LaheyKEpsilon< BasicTurbulenceModel > Class Template Reference
Turbulence models » RAS turbulence

Continuous-phase k-epsilon model including bubble-generated turbulence. More...

Inheritance diagram for LaheyKEpsilon< BasicTurbulenceModel >:
Inheritance graph
[legend]
Collaboration diagram for LaheyKEpsilon< BasicTurbulenceModel >:
Collaboration graph
[legend]

Public Types

typedef BasicTurbulenceModel::alphaField alphaField

typedef BasicTurbulenceModel::rhoField rhoField

typedef BasicTurbulenceModel::transportModel transportModel

- Public Types inherited from kEpsilon< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField alphaField

typedef BasicTurbulenceModel::rhoField rhoField

typedef BasicTurbulenceModel::transportModel transportModel

- Public Types inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
typedef RASModel< BasicTurbulenceModel > ::alphaField alphaField

typedef RASModel< BasicTurbulenceModel > ::rhoField rhoField

typedef RASModel< BasicTurbulenceModel > ::transportModel transportModel

- Public Types inherited from linearViscousStress< RASModel< BasicTurbulenceModel > >
typedef RASModel< BasicTurbulenceModel > ::alphaField alphaField

typedef RASModel< BasicTurbulenceModel > ::rhoField rhoField

typedef RASModel< BasicTurbulenceModel > ::transportModel transportModel

- Public Types inherited from RASModel< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField alphaField

typedef BasicTurbulenceModel::rhoField rhoField

typedef BasicTurbulenceModel::transportModel transportModel


Public Member Functions

 TypeName ("LaheyKEpsilon")

 LaheyKEpsilon (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)

virtual ~LaheyKEpsilon ()=default

virtual bool read ()

virtual void correct ()

- Public Member Functions inherited from kEpsilon< BasicTurbulenceModel >
 TypeName ("kEpsilon")

 kEpsilon (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)

virtual ~kEpsilon ()=default

tmp< volScalarField > DkEff () const

tmp< volScalarField > DepsilonEff () const

virtual tmp< volScalarField > k () const

virtual tmp< volScalarField > epsilon () const

- Public Member Functions inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
 eddyViscosity (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual ~eddyViscosity ()=default

virtual tmp< volScalarField > nut () const

virtual tmp< scalarField > nut (const label patchi) const

virtual tmp< volScalarField > k () const=0

virtual tmp< volSymmTensorField > R () const

virtual void validate ()

- Public Member Functions inherited from linearViscousStress< RASModel< BasicTurbulenceModel > >
 linearViscousStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual ~linearViscousStress ()=default

virtual tmp< volSymmTensorField > devRhoReff () const

virtual tmp< volSymmTensorField > devRhoReff (const volVectorField &U) const

virtual tmp< fvVectorMatrix > divDevRhoReff (volVectorField &U) const

virtual tmp< fvVectorMatrix > divDevRhoReff (const volScalarField &rho, volVectorField &U) const

- Public Member Functions inherited from RASModel< BasicTurbulenceModel >
 TypeName ("RAS")

 declareRunTimeSelectionTable (autoPtr, RASModel, dictionary,(const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName),(alpha, rho, U, alphaRhoPhi, phi, transport, propertiesName))

 RASModel (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual ~RASModel ()=default

const dimensionedScalar & kMin () const

const dimensionedScalar & epsilonMin () const

const dimensionedScalar & omegaMin () const

dimensionedScalar & kMin ()

dimensionedScalar & epsilonMin ()

dimensionedScalar & omegaMin ()

virtual const dictionary & coeffDict () const

virtual tmp< volScalarField > nuEff () const

virtual tmp< scalarField > nuEff (const label patchi) const

virtual tmp< volScalarField > omega () const


Protected Member Functions

virtual void correctNut ()

tmp< volScalarField > bubbleG () const

tmp< volScalarField > phaseTransferCoeff () const

virtual tmp< fvScalarMatrix > kSource () const

virtual tmp< fvScalarMatrix > epsilonSource () const

- Protected Member Functions inherited from RASModel< BasicTurbulenceModel >
virtual void printCoeffs (const word &type)

 RASModel (const RASModel &)=delete

void operator= (const RASModel &)=delete


Protected Attributes

dimensionedScalar alphaInversion_

dimensionedScalar Cp_

dimensionedScalar C3_

dimensionedScalar Cmub_

- Protected Attributes inherited from kEpsilon< BasicTurbulenceModel >
dimensionedScalar Cmu_

dimensionedScalar C1_

dimensionedScalar C2_

dimensionedScalar C3_

dimensionedScalar sigmak_

dimensionedScalar sigmaEps_

volScalarField k_

volScalarField epsilon_

- Protected Attributes inherited from eddyViscosity< RASModel< BasicTurbulenceModel > >
volScalarField nut_

- Protected Attributes inherited from RASModel< BasicTurbulenceModel >
dictionary RASDict_

Switch turbulence_

Switch printCoeffs_

dictionary coeffDict_

dimensionedScalar kMin_

dimensionedScalar epsilonMin_

dimensionedScalar omegaMin_


Additional Inherited Members

- Static Public Member Functions inherited from RASModel< BasicTurbulenceModel >
static autoPtr< RASModel > New (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName)


Detailed Description

template<class BasicTurbulenceModel>
class Foam::RASModels::LaheyKEpsilon< BasicTurbulenceModel >

Continuous-phase k-epsilon model including bubble-generated turbulence.

Reference:

    Lahey Jr, R. T. (2005).
    The simulation of multidimensional multiphase flows.
    Nuclear Engineering and Design, 235(10), 1043-1060.

The default model coefficients are

    LaheyKEpsilonCoeffs
    {
        Cmu             0.09;
        C1              1.44;
        C2              1.92;
        C3              -0.33;
        sigmak          1.0;
        sigmaEps        1.3;
        Cp              0.25;
        Cmub            0.6;
        alphaInversion  0.3;
    }
Source files

Definition at line 76 of file LaheyKEpsilon.H.

Member Typedef Documentation

◆ alphaField

typedef BasicTurbulenceModel::alphaField alphaField

Definition at line 127 of file LaheyKEpsilon.H.

◆ rhoField

typedef BasicTurbulenceModel::rhoField rhoField

Definition at line 128 of file LaheyKEpsilon.H.

◆ transportModel

typedef BasicTurbulenceModel::transportModel transportModel

Definition at line 129 of file LaheyKEpsilon.H.

Constructor & Destructor Documentation

◆ LaheyKEpsilon()

LaheyKEpsilon ( const alphaField &  alpha,
const rhoField &  rho,
const volVectorField &  U,
const surfaceScalarField &  alphaRhoPhi,
const surfaceScalarField &  phi,
const transportModel &  transport,
const word &  propertiesName = turbulenceModel::propertiesName,
const word &  type = typeName
)

Definition at line 38 of file LaheyKEpsilon.C.

References Foam::type().

Here is the call graph for this function:

◆ ~LaheyKEpsilon()

virtual ~LaheyKEpsilon ( )
virtualdefault

Member Function Documentation

◆ correctNut()

void correctNut
protectedvirtual

Reimplemented from kEpsilon< BasicTurbulenceModel >.

Definition at line 162 of file LaheyKEpsilon.C.

References optionList::correct(), Foam::mag(), options::New(), and Foam::sqr().

Here is the call graph for this function:

◆ bubbleG()

tmp< volScalarField > bubbleG
protected

Definition at line 180 of file LaheyKEpsilon.C.

References drag, fluid, Foam::mag(), Foam::pow(), and Foam::pow3().

Here is the call graph for this function:

◆ phaseTransferCoeff()

tmp< volScalarField > phaseTransferCoeff
protected

Definition at line 211 of file LaheyKEpsilon.C.

References Foam::constant::atomic::alpha, turbulenceModel::epsilon(), turbulenceModel::k(), Foam::max(), Foam::min(), rho, and U.

Here is the call graph for this function:

◆ kSource()

tmp< fvScalarMatrix > kSource
protectedvirtual

Reimplemented from kEpsilon< BasicTurbulenceModel >.

Definition at line 229 of file LaheyKEpsilon.C.

References Foam::constant::atomic::alpha, rho, and Foam::fvm::Sp().

Here is the call graph for this function:

◆ epsilonSource()

tmp< fvScalarMatrix > epsilonSource
protectedvirtual

Reimplemented from kEpsilon< BasicTurbulenceModel >.

Definition at line 247 of file LaheyKEpsilon.C.

References Foam::constant::atomic::alpha, rho, and Foam::fvm::Sp().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "LaheyKEpsilon< BasicTurbulenceModel >"  )

◆ read()

bool read
virtual

Reimplemented from kEpsilon< BasicTurbulenceModel >.

Definition at line 113 of file LaheyKEpsilon.C.

◆ correct()

void correct
virtual

Reimplemented from kEpsilon< BasicTurbulenceModel >.

Definition at line 265 of file LaheyKEpsilon.C.

References kEpsilon< BasicTurbulenceModel >::correct().

Here is the call graph for this function:

Member Data Documentation

◆ alphaInversion_

dimensionedScalar alphaInversion_
protected

Definition at line 110 of file LaheyKEpsilon.H.

◆ Cp_

dimensionedScalar Cp_
protected

Definition at line 111 of file LaheyKEpsilon.H.

◆ C3_

dimensionedScalar C3_
protected

Definition at line 112 of file LaheyKEpsilon.H.

◆ Cmub_

dimensionedScalar Cmub_
protected

Definition at line 113 of file LaheyKEpsilon.H.

The documentation for this class was generated from the following files:
