A templated (2 x 2) tensor of objects of <T> derived from VectorSpace. More...

Inheritance diagram for Tensor2D< Cmpt >:

Collaboration diagram for Tensor2D< Cmpt >:

Public Types
enum	components { XX, XY, YX, YY }

typedef Tensor2D< label >	labelType

Public Types inherited from VectorSpace< Tensor2D< Cmpt >, Cmpt, 4 >
typedef VectorSpace< Form, Cmpt, Ncmpts >	vsType

typedef Cmpt	cmptType

typedef Cmpt	magType

typedef Cmpt *	iterator

Public Member Functions
	Tensor2D ()=default

	Tensor2D (const Tensor2D &)=default

Tensor2D &	operator= (const Tensor2D &)=default

	Tensor2D (const Foam::zero)

	Tensor2D (const VectorSpace< Tensor2D< Cmpt >, Cmpt, 4 > &vs)

	Tensor2D (const SymmTensor2D< Cmpt > &st)

	Tensor2D (const SphericalTensor2D< Cmpt > &st)

	Tensor2D (const Vector2D< Cmpt > &x, const Vector2D< Cmpt > &y)

	Tensor2D (const Cmpt txx, const Cmpt txy, const Cmpt tyx, const Cmpt tyy)

	Tensor2D (Istream &is)

const Cmpt &	xx () const

const Cmpt &	xy () const

const Cmpt &	yx () const

const Cmpt &	yy () const

Cmpt &	xx ()

Cmpt &	xy ()

Cmpt &	yx ()

Cmpt &	yy ()

Vector2D< Cmpt >	cx () const

Vector2D< Cmpt >	cy () const

template<direction Col>
Vector2D< Cmpt >	col () const

Vector2D< Cmpt >	col (const direction c) const

template<direction Col>
void	col (const Vector2D< Cmpt > &v)

void	col (const direction c, const Vector2D< Cmpt > &v)

void	cols (const Vector2D< Cmpt > &x, const Vector2D< Cmpt > &y)

Vector2D< Cmpt >	x () const

Vector2D< Cmpt >	y () const

template<direction Row>
Vector2D< Cmpt >	row () const

Vector2D< Cmpt >	row (const direction r) const

template<direction Row>
void	row (const Vector2D< Cmpt > &v)

void	row (const direction r, const Vector2D< Cmpt > &v)

void	rows (const Vector2D< Cmpt > &x, const Vector2D< Cmpt > &y)

Vector2D< Cmpt >	diag () const

void	diag (const Vector2D< Cmpt > &v)

Tensor2D< Cmpt >	T () const

Tensor2D< Cmpt >	inner (const Tensor2D< Cmpt > &t2) const

Tensor2D< Cmpt >	schur (const Tensor2D< Cmpt > &t2) const

void	operator= (const SymmTensor2D< Cmpt > &)

void	operator= (const SphericalTensor2D< Cmpt > &)

Vector2D< Cmpt >	vectorComponent (const direction cmpt) const

template<Foam::direction Col>
Foam::Vector2D< Cmpt >	col () const

template<Foam::direction Row>
Foam::Vector2D< Cmpt >	row () const

Public Member Functions inherited from VectorSpace< Tensor2D< Cmpt >, Cmpt, 4 >
	VectorSpace ()=default

	VectorSpace (const Foam::zero)

	VectorSpace (const VectorSpace< Form, Cmpt, Ncmpts > &vs)

	VectorSpace (const VectorSpace< Form2, Cmpt2, Ncmpts > &)

	VectorSpace (Istream &is)

const Cmpt &	component (const direction) const

Cmpt &	component (const direction)

void	component (Cmpt &, const direction) const

void	replace (const direction, const Cmpt &)

const Cmpt *	cdata () const noexcept

Cmpt *	data () noexcept

const ConstBlock< SubVector, BStart >	block () const

const Foam::VectorSpace< Form, Cmpt, Ncmpts >::template ConstBlock< SubVector, BStart >	block () const

const Cmpt &	operator[] (const direction) const

Cmpt &	operator[] (const direction)

void	operator= (const VectorSpace< Form, Cmpt, Ncmpts > &)

void	operator= (const Foam::zero)

void	operator+= (const VectorSpace< Form, Cmpt, Ncmpts > &)

void	operator-= (const VectorSpace< Form, Cmpt, Ncmpts > &)

void	operator*= (const scalar)

void	operator/= (const scalar)

iterator	begin () noexcept

const_iterator	begin () const noexcept

iterator	end () noexcept

const_iterator	end () const noexcept

const_iterator	cbegin () const noexcept

const_iterator	cend () const noexcept

Static Public Attributes
static constexpr direction	rank = 2

static const Tensor2D	I

Static Public Attributes inherited from VectorSpace< Tensor2D< Cmpt >, Cmpt, 4 >
static constexpr direction	dim

static constexpr direction	nComponents

static constexpr direction	mRows

static constexpr direction	nCols

static const char *const	typeName

static const char *const	componentNames []

static const Form	zero

static const Form	one

static const Form	max

static const Form	min

static const Form	rootMax

static const Form	rootMin

Additional Inherited Members
Static Public Member Functions inherited from VectorSpace< Tensor2D< Cmpt >, Cmpt, 4 >
static constexpr direction	size () noexcept

static Form	uniform (const Cmpt &s)

Public Attributes inherited from VectorSpace< Tensor2D< Cmpt >, Cmpt, 4 >
const typedef Cmpt *	const_iterator

Cmpt	v_ [Ncmpts]

Detailed Description

template<class Cmpt>
class Foam::Tensor2D< Cmpt >

A templated (2 x 2) tensor of objects of <T> derived from VectorSpace.

See also: Test-Tensor2D.C

Source files

Definition at line 55 of file Tensor2D.H.

Member Typedef Documentation

◆ labelType

typedef Tensor2D<label> labelType

Definition at line 64 of file Tensor2D.H.

Member Enumeration Documentation

◆ components

enum components

Enumerator
XX
XY
YX
YY

Definition at line 79 of file Tensor2D.H.

Constructor & Destructor Documentation

◆ Tensor2D() [1/9]

Tensor2D ( )

default

◆ Tensor2D() [2/9]

Tensor2D ( const Tensor2D< Cmpt > & )

default

◆ Tensor2D() [3/9]

Tensor2D ( const Foam::zero )

inline

Definition at line 25 of file Tensor2DI.H.

◆ Tensor2D() [4/9]

Tensor2D ( const VectorSpace< Tensor2D< Cmpt >, Cmpt, 4 > & vs )

inline

Definition at line 33 of file Tensor2DI.H.

◆ Tensor2D() [5/9]

Tensor2D ( const SymmTensor2D< Cmpt > & st )

inline

Definition at line 42 of file Tensor2DI.H.

References SymmTensor2D< Cmpt >::xx(), SymmTensor2D< Cmpt >::xy(), and SymmTensor2D< Cmpt >::yy().

Here is the call graph for this function:

◆ Tensor2D() [6/9]

Tensor2D ( const SphericalTensor2D< Cmpt > & st )

inline

Definition at line 50 of file Tensor2DI.H.

References SphericalTensor2D< Cmpt >::ii(), and Foam::Zero.

Here is the call graph for this function:

◆ Tensor2D() [7/9]

Tensor2D	(	const Vector2D< Cmpt > &	x,
		const Vector2D< Cmpt > &	y
	)

inline

Definition at line 59 of file Tensor2DI.H.

References x, and y.

◆ Tensor2D() [8/9]

Tensor2D	(	const Cmpt	txx,
		const Cmpt	txy,
		const Cmpt	tyx,
		const Cmpt	tyy
	)

inline

Definition at line 71 of file Tensor2DI.H.

◆ Tensor2D() [9/9]

Tensor2D ( Istream & is )

inlineexplicit

Definition at line 82 of file Tensor2DI.H.

Member Function Documentation

◆ operator=() [1/3]

Tensor2D& operator= ( const Tensor2D< Cmpt > & )

default

◆ xx() [1/2]

Cmpt & xx

inline

Definition at line 91 of file Tensor2DI.H.

Referenced by Foam::cof(), Foam::det(), Tensor2D< Cmpt >::inner(), Foam::operator&(), Foam::operator&&(), Foam::operator+(), Foam::operator-(), Foam::operator/(), Tensor2D< Cmpt >::schur(), Foam::symm(), Foam::tr(), and Foam::twoSymm().

Here is the caller graph for this function:

◆ xy() [1/2]

Cmpt & xy

inline

Definition at line 97 of file Tensor2DI.H.

Referenced by Foam::cof(), Foam::det(), Tensor2D< Cmpt >::inner(), Foam::operator&(), Foam::operator&&(), Foam::operator+(), Foam::operator-(), Foam::operator/(), Tensor2D< Cmpt >::schur(), Foam::skew(), Foam::symm(), and Foam::twoSymm().

Here is the caller graph for this function:

◆ yx() [1/2]

Cmpt & yx

inline

Definition at line 103 of file Tensor2DI.H.

Referenced by Foam::cof(), Foam::det(), Tensor2D< Cmpt >::inner(), Foam::operator&(), Foam::operator&&(), Foam::operator+(), Foam::operator-(), Foam::operator/(), Tensor2D< Cmpt >::schur(), Foam::skew(), Foam::symm(), and Foam::twoSymm().

Here is the caller graph for this function:

◆ yy() [1/2]

Cmpt & yy

inline

Definition at line 109 of file Tensor2DI.H.

Referenced by Foam::cof(), Foam::det(), Tensor2D< Cmpt >::inner(), Foam::operator&(), Foam::operator&&(), Foam::operator+(), Foam::operator-(), Foam::operator/(), Tensor2D< Cmpt >::schur(), Foam::symm(), Foam::tr(), and Foam::twoSymm().

Here is the caller graph for this function:

◆ xx() [2/2]

Cmpt& xx ( )

inline

◆ xy() [2/2]

Cmpt& xy ( )

inline

◆ yx() [2/2]

Cmpt& yx ( )

inline

◆ yy() [2/2]

Cmpt& yy ( )

inline

◆ cx()

Foam::Vector2D< Cmpt > cx

inline

Definition at line 154 of file Tensor2DI.H.

◆ cy()

Foam::Vector2D< Cmpt > cy

inline

Definition at line 160 of file Tensor2DI.H.

◆ col() [1/5]

Vector2D<Cmpt> col ( ) const

inline

◆ col() [2/5]

Foam::Vector2D< Cmpt > col ( const direction c ) const

inline

Definition at line 179 of file Tensor2DI.H.

References Foam::abort(), Foam::constant::universal::c, Foam::FatalError, FatalErrorInFunction, and Foam::Zero.

Here is the call graph for this function:

◆ col() [3/5]

void col ( const Vector2D< Cmpt > & v )

inline

Definition at line 224 of file Tensor2DI.H.

References Vector2D< Cmpt >::x(), and Vector2D< Cmpt >::y().

Here is the call graph for this function:

◆ col() [4/5]

void col	(	const direction	c,
		const Vector2D< Cmpt > &	v
	)

inline

Definition at line 284 of file Tensor2DI.H.

References Foam::abort(), Foam::constant::universal::c, Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

◆ cols()

void cols	(	const Vector2D< Cmpt > &	x,
		const Vector2D< Cmpt > &	y
	)

inline

Definition at line 260 of file Tensor2DI.H.

References x, and y.

◆ x()

Foam::Vector2D< Cmpt > x

inline

Definition at line 141 of file Tensor2DI.H.

Referenced by triSurfaceTools::curvatures().

Here is the caller graph for this function:

◆ y()

Foam::Vector2D< Cmpt > y

inline

Definition at line 147 of file Tensor2DI.H.

Referenced by triSurfaceTools::curvatures().

Here is the caller graph for this function:

◆ row() [1/5]

Vector2D<Cmpt> row ( ) const

inline

Referenced by Tensor2D< Cmpt >::vectorComponent().

Here is the caller graph for this function:

◆ row() [2/5]

Foam::Vector2D< Cmpt > row ( const direction r ) const

inline

Definition at line 207 of file Tensor2DI.H.

References Foam::abort(), Foam::FatalError, FatalErrorInFunction, x, y, and Foam::Zero.

Here is the call graph for this function:

◆ row() [3/5]

void row ( const Vector2D< Cmpt > & v )

inline

Definition at line 243 of file Tensor2DI.H.

References Vector2D< Cmpt >::x(), and Vector2D< Cmpt >::y().

Here is the call graph for this function:

◆ row() [4/5]

void row	(	const direction	r,
		const Vector2D< Cmpt > &	v
	)

inline

Definition at line 303 of file Tensor2DI.H.

References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

◆ rows()

void rows	(	const Vector2D< Cmpt > &	x,
		const Vector2D< Cmpt > &	y
	)

inline

Definition at line 272 of file Tensor2DI.H.

References x, and y.

◆ diag() [1/2]

Foam::Vector2D< Cmpt > diag

inline

Definition at line 321 of file Tensor2DI.H.

◆ diag() [2/2]

void diag ( const Vector2D< Cmpt > & v )

inline

Definition at line 328 of file Tensor2DI.H.

References Vector2D< Cmpt >::x(), and Vector2D< Cmpt >::y().

Here is the call graph for this function:

◆ T()

Foam::Tensor2D< Cmpt > T

inline

Definition at line 337 of file Tensor2DI.H.

◆ inner()

Foam::Tensor2D< Cmpt > inner ( const Tensor2D< Cmpt > & t2 ) const

inline

Definition at line 349 of file Tensor2DI.H.

References Tensor2D< Cmpt >::xx(), Tensor2D< Cmpt >::xy(), Tensor2D< Cmpt >::yx(), and Tensor2D< Cmpt >::yy().

Referenced by Foam::operator&().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ schur()

Foam::Tensor2D< Cmpt > schur ( const Tensor2D< Cmpt > & t2 ) const

inline

Definition at line 366 of file Tensor2DI.H.

References Tensor2D< Cmpt >::xx(), Tensor2D< Cmpt >::xy(), Tensor2D< Cmpt >::yx(), and Tensor2D< Cmpt >::yy().

Here is the call graph for this function:

◆ operator=() [2/3]

void operator= ( const SymmTensor2D< Cmpt > & st )

inline

Definition at line 381 of file Tensor2DI.H.

References SymmTensor2D< Cmpt >::xx(), SymmTensor2D< Cmpt >::xy(), and SymmTensor2D< Cmpt >::yy().

Here is the call graph for this function:

◆ operator=() [3/3]

void operator= ( const SphericalTensor2D< Cmpt > & st )

inline

Definition at line 389 of file Tensor2DI.H.

References SphericalTensor2D< Cmpt >::ii(), and Foam::Zero.

Here is the call graph for this function:

◆ vectorComponent()

Vector2D<Cmpt> vectorComponent ( const direction cmpt ) const

inline

Definition at line 235 of file Tensor2D.H.

References Tensor2D< Cmpt >::row().

Here is the call graph for this function:

◆ col() [5/5]

Foam::Vector2D<Cmpt> col ( ) const

inline

Definition at line 168 of file Tensor2DI.H.

References Foam::Zero.

◆ row() [5/5]

Foam::Vector2D<Cmpt> row ( ) const

inline

Definition at line 196 of file Tensor2DI.H.

References x, y, and Foam::Zero.

Member Data Documentation

◆ rank

constexpr direction rank = 2

staticconstexpr

Definition at line 70 of file Tensor2D.H.

◆ I

const Foam::tensor2D I

static

Definition at line 75 of file Tensor2D.H.

The documentation for this class was generated from the following files:

src/OpenFOAM/primitives/Tensor2D/Tensor2D.H
src/OpenFOAM/primitives/Tensor2D/tensor2D/tensor2D.C
src/OpenFOAM/primitives/Tensor2D/Tensor2DI.H

Public Types

Public Member Functions

Static Public Attributes

Additional Inherited Members

Detailed Description

template<class Cmpt> class Foam::Tensor2D< Cmpt >

Member Typedef Documentation

◆ labelType

Member Enumeration Documentation

◆ components

Constructor & Destructor Documentation

◆ Tensor2D() [1/9]

◆ Tensor2D() [2/9]

◆ Tensor2D() [3/9]

◆ Tensor2D() [4/9]

◆ Tensor2D() [5/9]

◆ Tensor2D() [6/9]

◆ Tensor2D() [7/9]

◆ Tensor2D() [8/9]

◆ Tensor2D() [9/9]

Member Function Documentation

◆ operator=() [1/3]

◆ xx() [1/2]

◆ xy() [1/2]

◆ yx() [1/2]

◆ yy() [1/2]

◆ xx() [2/2]

◆ xy() [2/2]

◆ yx() [2/2]

◆ yy() [2/2]

◆ cx()

◆ cy()

◆ col() [1/5]

◆ col() [2/5]

◆ col() [3/5]

◆ col() [4/5]

◆ cols()

◆ x()

◆ y()

◆ row() [1/5]

◆ row() [2/5]

◆ row() [3/5]

◆ row() [4/5]

◆ rows()

◆ diag() [1/2]

◆ diag() [2/2]

◆ T()

◆ inner()

◆ schur()

◆ operator=() [2/3]

◆ operator=() [3/3]

◆ vectorComponent()

◆ col() [5/5]

◆ row() [5/5]

Member Data Documentation

◆ rank

◆ I

template<class Cmpt>
class Foam::Tensor2D< Cmpt >
