Particle secondary breakup model based on Pilch-Erdman total droplet breakup model. More...

Inheritance diagram for PilchErdman< CloudType >:

Collaboration diagram for PilchErdman< CloudType >:

Public Member Functions
	TypeName ("PilchErdman")

	PilchErdman (const dictionary &, CloudType &)

	PilchErdman (const PilchErdman< CloudType > &bum)

virtual autoPtr< BreakupModel< CloudType > >	clone () const

void	operator= (const PilchErdman< CloudType > &)=delete

virtual	~PilchErdman ()=default

virtual bool	update (const scalar dt, const vector &g, scalar &d, scalar &tc, scalar &ms, scalar &nParticle, scalar &KHindex, scalar &y, scalar &yDot, const scalar d0, const scalar rho, const scalar mu, const scalar sigma, const vector &U, const scalar rhoc, const scalar muc, const vector &Urel, const scalar Urmag, const scalar tMom, scalar &dChild, scalar &massChild)

Public Member Functions inherited from BreakupModel< CloudType >
	TypeName ("breakupModel")

	declareRunTimeSelectionTable (autoPtr, BreakupModel, dictionary,(const dictionary &dict, CloudType &owner),(dict, owner))

	BreakupModel (CloudType &owner)

	BreakupModel (const dictionary &dict, CloudType &owner, const word &type, bool solveOscillationEq=false)

	BreakupModel (const BreakupModel< CloudType > &bum)

virtual autoPtr< BreakupModel< CloudType > >	clone () const=0

virtual	~BreakupModel ()

bool	solveOscillationEq () const

const scalar &	y0 () const

const scalar &	yDot0 () const

const scalar &	TABComega () const

const scalar &	TABCmu () const

const scalar &	TABtwoWeCrit () const

Additional Inherited Members
Static Public Member Functions inherited from BreakupModel< CloudType >
static autoPtr< BreakupModel< CloudType > >	New (const dictionary &dict, CloudType &owner)

Protected Attributes inherited from BreakupModel< CloudType >
bool	solveOscillationEq_

scalar	y0_

scalar	yDot0_

scalar	TABComega_

scalar	TABCmu_

scalar	TABtwoWeCrit_

Detailed Description

template<class CloudType>
class Foam::PilchErdman< CloudType >

Particle secondary breakup model based on Pilch-Erdman total droplet breakup model.

Reference:

    Pilch, M., & Erdman, C. A. (1987).
    Use of breakup time data and velocity history data
    to predict the maximum size of stable fragments for
    acceleration-induced breakup of a liquid drop.
    International journal of multiphase flow, 13(6), 741-757.
    DOI:10.1016/0301-9322(87)90063-2

The droplet fragment velocity is described by the equation:

$V_d = V \sqrt(\epsilon)(B_1 T + B_2 T^2)$

where

	=	Fragment velocity
	=	Magnitude of the relative velocity
$\epsilon$	=	Density ratio (rho_carrier/rho_droplet)
	=	characteristic break-up time
	=	Model coefficient
	=	Model coefficient

Where:

The authors suggest that: compressible flow : B1 = 0.75*1.0; B2 = 3*0.116 incompressible flow : B1 = 0.75*0.5; B2 = 3*0.0758

Source files

Definition at line 107 of file PilchErdman.H.

Constructor & Destructor Documentation

◆ PilchErdman() [1/2]

PilchErdman	(	const dictionary &	dict,
		CloudType &	owner
	)

Definition at line 28 of file PilchErdman.C.

◆ PilchErdman() [2/2]

PilchErdman ( const PilchErdman< CloudType > & bum )

Definition at line 46 of file PilchErdman.C.

◆ ~PilchErdman()

virtual ~PilchErdman ( )

virtualdefault

Member Function Documentation

◆ TypeName()

TypeName ( "PilchErdman< CloudType >" )

◆ clone()

virtual autoPtr<BreakupModel<CloudType> > clone ( ) const

inlinevirtual

Definition at line 135 of file PilchErdman.H.

◆ operator=()

void operator= ( const PilchErdman< CloudType > & )

delete

◆ update()

bool update	(	const scalar	dt,
		const vector &	g,
		scalar &	d,
		scalar &	tc,
		scalar &	ms,
		scalar &	nParticle,
		scalar &	KHindex,
		scalar &	y,
		scalar &	yDot,
		const scalar	d0,
		const scalar	rho,
		const scalar	mu,
		const scalar	sigma,
		const vector &	U,
		const scalar	rhoc,
		const scalar	muc,
		const vector &	Urel,
		const scalar	Urmag,
		const scalar	tMom,
		scalar &	dChild,
		scalar &	massChild
	)
