PopulationBalancePhaseSystem< BasePhaseSystem > Class Template Reference

Class which provides population balance functionality. More...

Inheritance diagram for PopulationBalancePhaseSystem< BasePhaseSystem >:

Collaboration diagram for PopulationBalancePhaseSystem< BasePhaseSystem >:

Public Member Functions
	PopulationBalancePhaseSystem (const fvMesh &)
virtual	~PopulationBalancePhaseSystem ()
virtual tmp< volScalarField >	dmdt (const phasePairKey &key) const
virtual PtrList< volScalarField >	dmdts () const
virtual autoPtr< phaseSystem::massTransferTable >	massTransfer () const
virtual bool	read ()
virtual void	solve ()

Protected Types
typedef HashPtrTable< volScalarField, phasePairKey, phasePairKey::hash >	pDmdtTable

Protected Member Functions
virtual tmp< volScalarField >	pDmdt (const phasePairKey &key) const

Protected Attributes
PtrList< diameterModels::populationBalanceModel >	populationBalances_
pDmdtTable	pDmdt_

Detailed Description

template<class BasePhaseSystem>
class Foam::PopulationBalancePhaseSystem< BasePhaseSystem >

Class which provides population balance functionality.

See also

Foam::diameterModels::populationBalanceModel

Source files

• PopulationBalancePhaseSystem.H
• PopulationBalancePhaseSystem.C

Definition at line 51 of file PopulationBalancePhaseSystem.H.

Member Typedef Documentation

pDmdtTable

typedef HashPtrTable<volScalarField, phasePairKey, phasePairKey::hash> pDmdtTable

protected

Definition at line 60 of file PopulationBalancePhaseSystem.H.

Constructor & Destructor Documentation

PopulationBalancePhaseSystem()

PopulationBalancePhaseSystem

(

const fvMesh &

mesh

)

Definition at line 49 of file PopulationBalancePhaseSystem.C.

References Foam::dimDensity, Foam::dimTime, forAll, forAllConstIter, Foam::glTF::key(), phasePair::name(), phasePairKey::ordered(), and populationBalanceModel::phasePairs().

Here is the call graph for this function:

~PopulationBalancePhaseSystem()

~PopulationBalancePhaseSystem

virtual

Definition at line 128 of file PopulationBalancePhaseSystem.C.

Member Function Documentation

pDmdt()

Foam::tmp< Foam::volScalarField > pDmdt ( const phasePairKey &  key ) const

protectedvirtual

Definition at line 29 of file PopulationBalancePhaseSystem.C.

References Foam::glTF::key().

Here is the call graph for this function:

dmdt()

Foam::tmp< Foam::volScalarField > dmdt ( const phasePairKey &  key ) const

virtual

Definition at line 137 of file PopulationBalancePhaseSystem.C.

References Foam::glTF::key().

Here is the call graph for this function:

dmdts()

Foam::PtrList< Foam::volScalarField > dmdts

virtual

Definition at line 147 of file PopulationBalancePhaseSystem.C.

References forAllConstIter, phasePair::phase1(), and phasePair::phase2().

Here is the call graph for this function:

massTransfer()

Foam::autoPtr< Foam::phaseSystem::massTransferTable > massTransfer

virtual

Definition at line 166 of file PopulationBalancePhaseSystem.C.

References forAll, forAllConstIter, massTransfer(), phase::name(), phaseModel::name(), Foam::name(), Foam::negPart(), phasePairKey::ordered(), phasePair::phase1(), phasePair::phase2(), Foam::posPart(), psi, and Sp.

Here is the call graph for this function:

read()

bool read

virtual

Definition at line 226 of file PopulationBalancePhaseSystem.C.

References Foam::blockMeshTools::read().

Here is the call graph for this function:

solve()

void solve

virtual

Definition at line 244 of file PopulationBalancePhaseSystem.C.

References forAll, and solve().

Here is the call graph for this function:

Member Data Documentation

populationBalances_

PtrList<diameterModels::populationBalanceModel> populationBalances_

protected

Definition at line 66 of file PopulationBalancePhaseSystem.H.

pDmdt_

pDmdtTable pDmdt_

protected

Definition at line 69 of file PopulationBalancePhaseSystem.H.

---

The documentation for this class was generated from the following files:

• src/phaseSystemModels/reactingEuler/multiphaseSystem/PhaseSystems/PopulationBalancePhaseSystem/PopulationBalancePhaseSystem.H
• src/phaseSystemModels/reactingEuler/multiphaseSystem/PhaseSystems/PopulationBalancePhaseSystem/PopulationBalancePhaseSystem.C
