Patch injection, by using patch flow rate to determine concentration and velocity. More...

Inheritance diagram for PatchFlowRateInjection< CloudType >:

Collaboration diagram for PatchFlowRateInjection< CloudType >:

Public Member Functions
	TypeName ("patchFlowRateInjection")

	PatchFlowRateInjection (const dictionary &dict, CloudType &owner, const word &modelName)

	PatchFlowRateInjection (const PatchFlowRateInjection< CloudType > &im)

virtual autoPtr< InjectionModel< CloudType > >	clone () const

virtual	~PatchFlowRateInjection ()

virtual void	updateMesh ()

scalar	timeEnd () const

virtual scalar	flowRate () const

virtual label	parcelsToInject (const scalar time0, const scalar time1)

virtual scalar	volumeToInject (const scalar time0, const scalar time1)

virtual void	setPositionAndCell (const label parcelI, const label nParcels, const scalar time, vector &position, label &cellOwner, label &tetFacei, label &tetPti)

virtual void	setProperties (const label parcelI, const label nParcels, const scalar time, typename CloudType::parcelType &parcel)

virtual bool	fullyDescribed () const

virtual bool	validInjection (const label parcelI)

virtual void	updateMesh (const polyMesh &mesh)

label	setPositionAndCell (const fvMesh &mesh, const scalar fraction01, Random &rnd, vector &position, label &cellOwner, label &tetFacei, label &tetPti)

virtual label	setPositionAndCell (const fvMesh &mesh, Random &rnd, vector &position, label &cellOwner, label &tetFacei, label &tetPti)

Public Member Functions inherited from InjectionModel< CloudType >
	TypeName ("injectionModel")

	declareRunTimeSelectionTable (autoPtr, InjectionModel, dictionary,(const dictionary &dict, CloudType &owner, const word &modelType),(dict, owner, modelType))

	InjectionModel (CloudType &owner)

	InjectionModel (const dictionary &dict, CloudType &owner, const word &modelName, const word &modelType)

	InjectionModel (const InjectionModel< CloudType > &im)

virtual	~InjectionModel ()=default

scalar	timeStart () const

scalar	volumeTotal () const

scalar	massTotal () const

scalar	massInjected () const

label	injectorID () const

virtual scalar	averageParcelMass ()

label	nInjections () const

label	parcelsAddedTotal () const

template<class TrackCloudType >
void	inject (TrackCloudType &cloud, typename CloudType::parcelType::trackingData &td)

template<class TrackCloudType >
void	injectSteadyState (TrackCloudType &cloud, typename CloudType::parcelType::trackingData &td, const scalar trackTime)

virtual void	info (Ostream &os)

Public Member Functions inherited from CloudSubModelBase< CloudType >
	CloudSubModelBase (CloudType &owner)

	CloudSubModelBase (CloudType &owner, const dictionary &dict, const word &baseName, const word &modelType, const word &dictExt="Coeffs")

	CloudSubModelBase (const word &modelName, CloudType &owner, const dictionary &dict, const word &baseName, const word &modelType)

	CloudSubModelBase (const CloudSubModelBase< CloudType > &smb)

virtual	~CloudSubModelBase ()

const CloudType &	owner () const

virtual bool	writeTime () const

virtual fileName	localPath () const

CloudType &	owner ()

virtual void	write (Ostream &os) const

Public Member Functions inherited from subModelBase
	subModelBase (dictionary &properties)

	subModelBase (dictionary &properties, const dictionary &dict, const word &baseName, const word &modelType, const word &dictExt="Coeffs")

	subModelBase (const word &modelName, dictionary &properties, const dictionary &dict, const word &baseName, const word &modelType)

	subModelBase (const subModelBase &smb)

virtual	~subModelBase ()

const word &	modelName () const

const dictionary &	dict () const

const word &	baseName () const

const word &	modelType () const

const dictionary &	coeffDict () const

const dictionary &	properties () const

virtual bool	defaultCoeffs (const bool printMsg) const

virtual bool	active () const

virtual void	cacheFields (const bool store)

template<class Type >
Type	getBaseProperty (const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
void	getBaseProperty (const word &entryName, Type &value) const

template<class Type >
void	setBaseProperty (const word &entryName, const Type &value)

bool	getModelDict (const word &entryName, dictionary &dict) const

template<class Type >
void	getModelProperty (const word &entryName, Type &value) const

template<class Type >
Type	getModelProperty (const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
void	setModelProperty (const word &entryName, const Type &value)

Public Member Functions inherited from patchInjectionBase
	patchInjectionBase (const polyMesh &mesh, const word &patchName)

	patchInjectionBase (const patchInjectionBase &pib)

virtual	~patchInjectionBase ()=default

virtual void	updateMesh (const polyMesh &mesh)

label	setPositionAndCell (const fvMesh &mesh, const scalar fraction01, Random &rnd, vector &position, label &cellOwner, label &tetFacei, label &tetPti)

virtual label	setPositionAndCell (const fvMesh &mesh, Random &rnd, vector &position, label &cellOwner, label &tetFacei, label &tetPti)

label	whichProc (const scalar fraction01) const

Additional Inherited Members
Public Types inherited from InjectionModel< CloudType >
enum	parcelBasis { pbNumber, pbMass, pbFixed }

typedef CloudType::parcelType	parcelType

Public Types inherited from CloudSubModelBase< CloudType >
typedef CloudType	cloudType

Static Public Member Functions inherited from InjectionModel< CloudType >
static autoPtr< InjectionModel< CloudType > >	New (const dictionary &dict, CloudType &owner)

static autoPtr< InjectionModel< CloudType > >	New (const dictionary &dict, const word &modelName, const word &modelType, CloudType &owner)

Protected Member Functions inherited from InjectionModel< CloudType >
virtual bool	prepareForNextTimeStep (const scalar time, label &newParcels, scalar &newVolumeFraction)

virtual bool	findCellAtPosition (label &celli, label &tetFacei, label &tetPti, vector &position, bool errorOnNotFound=true)

virtual scalar	setNumberOfParticles (const label parcels, const scalar volumeFraction, const scalar diameter, const scalar rho)

virtual void	postInjectCheck (const label parcelsAdded, const scalar massAdded)

Protected Member Functions inherited from subModelBase
bool	inLine () const

Protected Attributes inherited from InjectionModel< CloudType >
scalar	SOI_

scalar	volumeTotal_

scalar	massTotal_

autoPtr< Function1< scalar > >	massFlowRate_

scalar	massInjected_

label	nInjections_

label	parcelsAddedTotal_

parcelBasis	parcelBasis_

scalar	nParticleFixed_

scalar	time0_

scalar	timeStep0_

scalar	minParticlesPerParcel_

scalar	delayedVolume_

label	injectorID_

bool	ignoreOutOfBounds_

Protected Attributes inherited from CloudSubModelBase< CloudType >
CloudType &	owner_

Protected Attributes inherited from subModelBase
const word	modelName_

dictionary &	properties_

const dictionary	dict_

const word	baseName_

const word	modelType_

const dictionary	coeffDict_

Protected Attributes inherited from patchInjectionBase
const word	patchName_

const label	patchId_

scalar	patchArea_

vectorList	patchNormal_

labelList	cellOwners_

faceList	triFace_

labelList	triToFace_

scalarList	triCumulativeMagSf_

scalarList	sumTriMagSf_

Detailed Description

template<class CloudType>
class Foam::PatchFlowRateInjection< CloudType >

Patch injection, by using patch flow rate to determine concentration and velocity.

User specifies:

Total mass to inject
Name of patch
Injection duration
Injection target concentration/carrier volume flow rate

Properties:

Initial parcel velocity given by local flow velocity
Parcel diameters obtained by distribution model
Parcels injected randomly across the patch

Source files

Definition at line 65 of file PatchFlowRateInjection.H.

Constructor & Destructor Documentation

◆ PatchFlowRateInjection() [1/2]

PatchFlowRateInjection	(	const dictionary &	dict,
		CloudType &	owner,
		const word &	modelName
	)

Definition at line 31 of file PatchFlowRateInjection.C.

References DSMCCloud< ParcelType >::mesh(), and TimeState::userTimeToTime().

Here is the call graph for this function:

◆ PatchFlowRateInjection() [2/2]

PatchFlowRateInjection ( const PatchFlowRateInjection< CloudType > & im )

Definition at line 80 of file PatchFlowRateInjection.C.

◆ ~PatchFlowRateInjection()

~PatchFlowRateInjection

virtual

Definition at line 98 of file PatchFlowRateInjection.C.

Member Function Documentation

◆ TypeName()

TypeName ( "patchFlowRateInjection" )

◆ clone()

virtual autoPtr<InjectionModel<CloudType> > clone ( ) const

inlinevirtual

Implements InjectionModel< CloudType >.

Definition at line 111 of file PatchFlowRateInjection.H.

◆ updateMesh() [1/2]

void updateMesh

virtual

Reimplemented from InjectionModel< CloudType >.

Definition at line 105 of file PatchFlowRateInjection.C.

References mesh.

◆ timeEnd()

Foam::scalar timeEnd

virtual

Implements InjectionModel< CloudType >.

Definition at line 112 of file PatchFlowRateInjection.C.

◆ flowRate()

Foam::scalar flowRate

virtual

Definition at line 119 of file PatchFlowRateInjection.C.

References Foam::dimArea, Foam::dimVelocity, Foam::max(), mesh, DSMCCloud< ParcelType >::mesh(), phi, reduce(), rho, and Foam::sum().

Here is the call graph for this function:

◆ parcelsToInject()

Foam::label parcelsToInject	(	const scalar	time0,
		const scalar	time1
	)

virtual

Implements InjectionModel< CloudType >.

Definition at line 150 of file PatchFlowRateInjection.C.

References Foam::constant::universal::c, Random::globalPosition(), DSMCCloud< ParcelType >::rndGen(), and dimensioned::value().

Here is the call graph for this function:

◆ volumeToInject()

Foam::scalar volumeToInject	(	const scalar	time0,
		const scalar	time1
	)

virtual

Implements InjectionModel< CloudType >.

Definition at line 190 of file PatchFlowRateInjection.C.

References Foam::constant::universal::c, DSMCCloud< ParcelType >::constProps(), dimensioned::value(), and Foam::fieldTypes::volume.

Here is the call graph for this function:

◆ setPositionAndCell() [1/3]

void setPositionAndCell	(	const label	parcelI,
		const label	nParcels,
		const scalar	time,
		vector &	position,
		label &	cellOwner,
		label &	tetFacei,
		label &	tetPti
	)

virtual

Implements InjectionModel< CloudType >.

Definition at line 213 of file PatchFlowRateInjection.C.

References mesh, and rndGen.

◆ setProperties()

void setProperties	(	const label	parcelI,
		const label	nParcels,
		const scalar	time,
		typename CloudType::parcelType &	parcel
	)

virtual

Implements InjectionModel< CloudType >.

Definition at line 237 of file PatchFlowRateInjection.C.

◆ fullyDescribed()

bool fullyDescribed

virtual

Implements InjectionModel< CloudType >.

Definition at line 253 of file PatchFlowRateInjection.C.

◆ validInjection()

bool validInjection ( const label parcelI )

virtual

Implements InjectionModel< CloudType >.

Definition at line 260 of file PatchFlowRateInjection.C.

◆ updateMesh() [2/2]

void updateMesh

Definition at line 75 of file patchInjectionBase.C.

◆ setPositionAndCell() [2/3]

Foam::label setPositionAndCell

Definition at line 141 of file patchInjectionBase.C.

◆ setPositionAndCell() [3/3]

Foam::label setPositionAndCell

Definition at line 265 of file patchInjectionBase.C.

The documentation for this class was generated from the following files:

src/lagrangian/intermediate/submodels/Kinematic/InjectionModel/PatchFlowRateInjection/PatchFlowRateInjection.H
src/lagrangian/intermediate/submodels/Kinematic/InjectionModel/PatchFlowRateInjection/PatchFlowRateInjection.C
