kOmegaSSTLM< BasicTurbulenceModel > Class Template Reference
Turbulence models » LES turbulence

Langtry-Menter 4-equation transitional SST model based on the k-omega-SST RAS model. More...

Inheritance diagram for kOmegaSSTLM< BasicTurbulenceModel >:
Inheritance graph
[legend]
Collaboration diagram for kOmegaSSTLM< BasicTurbulenceModel >:
Collaboration graph
[legend]

Public Types

typedef BasicTurbulenceModel::alphaField alphaField

typedef BasicTurbulenceModel::rhoField rhoField

typedef BasicTurbulenceModel::transportModel transportModel

- Public Types inherited from kOmegaSST< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField alphaField

typedef BasicTurbulenceModel::rhoField rhoField

typedef BasicTurbulenceModel::transportModel transportModel

- Public Types inherited from kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >
typedef eddyViscosity< RASModel< BasicTurbulenceModel > > ::alphaField alphaField

typedef eddyViscosity< RASModel< BasicTurbulenceModel > > ::rhoField rhoField

typedef eddyViscosity< RASModel< BasicTurbulenceModel > > ::transportModel transportModel

- Public Types inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
typedef RASModel< BasicTurbulenceModel > ::alphaField alphaField

typedef RASModel< BasicTurbulenceModel > ::rhoField rhoField

typedef RASModel< BasicTurbulenceModel > ::transportModel transportModel

- Public Types inherited from linearViscousStress< RASModel< BasicTurbulenceModel > >
typedef RASModel< BasicTurbulenceModel > ::alphaField alphaField

typedef RASModel< BasicTurbulenceModel > ::rhoField rhoField

typedef RASModel< BasicTurbulenceModel > ::transportModel transportModel

- Public Types inherited from RASModel< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField alphaField

typedef BasicTurbulenceModel::rhoField rhoField

typedef BasicTurbulenceModel::transportModel transportModel


Public Member Functions

 TypeName ("kOmegaSSTLM")

 kOmegaSSTLM (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)

virtual ~kOmegaSSTLM ()=default

virtual bool read ()

const volScalarField & ReThetat () const

const volScalarField & gammaInt () const

tmp< volScalarField > DReThetatEff () const

tmp< volScalarField > DgammaIntEff () const

virtual void correct ()

- Public Member Functions inherited from kOmegaSST< BasicTurbulenceModel >
 TypeName ("kOmegaSST")

 kOmegaSST (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)

virtual ~kOmegaSST ()=default

- Public Member Functions inherited from kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >
 kOmegaSSTBase (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName)

virtual ~kOmegaSSTBase ()=default

tmp< volScalarField > DkEff (const volScalarField &F1) const

tmp< volScalarField > DomegaEff (const volScalarField &F1) const

virtual tmp< volScalarField > k () const

virtual tmp< volScalarField > omega () const

- Public Member Functions inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
 eddyViscosity (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual ~eddyViscosity ()=default

virtual tmp< volScalarField > nut () const

virtual tmp< scalarField > nut (const label patchi) const

virtual tmp< volSymmTensorField > R () const

virtual void validate ()

- Public Member Functions inherited from linearViscousStress< RASModel< BasicTurbulenceModel > >
 linearViscousStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual ~linearViscousStress ()=default

virtual tmp< volSymmTensorField > devRhoReff () const

virtual tmp< volSymmTensorField > devRhoReff (const volVectorField &U) const

virtual tmp< fvVectorMatrix > divDevRhoReff (volVectorField &U) const

virtual tmp< fvVectorMatrix > divDevRhoReff (const volScalarField &rho, volVectorField &U) const

- Public Member Functions inherited from RASModel< BasicTurbulenceModel >
 TypeName ("RAS")

 declareRunTimeSelectionTable (autoPtr, RASModel, dictionary,(const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName),(alpha, rho, U, alphaRhoPhi, phi, transport, propertiesName))

 RASModel (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual ~RASModel ()=default

const dimensionedScalar & kMin () const

const dimensionedScalar & epsilonMin () const

const dimensionedScalar & omegaMin () const

dimensionedScalar & kMin ()

dimensionedScalar & epsilonMin ()

dimensionedScalar & omegaMin ()

virtual const dictionary & coeffDict () const

virtual tmp< volScalarField > nuEff () const

virtual tmp< scalarField > nuEff (const label patchi) const

virtual tmp< volScalarField > epsilon () const

virtual tmp< volScalarField > omega () const


Protected Member Functions

virtual tmp< volScalarField > F1 (const volScalarField &CDkOmega) const

virtual tmp< volScalarField::Internal > Pk (const volScalarField::Internal &G) const

virtual tmp< volScalarField::Internal > epsilonByk (const volScalarField &F1, const volTensorField &gradU) const

tmp< volScalarField::Internal > Fthetat (const volScalarField::Internal &Us, const volScalarField::Internal &Omega, const volScalarField::Internal &nu) const

tmp< volScalarField::Internal > ReThetac () const

tmp< volScalarField::Internal > Flength (const volScalarField::Internal &nu) const

tmp< volScalarField::Internal > Fonset (const volScalarField::Internal &Rev, const volScalarField::Internal &ReThetac, const volScalarField::Internal &RT) const

tmp< volScalarField::Internal > ReThetat0 (const volScalarField::Internal &Us, const volScalarField::Internal &dUsds, const volScalarField::Internal &nu) const

void correctReThetatGammaInt ()

- Protected Member Functions inherited from kOmegaSST< BasicTurbulenceModel >
virtual void correctNut (const volScalarField &S2)

virtual void correctNut ()

- Protected Member Functions inherited from kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >
void setDecayControl (const dictionary &dict)

virtual tmp< volScalarField > F2 () const

virtual tmp< volScalarField > F3 () const

virtual tmp< volScalarField > F23 () const

tmp< volScalarField > blend (const volScalarField &F1, const dimensionedScalar &psi1, const dimensionedScalar &psi2) const

tmp< volScalarField::Internal > blend (const volScalarField::Internal &F1, const dimensionedScalar &psi1, const dimensionedScalar &psi2) const

tmp< volScalarField > alphaK (const volScalarField &F1) const

tmp< volScalarField > alphaOmega (const volScalarField &F1) const

tmp< volScalarField::Internal > beta (const volScalarField::Internal &F1) const

tmp< volScalarField::Internal > gamma (const volScalarField::Internal &F1) const

virtual tmp< volScalarField::Internal > GbyNu (const volScalarField::Internal &GbyNu0, const volScalarField::Internal &F2, const volScalarField::Internal &S2) const

virtual tmp< fvScalarMatrix > kSource () const

virtual tmp< fvScalarMatrix > omegaSource () const

virtual tmp< fvScalarMatrix > Qsas (const volScalarField::Internal &S2, const volScalarField::Internal &gamma, const volScalarField::Internal &beta) const

- Protected Member Functions inherited from RASModel< BasicTurbulenceModel >
virtual void printCoeffs (const word &type)

 RASModel (const RASModel &)=delete

void operator= (const RASModel &)=delete


Protected Attributes

dimensionedScalar ca1_

dimensionedScalar ca2_

dimensionedScalar ce1_

dimensionedScalar ce2_

dimensionedScalar cThetat_

dimensionedScalar sigmaThetat_

scalar lambdaErr_

label maxLambdaIter_

const dimensionedScalar deltaU_

volScalarField ReThetat_

volScalarField gammaInt_

volScalarField::Internal gammaIntEff_

- Protected Attributes inherited from kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >
dimensionedScalar alphaK1_

dimensionedScalar alphaK2_

dimensionedScalar alphaOmega1_

dimensionedScalar alphaOmega2_

dimensionedScalar gamma1_

dimensionedScalar gamma2_

dimensionedScalar beta1_

dimensionedScalar beta2_

dimensionedScalar betaStar_

dimensionedScalar a1_

dimensionedScalar b1_

dimensionedScalar c1_

Switch F3_

const volScalarField & y_

volScalarField k_

volScalarField omega_

Switch decayControl_

dimensionedScalar kInf_

dimensionedScalar omegaInf_

- Protected Attributes inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
volScalarField nut_

- Protected Attributes inherited from RASModel< BasicTurbulenceModel >
dictionary RASDict_

Switch turbulence_

Switch printCoeffs_

dictionary coeffDict_

dimensionedScalar kMin_

dimensionedScalar epsilonMin_

dimensionedScalar omegaMin_


Additional Inherited Members

- Static Public Member Functions inherited from RASModel< BasicTurbulenceModel >
static autoPtr< RASModel > New (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName)


Detailed Description

template<class BasicTurbulenceModel>
class Foam::RASModels::kOmegaSSTLM< BasicTurbulenceModel >

Langtry-Menter 4-equation transitional SST model based on the k-omega-SST RAS model.

References:

    Langtry, R. B., & Menter, F. R. (2009).
    Correlation-based transition modeling for unstructured parallelized
    computational fluid dynamics codes.
    AIAA journal, 47(12), 2894-2906.

    Menter, F. R., Langtry, R., & Volker, S. (2006).
    Transition modelling for general purpose CFD codes.
    Flow, turbulence and combustion, 77(1-4), 277-303.

    Langtry, R. B. (2006).
    A correlation-based transition model using local variables for
    unstructured parallelized CFD codes.
    Phd. Thesis, Universität Stuttgart.

The model coefficients are

    kOmegaSSTCoeffs
    {
        // Default SST coefficients
        alphaK1     0.85;
        alphaK2     1;
        alphaOmega1 0.5;
        alphaOmega2 0.856;
        beta1       0.075;
        beta2       0.0828;
        betaStar    0.09;
        gamma1      5/9;
        gamma2      0.44;
        a1          0.31;
        b1          1;
        c1          10;
        F3          no;

        // Default LM coefficients
        ca1         2;
        ca2         0.06;
        ce1         1;
        ce2         50;
        cThetat     0.03;
        sigmaThetat 2;

        lambdaErr   1e-6;
        maxLambdaIter 10;
    }
Source files

Definition at line 103 of file kOmegaSSTLM.H.

Member Typedef Documentation

◆ alphaField

typedef BasicTurbulenceModel::alphaField alphaField

Definition at line 213 of file kOmegaSSTLM.H.

◆ rhoField

typedef BasicTurbulenceModel::rhoField rhoField

Definition at line 214 of file kOmegaSSTLM.H.

◆ transportModel

typedef BasicTurbulenceModel::transportModel transportModel

Definition at line 215 of file kOmegaSSTLM.H.

Constructor & Destructor Documentation

◆ kOmegaSSTLM()

kOmegaSSTLM ( const alphaField &  alpha,
const rhoField &  rho,
const volVectorField &  U,
const surfaceScalarField &  alphaRhoPhi,
const surfaceScalarField &  phi,
const transportModel &  transport,
const word &  propertiesName = turbulenceModel::propertiesName,
const word &  type = typeName
)

Definition at line 360 of file kOmegaSSTLM.C.

References Foam::type().

Here is the call graph for this function:

◆ ~kOmegaSSTLM()

virtual ~kOmegaSSTLM ( )
virtualdefault

Member Function Documentation

◆ F1()

tmp< volScalarField > F1 ( const volScalarField &  CDkOmega) const
protectedvirtual

Reimplemented from kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >.

Definition at line 37 of file kOmegaSSTLM.C.

References Foam::exp(), F3, Foam::max(), nu, Foam::pow(), Foam::Ry(), and Foam::sqrt().

Here is the call graph for this function:

◆ Pk()

tmp< volScalarField::Internal > Pk ( const volScalarField::Internal &  G) const
protectedvirtual

Reimplemented from kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >.

Definition at line 50 of file kOmegaSSTLM.C.

References Foam::constant::universal::G, and kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::Pk().

Here is the call graph for this function:

◆ epsilonByk()

tmp< volScalarField::Internal > epsilonByk ( const volScalarField &  F1,
const volTensorField &  gradU
) const
protectedvirtual

Reimplemented from kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >.

Definition at line 60 of file kOmegaSSTLM.C.

References kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::epsilonByk(), F1, Foam::max(), and Foam::min().

Here is the call graph for this function:

◆ Fthetat()

tmp< volScalarField::Internal > Fthetat ( const volScalarField::Internal &  Us,
const volScalarField::Internal &  Omega,
const volScalarField::Internal &  nu
) const
protected

Definition at line 73 of file kOmegaSSTLM.C.

References delta, Foam::dimLength, Foam::exp(), IOobject::groupName(), Foam::max(), Foam::min(), nu, Foam::pow4(), Foam::sqr(), Us, and y.

Here is the call graph for this function:

◆ ReThetac()

tmp< volScalarField::Internal > ReThetac
protected

Definition at line 112 of file kOmegaSSTLM.C.

References Foam::dimless, forAll, IOobject::groupName(), Foam::pow3(), Foam::pow4(), tmp::ref(), and Foam::sqr().

Here is the call graph for this function:

◆ Flength()

tmp< volScalarField::Internal > Flength ( const volScalarField::Internal &  nu) const
protected

Definition at line 153 of file kOmegaSSTLM.C.

References Foam::dimless, Foam::constant::electromagnetic::e, Foam::exp(), forAll, IOobject::groupName(), nu, Foam::pow3(), tmp::ref(), Foam::sqr(), and y.

Here is the call graph for this function:

◆ Fonset()

tmp< volScalarField::Internal > Fonset ( const volScalarField::Internal &  Rev,
const volScalarField::Internal &  ReThetac,
const volScalarField::Internal &  RT
) const
protected

Definition at line 330 of file kOmegaSSTLM.C.

References IOobject::groupName(), Foam::max(), Foam::min(), Foam::pow3(), and Foam::pow4().

Here is the call graph for this function:

◆ ReThetat0()

tmp< volScalarField::Internal > ReThetat0 ( const volScalarField::Internal &  Us,
const volScalarField::Internal &  dUsds,
const volScalarField::Internal &  nu
) const
protected

Definition at line 216 of file kOmegaSSTLM.C.

References Foam::dimless, Foam::endl(), Foam::exp(), forAll, IOobject::groupName(), k, lambda(), Foam::mag(), Foam::max(), Foam::min(), nu, Foam::pow(), Foam::pow3(), tmp::ref(), Foam::sqr(), Foam::sqrt(), Us, and WarningInFunction.

Here is the call graph for this function:

◆ correctReThetatGammaInt()

void correctReThetatGammaInt
protected

Definition at line 516 of file kOmegaSSTLM.C.

References Foam::constant::atomic::alpha, Foam::bound(), tmp::clear(), Foam::fvm::ddt(), Foam::fvm::div(), Foam::exp(), fvOptions, Foam::fvc::grad(), k, Foam::fvm::laplacian(), Foam::mag(), Foam::magSqr(), Foam::max(), Foam::min(), options::New(), nu, Foam::pow4(), tmp::ref(), rho, Foam::skew(), Foam::solve(), Foam::fvm::Sp(), Foam::sqr(), Foam::sqrt(), Foam::symm(), U, Us, and y.

Here is the call graph for this function:

◆ TypeName()

TypeName ( "kOmegaSSTLM< BasicTurbulenceModel >"  )

◆ read()

bool read
virtual

Reimplemented from kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >.

Definition at line 495 of file kOmegaSSTLM.C.

◆ ReThetat()

const volScalarField& ReThetat ( ) const
inline

Definition at line 248 of file kOmegaSSTLM.H.

References kOmegaSSTLM< BasicTurbulenceModel >::ReThetat_.

◆ gammaInt()

const volScalarField& gammaInt ( ) const
inline

Definition at line 254 of file kOmegaSSTLM.H.

References kOmegaSSTLM< BasicTurbulenceModel >::gammaInt_.

◆ DReThetatEff()

tmp<volScalarField> DReThetatEff ( ) const
inline

Definition at line 261 of file kOmegaSSTLM.H.

References nu, eddyViscosity< RASModel< BasicTurbulenceModel > >::nut_, and kOmegaSSTLM< BasicTurbulenceModel >::sigmaThetat_.

◆ DgammaIntEff()

tmp<volScalarField> DgammaIntEff ( ) const
inline

Definition at line 274 of file kOmegaSSTLM.H.

References nu, and eddyViscosity< RASModel< BasicTurbulenceModel > >::nut_.

◆ correct()

void correct
virtual

Reimplemented from kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >.

Definition at line 614 of file kOmegaSSTLM.C.

References kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >::correct().

Here is the call graph for this function:

Member Data Documentation

◆ ca1_

dimensionedScalar ca1_
protected

Definition at line 122 of file kOmegaSSTLM.H.

◆ ca2_

dimensionedScalar ca2_
protected

Definition at line 123 of file kOmegaSSTLM.H.

◆ ce1_

dimensionedScalar ce1_
protected

Definition at line 125 of file kOmegaSSTLM.H.

◆ ce2_

dimensionedScalar ce2_
protected

Definition at line 126 of file kOmegaSSTLM.H.

◆ cThetat_

dimensionedScalar cThetat_
protected

Definition at line 128 of file kOmegaSSTLM.H.

◆ sigmaThetat_

dimensionedScalar sigmaThetat_
protected

Definition at line 129 of file kOmegaSSTLM.H.

Referenced by kOmegaSSTLM< BasicTurbulenceModel >::DReThetatEff().

◆ lambdaErr_

scalar lambdaErr_
protected

Definition at line 132 of file kOmegaSSTLM.H.

◆ maxLambdaIter_

label maxLambdaIter_
protected

Definition at line 135 of file kOmegaSSTLM.H.

◆ deltaU_

const dimensionedScalar deltaU_
protected

Definition at line 138 of file kOmegaSSTLM.H.

◆ ReThetat_

volScalarField ReThetat_
protected

Definition at line 144 of file kOmegaSSTLM.H.

Referenced by kOmegaSSTLM< BasicTurbulenceModel >::ReThetat().

◆ gammaInt_

volScalarField gammaInt_
protected

Definition at line 147 of file kOmegaSSTLM.H.

Referenced by kOmegaSSTLM< BasicTurbulenceModel >::gammaInt().

◆ gammaIntEff_

volScalarField::Internal gammaIntEff_
protected

Definition at line 150 of file kOmegaSSTLM.H.

The documentation for this class was generated from the following files:

Copyright © 2011-2018  OpenFOAM | OPENFOAM® is a registered trademark of OpenCFD Ltd.

Generated by   doxygen 1.8.17
