Public Types | Public Member Functions | Protected Member Functions | Protected Attributes | List of all members
kL< BasicTurbulenceModel > Class Template Reference
Turbulence models » RAS turbulence

A one-equation (turbulent kinetic energy k) turbulence closure model for incompressible and compressible geophysical applications. More...

Inheritance diagram for kL< BasicTurbulenceModel >:
Inheritance graph
[legend]
Collaboration diagram for kL< BasicTurbulenceModel >:
Collaboration graph
[legend]

Public Types

typedef BasicTurbulenceModel::alphaField alphaField

typedef BasicTurbulenceModel::rhoField rhoField

typedef BasicTurbulenceModel::transportModel transportModel

- Public Types inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
typedef RASModel< BasicTurbulenceModel > ::alphaField alphaField

typedef RASModel< BasicTurbulenceModel > ::rhoField rhoField

typedef RASModel< BasicTurbulenceModel > ::transportModel transportModel

- Public Types inherited from linearViscousStress< RASModel< BasicTurbulenceModel > >
typedef RASModel< BasicTurbulenceModel > ::alphaField alphaField

typedef RASModel< BasicTurbulenceModel > ::rhoField rhoField

typedef RASModel< BasicTurbulenceModel > ::transportModel transportModel

- Public Types inherited from RASModel< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField alphaField

typedef BasicTurbulenceModel::rhoField rhoField

typedef BasicTurbulenceModel::transportModel transportModel


Public Member Functions

 TypeName ("kL")

 kL (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)

virtual ~kL ()=default

virtual bool read ()

tmp< volScalarField > DkEff () const

virtual tmp< volScalarField > k () const

virtual void correct ()

- Public Member Functions inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
 eddyViscosity (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual ~eddyViscosity ()=default

virtual tmp< volScalarField > nut () const

virtual tmp< scalarField > nut (const label patchi) const

virtual tmp< volScalarField > k () const=0

virtual tmp< volSymmTensorField > R () const

virtual void validate ()

- Public Member Functions inherited from linearViscousStress< RASModel< BasicTurbulenceModel > >
 linearViscousStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual ~linearViscousStress ()=default

virtual tmp< volSymmTensorField > devRhoReff () const

virtual tmp< volSymmTensorField > devRhoReff (const volVectorField &U) const

virtual tmp< fvVectorMatrix > divDevRhoReff (volVectorField &U) const

virtual tmp< fvVectorMatrix > divDevRhoReff (const volScalarField &rho, volVectorField &U) const

- Public Member Functions inherited from RASModel< BasicTurbulenceModel >
 TypeName ("RAS")

 declareRunTimeSelectionTable (autoPtr, RASModel, dictionary,(const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName),(alpha, rho, U, alphaRhoPhi, phi, transport, propertiesName))

 RASModel (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual ~RASModel ()=default

const dimensionedScalar & kMin () const

const dimensionedScalar & epsilonMin () const

const dimensionedScalar & omegaMin () const

dimensionedScalar & kMin ()

dimensionedScalar & epsilonMin ()

dimensionedScalar & omegaMin ()

virtual const dictionary & coeffDict () const

virtual tmp< volScalarField > nuEff () const

virtual tmp< scalarField > nuEff (const label patchi) const

virtual tmp< volScalarField > omega () const


Protected Member Functions

virtual void correctNut ()

virtual tmp< fvScalarMatrix > kSource () const

- Protected Member Functions inherited from RASModel< BasicTurbulenceModel >
virtual void printCoeffs (const word &type)

 RASModel (const RASModel &)=delete

void operator= (const RASModel &)=delete


Protected Attributes

dimensionedScalar kappa_

dimensionedScalar sigmak_

dimensionedScalar beta_

dimensionedScalar Cmu0_

dimensionedScalar Lmax_

dimensionedScalar CbStable_

dimensionedScalar CbUnstable_

volScalarField k_

volScalarField L_

volScalarField Rt_

const uniformDimensionedVectorField & g_

const volScalarField & y_

- Protected Attributes inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
volScalarField nut_

- Protected Attributes inherited from RASModel< BasicTurbulenceModel >
dictionary RASDict_

Switch turbulence_

Switch printCoeffs_

dictionary coeffDict_

dimensionedScalar kMin_

dimensionedScalar epsilonMin_

dimensionedScalar omegaMin_


Additional Inherited Members

- Static Public Member Functions inherited from RASModel< BasicTurbulenceModel >
static autoPtr< RASModel > New (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName)


Detailed Description

template<class BasicTurbulenceModel>
class Foam::RASModels::kL< BasicTurbulenceModel >

A one-equation (turbulent kinetic energy k) turbulence closure model for incompressible and compressible geophysical applications.

Turbulent kinetic energy (k) is computed with a transport equation and the turbulent length scale (L) is computed with an algebraic expression which depends on the local stratification.

References:

    Standard model (tag:A):
        Axell, L. B., & Liungman, O. (2001).
        A one-equation turbulence model for geophysical applications:
        comparison with data and the k−ε model.
        Environmental Fluid Mechanics, 1(1), 71-106.
        DOI:10.1023/A:1011560202388

    Canopy-related models (tag:W):
        Wilson, J. D., & Flesch, T. K. (1999).
        Wind and remnant tree sway in forest cutblocks.
        III. A windflow model to diagnose spatial variation.
        Agricultural and Forest Meteorology, 93(4), 259-282.
        DOI:10.1016/S0168-1923(98)00121-X
Usage
Example by using constant/turbulenceProperties:
RAS
{
    // Mandatory entries
    RASModel        kL;

    // Optional entries
    kLCoeffs
    {
        kappa       <scalar>;
        sigmak      <scalar>;
        beta        <scalar>;
        Cmu0        <scalar>;
        Lmax        <scalar>;
        CbStable    <scalar>;
        CbUnstable  <scalar>;
    }

    // Inherited entries
    ...
}

where the entries mean:

Property Description Type Reqd Deflt
RASModel Type name: kL word yes -
kappa von Karman constant scalar no 0.41
sigmak Empirical model coefficient scalar no 1.0
beta Thermal expansion coefficient [1/K] scalar no 3.3e-3
Cmu0 Empirical model coefficient scalar no 0.556
Lmax Maximum mixing-length scale [m] scalar no GREAT
CbStable Stable stratification constant scalar no 0.25
CbUnstable Unstable stratification constant scalar no 0.35

The inherited entries are elaborated in:


Input fields (mandatory)

k : Turbulent kinetic energy [m2/s2]
T : Potential temperature [K]


Input fields (optional)

canopyHeight : Canopy height [m]
plantCd : Plant canopy drag coefficient [-]
leafAreaDensity : Leaf area density [1/m]
Rt : Turbulent Richardson number [-]
L : Characteristic length scale [m]
Note
  • Optional input fields can/should be input by using readFields function object.
Source files

Definition at line 218 of file kL.H.

Member Typedef Documentation

◆ alphaField

typedef BasicTurbulenceModel::alphaField alphaField

Definition at line 320 of file kL.H.

◆ rhoField

typedef BasicTurbulenceModel::rhoField rhoField

Definition at line 321 of file kL.H.

◆ transportModel

typedef BasicTurbulenceModel::transportModel transportModel

Definition at line 322 of file kL.H.

Constructor & Destructor Documentation

◆ kL()

kL ( const alphaField &  alpha,
const rhoField &  rho,
const volVectorField &  U,
const surfaceScalarField &  alphaRhoPhi,
const surfaceScalarField &  phi,
const transportModel &  transport,
const word &  propertiesName = turbulenceModel::propertiesName,
const word &  type = typeName
)

Definition at line 243 of file kL.C.

References Foam::bound(), and Foam::type().

Here is the call graph for this function:

◆ ~kL()

virtual ~kL ( )
virtualdefault

Member Function Documentation

◆ correctNut()

void correctNut
protectedvirtual

Implements eddyViscosity< RASModel< BasicTurbulenceModel > >.

Definition at line 218 of file kL.C.

References optionList::correct(), options::New(), and Foam::sqrt().

Here is the call graph for this function:

◆ kSource()

tmp< fvScalarMatrix > kSource
protectedvirtual

Definition at line 229 of file kL.C.

References Foam::dimTime, Foam::dimVolume, and tmp::New().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "kL< BasicTurbulenceModel >"  )

◆ read()

bool read
virtual

Implements eddyViscosity< RASModel< BasicTurbulenceModel > >.

Definition at line 385 of file kL.C.

References Foam::read().

Here is the call graph for this function:

◆ DkEff()

tmp<volScalarField> DkEff ( ) const
inline

Definition at line 355 of file kL.H.

References tmp::New(), nu, and eddyViscosity< RASModel< BasicTurbulenceModel > >::nut_.

Here is the call graph for this function:

◆ k()

virtual tmp<volScalarField> k ( ) const
inlinevirtual

Definition at line 365 of file kL.H.

References kL< BasicTurbulenceModel >::k_.

◆ correct()

void correct
virtual

Implements eddyViscosity< RASModel< BasicTurbulenceModel > >.

Definition at line 405 of file kL.C.

References Foam::fvc::absolute(), Foam::constant::atomic::alpha, Foam::bound(), tmp::clear(), correct(), tmp::cref(), Foam::fvm::ddt(), Foam::dev(), Foam::fvm::div(), Foam::fvc::div(), divU, epsilon, fvOptions, Foam::constant::universal::G, Foam::fvc::grad(), Foam::fvm::laplacian(), Foam::magSqr(), options::New(), nut, phi, tmp::ref(), rho, Foam::solve(), Foam::sqr(), Foam::fvm::SuSp(), Foam::symm(), Foam::T(), and U.

Here is the call graph for this function:

Member Data Documentation

◆ kappa_

dimensionedScalar kappa_
protected

Definition at line 268 of file kL.H.

◆ sigmak_

dimensionedScalar sigmak_
protected

Definition at line 271 of file kL.H.

◆ beta_

dimensionedScalar beta_
protected

Definition at line 274 of file kL.H.

◆ Cmu0_

dimensionedScalar Cmu0_
protected

Definition at line 277 of file kL.H.

◆ Lmax_

dimensionedScalar Lmax_
protected

Definition at line 280 of file kL.H.

◆ CbStable_

dimensionedScalar CbStable_
protected

Definition at line 283 of file kL.H.

◆ CbUnstable_

dimensionedScalar CbUnstable_
protected

Definition at line 286 of file kL.H.

◆ k_

volScalarField k_
protected

Definition at line 292 of file kL.H.

Referenced by kL< BasicTurbulenceModel >::k().

◆ L_

volScalarField L_
protected

Definition at line 295 of file kL.H.

◆ Rt_

volScalarField Rt_
protected

Definition at line 298 of file kL.H.

◆ g_

const uniformDimensionedVectorField& g_
protected

Definition at line 301 of file kL.H.

◆ y_

const volScalarField& y_
protected

Definition at line 306 of file kL.H.

The documentation for this class was generated from the following files:
