SRFFreestreamVelocityFvPatchVectorField Class Reference

Freestream velocity condition to be used in conjunction with the single rotating frame (SRF) model (see: SRFModel class) More...

Inheritance diagram for SRFFreestreamVelocityFvPatchVectorField:
Inheritance graph
[legend]
Collaboration diagram for SRFFreestreamVelocityFvPatchVectorField:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("SRFFreestreamVelocity")

 SRFFreestreamVelocityFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &)

 SRFFreestreamVelocityFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &, const dictionary &)

 SRFFreestreamVelocityFvPatchVectorField (const SRFFreestreamVelocityFvPatchVectorField &, const fvPatch &, const DimensionedField< vector, volMesh > &, const fvPatchFieldMapper &)

 SRFFreestreamVelocityFvPatchVectorField (const SRFFreestreamVelocityFvPatchVectorField &)

virtual tmp< fvPatchVectorField > clone () const

 SRFFreestreamVelocityFvPatchVectorField (const SRFFreestreamVelocityFvPatchVectorField &, const DimensionedField< vector, volMesh > &)

virtual tmp< fvPatchVectorField > clone (const DimensionedField< vector, volMesh > &iF) const

const vector & UInf () const

vector & UInf ()

virtual void updateCoeffs ()

virtual void write (Ostream &) const


Detailed Description

Freestream velocity condition to be used in conjunction with the single rotating frame (SRF) model (see: SRFModel class)

Given the free stream velocity in the absolute frame, the condition applies the appropriate rotation transformation in time and space to determine the local velocity using:

\[ U_p = cos(\theta) U_{Inf} + sin(\theta) (n \times U_{Inf}) - U_{p,srf} \]

where

$ U_p $ = patch velocity [m/s]
$ U_{Inf} $ = free stream velocity in the absolute frame [m/s]
$ \theta $ = swept angle [rad]
$ n $ = axis direction of the SRF
$ U_{p,srf} $ = SRF velocity of the patch [m/s]
Usage
Property Description Required Default value
UInf freestream velocity yes
relative UInf relative to the SRF? no

Example of the boundary condition specification:

    <patchName>
    {
        type            SRFFreestreamVelocity;
        UInf            uniform (0 0 0);
        relative        no;
        value           uniform (0 0 0);    // initial value
    }
See also
Foam::freestreamFvPatchField Foam::SRFVelocityFvPatchVectorField
Source files

Definition at line 124 of file SRFFreestreamVelocityFvPatchVectorField.H.

Constructor & Destructor Documentation

◆ SRFFreestreamVelocityFvPatchVectorField() [1/5]

SRFFreestreamVelocityFvPatchVectorField ( const fvPatch &  p,
const DimensionedField< vector, volMesh > &  iF
)

Definition at line 34 of file SRFFreestreamVelocityFvPatchVectorField.C.

Referenced by SRFFreestreamVelocityFvPatchVectorField::clone().

Here is the caller graph for this function:

◆ SRFFreestreamVelocityFvPatchVectorField() [2/5]

SRFFreestreamVelocityFvPatchVectorField ( const fvPatch &  p,
const DimensionedField< vector, volMesh > &  iF,
const dictionary &  dict
)

Definition at line 62 of file SRFFreestreamVelocityFvPatchVectorField.C.

References dict, and p.

◆ SRFFreestreamVelocityFvPatchVectorField() [3/5]

SRFFreestreamVelocityFvPatchVectorField ( const SRFFreestreamVelocityFvPatchVectorField &  ptf,
const fvPatch &  p,
const DimensionedField< vector, volMesh > &  iF,
const fvPatchFieldMapper &  mapper
)

Definition at line 47 of file SRFFreestreamVelocityFvPatchVectorField.C.

◆ SRFFreestreamVelocityFvPatchVectorField() [4/5]

SRFFreestreamVelocityFvPatchVectorField ( const SRFFreestreamVelocityFvPatchVectorField &  srfvpvf)

Definition at line 80 of file SRFFreestreamVelocityFvPatchVectorField.C.

◆ SRFFreestreamVelocityFvPatchVectorField() [5/5]

SRFFreestreamVelocityFvPatchVectorField ( const SRFFreestreamVelocityFvPatchVectorField &  srfvpvf,
const DimensionedField< vector, volMesh > &  iF
)

Definition at line 92 of file SRFFreestreamVelocityFvPatchVectorField.C.

Member Function Documentation

◆ TypeName()

TypeName ( "SRFFreestreamVelocity"  )

◆ clone() [1/2]

virtual tmp<fvPatchVectorField> clone ( ) const
inlinevirtual

Definition at line 177 of file SRFFreestreamVelocityFvPatchVectorField.H.

References SRFFreestreamVelocityFvPatchVectorField::SRFFreestreamVelocityFvPatchVectorField().

Here is the call graph for this function:

◆ clone() [2/2]

virtual tmp<fvPatchVectorField> clone ( const DimensionedField< vector, volMesh > &  iF) const
inlinevirtual

Definition at line 194 of file SRFFreestreamVelocityFvPatchVectorField.H.

References SRFFreestreamVelocityFvPatchVectorField::SRFFreestreamVelocityFvPatchVectorField().

Here is the call graph for this function:

◆ UInf() [1/2]

const vector& UInf ( ) const
inline

Definition at line 210 of file SRFFreestreamVelocityFvPatchVectorField.H.

◆ UInf() [2/2]

vector& UInf ( )
inline

Definition at line 216 of file SRFFreestreamVelocityFvPatchVectorField.H.

◆ updateCoeffs()

void updateCoeffs ( )
virtual

Definition at line 105 of file SRFFreestreamVelocityFvPatchVectorField.C.

References SRFModel::axis(), Foam::cos(), Foam::mag(), mesh, Foam::name(), SRFModel::omega(), Foam::foamVersion::patch, Foam::pos0(), Foam::sin(), fvPatchField< Type >::updateCoeffs(), dimensioned::value(), and SRFModel::velocity().

Here is the call graph for this function:

◆ write()

void write ( Ostream &  os) const
virtual

Definition at line 154 of file SRFFreestreamVelocityFvPatchVectorField.C.

References os(), fvPatchField::write(), and Ostream::writeEntry().

Here is the call graph for this function:
The documentation for this class was generated from the following files:
