Public Types | Public Member Functions | Protected Member Functions | List of all members
kOmegaSST< BasicTurbulenceModel > Class Template Reference
Turbulence models » RAS turbulence

Implementation of the k-omega-SST turbulence model for incompressible and compressible flows. More...

Inheritance diagram for kOmegaSST< BasicTurbulenceModel >:
Inheritance graph
[legend]
Collaboration diagram for kOmegaSST< BasicTurbulenceModel >:
Collaboration graph
[legend]

Public Types

typedef BasicTurbulenceModel::alphaField alphaField

typedef BasicTurbulenceModel::rhoField rhoField

typedef BasicTurbulenceModel::transportModel transportModel

- Public Types inherited from kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >
typedef eddyViscosity< RASModel< BasicTurbulenceModel > > ::alphaField alphaField

typedef eddyViscosity< RASModel< BasicTurbulenceModel > > ::rhoField rhoField

typedef eddyViscosity< RASModel< BasicTurbulenceModel > > ::transportModel transportModel

- Public Types inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
typedef RASModel< BasicTurbulenceModel > ::alphaField alphaField

typedef RASModel< BasicTurbulenceModel > ::rhoField rhoField

typedef RASModel< BasicTurbulenceModel > ::transportModel transportModel

- Public Types inherited from linearViscousStress< RASModel< BasicTurbulenceModel > >
typedef RASModel< BasicTurbulenceModel > ::alphaField alphaField

typedef RASModel< BasicTurbulenceModel > ::rhoField rhoField

typedef RASModel< BasicTurbulenceModel > ::transportModel transportModel

- Public Types inherited from RASModel< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField alphaField

typedef BasicTurbulenceModel::rhoField rhoField

typedef BasicTurbulenceModel::transportModel transportModel


Public Member Functions

 TypeName ("kOmegaSST")

 kOmegaSST (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)

virtual ~kOmegaSST ()=default

- Public Member Functions inherited from kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >
 kOmegaSSTBase (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName)

virtual ~kOmegaSSTBase ()=default

virtual bool read ()

tmp< volScalarField > DkEff (const volScalarField &F1) const

tmp< volScalarField > DomegaEff (const volScalarField &F1) const

virtual tmp< volScalarField > k () const

virtual tmp< volScalarField > omega () const

virtual void correct ()

- Public Member Functions inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
 eddyViscosity (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual ~eddyViscosity ()=default

virtual tmp< volScalarField > nut () const

virtual tmp< scalarField > nut (const label patchi) const

virtual tmp< volSymmTensorField > R () const

virtual void validate ()

- Public Member Functions inherited from linearViscousStress< RASModel< BasicTurbulenceModel > >
 linearViscousStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual ~linearViscousStress ()=default

virtual tmp< volSymmTensorField > devRhoReff () const

virtual tmp< volSymmTensorField > devRhoReff (const volVectorField &U) const

virtual tmp< fvVectorMatrix > divDevRhoReff (volVectorField &U) const

virtual tmp< fvVectorMatrix > divDevRhoReff (const volScalarField &rho, volVectorField &U) const

- Public Member Functions inherited from RASModel< BasicTurbulenceModel >
 TypeName ("RAS")

 declareRunTimeSelectionTable (autoPtr, RASModel, dictionary,(const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName),(alpha, rho, U, alphaRhoPhi, phi, transport, propertiesName))

 RASModel (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual ~RASModel ()=default

const dimensionedScalar & kMin () const

const dimensionedScalar & epsilonMin () const

const dimensionedScalar & omegaMin () const

dimensionedScalar & kMin ()

dimensionedScalar & epsilonMin ()

dimensionedScalar & omegaMin ()

virtual const dictionary & coeffDict () const

virtual tmp< volScalarField > nuEff () const

virtual tmp< scalarField > nuEff (const label patchi) const

virtual tmp< volScalarField > epsilon () const

virtual tmp< volScalarField > omega () const


Protected Member Functions

virtual void correctNut (const volScalarField &S2)

virtual void correctNut ()

- Protected Member Functions inherited from kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >
void setDecayControl (const dictionary &dict)

virtual tmp< volScalarField > F1 (const volScalarField &CDkOmega) const

virtual tmp< volScalarField > F2 () const

virtual tmp< volScalarField > F3 () const

virtual tmp< volScalarField > F23 () const

tmp< volScalarField > blend (const volScalarField &F1, const dimensionedScalar &psi1, const dimensionedScalar &psi2) const

tmp< volScalarField::Internal > blend (const volScalarField::Internal &F1, const dimensionedScalar &psi1, const dimensionedScalar &psi2) const

tmp< volScalarField > alphaK (const volScalarField &F1) const

tmp< volScalarField > alphaOmega (const volScalarField &F1) const

tmp< volScalarField::Internal > beta (const volScalarField::Internal &F1) const

tmp< volScalarField::Internal > gamma (const volScalarField::Internal &F1) const

virtual tmp< volScalarField::Internal > Pk (const volScalarField::Internal &G) const

virtual tmp< volScalarField::Internal > epsilonByk (const volScalarField &F1, const volTensorField &gradU) const

virtual tmp< volScalarField::Internal > GbyNu (const volScalarField::Internal &GbyNu0, const volScalarField::Internal &F2, const volScalarField::Internal &S2) const

virtual tmp< fvScalarMatrix > kSource () const

virtual tmp< fvScalarMatrix > omegaSource () const

virtual tmp< fvScalarMatrix > Qsas (const volScalarField::Internal &S2, const volScalarField::Internal &gamma, const volScalarField::Internal &beta) const

- Protected Member Functions inherited from RASModel< BasicTurbulenceModel >
virtual void printCoeffs (const word &type)

 RASModel (const RASModel &)=delete

void operator= (const RASModel &)=delete


Additional Inherited Members

- Static Public Member Functions inherited from RASModel< BasicTurbulenceModel >
static autoPtr< RASModel > New (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName)

- Protected Attributes inherited from kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >
dimensionedScalar alphaK1_

dimensionedScalar alphaK2_

dimensionedScalar alphaOmega1_

dimensionedScalar alphaOmega2_

dimensionedScalar gamma1_

dimensionedScalar gamma2_

dimensionedScalar beta1_

dimensionedScalar beta2_

dimensionedScalar betaStar_

dimensionedScalar a1_

dimensionedScalar b1_

dimensionedScalar c1_

Switch F3_

const volScalarField & y_

volScalarField k_

volScalarField omega_

Switch decayControl_

dimensionedScalar kInf_

dimensionedScalar omegaInf_

- Protected Attributes inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
volScalarField nut_

- Protected Attributes inherited from RASModel< BasicTurbulenceModel >
dictionary RASDict_

Switch turbulence_

Switch printCoeffs_

dictionary coeffDict_

dimensionedScalar kMin_

dimensionedScalar epsilonMin_

dimensionedScalar omegaMin_


Detailed Description

template<class BasicTurbulenceModel>
class Foam::RASModels::kOmegaSST< BasicTurbulenceModel >

Implementation of the k-omega-SST turbulence model for incompressible and compressible flows.

Light wrapper around base class.

Turbulence model described in:

    Menter, F. R. & Esch, T. (2001).
    Elements of Industrial Heat Transfer Prediction.
    16th Brazilian Congress of Mechanical Engineering (COBEM).

with updated coefficients from

    Menter, F. R., Kuntz, M., and Langtry, R. (2003).
    Ten Years of Industrial Experience with the SST Turbulence Model.
    Turbulence, Heat and Mass Transfer 4, ed: K. Hanjalic, Y. Nagano,
    & M. Tummers, Begell House, Inc., 625 - 632.

but with the consistent production terms from the 2001 paper as form in the 2003 paper is a typo, see

    http://turbmodels.larc.nasa.gov/sst.html

and the addition of the optional F3 term for rough walls from

    Hellsten, A. (1998).
    "Some Improvements in Menter’s k-omega-SST turbulence model"
    29th AIAA Fluid Dynamics Conference, AIAA-98-2554.

Note that this implementation is written in terms of alpha diffusion coefficients rather than the more traditional sigma (alpha = 1/sigma) so that the blending can be applied to all coefficuients in a consistent manner. The paper suggests that sigma is blended but this would not be consistent with the blending of the k-epsilon and k-omega models.

Also note that the error in the last term of equation (2) relating to sigma has been corrected.

Wall-functions are applied in this implementation by using equations (14) to specify the near-wall omega as appropriate.

The blending functions (15) and (16) are not currently used because of the uncertainty in their origin, range of applicability and that if y+ becomes sufficiently small blending u_tau in this manner clearly becomes nonsense.

The default model coefficients are

    kOmegaSSTCoeffs
    {
        alphaK1     0.85;
        alphaK2     1.0;
        alphaOmega1 0.5;
        alphaOmega2 0.856;
        beta1       0.075;
        beta2       0.0828;
        betaStar    0.09;
        gamma1      5/9;
        gamma2      0.44;
        a1          0.31;
        b1          1.0;
        c1          10.0;
        F3          no;
    }
Source files
See also
kOmegaSSTBase.H

Definition at line 125 of file kOmegaSST.H.

Member Typedef Documentation

◆ alphaField

typedef BasicTurbulenceModel::alphaField alphaField

Definition at line 148 of file kOmegaSST.H.

◆ rhoField

typedef BasicTurbulenceModel::rhoField rhoField

Definition at line 149 of file kOmegaSST.H.

◆ transportModel

typedef BasicTurbulenceModel::transportModel transportModel

Definition at line 150 of file kOmegaSST.H.

Constructor & Destructor Documentation

◆ kOmegaSST()

kOmegaSST ( const alphaField &  alpha,
const rhoField &  rho,
const volVectorField &  U,
const surfaceScalarField &  alphaRhoPhi,
const surfaceScalarField &  phi,
const transportModel &  transport,
const word &  propertiesName = turbulenceModel::propertiesName,
const word &  type = typeName
)

Definition at line 57 of file kOmegaSST.C.

References Foam::type().

Here is the call graph for this function:

◆ ~kOmegaSST()

virtual ~kOmegaSST ( )
virtualdefault

Member Function Documentation

◆ correctNut() [1/2]

void correctNut ( const volScalarField &  S2)
protectedvirtual

Reimplemented from kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >.

Reimplemented in kOmegaSSTSato< BasicTurbulenceModel >.

Definition at line 33 of file kOmegaSST.C.

◆ correctNut() [2/2]

void correctNut
protectedvirtual

Reimplemented from kOmegaSSTBase< eddyViscosity< RASModel< BasicTurbulenceModel > > >.

Definition at line 47 of file kOmegaSST.C.

References Foam::fvc::grad(), Foam::magSqr(), and Foam::symm().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "kOmegaSST< BasicTurbulenceModel >"  )
The documentation for this class was generated from the following files:
