Public Types | Public Member Functions | Protected Member Functions | Protected Attributes | List of all members
SSG< BasicTurbulenceModel > Class Template Reference
Turbulence models » RAS turbulence

Speziale, Sarkar and Gatski Reynolds-stress turbulence model for incompressible and compressible flows. More...

Inheritance diagram for SSG< BasicTurbulenceModel >:
Inheritance graph
[legend]
Collaboration diagram for SSG< BasicTurbulenceModel >:
Collaboration graph
[legend]

Public Types

typedef BasicTurbulenceModel::alphaField alphaField

typedef BasicTurbulenceModel::rhoField rhoField

typedef BasicTurbulenceModel::transportModel transportModel

- Public Types inherited from ReynoldsStress< RASModel< BasicTurbulenceModel > >
typedef RASModel< BasicTurbulenceModel > ::alphaField alphaField

typedef RASModel< BasicTurbulenceModel > ::rhoField rhoField

typedef RASModel< BasicTurbulenceModel > ::transportModel transportModel

- Public Types inherited from RASModel< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField alphaField

typedef BasicTurbulenceModel::rhoField rhoField

typedef BasicTurbulenceModel::transportModel transportModel


Public Member Functions

 TypeName ("SSG")

 SSG (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)

virtual ~SSG ()=default

virtual bool read ()

virtual tmp< volScalarField > k () const

virtual tmp< volScalarField > epsilon () const

tmp< volSymmTensorField > DREff () const

tmp< volSymmTensorField > DepsilonEff () const

virtual void correct ()

- Public Member Functions inherited from ReynoldsStress< RASModel< BasicTurbulenceModel > >
Foam::tmp< Foam::fvVectorMatrix > DivDevRhoReff (const RhoFieldType &rho, volVectorField &U) const

 ReynoldsStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual ~ReynoldsStress ()=default

virtual tmp< volScalarField > nut () const

virtual tmp< scalarField > nut (const label patchi) const

virtual tmp< volScalarField > k () const

virtual tmp< volSymmTensorField > R () const

virtual tmp< volSymmTensorField > devRhoReff () const

virtual tmp< volSymmTensorField > devRhoReff (const volVectorField &U) const

virtual tmp< fvVectorMatrix > divDevRhoReff (volVectorField &U) const

virtual tmp< fvVectorMatrix > divDevRhoReff (const volScalarField &rho, volVectorField &U) const

virtual void validate ()

- Public Member Functions inherited from RASModel< BasicTurbulenceModel >
 TypeName ("RAS")

 declareRunTimeSelectionTable (autoPtr, RASModel, dictionary,(const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName),(alpha, rho, U, alphaRhoPhi, phi, transport, propertiesName))

 RASModel (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual ~RASModel ()=default

const dimensionedScalar & kMin () const

const dimensionedScalar & epsilonMin () const

const dimensionedScalar & omegaMin () const

dimensionedScalar & kMin ()

dimensionedScalar & epsilonMin ()

dimensionedScalar & omegaMin ()

virtual const dictionary & coeffDict () const

virtual tmp< volScalarField > nuEff () const

virtual tmp< scalarField > nuEff (const label patchi) const

virtual tmp< volScalarField > omega () const


Protected Member Functions

virtual void correctNut ()

- Protected Member Functions inherited from ReynoldsStress< RASModel< BasicTurbulenceModel > >
void boundNormalStress (volSymmTensorField &R) const

void correctWallShearStress (volSymmTensorField &R) const

tmp< fvVectorMatrix > DivDevRhoReff (const RhoFieldType &rho, volVectorField &U) const

- Protected Member Functions inherited from RASModel< BasicTurbulenceModel >
virtual void printCoeffs (const word &type)

 RASModel (const RASModel &)=delete

void operator= (const RASModel &)=delete


Protected Attributes

dimensionedScalar Cmu_

dimensionedScalar C1_

dimensionedScalar C1s_

dimensionedScalar C2_

dimensionedScalar C3_

dimensionedScalar C3s_

dimensionedScalar C4_

dimensionedScalar C5_

dimensionedScalar Ceps1_

dimensionedScalar Ceps2_

dimensionedScalar Cs_

dimensionedScalar Ceps_

volScalarField k_

volScalarField epsilon_

- Protected Attributes inherited from ReynoldsStress< RASModel< BasicTurbulenceModel > >
dimensionedScalar couplingFactor_

volSymmTensorField R_

volScalarField nut_

- Protected Attributes inherited from RASModel< BasicTurbulenceModel >
dictionary RASDict_

Switch turbulence_

Switch printCoeffs_

dictionary coeffDict_

dimensionedScalar kMin_

dimensionedScalar epsilonMin_

dimensionedScalar omegaMin_


Additional Inherited Members

- Static Public Member Functions inherited from RASModel< BasicTurbulenceModel >
static autoPtr< RASModel > New (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName)


Detailed Description

template<class BasicTurbulenceModel>
class Foam::RASModels::SSG< BasicTurbulenceModel >

Speziale, Sarkar and Gatski Reynolds-stress turbulence model for incompressible and compressible flows.

Reference:

    Speziale, C. G., Sarkar, S., & Gatski, T. B. (1991).
    Modelling the pressure-strain correlation of turbulence:
    an invariant dynamical systems approach.
    Journal of Fluid Mechanics, 227, 245-272.

Including the generalized gradient diffusion model of Daly and Harlow:

    Daly, B. J., & Harlow, F. H. (1970).
    Transport equations in turbulence.
    Physics of Fluids (1958-1988), 13(11), 2634-2649.

The default model coefficients are:

    SSGCoeffs
    {
        Cmu             0.09;

        C1              3.4;
        C1s             1.8;
        C2              4.2;
        C3              0.8;
        C3s             1.3;
        C4              1.25;
        C5              0.4;

        Ceps1           1.44;
        Ceps2           1.92;
        Cs              0.25;
        Ceps            0.15;

        couplingFactor  0.0;
    }
Source files

Definition at line 94 of file SSG.H.

Member Typedef Documentation

◆ alphaField

typedef BasicTurbulenceModel::alphaField alphaField

Definition at line 142 of file SSG.H.

◆ rhoField

typedef BasicTurbulenceModel::rhoField rhoField

Definition at line 143 of file SSG.H.

◆ transportModel

typedef BasicTurbulenceModel::transportModel transportModel

Definition at line 144 of file SSG.H.

Constructor & Destructor Documentation

◆ SSG()

SSG ( const alphaField &  alpha,
const rhoField &  rho,
const volVectorField &  U,
const surfaceScalarField &  alphaRhoPhi,
const surfaceScalarField &  phi,
const transportModel &  transport,
const word &  propertiesName = turbulenceModel::propertiesName,
const word &  type = typeName
)

Definition at line 50 of file SSG.C.

References Foam::bound(), Foam::tr(), and Foam::type().

Here is the call graph for this function:

◆ ~SSG()

virtual ~SSG ( )
virtualdefault

Member Function Documentation

◆ correctNut()

void correctNut
protectedvirtual

Implements ReynoldsStress< RASModel< BasicTurbulenceModel > >.

Definition at line 36 of file SSG.C.

References optionList::correct(), options::New(), and Foam::sqr().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "SSG< BasicTurbulenceModel >"  )

◆ read()

bool read
virtual

Implements ReynoldsStress< RASModel< BasicTurbulenceModel > >.

Definition at line 222 of file SSG.C.

References Foam::read().

Here is the call graph for this function:

◆ k()

virtual tmp<volScalarField> k ( ) const
inlinevirtual

Definition at line 177 of file SSG.H.

References SSG< BasicTurbulenceModel >::k_.

◆ epsilon()

virtual tmp<volScalarField> epsilon ( ) const
inlinevirtual

Reimplemented from RASModel< BasicTurbulenceModel >.

Definition at line 183 of file SSG.H.

References SSG< BasicTurbulenceModel >::epsilon_.

◆ DREff()

tmp< volSymmTensorField > DREff

Definition at line 248 of file SSG.C.

References Foam::I, and nu.

◆ DepsilonEff()

tmp< volSymmTensorField > DepsilonEff

Definition at line 262 of file SSG.C.

References Foam::I, and nu.

◆ correct()

void correct
virtual

Implements ReynoldsStress< RASModel< BasicTurbulenceModel > >.

Definition at line 276 of file SSG.C.

References Foam::constant::atomic::alpha, Foam::constant::physicoChemical::b, Foam::bound(), correct(), Foam::fvm::ddt(), Foam::dev(), Foam::fvm::div(), fvPatch::faceCells(), forAll, fvOptions, Foam::constant::universal::G, Foam::fvc::grad(), Foam::I, Foam::innerSqr(), Foam::fvm::laplacian(), Foam::mag(), Foam::min(), options::New(), patches, R, tmp::ref(), rho, Foam::skew(), Foam::solve(), Foam::fvm::Sp(), Foam::symm(), Foam::tr(), Foam::twoSymm(), and U.

Here is the call graph for this function:

Member Data Documentation

◆ Cmu_

dimensionedScalar Cmu_
protected

Definition at line 113 of file SSG.H.

◆ C1_

dimensionedScalar C1_
protected

Definition at line 115 of file SSG.H.

◆ C1s_

dimensionedScalar C1s_
protected

Definition at line 116 of file SSG.H.

◆ C2_

dimensionedScalar C2_
protected

Definition at line 117 of file SSG.H.

◆ C3_

dimensionedScalar C3_
protected

Definition at line 118 of file SSG.H.

◆ C3s_

dimensionedScalar C3s_
protected

Definition at line 119 of file SSG.H.

◆ C4_

dimensionedScalar C4_
protected

Definition at line 120 of file SSG.H.

◆ C5_

dimensionedScalar C5_
protected

Definition at line 121 of file SSG.H.

◆ Ceps1_

dimensionedScalar Ceps1_
protected

Definition at line 123 of file SSG.H.

◆ Ceps2_

dimensionedScalar Ceps2_
protected

Definition at line 124 of file SSG.H.

◆ Cs_

dimensionedScalar Cs_
protected

Definition at line 125 of file SSG.H.

◆ Ceps_

dimensionedScalar Ceps_
protected

Definition at line 126 of file SSG.H.

◆ k_

volScalarField k_
protected

Definition at line 130 of file SSG.H.

Referenced by SSG< BasicTurbulenceModel >::k().

◆ epsilon_

volScalarField epsilon_
protected

Definition at line 131 of file SSG.H.

Referenced by SSG< BasicTurbulenceModel >::epsilon().

The documentation for this class was generated from the following files:
