RNGkEpsilon< BasicTurbulenceModel > Class Template Reference
Turbulence models » RAS turbulence

Renormalization group k-epsilon turbulence model for incompressible and compressible flows. More...

Inheritance diagram for RNGkEpsilon< BasicTurbulenceModel >:
Inheritance graph
[legend]
Collaboration diagram for RNGkEpsilon< BasicTurbulenceModel >:
Collaboration graph
[legend]

Public Types

typedef BasicTurbulenceModel::alphaField alphaField

typedef BasicTurbulenceModel::rhoField rhoField

typedef BasicTurbulenceModel::transportModel transportModel

- Public Types inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
typedef RASModel< BasicTurbulenceModel > ::alphaField alphaField

typedef RASModel< BasicTurbulenceModel > ::rhoField rhoField

typedef RASModel< BasicTurbulenceModel > ::transportModel transportModel

- Public Types inherited from linearViscousStress< RASModel< BasicTurbulenceModel > >
typedef RASModel< BasicTurbulenceModel > ::alphaField alphaField

typedef RASModel< BasicTurbulenceModel > ::rhoField rhoField

typedef RASModel< BasicTurbulenceModel > ::transportModel transportModel

- Public Types inherited from RASModel< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField alphaField

typedef BasicTurbulenceModel::rhoField rhoField

typedef BasicTurbulenceModel::transportModel transportModel


Public Member Functions

 TypeName ("RNGkEpsilon")

 RNGkEpsilon (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)

virtual ~RNGkEpsilon ()=default

virtual bool read ()

tmp< volScalarField > DkEff () const

tmp< volScalarField > DepsilonEff () const

virtual tmp< volScalarField > k () const

virtual tmp< volScalarField > epsilon () const

virtual void correct ()

- Public Member Functions inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
 eddyViscosity (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual ~eddyViscosity ()=default

virtual tmp< volScalarField > nut () const

virtual tmp< scalarField > nut (const label patchi) const

virtual tmp< volScalarField > k () const=0

virtual tmp< volSymmTensorField > R () const

virtual void validate ()

- Public Member Functions inherited from linearViscousStress< RASModel< BasicTurbulenceModel > >
 linearViscousStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual ~linearViscousStress ()=default

virtual tmp< volSymmTensorField > devRhoReff () const

virtual tmp< volSymmTensorField > devRhoReff (const volVectorField &U) const

virtual tmp< fvVectorMatrix > divDevRhoReff (volVectorField &U) const

virtual tmp< fvVectorMatrix > divDevRhoReff (const volScalarField &rho, volVectorField &U) const

- Public Member Functions inherited from RASModel< BasicTurbulenceModel >
 TypeName ("RAS")

 declareRunTimeSelectionTable (autoPtr, RASModel, dictionary,(const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName),(alpha, rho, U, alphaRhoPhi, phi, transport, propertiesName))

 RASModel (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual ~RASModel ()=default

const dimensionedScalar & kMin () const

const dimensionedScalar & epsilonMin () const

const dimensionedScalar & omegaMin () const

dimensionedScalar & kMin ()

dimensionedScalar & epsilonMin ()

dimensionedScalar & omegaMin ()

virtual const dictionary & coeffDict () const

virtual tmp< volScalarField > nuEff () const

virtual tmp< scalarField > nuEff (const label patchi) const

virtual tmp< volScalarField > omega () const


Protected Member Functions

virtual void correctNut ()

virtual tmp< fvScalarMatrix > kSource () const

virtual tmp< fvScalarMatrix > epsilonSource () const

- Protected Member Functions inherited from RASModel< BasicTurbulenceModel >
virtual void printCoeffs (const word &type)

 RASModel (const RASModel &)=delete

void operator= (const RASModel &)=delete


Protected Attributes

dimensionedScalar Cmu_

dimensionedScalar C1_

dimensionedScalar C2_

dimensionedScalar C3_

dimensionedScalar sigmak_

dimensionedScalar sigmaEps_

dimensionedScalar eta0_

dimensionedScalar beta_

volScalarField k_

volScalarField epsilon_

- Protected Attributes inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
volScalarField nut_

- Protected Attributes inherited from RASModel< BasicTurbulenceModel >
dictionary RASDict_

Switch turbulence_

Switch printCoeffs_

dictionary coeffDict_

dimensionedScalar kMin_

dimensionedScalar epsilonMin_

dimensionedScalar omegaMin_


Additional Inherited Members

- Static Public Member Functions inherited from RASModel< BasicTurbulenceModel >
static autoPtr< RASModel > New (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName)


Detailed Description

template<class BasicTurbulenceModel>
class Foam::RASModels::RNGkEpsilon< BasicTurbulenceModel >

Renormalization group k-epsilon turbulence model for incompressible and compressible flows.

Reference:

    Yakhot, V., Orszag, S. A., Thangam, S.,
    Gatski, T. B., & Speziale, C. G. (1992).
    Development of turbulence models for shear flows
    by a double expansion technique.
    Physics of Fluids A: Fluid Dynamics (1989-1993), 4(7), 1510-1520.

For the RDT-based compression term:
    El Tahry, S. H. (1983).
    k-epsilon equation for compressible reciprocating engine flows.
    Journal of Energy, 7(4), 345-353.

The default model coefficients are

    RNGkEpsilonCoeffs
    {
        Cmu         0.0845;
        C1          1.42;
        C2          1.68;
        C3          -0.33;
        sigmak      0.71942;
        sigmaEps    0.71942;
        eta0        4.38;
        beta        0.012;
    }
Source files

Definition at line 84 of file RNGkEpsilon.H.

Member Typedef Documentation

◆ alphaField

typedef BasicTurbulenceModel::alphaField alphaField

Definition at line 128 of file RNGkEpsilon.H.

◆ rhoField

typedef BasicTurbulenceModel::rhoField rhoField

Definition at line 129 of file RNGkEpsilon.H.

◆ transportModel

typedef BasicTurbulenceModel::transportModel transportModel

Definition at line 130 of file RNGkEpsilon.H.

Constructor & Destructor Documentation

◆ RNGkEpsilon()

RNGkEpsilon ( const alphaField &  alpha,
const rhoField &  rho,
const volVectorField &  U,
const surfaceScalarField &  alphaRhoPhi,
const surfaceScalarField &  phi,
const transportModel &  transport,
const word &  propertiesName = turbulenceModel::propertiesName,
const word &  type = typeName
)

Definition at line 80 of file RNGkEpsilon.C.

References Foam::bound(), and Foam::type().

Here is the call graph for this function:

◆ ~RNGkEpsilon()

virtual ~RNGkEpsilon ( )
virtualdefault

Member Function Documentation

◆ correctNut()

void correctNut
protectedvirtual

Implements eddyViscosity< RASModel< BasicTurbulenceModel > >.

Definition at line 36 of file RNGkEpsilon.C.

References optionList::correct(), options::New(), and Foam::sqr().

Here is the call graph for this function:

◆ kSource()

tmp< fvScalarMatrix > kSource
protectedvirtual

Definition at line 47 of file RNGkEpsilon.C.

References Foam::dimTime, and Foam::dimVolume.

◆ epsilonSource()

tmp< fvScalarMatrix > epsilonSource
protectedvirtual

Definition at line 62 of file RNGkEpsilon.C.

References Foam::dimTime, and Foam::dimVolume.

◆ TypeName()

TypeName ( "RNGkEpsilon< BasicTurbulenceModel >"  )

◆ read()

bool read
virtual

Implements eddyViscosity< RASModel< BasicTurbulenceModel > >.

Definition at line 214 of file RNGkEpsilon.C.

References Foam::read().

Here is the call graph for this function:

◆ DkEff()

tmp<volScalarField> DkEff ( ) const
inline

Definition at line 163 of file RNGkEpsilon.H.

References nu, and eddyViscosity< RASModel< BasicTurbulenceModel > >::nut_.

◆ DepsilonEff()

tmp<volScalarField> DepsilonEff ( ) const
inline

Definition at line 176 of file RNGkEpsilon.H.

References nu, and eddyViscosity< RASModel< BasicTurbulenceModel > >::nut_.

◆ k()

virtual tmp<volScalarField> k ( ) const
inlinevirtual

Definition at line 189 of file RNGkEpsilon.H.

References RNGkEpsilon< BasicTurbulenceModel >::k_.

◆ epsilon()

virtual tmp<volScalarField> epsilon ( ) const
inlinevirtual

Reimplemented from RASModel< BasicTurbulenceModel >.

Definition at line 195 of file RNGkEpsilon.H.

References RNGkEpsilon< BasicTurbulenceModel >::epsilon_.

◆ correct()

void correct
virtual

Implements eddyViscosity< RASModel< BasicTurbulenceModel > >.

Definition at line 235 of file RNGkEpsilon.C.

References Foam::fvc::absolute(), Foam::constant::atomic::alpha, Foam::bound(), tmp::clear(), correct(), Foam::fvm::ddt(), Foam::dev(), Foam::fvm::div(), Foam::fvc::div(), divU, fvOptions, Foam::constant::universal::G, Foam::fvc::grad(), Foam::fvm::laplacian(), Foam::mag(), options::New(), nut, phi, R, tmp::ref(), rho, Foam::solve(), Foam::fvm::Sp(), Foam::sqr(), Foam::sqrt(), Foam::fvm::SuSp(), Foam::twoSymm(), and U.

Here is the call graph for this function:

Member Data Documentation

◆ Cmu_

dimensionedScalar Cmu_
protected

Definition at line 103 of file RNGkEpsilon.H.

◆ C1_

dimensionedScalar C1_
protected

Definition at line 104 of file RNGkEpsilon.H.

◆ C2_

dimensionedScalar C2_
protected

Definition at line 105 of file RNGkEpsilon.H.

◆ C3_

dimensionedScalar C3_
protected

Definition at line 106 of file RNGkEpsilon.H.

◆ sigmak_

dimensionedScalar sigmak_
protected

Definition at line 107 of file RNGkEpsilon.H.

◆ sigmaEps_

dimensionedScalar sigmaEps_
protected

Definition at line 108 of file RNGkEpsilon.H.

◆ eta0_

dimensionedScalar eta0_
protected

Definition at line 109 of file RNGkEpsilon.H.

◆ beta_

dimensionedScalar beta_
protected

Definition at line 110 of file RNGkEpsilon.H.

◆ k_

volScalarField k_
protected

Definition at line 115 of file RNGkEpsilon.H.

Referenced by RNGkEpsilon< BasicTurbulenceModel >::k().

◆ epsilon_

volScalarField epsilon_
protected

Definition at line 116 of file RNGkEpsilon.H.

Referenced by RNGkEpsilon< BasicTurbulenceModel >::epsilon().

The documentation for this class was generated from the following files:
