SRFVelocityFvPatchVectorField Class Reference

Velocity condition to be used in conjunction with the single rotating frame (SRF) model (see: SRFModel class) More...

Inheritance diagram for SRFVelocityFvPatchVectorField:

Collaboration diagram for SRFVelocityFvPatchVectorField:

Public Member Functions
	TypeName ("SRFVelocity")
	SRFVelocityFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &)
	SRFVelocityFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &, const dictionary &)
	SRFVelocityFvPatchVectorField (const SRFVelocityFvPatchVectorField &, const fvPatch &, const DimensionedField< vector, volMesh > &, const fvPatchFieldMapper &)
	SRFVelocityFvPatchVectorField (const SRFVelocityFvPatchVectorField &)
virtual tmp< fvPatchVectorField >	clone () const
	SRFVelocityFvPatchVectorField (const SRFVelocityFvPatchVectorField &, const DimensionedField< vector, volMesh > &)
virtual tmp< fvPatchVectorField >	clone (const DimensionedField< vector, volMesh > &iF) const
bool	relative () const
virtual void	autoMap (const fvPatchFieldMapper &)
virtual void	rmap (const fvPatchVectorField &, const labelList &)
virtual void	updateCoeffs ()
virtual void	write (Ostream &) const

Detailed Description

Velocity condition to be used in conjunction with the single rotating frame (SRF) model (see: SRFModel class)

Given the free stream velocity in the absolute frame, the condition applies the appropriate rotation transformation in time and space to determine the local velocity.

The optional relative flag switches the behaviour of the patch such that:

• relative = yes: inlet velocity applied 'as is':

• relative = no : SRF velocity is subtracted from the inlet velocity:

where

	=	patch velocity [m/s]
	=	user-specified inlet velocity
	=	SRF velocity

Usage

Property	Description	Required	Default value
inletValue	inlet velocity	yes
relative	inletValue relative motion to the SRF?	yes

Example of the boundary condition specification:

    <patchName>
    {
        type            SRFVelocity;
        inletValue      uniform (0 0 0);
        relative        yes;
        value           uniform (0 0 0);    // initial value
    }

See also

Foam::fixedValueFvPatchField

Source files

• SRFVelocityFvPatchVectorField.H
• SRFVelocityFvPatchVectorField.C

Definition at line 127 of file SRFVelocityFvPatchVectorField.H.

Constructor & Destructor Documentation

SRFVelocityFvPatchVectorField() [1/5]

SRFVelocityFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 30 of file SRFVelocityFvPatchVectorField.C.

Referenced by SRFVelocityFvPatchVectorField::clone().

Here is the caller graph for this function:

SRFVelocityFvPatchVectorField() [2/5]

SRFVelocityFvPatchVectorField	(	const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const dictionary &	dict
	)

Definition at line 56 of file SRFVelocityFvPatchVectorField.C.

SRFVelocityFvPatchVectorField() [3/5]

SRFVelocityFvPatchVectorField	(	const SRFVelocityFvPatchVectorField &	ptf,
		const fvPatch &	p,
		const DimensionedField< vector, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Definition at line 42 of file SRFVelocityFvPatchVectorField.C.

SRFVelocityFvPatchVectorField() [4/5]

SRFVelocityFvPatchVectorField

(

const SRFVelocityFvPatchVectorField &

srfvpvf

)

Definition at line 69 of file SRFVelocityFvPatchVectorField.C.

SRFVelocityFvPatchVectorField() [5/5]

SRFVelocityFvPatchVectorField	(	const SRFVelocityFvPatchVectorField &	srfvpvf,
		const DimensionedField< vector, volMesh > &	iF
	)

Definition at line 80 of file SRFVelocityFvPatchVectorField.C.

Member Function Documentation

TypeName()

TypeName

(

"SRFVelocity"

)

clone() [1/2]

virtual tmp<fvPatchVectorField> clone ( ) const

inlinevirtual

Definition at line 180 of file SRFVelocityFvPatchVectorField.H.

References SRFVelocityFvPatchVectorField::SRFVelocityFvPatchVectorField().

Here is the call graph for this function:

clone() [2/2]

virtual tmp<fvPatchVectorField> clone ( const DimensionedField< vector, volMesh > &  iF ) const

inlinevirtual

Definition at line 197 of file SRFVelocityFvPatchVectorField.H.

References SRFVelocityFvPatchVectorField::SRFVelocityFvPatchVectorField().

Here is the call graph for this function:

relative()

bool relative ( ) const

inline

Definition at line 213 of file SRFVelocityFvPatchVectorField.H.

Referenced by SRFModel::Uabs().

Here is the caller graph for this function:

autoMap()

void autoMap ( const fvPatchFieldMapper &  m )

virtual

Definition at line 94 of file SRFVelocityFvPatchVectorField.C.

rmap()

void rmap ( const fvPatchVectorField &  ptf, const labelList &  addr  )

virtual

Definition at line 104 of file SRFVelocityFvPatchVectorField.C.

updateCoeffs()

void updateCoeffs ( )

virtual

Definition at line 118 of file SRFVelocityFvPatchVectorField.C.

References Foam::operator==(), Foam::foamVersion::patch, and SRFModel::velocity().

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Definition at line 148 of file SRFVelocityFvPatchVectorField.C.

References os(), fvPatchField::write(), and Ostream::writeEntry().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/finiteVolume/cfdTools/general/SRF/derivedFvPatchFields/SRFVelocityFvPatchVectorField/SRFVelocityFvPatchVectorField.H
• src/finiteVolume/cfdTools/general/SRF/derivedFvPatchFields/SRFVelocityFvPatchVectorField/SRFVelocityFvPatchVectorField.C
