k-epsilon model for the gas-phase in a two-phase system supporting phase-inversion. More...

Inheritance diagram for continuousGasKEpsilon< BasicTurbulenceModel >:

Collaboration diagram for continuousGasKEpsilon< BasicTurbulenceModel >:

Public Types
typedef BasicTurbulenceModel::alphaField	alphaField

typedef BasicTurbulenceModel::rhoField	rhoField

typedef BasicTurbulenceModel::transportModel	transportModel

Public Types inherited from kEpsilon< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField	alphaField

typedef BasicTurbulenceModel::rhoField	rhoField

typedef BasicTurbulenceModel::transportModel	transportModel

Public Types inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
typedef RASModel< BasicTurbulenceModel > ::alphaField	alphaField

typedef RASModel< BasicTurbulenceModel > ::rhoField	rhoField

typedef RASModel< BasicTurbulenceModel > ::transportModel	transportModel

Public Types inherited from linearViscousStress< RASModel< BasicTurbulenceModel > >
typedef RASModel< BasicTurbulenceModel > ::alphaField	alphaField

typedef RASModel< BasicTurbulenceModel > ::rhoField	rhoField

typedef RASModel< BasicTurbulenceModel > ::transportModel	transportModel

Public Types inherited from RASModel< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField	alphaField

typedef BasicTurbulenceModel::rhoField	rhoField

typedef BasicTurbulenceModel::transportModel	transportModel

Public Member Functions
	TypeName ("continuousGasKEpsilon")

	continuousGasKEpsilon (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)

virtual	~continuousGasKEpsilon ()=default

virtual bool	read ()

const turbulenceModel &	liquidTurbulence () const

virtual tmp< volScalarField >	nuEff () const

virtual tmp< volScalarField >	rhoEff () const

virtual tmp< volSymmTensorField >	R () const

Public Member Functions inherited from kEpsilon< BasicTurbulenceModel >
	TypeName ("kEpsilon")

	kEpsilon (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)

virtual	~kEpsilon ()=default

tmp< volScalarField >	DkEff () const

tmp< volScalarField >	DepsilonEff () const

virtual tmp< volScalarField >	k () const

virtual tmp< volScalarField >	epsilon () const

virtual void	correct ()

Public Member Functions inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
	eddyViscosity (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual	~eddyViscosity ()=default

virtual tmp< volScalarField >	nut () const

virtual tmp< scalarField >	nut (const label patchi) const

virtual tmp< volScalarField >	k () const=0

virtual tmp< volSymmTensorField >	R () const

virtual void	validate ()

Public Member Functions inherited from linearViscousStress< RASModel< BasicTurbulenceModel > >
	linearViscousStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual	~linearViscousStress ()=default

virtual tmp< volSymmTensorField >	devRhoReff () const

virtual tmp< volSymmTensorField >	devRhoReff (const volVectorField &U) const

virtual tmp< fvVectorMatrix >	divDevRhoReff (volVectorField &U) const

virtual tmp< fvVectorMatrix >	divDevRhoReff (const volScalarField &rho, volVectorField &U) const

Public Member Functions inherited from RASModel< BasicTurbulenceModel >
	TypeName ("RAS")

	declareRunTimeSelectionTable (autoPtr, RASModel, dictionary,(const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName),(alpha, rho, U, alphaRhoPhi, phi, transport, propertiesName))

	RASModel (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual	~RASModel ()=default

const dimensionedScalar &	kMin () const

const dimensionedScalar &	epsilonMin () const

const dimensionedScalar &	omegaMin () const

dimensionedScalar &	kMin ()

dimensionedScalar &	epsilonMin ()

dimensionedScalar &	omegaMin ()

virtual const dictionary &	coeffDict () const

virtual tmp< scalarField >	nuEff (const label patchi) const

virtual tmp< volScalarField >	omega () const

Protected Member Functions
virtual void	correctNut ()

tmp< volScalarField >	phaseTransferCoeff () const

virtual tmp< fvScalarMatrix >	kSource () const

virtual tmp< fvScalarMatrix >	epsilonSource () const

Protected Member Functions inherited from RASModel< BasicTurbulenceModel >
virtual void	printCoeffs (const word &type)

	RASModel (const RASModel &)=delete

void	operator= (const RASModel &)=delete

Protected Attributes
dimensionedScalar	alphaInversion_

Protected Attributes inherited from kEpsilon< BasicTurbulenceModel >
dimensionedScalar	Cmu_

dimensionedScalar	C1_

dimensionedScalar	C2_

dimensionedScalar	C3_

dimensionedScalar	sigmak_

dimensionedScalar	sigmaEps_

volScalarField	k_

volScalarField	epsilon_

Protected Attributes inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
volScalarField	nut_

Protected Attributes inherited from RASModel< BasicTurbulenceModel >
dictionary	RASDict_

Switch	turbulence_

Switch	printCoeffs_

dictionary	coeffDict_

dimensionedScalar	kMin_

dimensionedScalar	epsilonMin_

dimensionedScalar	omegaMin_

Additional Inherited Members
Static Public Member Functions inherited from RASModel< BasicTurbulenceModel >
static autoPtr< RASModel >	New (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName)

Detailed Description

template<class BasicTurbulenceModel>
class Foam::RASModels::continuousGasKEpsilon< BasicTurbulenceModel >

k-epsilon model for the gas-phase in a two-phase system supporting phase-inversion.

In the limit that the gas-phase fraction approaches zero a contribution from the other phase is blended into the k and epsilon equations up to the phase-fraction of alphaInversion at which point phase-inversion is considered to have occurred and the model reverts to the pure single-phase form.

This model is unpublished and is provided as a stable numerical framework on which a more physical model may be built.

The default model coefficients are

    continuousGasKEpsilonCoeffs
    {
        Cmu             0.09;
        C1              1.44;
        C2              1.92;
        C3              -0.33;
        sigmak          1.0;
        sigmaEps        1.3;
        alphaInversion  0.7;
    }

Source files

Definition at line 77 of file continuousGasKEpsilon.H.

Member Typedef Documentation

◆ alphaField

typedef BasicTurbulenceModel::alphaField alphaField

Definition at line 116 of file continuousGasKEpsilon.H.

◆ rhoField

typedef BasicTurbulenceModel::rhoField rhoField

Definition at line 117 of file continuousGasKEpsilon.H.

◆ transportModel

typedef BasicTurbulenceModel::transportModel transportModel

Definition at line 118 of file continuousGasKEpsilon.H.

Constructor & Destructor Documentation

◆ continuousGasKEpsilon()

continuousGasKEpsilon	(	const alphaField &	alpha,
		const rhoField &	rho,
		const volVectorField &	U,
		const surfaceScalarField &	alphaRhoPhi,
		const surfaceScalarField &	phi,
		const transportModel &	transport,
		const word &	propertiesName = `turbulenceModel::propertiesName`,
		const word &	type = `typeName`
	)

Definition at line 39 of file continuousGasKEpsilon.C.

References Foam::type().

Here is the call graph for this function:

◆ ~continuousGasKEpsilon()

virtual ~continuousGasKEpsilon ( )

virtualdefault

Member Function Documentation

◆ correctNut()

void correctNut

protectedvirtual

Reimplemented from kEpsilon< BasicTurbulenceModel >.

Definition at line 111 of file continuousGasKEpsilon.C.

References optionList::correct(), kEpsilon< BasicTurbulenceModel >::correctNut(), virtualMassModel::Cvm(), turbulenceModel::epsilon(), Foam::exp(), fluid, turbulenceModel::k(), Foam::min(), options::New(), turbulenceModel::nut(), liquid::rho(), and Foam::sqr().

Here is the call graph for this function:

◆ phaseTransferCoeff()

tmp< volScalarField > phaseTransferCoeff

protected

Definition at line 223 of file continuousGasKEpsilon.C.

References Foam::constant::atomic::alpha, turbulenceModel::epsilon(), turbulenceModel::k(), Foam::max(), Foam::min(), rho, and U.

Here is the call graph for this function:

◆ kSource()

tmp< fvScalarMatrix > kSource

protectedvirtual

Reimplemented from kEpsilon< BasicTurbulenceModel >.

Definition at line 246 of file continuousGasKEpsilon.C.

References turbulenceModel::k(), and Foam::fvm::Sp().

Here is the call graph for this function:

◆ epsilonSource()

tmp< fvScalarMatrix > epsilonSource

protectedvirtual

Reimplemented from kEpsilon< BasicTurbulenceModel >.

Definition at line 259 of file continuousGasKEpsilon.C.

References turbulenceModel::epsilon(), and Foam::fvm::Sp().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "continuousGasKEpsilon< BasicTurbulenceModel >" )

◆ read()

bool read

virtual

Reimplemented from kEpsilon< BasicTurbulenceModel >.

Definition at line 97 of file continuousGasKEpsilon.C.

◆ liquidTurbulence()

const turbulenceModel & liquidTurbulence

Definition at line 143 of file continuousGasKEpsilon.C.

References fluid, IOobject::groupName(), turbulenceModel::propertiesName, and U.

Here is the call graph for this function:

◆ nuEff()

tmp< Foam::volScalarField > nuEff

virtual

Reimplemented from RASModel< BasicTurbulenceModel >.

Definition at line 171 of file continuousGasKEpsilon.C.

References IOobject::groupName(), Foam::max(), Foam::min(), nu, and rho.

Here is the call graph for this function:

◆ rhoEff()

tmp< Foam::volScalarField > rhoEff

virtual

Definition at line 201 of file continuousGasKEpsilon.C.

References virtualMassModel::Cvm(), fluid, IOobject::groupName(), and liquid::rho().

Here is the call graph for this function:

◆ R()

tmp< volSymmTensorField > R

virtual

Definition at line 272 of file continuousGasKEpsilon.C.

References Foam::dev(), Foam::fvc::grad(), IOobject::groupName(), Foam::I, k, IOobject::NO_READ, IOobject::NO_WRITE, and Foam::twoSymm().

Here is the call graph for this function:

Member Data Documentation

◆ alphaInversion_

dimensionedScalar alphaInversion_

protected

Definition at line 103 of file continuousGasKEpsilon.H.

The documentation for this class was generated from the following files:

src/TurbulenceModels/phaseCompressible/RAS/continuousGasKEpsilon/continuousGasKEpsilon.H
src/TurbulenceModels/phaseCompressible/RAS/continuousGasKEpsilon/continuousGasKEpsilon.C
