SRFWallVelocityFvPatchVectorField Class Reference

Wall-velocity condition to be used in conjunction with the single rotating frame (SRF) model (see: FOAM::SRFModel) More...

Inheritance diagram for SRFWallVelocityFvPatchVectorField:

Collaboration diagram for SRFWallVelocityFvPatchVectorField:

Public Member Functions
	TypeName ("SRFWallVelocity")
	SRFWallVelocityFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &)
	SRFWallVelocityFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &, const dictionary &)
	SRFWallVelocityFvPatchVectorField (const SRFWallVelocityFvPatchVectorField &, const fvPatch &, const DimensionedField< vector, volMesh > &, const fvPatchFieldMapper &)
	SRFWallVelocityFvPatchVectorField (const SRFWallVelocityFvPatchVectorField &)
virtual tmp< fvPatchVectorField >	clone () const
	SRFWallVelocityFvPatchVectorField (const SRFWallVelocityFvPatchVectorField &, const DimensionedField< vector, volMesh > &)
virtual tmp< fvPatchVectorField >	clone (const DimensionedField< vector, volMesh > &iF) const
virtual void	autoMap (const fvPatchFieldMapper &)
virtual void	rmap (const fvPatchVectorField &, const labelList &)
virtual void	updateCoeffs ()
virtual void	write (Ostream &) const

Detailed Description

Wall-velocity condition to be used in conjunction with the single rotating frame (SRF) model (see: FOAM::SRFModel)

The condition applies the appropriate rotation transformation in time and space to determine the local SRF velocity of the wall.

where

	=
	=

The normal component of is removed to ensure 0 wall-flux even if the wall patch faces are irregular.

Usage

Example of the boundary condition specification:

<patchName>
{
    type            SRFWallVelocity;
    value           uniform (0 0 0);    // Initial value
}

See also

Foam::SRFModel Foam::SRFVelocityFvPatchVectorField Foam::fixedValueFvPatchField

Source files

• SRFWallVelocityFvPatchVectorField.H
• SRFWallVelocityFvPatchVectorField.C

Definition at line 89 of file SRFWallVelocityFvPatchVectorField.H.

Constructor & Destructor Documentation

SRFWallVelocityFvPatchVectorField() [1/5]

SRFWallVelocityFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 30 of file SRFWallVelocityFvPatchVectorField.C.

Referenced by SRFWallVelocityFvPatchVectorField::clone().

Here is the caller graph for this function:

SRFWallVelocityFvPatchVectorField() [2/5]

SRFWallVelocityFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 52 of file SRFWallVelocityFvPatchVectorField.C.

SRFWallVelocityFvPatchVectorField() [3/5]

SRFWallVelocityFvPatchVectorField	(	const SRFWallVelocityFvPatchVectorField &	ptf,
		const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 40 of file SRFWallVelocityFvPatchVectorField.C.

SRFWallVelocityFvPatchVectorField() [4/5]

SRFWallVelocityFvPatchVectorField

(

const SRFWallVelocityFvPatchVectorField &

srfvpvf

)

Definition at line 63 of file SRFWallVelocityFvPatchVectorField.C.

SRFWallVelocityFvPatchVectorField() [5/5]

SRFWallVelocityFvPatchVectorField	(	const SRFWallVelocityFvPatchVectorField &	srfvpvf,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 72 of file SRFWallVelocityFvPatchVectorField.C.

Member Function Documentation

TypeName()

TypeName

(

"SRFWallVelocity"

)

clone() [1/2]

virtual tmp<fvPatchVectorField> clone ( ) const

inlinevirtual

Definition at line 134 of file SRFWallVelocityFvPatchVectorField.H.

References SRFWallVelocityFvPatchVectorField::SRFWallVelocityFvPatchVectorField().

Here is the call graph for this function:

clone() [2/2]

virtual tmp<fvPatchVectorField> clone ( const DimensionedField< vector, volMesh > &  iF ) const

inlinevirtual

Definition at line 151 of file SRFWallVelocityFvPatchVectorField.H.

References SRFWallVelocityFvPatchVectorField::SRFWallVelocityFvPatchVectorField().

Here is the call graph for this function:

autoMap()

void autoMap ( const fvPatchFieldMapper &  m )

virtual

Definition at line 84 of file SRFWallVelocityFvPatchVectorField.C.

rmap()

void rmap ( const fvPatchVectorField &  ptf, const labelList &  addr  )

virtual

Definition at line 93 of file SRFWallVelocityFvPatchVectorField.C.

updateCoeffs()

void updateCoeffs ( )

virtual

Definition at line 102 of file SRFWallVelocityFvPatchVectorField.C.

References n, Field::operator=(), Foam::foamVersion::patch, and SRFModel::velocity().

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Definition at line 125 of file SRFWallVelocityFvPatchVectorField.C.

References os(), and fvPatchField::write().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/finiteVolume/cfdTools/general/SRF/derivedFvPatchFields/SRFWallVelocityFvPatchVectorField/SRFWallVelocityFvPatchVectorField.H
• src/finiteVolume/cfdTools/general/SRF/derivedFvPatchFields/SRFWallVelocityFvPatchVectorField/SRFWallVelocityFvPatchVectorField.C
