buoyantKEpsilon< BasicTurbulenceModel > Class Template Reference

Additional buoyancy generation/dissipation term applied to the k and epsilon equations of the standard k-epsilon model. More...

Inheritance diagram for buoyantKEpsilon< BasicTurbulenceModel >:

Collaboration diagram for buoyantKEpsilon< BasicTurbulenceModel >:

Public Types
typedef BasicTurbulenceModel::alphaField	alphaField
typedef BasicTurbulenceModel::rhoField	rhoField
typedef BasicTurbulenceModel::transportModel	transportModel
Public Types inherited from kEpsilon< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField	alphaField
typedef BasicTurbulenceModel::rhoField	rhoField
typedef BasicTurbulenceModel::transportModel	transportModel
Public Types inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
typedef RASModel< BasicTurbulenceModel > ::alphaField	alphaField
typedef RASModel< BasicTurbulenceModel > ::rhoField	rhoField
typedef RASModel< BasicTurbulenceModel > ::transportModel	transportModel
Public Types inherited from linearViscousStress< RASModel< BasicTurbulenceModel > >
typedef RASModel< BasicTurbulenceModel > ::alphaField	alphaField
typedef RASModel< BasicTurbulenceModel > ::rhoField	rhoField
typedef RASModel< BasicTurbulenceModel > ::transportModel	transportModel
Public Types inherited from RASModel< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField	alphaField
typedef BasicTurbulenceModel::rhoField	rhoField
typedef BasicTurbulenceModel::transportModel	transportModel

Public Member Functions
	TypeName ("buoyantKEpsilon")
	buoyantKEpsilon (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)
virtual	~buoyantKEpsilon ()=default
virtual bool	read ()
Public Member Functions inherited from kEpsilon< BasicTurbulenceModel >
	TypeName ("kEpsilon")
	kEpsilon (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)
virtual	~kEpsilon ()=default
tmp< volScalarField >	DkEff () const
tmp< volScalarField >	DepsilonEff () const
virtual tmp< volScalarField >	k () const
virtual tmp< volScalarField >	epsilon () const
virtual void	correct ()
Public Member Functions inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
	eddyViscosity (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)
virtual	~eddyViscosity ()=default
virtual tmp< volScalarField >	nut () const
virtual tmp< scalarField >	nut (const label patchi) const
virtual tmp< volScalarField >	k () const=0
virtual tmp< volSymmTensorField >	R () const
virtual void	validate ()
Public Member Functions inherited from linearViscousStress< RASModel< BasicTurbulenceModel > >
	linearViscousStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)
virtual	~linearViscousStress ()=default
virtual tmp< volSymmTensorField >	devRhoReff () const
virtual tmp< volSymmTensorField >	devRhoReff (const volVectorField &U) const
virtual tmp< fvVectorMatrix >	divDevRhoReff (volVectorField &U) const
virtual tmp< fvVectorMatrix >	divDevRhoReff (const volScalarField &rho, volVectorField &U) const
Public Member Functions inherited from RASModel< BasicTurbulenceModel >
	TypeName ("RAS")
	declareRunTimeSelectionTable (autoPtr, RASModel, dictionary,(const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName),(alpha, rho, U, alphaRhoPhi, phi, transport, propertiesName))
	RASModel (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)
virtual	~RASModel ()=default
const dimensionedScalar &	kMin () const
const dimensionedScalar &	epsilonMin () const
const dimensionedScalar &	omegaMin () const
dimensionedScalar &	kMin ()
dimensionedScalar &	epsilonMin ()
dimensionedScalar &	omegaMin ()
virtual const dictionary &	coeffDict () const
virtual tmp< volScalarField >	nuEff () const
virtual tmp< scalarField >	nuEff (const label patchi) const
virtual tmp< volScalarField >	omega () const

Protected Member Functions
tmp< volScalarField >	Gcoef () const
virtual tmp< fvScalarMatrix >	kSource () const
virtual tmp< fvScalarMatrix >	epsilonSource () const
Protected Member Functions inherited from kEpsilon< BasicTurbulenceModel >
virtual void	correctNut ()
Protected Member Functions inherited from RASModel< BasicTurbulenceModel >
virtual void	printCoeffs (const word &type)
	RASModel (const RASModel &)=delete
void	operator= (const RASModel &)=delete

Protected Attributes
dimensionedScalar	Cg_
Protected Attributes inherited from kEpsilon< BasicTurbulenceModel >
dimensionedScalar	Cmu_
dimensionedScalar	C1_
dimensionedScalar	C2_
dimensionedScalar	C3_
dimensionedScalar	sigmak_
dimensionedScalar	sigmaEps_
volScalarField	k_
volScalarField	epsilon_
Protected Attributes inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
volScalarField	nut_
Protected Attributes inherited from RASModel< BasicTurbulenceModel >
dictionary	RASDict_
Switch	turbulence_
Switch	printCoeffs_
dictionary	coeffDict_
dimensionedScalar	kMin_
dimensionedScalar	epsilonMin_
dimensionedScalar	omegaMin_

Additional Inherited Members
Static Public Member Functions inherited from RASModel< BasicTurbulenceModel >
static autoPtr< RASModel >	New (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName)

Detailed Description

template<class BasicTurbulenceModel>
class Foam::RASModels::buoyantKEpsilon< BasicTurbulenceModel >

Additional buoyancy generation/dissipation term applied to the k and epsilon equations of the standard k-epsilon model.

Reference:

    Henkes, R.A.W.M., Van Der Vlugt, F.F. & Hoogendoorn, C.J. (1991).
    Natural Convection Flow in a Square Cavity Calculated with
    Low-Reynolds-Number Turbulence Models.
    Int. J. Heat Mass Transfer, 34, 1543-1557.

This implementation is based on the density rather than temperature gradient extending the applicability to systems in which the density gradient may be generated by variation of composition rather than temperature. Further, the 1/Prt coefficient is replaced by Cg to provide more general control of model.

The default model coefficients are

    buoyantKEpsilonCoeffs
    {
        Cg              1.0;
    }

See also

Foam::RASModels::kEpsilon

Source files

• buoyantKEpsilon.H
• buoyantKEpsilon.C

Definition at line 79 of file buoyantKEpsilon.H.

Member Typedef Documentation

alphaField

typedef BasicTurbulenceModel::alphaField alphaField

Definition at line 110 of file buoyantKEpsilon.H.

rhoField

typedef BasicTurbulenceModel::rhoField rhoField

Definition at line 111 of file buoyantKEpsilon.H.

transportModel

typedef BasicTurbulenceModel::transportModel transportModel

Definition at line 112 of file buoyantKEpsilon.H.

Constructor & Destructor Documentation

buoyantKEpsilon()

buoyantKEpsilon	(	const alphaField &	alpha,
		const rhoField &	rho,
		const volVectorField &	U,
		const surfaceScalarField &	alphaRhoPhi,
		const surfaceScalarField &	phi,
		const transportModel &	transport,
		const word &	propertiesName = turbulenceModel::propertiesName,
		const word &	type = typeName
	)

Definition at line 38 of file buoyantKEpsilon.C.

References Foam::type().

Here is the call graph for this function:

~buoyantKEpsilon()

virtual ~buoyantKEpsilon ( )

virtualdefault

Member Function Documentation

Gcoef()

tmp< volScalarField > Gcoef

protected

Definition at line 96 of file buoyantKEpsilon.C.

References g, Foam::fvc::grad(), and gravity::New().

Here is the call graph for this function:

kSource()

tmp< fvScalarMatrix > kSource

protectedvirtual

Reimplemented from kEpsilon< BasicTurbulenceModel >.

Definition at line 109 of file buoyantKEpsilon.C.

References g, kEpsilon< BasicTurbulenceModel >::kSource(), Foam::mag(), gravity::New(), and Foam::fvm::SuSp().

Here is the call graph for this function:

epsilonSource()

tmp< fvScalarMatrix > epsilonSource

protectedvirtual

Reimplemented from kEpsilon< BasicTurbulenceModel >.

Definition at line 125 of file buoyantKEpsilon.C.

References Foam::dimVelocity, kEpsilon< BasicTurbulenceModel >::epsilonSource(), g, Foam::mag(), gravity::New(), Foam::fvm::SuSp(), and Foam::tanh().

Here is the call graph for this function:

TypeName()

TypeName

(

"buoyantKEpsilon< BasicTurbulenceModel >"

)

read()

bool read

virtual

Reimplemented from kEpsilon< BasicTurbulenceModel >.

Definition at line 81 of file buoyantKEpsilon.C.

Member Data Documentation

Cg_

dimensionedScalar Cg_

protected

Definition at line 98 of file buoyantKEpsilon.H.

---

The documentation for this class was generated from the following files:

• src/TurbulenceModels/compressible/RAS/buoyantKEpsilon/buoyantKEpsilon.H
• src/TurbulenceModels/compressible/RAS/buoyantKEpsilon/buoyantKEpsilon.C
