NURBS3DVolume::writeCps(), decomposedBlockData::writeData(), lumpedPointMovement::writeData(), lumpedPointMovement::writeForcesAndMomentsVTP(), externalCoupled::writeGeometry(), objective::writeInstantaneousSeparator(), objective::writeInstantaneousValue(), isoAdvection::writeIsoFaces(), objective::writeMeanValue(), faMeshReconstructor::writeMesh(), patchMeshWriter::writeNeighIDs(), collatedFileOperation::writeObject(), decomposedBlockData::writeObject(), patchMeshWriter::writePatchIDs(), patchMeshWriter::writePoints(), fileWriter::writeProcIDs(), sampledSets::writeSampleFile(), surfaceNoise::writeSurfaceData(), foamWriter::writeTemplate(), starcdWriter::writeTemplate(), boundaryDataWriter::writeTemplate(), x3dWriter::writeTemplate(), vtkWriter::writeTemplate(), streamLineBase::writeToFile(), ensightWriter::writeUncollated(), NURBS3DSurface::writeVTK(), propellerInfo::writeWake(), AMIWeights::writeWeightField(), NURBS3DCurve::writeWParses(), and NURBS3DSurface::writeWParses().

Here is the call graph for this function:

myProcNo()

static int myProcNo ( const label  communicator = worldComm )

inlinestatic

Definition at line 459 of file UPstream.H.

Referenced by surfaceZonesInfo::addCellZonesToMesh(), surfaceZonesInfo::addFaceZonesToMesh(), masterCoarsestGAMGProcAgglomeration::agglomerate(), eagerGAMGProcAgglomeration::agglomerate(), manualGAMGProcAgglomeration::agglomerate(), sensitivitySurfacePoints::assembleSensitivities(), faPatch::boundaryProcs(), faMesh::boundaryProcs(), faPatch::boundaryProcSizes(), faMesh::boundaryProcSizes(), mapDistributeBase::calcCompactAddressing(), addPatchCellLayer::calcExtrudeInfo(), viewFactor::calculate(), GAMGAgglomeration::calculateRegionMaster(), meshRefinement::checkCoupledFaceZones(), polyBoundaryMesh::checkParallelSync(), mappedPatchBase::collectSamples(), fieldValue::combineFields(), sizeDistribution::combineFields(), mapDistributeBase::compact(), noDecomp::decompose(), fvMeshDistribute::distribute(), distributedTriSurfaceMesh::distribute(), distributedTriSurfaceMesh::distributedTriSurfaceMesh(), Pstream::exchange(), mapDistributeBase::exchangeAddressing(), processorField::execute(), InjectionModel< CloudType >::findCellAtPosition(), patchProbes::findElements(), probes::findElements(), mappedPatchBase::findLocalSamples(), distributedTriSurfaceMesh::findNearest(), meshRefinement::findRegions(), mappedPatchBase::findSamples(), Pstream::gather(), lduPrimitiveMesh::gather(), externalCoupled::gatherAndCombine(), Pstream::gatherList(), zoneDistribute::getDatafromOtherProc(), InjectedParticleInjection< CloudType >::initialise(), viewFactor::initialise(), InjectedParticleDistributionInjection< CloudType >::initialise(), globalIndex::inplaceToGlobal(), globalIndex::isLocal(), lduPrimitiveMesh::lduPrimitiveMesh(), distributedTriSurfaceMesh::localQueries(), globalIndex::localSize(), globalIndex::localStart(), mapDistribute::mapDistribute(), mapDistributeBase::mapDistributeBase(), globalIndex::maxNonLocalSize(), Cloud< passivePositionParticle >::move(), UPstream::myWorldID(), masterUncollatedFileOperation::NewIFstream(), regionSplit::nLocalRegions(), InflationInjection< CloudType >::parcelsToInject(), argList::parse(), pointHistory::pointHistory(), probes::prepare(), mapDistributeBase::printLayout(), backgroundMeshDecomposition::procBounds(), globalIndex::range(), masterUncollatedFileOperation::read(), lumpedPointState::readData(), masterUncollatedFileOperation::readHeader(), masterUncollatedFileOperation::readStream(), surfaceNoise::readSurfaceData(), indexedVertex::referred(), parProfiling::report(), faMeshBoundaryHalo::reset(), globalIndex::reset(), Pstream::scatter(), Pstream::scatterList(), fvMeshSubset::setCellSubset(), Time::setControls(), patchInjectionBase::setPositionAndCell(), zoneDistribute::setUpCommforZone(), ParSortableList< Type >::sort(), KinematicSurfaceFilm< CloudType >::splashInteraction(), globalIndex::toGlobal(), globalIndex::toLocal(), trackingInverseDistance::update(), inverseDistance::update(), dynamicOversetFvMesh::updateAddressing(), patchInjectionBase::updateMesh(), propellerInfo::updateSampleDiskCells(), meshToMeshMethod::writeConnectivity(), AMIInterpolation::writeFaceConnectivity(), externalCoupled::writeGeometry(), isoAdvection::writeIsoFaces(), and fileWriter::writeProcIDs().

parent()

static label parent ( const label  communicator )

inlinestatic

Definition at line 464 of file UPstream.H.

Referenced by UPstream::baseProcNo().

Here is the caller graph for this function:

procID()

static List<int>& procID ( label  communicator )

inlinestatic

Definition at line 470 of file UPstream.H.

Referenced by UPstream::baseProcNo(), and collatedFileOperation::processorsDir().

Here is the caller graph for this function:

allWorlds()

static const wordList& allWorlds ( )

inlinestaticnoexcept

Definition at line 479 of file UPstream.H.

Referenced by mappedPatchBase::calcMapping(), mappedPatchBase::masterWorld(), UPstream::myWorld(), argList::parse(), Foam::printDOT(), and mappedPatchBase::sameWorld().

Here is the caller graph for this function:

worldIDs()

static const labelList& worldIDs ( )

inlinestaticnoexcept

Definition at line 485 of file UPstream.H.

myWorldID()

static label myWorldID ( )

inlinestatic

Definition at line 491 of file UPstream.H.

References UPstream::myProcNo().

Referenced by mappedPatchBase::calcMapping(), multiWorldConnections::createComms(), mappedPatchBase::masterWorld(), and UPstream::myWorld().

Here is the call graph for this function:

Here is the caller graph for this function:

myWorld()

static const word& myWorld ( )

inlinestatic

Definition at line 497 of file UPstream.H.

References UPstream::allWorlds(), and UPstream::myWorldID().

Referenced by multiWorldConnections::addConnectionById(), multiWorldConnections::addConnectionByName(), mappedPatchBase::calcMapping(), argList::parse(), mappedPatchBase::sameWorld(), and mappedPatchBase::sampleMesh().

Here is the call graph for this function:

Here is the caller graph for this function:

allProcs()

static rangeType allProcs ( const label  communicator = worldComm )

inlinestatic

Definition at line 504 of file UPstream.H.

References UPstream::nProcs().

Referenced by mapDistributeBase::compact(), refinementHistory::distribute(), zoneDistribute::getDatafromOtherProc(), viewFactor::initialise(), surfaceNoise::readSurfaceData(), mapDistributeBase::receive(), mapDistributeBase::send(), zoneDistribute::setUpCommforZone(), ParSortableList< Type >::sort(), energySpectrum::write(), externalCoupled::writeGeometry(), and fileWriter::writeProcIDs().

Here is the call graph for this function:

Here is the caller graph for this function:

subProcs()

static rangeType subProcs ( const label  communicator = worldComm )

inlinestatic

Definition at line 511 of file UPstream.H.

References UPstream::nProcs().

Referenced by polyBoundaryMesh::checkParallelSync(), simpleGeomDecomp::decompose(), LUscalarMatrix::LUscalarMatrix(), masterUncollatedFileOperation::NewIFstream(), fvMeshTools::newMesh(), argList::parse(), globalMeshData::sharedPoints(), surfaceNoise::surfaceAverage(), syncTools::syncEdgeMap(), syncTools::syncPointMap(), patchMeshWriter::writeNeighIDs(), patchMeshWriter::writePatchIDs(), patchMeshWriter::writePoints(), and surfaceNoise::writeSurfaceData().

Here is the call graph for this function:

Here is the caller graph for this function:

linearCommunication()

static const List<commsStruct>& linearCommunication ( const label  communicator = worldComm )

inlinestatic

Definition at line 519 of file UPstream.H.

Referenced by Foam::combineReduce(), Pstream::gather(), Pstream::gatherList(), masterUncollatedFileOperation::read(), lumpedPointState::readData(), Foam::reduce(), Foam::returnReduce(), Pstream::scatter(), and Pstream::scatterList().

Here is the caller graph for this function:

treeCommunication()

static const List<commsStruct>& treeCommunication ( const label  communicator = worldComm )

inlinestatic

Definition at line 528 of file UPstream.H.

Referenced by Foam::combineReduce(), Pstream::gather(), Pstream::gatherList(), masterUncollatedFileOperation::read(), lumpedPointState::readData(), Foam::reduce(), Foam::returnReduce(), Pstream::scatter(), and Pstream::scatterList().

Here is the caller graph for this function:

msgType()

static int& msgType ( )

inlinestaticnoexcept

Definition at line 536 of file UPstream.H.

Referenced by solidAbsorption::a(), decompositionMethod::calcCellCells(), mappedPatchBase::calcMapping(), masterUncollatedFileOperation::chMod(), mappedPatchBase::collectSamples(), extendedCentredCellToFaceStencil::compact(), extendedCentredFaceToCellStencil::compact(), extendedCentredCellToCellStencil::compact(), masterUncollatedFileOperation::cp(), masterUncollatedFileOperation::dirPath(), mappedPatchBase::distribute(), solidAbsorption::e(), masterUncollatedFileOperation::exists(), masterUncollatedFileOperation::filePath(), masterUncollatedFileOperation::fileSize(), masterUncollatedFileOperation::findInstance(), distributedTriSurfaceMesh::findNearest(), mappedPatchBase::findSamples(), lduPrimitiveMesh::gather(), Foam::gAverage(), distributedTriSurfaceMesh::getVolumeType(), Foam::gSumCmptProd(), Foam::gSumProd(), masterUncollatedFileOperation::highResLastModified(), dynamicOversetFvMesh::interpolate(), regionModel::interRegionAMI(), masterUncollatedFileOperation::isDir(), masterUncollatedFileOperation::isFile(), masterUncollatedFileOperation::lastModified(), lduPrimitiveMesh::lduPrimitiveMesh(), masterUncollatedFileOperation::ln(), fileOperation::lookupAndCacheProcessorsPath(), LUscalarMatrix::LUscalarMatrix(), masterUncollatedFileOperation::mkDir(), masterUncollatedFileOperation::mode(), masterUncollatedFileOperation::mv(), masterUncollatedFileOperation::mvBak(), masterUncollatedFileOperation::NewIFstream(), fileOperation::nProcs(), masterUncollatedFileOperation::read(), lumpedPointState::readData(), masterUncollatedFileOperation::readDir(), masterUncollatedFileOperation::readHeader(), masterUncollatedFileOperation::readStream(), faMeshBoundaryHalo::reset(), globalIndex::reset(), mappedPatchBase::reverseDistribute(), masterUncollatedFileOperation::rm(), masterUncollatedFileOperation::rmDir(), mapDistributeBase::schedule(), syncObjects::sync(), processorFvPatch::tag(), processorFaPatch::tag(), processorCyclicPolyPatch::tag(), processorPolyPatch::tag(), masterUncollatedFileOperation::type(), dynamicOversetFvMesh::updateAddressing(), wideBandDiffusiveRadiationMixedFvPatchScalarField::updateCoeffs(), mappedVelocityFluxFixedValueFvPatchField::updateCoeffs(), filmPyrolysisTemperatureCoupledFvPatchScalarField::updateCoeffs(), filmPyrolysisVelocityCoupledFvPatchVectorField::updateCoeffs(), greyDiffusiveRadiationMixedFvPatchScalarField::updateCoeffs(), mappedFlowRateFvPatchVectorField::updateCoeffs(), MarshakRadiationFvPatchScalarField::updateCoeffs(), MarshakRadiationFixedTemperatureFvPatchScalarField::updateCoeffs(), alphatFilmWallFunctionFvPatchScalarField::updateCoeffs(), thermalBaffle1DFvPatchScalarField< solidType >::updateCoeffs(), turbulentTemperatureCoupledBaffleMixedFvPatchScalarField::updateCoeffs(), turbulentTemperatureRadCoupledMixedFvPatchScalarField::updateCoeffs(), globalMeshData::updateMesh(), OFstreamCollator::write(), and decomposedBlockData::writeData().

commsType() [1/2]

commsTypes commsType ( ) const

inlinenoexcept

Definition at line 543 of file UPstream.H.

References UPstream::commsType_.

commsType() [2/2]

commsTypes commsType ( const commsTypes  ct )

inlinenoexcept

Definition at line 549 of file UPstream.H.

References UPstream::commsType_.

shutdown()

void shutdown ( int  errNo = 0 )

static

Definition at line 52 of file UPstream.C.

Referenced by ParRunControl::~ParRunControl().

Here is the caller graph for this function:

abort()

void abort ( )

static

Definition at line 63 of file UPstream.C.

References Foam::abort().

Referenced by error::simpleExit().

Here is the call graph for this function:

Here is the caller graph for this function:

exit()

void exit ( int  errNo = 1 )

static

Definition at line 56 of file UPstream.C.

References Foam::exit().

Referenced by snappyLayerDriver::addLayers(), argList::argList(), Foam::exitNow(), argList::parse(), ParRunControl::runPar(), and error::simpleExit().

Here is the call graph for this function:

Here is the caller graph for this function:

allToAll() [1/2]

void allToAll ( const labelUList &  sendData, labelUList &  recvData, const label  communicator = worldComm  )

static

Definition at line 165 of file UPstream.C.

References UList::deepCopy().

Referenced by fvMeshDistribute::distribute().

Here is the call graph for this function:

Here is the caller graph for this function:

allToAll() [2/2]

void allToAll ( const char *  sendData, const UList< int > &  sendSizes, const UList< int > &  sendOffsets, char *  recvData, const UList< int > &  recvSizes, const UList< int > &  recvOffsets, const label  communicator = worldComm  )

static

Definition at line 793 of file UPstream.C.

References Foam::abort(), profilingPstream::addAllToAllTime(), profilingPstream::beginTiming(), UList::cdata(), Foam::endl(), Foam::FatalError, FatalErrorInFunction, Foam::PstreamGlobals::MPICommunicators_, UPstream::parRun(), Foam::Pout, error::printStack(), UList::size(), and UPstream::warnComm.

Here is the call graph for this function:

mpiGather()

void mpiGather ( const char *  sendData, int  sendSize, char *  recvData, int  recvSize, const label  communicator = worldComm  )

static

Definition at line 176 of file UPstream.C.

mpiScatter()

void mpiScatter ( const char *  sendData, int  sendSize, char *  recvData, int  recvSize, const label  communicator = worldComm  )

static

Definition at line 190 of file UPstream.C.

gather()

void gather ( const char *  sendData, int  sendSize, char *  recvData, const UList< int > &  recvSizes, const UList< int > &  recvOffsets, const label  communicator = worldComm  )

static

Definition at line 204 of file UPstream.C.

scatter()

void scatter ( const char *  sendData, const UList< int > &  sendSizes, const UList< int > &  sendOffsets, char *  recvData, int  recvSize, const label  communicator = worldComm  )

static

Definition at line 219 of file UPstream.C.

listGatherValues() [1/2]

static List<T> listGatherValues ( const T &  localValue, const label  communicator = worldComm  )

static

listScatterValues()

T listScatterValues ( const UList< T > &  allValues, const label  communicator = worldComm  )

static

Definition at line 71 of file UPstreamTemplates.C.

References Foam::abort(), UList::cdata_bytes(), UList::empty(), Foam::endl(), Foam::FatalError, FatalErrorInFunction, UList::size(), T, and Foam::Zero.

Here is the call graph for this function:

firstSlave()

static constexpr int firstSlave ( )

inlinestaticconstexprnoexcept

Definition at line 666 of file UPstream.H.

lastSlave()

static int lastSlave ( const label  communicator = worldComm )

inlinestatic

Definition at line 673 of file UPstream.H.

References UPstream::nProcs().

Here is the call graph for this function:

listGatherValues() [2/2]

Foam::List<T> listGatherValues	(	const T &	localValue,
		const label	comm
	)

Definition at line 25 of file UPstreamTemplates.C.

References Foam::abort(), Foam::endl(), Foam::FatalError, FatalErrorInFunction, List::resize(), and T.

Here is the call graph for this function:

Member Data Documentation

commsTypeNames

const Foam::Enum< Foam::UPstream::commsTypes > commsTypeNames

static

Definition at line 73 of file UPstream.H.

Referenced by GeometricField::Boundary::evaluate(), PstreamBuffers::finishedSends(), argList::parse(), addcommsTypeToOpt::readData(), and addcommsTypeToOpt::writeData().

commsType_

commsTypes commsType_

protected

Definition at line 256 of file UPstream.H.

Referenced by UPstream::commsType().

floatTransfer

bool floatTransfer

static

Definition at line 270 of file UPstream.H.

Referenced by argList::parse().

nProcsSimpleSum

int nProcsSimpleSum

static

Definition at line 274 of file UPstream.H.

Referenced by Foam::combineReduce(), Pstream::gather(), Pstream::gatherList(), UList< Foam::wordRe >::operator[](), argList::parse(), masterUncollatedFileOperation::read(), lumpedPointState::readData(), Foam::reduce(), Foam::returnReduce(), Pstream::scatter(), and Pstream::scatterList().

defaultCommsType

Foam::UPstream::commsTypes defaultCommsType

static

Definition at line 277 of file UPstream.H.

Referenced by dynamicOversetFvMesh::correctBoundaryConditions(), dynamicOversetFvMesh::correctCoupledBoundaryConditions(), mapDistributeBase::distribute(), distributedTriSurfaceMesh::distribute(), mappedPatchBase::distribute(), GeometricField::Boundary::evaluate(), Foam::evaluateConstraintTypes(), pointBoundaryMesh::movePoints(), polyBoundaryMesh::movePoints(), argList::parse(), addcommsTypeToOpt::readData(), mapDistributeBase::reverseDistribute(), mappedPatchBase::reverseDistribute(), syncTools::syncBoundaryFaceList(), pointBoundaryMesh::updateMesh(), polyBoundaryMesh::updateMesh(), and addcommsTypeToOpt::writeData().

nPollProcInterfaces

int nPollProcInterfaces

static

Definition at line 280 of file UPstream.H.

Referenced by argList::parse().

maxCommsSize

int maxCommsSize

static

Definition at line 283 of file UPstream.H.

Referenced by Pstream::exchange().

mpiBufferSize

const int mpiBufferSize

static

Definition at line 286 of file UPstream.H.

Referenced by attachOurBuffers().

worldComm

Foam::label worldComm

static

Definition at line 289 of file UPstream.H.

Referenced by mappedPatchBase::calcAMI(), decompositionMethod::calcCellCells(), processorFaPatchField< Type >::comm(), multiWorldConnections::comms(), multiWorldConnections::createComms(), mappedPatchBase::distribute(), masterUncollatedFileOperation::findInstance(), multiWorldConnections::getCommById(), multiWorldConnections::getCommByName(), mappedPatchBase::getWorldCommunicator(), messageStream::masterStream(), masterUncollatedFileOperation::NewIFstream(), masterUncollatedFileOperation::read(), lumpedPointState::readData(), masterUncollatedFileOperation::readHeader(), masterUncollatedFileOperation::readStream(), globalIndex::reset(), mappedPatchBase::reverseDistribute(), globalMeshData::updateMesh(), collatedFileOperation::~collatedFileOperation(), hostCollatedFileOperation::~hostCollatedFileOperation(), and masterUncollatedFileOperation::~masterUncollatedFileOperation().

warnComm

Foam::label warnComm

static

Definition at line 292 of file UPstream.H.

Referenced by UPstream::allToAll(), mappedPatchBase::calcAMI(), mappedPatchBase::collectSamples(), multiWorldConnections::createComms(), mappedPatchBase::distribute(), mappedPatchBase::findSamples(), messageStream::masterStream(), Foam::reduce(), mappedPatchBase::reverseDistribute(), syncObjects::sync(), and globalMeshData::updateMesh().

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/db/IOstreams/Pstreams/UPstream.H
• src/OpenFOAM/db/IOstreams/Pstreams/UPstream.C
• src/OpenFOAM/db/IOstreams/Pstreams/UPstreamTemplates.C
