RecycleInteraction< CloudType > Class Template Reference

Patch interaction model to perform parcel transfer and recycle from one patch to another. More...

Inheritance diagram for RecycleInteraction< CloudType >:

Collaboration diagram for RecycleInteraction< CloudType >:

Public Member Functions
	TypeName ("recycleInteraction")
	RecycleInteraction (const dictionary &dict, CloudType &cloud)
	RecycleInteraction (const RecycleInteraction< CloudType > &pim)
virtual autoPtr< PatchInteractionModel< CloudType > >	clone () const
virtual	~RecycleInteraction ()=default
virtual bool	correct (typename CloudType::parcelType &p, const polyPatch &pp, bool &keepParticle)
virtual void	postEvolve ()
virtual void	info (Ostream &os)
Public Member Functions inherited from PatchInteractionModel< CloudType >
	TypeName ("patchInteractionModel")
	declareRunTimeSelectionTable (autoPtr, PatchInteractionModel, dictionary,(const dictionary &dict, CloudType &owner),(dict, owner))
	PatchInteractionModel (CloudType &owner)
	PatchInteractionModel (const dictionary &dict, CloudType &owner, const word &type)
	PatchInteractionModel (const PatchInteractionModel< CloudType > &pim)
virtual autoPtr< PatchInteractionModel< CloudType > >	clone () const=0
virtual	~PatchInteractionModel ()=default
const word &	UName () const
const scalar &	Urmax () const
virtual void	addToEscapedParcels (const scalar mass)

Protected Types
typedef CloudType::parcelType	parcelType

Protected Member Functions
virtual void	writeFileHeader (Ostream &os)

Protected Attributes
const fvMesh &	mesh_
List< Pair< word > >	recyclePatches_
List< Pair< label > >	recyclePatchesIds_
List< IDLList< parcelType > >	recycledParcels_
List< List< label > >	nRemoved_
List< List< scalar > >	massRemoved_
List< List< label > >	nInjected_
List< List< scalar > >	massInjected_
Map< label >	injIdToIndex_
PtrList< patchInjectionBase >	injectionPatchPtr_
const scalar	recycleFraction_
bool	outputByInjectorId_
Protected Attributes inherited from PatchInteractionModel< CloudType >
const word	UName_
label	escapedParcels_
scalar	escapedMass_
scalar	Urmax_

Additional Inherited Members
Public Types inherited from PatchInteractionModel< CloudType >
enum	interactionType
Static Public Member Functions inherited from PatchInteractionModel< CloudType >
static autoPtr< PatchInteractionModel< CloudType > >	New (const dictionary &dict, CloudType &owner)
static word	interactionTypeToWord (const interactionType &itEnum)
static interactionType	wordToInteractionType (const word &itWord)
Static Public Attributes inherited from PatchInteractionModel< CloudType >
static wordList	interactionTypeNames_

Detailed Description

template<class CloudType>
class Foam::RecycleInteraction< CloudType >

Patch interaction model to perform parcel transfer and recycle from one patch to another.

Parcels that hit a given 'outflow' patch are recycled to a given 'inflow' patch, with optional:

• recycle fraction [0-1]

Usage

Minimal example by using constant/reactingCloud1Properties.subModels.multiInteractionCoeffs

multiInteractionCoeffs
{
    ...

    model1
    {
        // Mandatory entries (unmodifiable)
        patchInteractionModel    recycleInteraction;

        recycleInteractionCoeffs
        {
            recyclePatches
            (
                (<outletPatch1> <inletPatch1>)
                (<outletPatch2> <inletPatch2>)
                ...
            );

            recycleFraction      0.8; // [0-1]

            // Optional entries (unmodifiable)
            outputByInjectorId   false;
        }
    }

    ...
}

where the entries mean:

Property	Description	Type	Reqd	Dflt
patchInteractionModel	Type name: recycleInteraction	word	yes	-
recyclePatches	Names of outlet-inlet patch pairs	(word word)	yes	-
recycleFraction	Fraction of parcels recycled from outlet to inlet	scalar	yes	-
outputByInjectorId	Flag to output escaped/mass particles sorted by injectorID	bool	no	false

Source files

• RecycleInteraction.H
• RecycleInteraction.C

Definition at line 141 of file RecycleInteraction.H.

Member Typedef Documentation

parcelType

typedef CloudType::parcelType parcelType

protected

Definition at line 147 of file RecycleInteraction.H.

Constructor & Destructor Documentation

RecycleInteraction() [1/2]

RecycleInteraction	(	const dictionary &	dict,
		CloudType &	cloud
	)

Definition at line 57 of file RecycleInteraction.C.

References forAll, and Foam::Zero.

RecycleInteraction() [2/2]

RecycleInteraction

(

const RecycleInteraction< CloudType > &

pim

)

Definition at line 127 of file RecycleInteraction.C.

~RecycleInteraction()

virtual ~RecycleInteraction ( )

virtualdefault

Member Function Documentation

writeFileHeader()

void writeFileHeader ( Ostream &  os )

protectedvirtual

Reimplemented from PatchInteractionModel< CloudType >.

Definition at line 26 of file RecycleInteraction.C.

References forAll, Foam::name(), and os().

Here is the call graph for this function:

TypeName()

TypeName

(

"recycleInteraction"

)

clone()

virtual autoPtr<PatchInteractionModel<CloudType> > clone ( ) const

inlinevirtual

Definition at line 213 of file RecycleInteraction.H.

correct()

bool correct ( typename CloudType::parcelType &  p, const polyPatch &  pp, bool &  keepParticle  )

virtual

Implements PatchInteractionModel< CloudType >.

Definition at line 150 of file RecycleInteraction.C.

References forAll, patchIdentifier::index(), and p.

Here is the call graph for this function:

postEvolve()

void postEvolve

virtual

Reimplemented from PatchInteractionModel< CloudType >.

Definition at line 197 of file RecycleInteraction.C.

References List::append(), PstreamBuffers::clear(), List::clear(), PstreamBuffers::finishedSends(), forAll, forAllIters, fractions(), mesh, n, reduce(), and rndGen.

Here is the call graph for this function:

info()

void info ( Ostream &  os )

virtual

Reimplemented from PatchInteractionModel< CloudType >.

Definition at line 365 of file RecycleInteraction.C.

References Foam::endl(), forAll, forAllConstIters(), Foam::nl, os(), List::setSize(), Foam::tab, and Foam::Zero.

Here is the call graph for this function:

Member Data Documentation

mesh_

const fvMesh& mesh_

protected

Definition at line 152 of file RecycleInteraction.H.

recyclePatches_

List<Pair<word> > recyclePatches_

protected

Definition at line 155 of file RecycleInteraction.H.

recyclePatchesIds_

List<Pair<label> > recyclePatchesIds_

protected

Definition at line 158 of file RecycleInteraction.H.

recycledParcels_

List<IDLList<parcelType> > recycledParcels_

protected

Definition at line 161 of file RecycleInteraction.H.

nRemoved_

List<List<label> > nRemoved_

protected

Definition at line 167 of file RecycleInteraction.H.

massRemoved_

List<List<scalar> > massRemoved_

protected

Definition at line 170 of file RecycleInteraction.H.

nInjected_

List<List<label> > nInjected_

protected

Definition at line 173 of file RecycleInteraction.H.

massInjected_

List<List<scalar> > massInjected_

protected

Definition at line 176 of file RecycleInteraction.H.

injIdToIndex_

Map<label> injIdToIndex_

protected

Definition at line 180 of file RecycleInteraction.H.

injectionPatchPtr_

PtrList<patchInjectionBase> injectionPatchPtr_

protected

Definition at line 183 of file RecycleInteraction.H.

recycleFraction_

const scalar recycleFraction_

protected

Definition at line 186 of file RecycleInteraction.H.

outputByInjectorId_

bool outputByInjectorId_

protected

Definition at line 189 of file RecycleInteraction.H.

---

The documentation for this class was generated from the following files:

• src/lagrangian/intermediate/submodels/Kinematic/PatchInteractionModel/RecycleInteraction/RecycleInteraction.H
• src/lagrangian/intermediate/submodels/Kinematic/PatchInteractionModel/RecycleInteraction/RecycleInteraction.C
