SymmTensor2D< Cmpt > Class Template Reference

A templated (2 x 2) symmetric tensor of objects of <T>, effectively containing 3 elements, derived from VectorSpace. More...

Inheritance diagram for SymmTensor2D< Cmpt >:

Collaboration diagram for SymmTensor2D< Cmpt >:

Public Types
enum	components { XX, XY, YY }
typedef SymmTensor2D< label >	labelType
Public Types inherited from VectorSpace< SymmTensor2D< Cmpt >, Cmpt, 3 >
typedef VectorSpace< Form, Cmpt, Ncmpts >	vsType
typedef Cmpt	cmptType
typedef Cmpt	magType
typedef Cmpt *	iterator

Public Member Functions
	SymmTensor2D ()=default
	SymmTensor2D (const SymmTensor2D &)=default
SymmTensor2D &	operator= (const SymmTensor2D &)=default
	SymmTensor2D (const Foam::zero)
	SymmTensor2D (const VectorSpace< SymmTensor2D< Cmpt >, Cmpt, 3 > &)
	SymmTensor2D (const SphericalTensor2D< Cmpt > &)
	SymmTensor2D (const Cmpt txx, const Cmpt txy, const Cmpt tyy)
	SymmTensor2D (Istream &is)
const Cmpt &	xx () const
const Cmpt &	xy () const
const Cmpt &	yx () const
const Cmpt &	yy () const
Cmpt &	xx ()
Cmpt &	xy ()
Cmpt &	yx ()
Cmpt &	yy ()
Vector2D< Cmpt >	diag () const
void	diag (const Vector2D< Cmpt > &v)
const SymmTensor2D< Cmpt > &	T () const
void	operator= (const SphericalTensor2D< Cmpt > &)
Public Member Functions inherited from VectorSpace< SymmTensor2D< Cmpt >, Cmpt, 3 >
	VectorSpace ()=default
	VectorSpace (const Foam::zero)
	VectorSpace (const VectorSpace< Form, Cmpt, Ncmpts > &vs)
	VectorSpace (const VectorSpace< Form2, Cmpt2, Ncmpts > &)
	VectorSpace (Istream &is)
const Cmpt &	component (const direction) const
Cmpt &	component (const direction)
void	component (Cmpt &, const direction) const
void	replace (const direction, const Cmpt &)
const Cmpt *	cdata () const noexcept
Cmpt *	data () noexcept
const ConstBlock< SubVector, BStart >	block () const
const Foam::VectorSpace< Form, Cmpt, Ncmpts >::template ConstBlock< SubVector, BStart >	block () const
const Cmpt &	operator[] (const direction) const
Cmpt &	operator[] (const direction)
void	operator= (const VectorSpace< Form, Cmpt, Ncmpts > &)
void	operator= (const Foam::zero)
void	operator+= (const VectorSpace< Form, Cmpt, Ncmpts > &)
void	operator-= (const VectorSpace< Form, Cmpt, Ncmpts > &)
void	operator*= (const scalar)
void	operator/= (const scalar)
iterator	begin () noexcept
const_iterator	begin () const noexcept
iterator	end () noexcept
const_iterator	end () const noexcept
const_iterator	cbegin () const noexcept
const_iterator	cend () const noexcept

Static Public Attributes
static constexpr direction	rank = 2
static const SymmTensor2D	I
Static Public Attributes inherited from VectorSpace< SymmTensor2D< Cmpt >, Cmpt, 3 >
static constexpr direction	dim
static constexpr direction	nComponents
static constexpr direction	mRows
static constexpr direction	nCols
static const char *const	typeName
static const char *const	componentNames []
static const Form	zero
static const Form	one
static const Form	max
static const Form	min
static const Form	rootMax
static const Form	rootMin

Additional Inherited Members
Static Public Member Functions inherited from VectorSpace< SymmTensor2D< Cmpt >, Cmpt, 3 >
static constexpr direction	size () noexcept
static Form	uniform (const Cmpt &s)
Public Attributes inherited from VectorSpace< SymmTensor2D< Cmpt >, Cmpt, 3 >
const typedef Cmpt *	const_iterator
Cmpt	v_ [Ncmpts]

Detailed Description

template<class Cmpt>
class Foam::SymmTensor2D< Cmpt >

A templated (2 x 2) symmetric tensor of objects of <T>, effectively containing 3 elements, derived from VectorSpace.

See also

Test-SymmTensor2D.C

Source files

• SymmTensor2D.H
• SymmTensor2DI.H

Definition at line 54 of file SymmTensor2D.H.

Member Typedef Documentation

labelType

typedef SymmTensor2D<label> labelType

Definition at line 63 of file SymmTensor2D.H.

Member Enumeration Documentation

components

enum components

Enumerator
XX
XY
YY

Definition at line 78 of file SymmTensor2D.H.

Constructor & Destructor Documentation

SymmTensor2D() [1/7]

SymmTensor2D ( )

default

SymmTensor2D() [2/7]

SymmTensor2D ( const SymmTensor2D< Cmpt > &  )

default

SymmTensor2D() [3/7]

SymmTensor2D ( const Foam::zero  )

inline

Definition at line 27 of file SymmTensor2DI.H.

SymmTensor2D() [4/7]

SymmTensor2D ( const VectorSpace< SymmTensor2D< Cmpt >, Cmpt, 3 > &  vs )

inline

Definition at line 35 of file SymmTensor2DI.H.

SymmTensor2D() [5/7]

SymmTensor2D ( const SphericalTensor2D< Cmpt > &  st )

inline

Definition at line 44 of file SymmTensor2DI.H.

References SphericalTensor2D< Cmpt >::ii(), and Foam::Zero.

Here is the call graph for this function:

SymmTensor2D() [6/7]

SymmTensor2D ( const Cmpt  txx, const Cmpt  txy, const Cmpt  tyy  )

inline

Definition at line 53 of file SymmTensor2DI.H.

SymmTensor2D() [7/7]

SymmTensor2D ( Istream &  is )

inlineexplicit

Definition at line 64 of file SymmTensor2DI.H.

Member Function Documentation

operator=() [1/2]

SymmTensor2D& operator= ( const SymmTensor2D< Cmpt > &  )

default

xx() [1/2]

Cmpt & xx

inline

Definition at line 73 of file SymmTensor2DI.H.

Referenced by Foam::cof(), Foam::det(), Foam::innerSqr(), Foam::magSqr(), Foam::operator&(), Foam::operator&&(), Foam::operator+(), Foam::operator-(), Foam::operator/(), Tensor2D< Cmpt >::operator=(), Tensor2D< Cmpt >::Tensor2D(), and Foam::tr().

Here is the caller graph for this function:

xy() [1/2]

Cmpt & xy

inline

Definition at line 79 of file SymmTensor2DI.H.

Referenced by Foam::det(), Foam::innerSqr(), Foam::magSqr(), Foam::operator&(), Foam::operator&&(), Foam::operator+(), Foam::operator-(), Foam::operator/(), Tensor2D< Cmpt >::operator=(), and Tensor2D< Cmpt >::Tensor2D().

Here is the caller graph for this function:

yx() [1/2]

Cmpt & yx

inline

Definition at line 85 of file SymmTensor2DI.H.

Referenced by Foam::cof().

Here is the caller graph for this function:

yy() [1/2]

Cmpt & yy

inline

Definition at line 91 of file SymmTensor2DI.H.

Referenced by Foam::cof(), Foam::det(), Foam::innerSqr(), Foam::magSqr(), Foam::operator&(), Foam::operator&&(), Foam::operator+(), Foam::operator-(), Foam::operator/(), Tensor2D< Cmpt >::operator=(), Tensor2D< Cmpt >::Tensor2D(), and Foam::tr().

Here is the caller graph for this function:

xx() [2/2]

Cmpt& xx ( )

inline

xy() [2/2]

Cmpt& xy ( )

inline

yx() [2/2]

Cmpt& yx ( )

inline

yy() [2/2]

Cmpt& yy ( )

inline

diag() [1/2]

Foam::Vector2D< Cmpt > diag

inline

Definition at line 123 of file SymmTensor2DI.H.

diag() [2/2]

void diag ( const Vector2D< Cmpt > &  v )

inline

Definition at line 130 of file SymmTensor2DI.H.

References Vector2D< Cmpt >::x(), and Vector2D< Cmpt >::y().

Here is the call graph for this function:

T()

const Foam::SymmTensor2D< Cmpt > & T

inline

Definition at line 137 of file SymmTensor2DI.H.

operator=() [2/2]

void operator= ( const SphericalTensor2D< Cmpt > &  st )

inline

Definition at line 147 of file SymmTensor2DI.H.

References Foam::Zero.

Member Data Documentation

rank

constexpr direction rank = 2

staticconstexpr

Definition at line 69 of file SymmTensor2D.H.

I

const Foam::symmTensor2D I

static

Definition at line 74 of file SymmTensor2D.H.

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/primitives/SymmTensor2D/SymmTensor2D.H
• src/OpenFOAM/primitives/SymmTensor2D/symmTensor2D/symmTensor2D.C
• src/OpenFOAM/primitives/SymmTensor2D/SymmTensor2DI.H
