PatchEdgeFaceWave< PrimitivePatchType, Type, TrackingData > Class Template Reference

Wave propagation of information along patch. Every iteration information goes through one layer of faces. Templated on information that is transferred. More...

Inheritance diagram for PatchEdgeFaceWave< PrimitivePatchType, Type, TrackingData >:

Collaboration diagram for PatchEdgeFaceWave< PrimitivePatchType, Type, TrackingData >:

Public Member Functions
	PatchEdgeFaceWave (const polyMesh &mesh, const PrimitivePatchType &patch, const labelList &initialEdges, const List< Type > &initialEdgesInfo, UList< Type > &allEdgeInfo, UList< Type > &allFaceInfo, const label maxIter, TrackingData &td=dummyTrackData_)
	PatchEdgeFaceWave (const polyMesh &mesh, const PrimitivePatchType &patch, UList< Type > &allEdgeInfo, UList< Type > &allFaceInfo, TrackingData &td=dummyTrackData_)
UList< Type > &	allEdgeInfo () const
UList< Type > &	allFaceInfo () const
const TrackingData &	data () const
label	nUnvisitedFaces () const
label	nUnvisitedEdges () const
void	setEdgeInfo (const labelList &changedEdges, const List< Type > &changedEdgesInfo)
label	edgeToFace ()
label	faceToEdge ()
label	iterate (const label maxIter)

Static Public Member Functions
static scalar	propagationTol ()
static void	setPropagationTol (const scalar tol)

Detailed Description

template<class PrimitivePatchType, class Type, class TrackingData = label>
class Foam::PatchEdgeFaceWave< PrimitivePatchType, Type, TrackingData >

Wave propagation of information along patch. Every iteration information goes through one layer of faces. Templated on information that is transferred.

Source files

• PatchEdgeFaceWave.H
• PatchEdgeFaceWave.C

Definition at line 68 of file PatchEdgeFaceWave.H.

Constructor & Destructor Documentation

PatchEdgeFaceWave() [1/2]

PatchEdgeFaceWave	(	const polyMesh &	mesh,
		const PrimitivePatchType &	patch,
		const labelList &	initialEdges,
		const List< Type > &	initialEdgesInfo,
		UList< Type > &	allEdgeInfo,
		UList< Type > &	allFaceInfo,
		const label	maxIter,
		TrackingData &	td = dummyTrackData_
	)

Definition at line 284 of file PatchEdgeFaceWave.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, and Foam::Pout.

Here is the call graph for this function:

PatchEdgeFaceWave() [2/2]

PatchEdgeFaceWave	(	const polyMesh &	mesh,
		const PrimitivePatchType &	patch,
		UList< Type > &	allEdgeInfo,
		UList< Type > &	allFaceInfo,
		TrackingData &	td = dummyTrackData_
	)

Definition at line 374 of file PatchEdgeFaceWave.C.

Member Function Documentation

propagationTol()

static scalar propagationTol ( )

inlinestatic

Definition at line 163 of file PatchEdgeFaceWave.H.

setPropagationTol()

static void setPropagationTol ( const scalar  tol )

inlinestatic

Definition at line 169 of file PatchEdgeFaceWave.H.

allEdgeInfo()

UList<Type>& allEdgeInfo ( ) const

inline

Definition at line 210 of file PatchEdgeFaceWave.H.

allFaceInfo()

UList<Type>& allFaceInfo ( ) const

inline

Definition at line 216 of file PatchEdgeFaceWave.H.

data()

const TrackingData& data ( ) const

inline

Definition at line 222 of file PatchEdgeFaceWave.H.

nUnvisitedFaces()

label nUnvisitedFaces ( ) const

inline

Definition at line 234 of file PatchEdgeFaceWave.H.

nUnvisitedEdges()

label nUnvisitedEdges ( ) const

inline

Definition at line 239 of file PatchEdgeFaceWave.H.

setEdgeInfo()

void setEdgeInfo	(	const labelList &	changedEdges,
		const List< Type > &	changedEdgesInfo
	)

Definition at line 420 of file PatchEdgeFaceWave.C.

References forAll, and List::set().

Here is the call graph for this function:

edgeToFace()

Foam::label edgeToFace

Definition at line 522 of file PatchEdgeFaceWave.C.

References Foam::abort(), Foam::expressions::patchExpr::debug, Foam::endl(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::nl, Foam::Pout, and Foam::returnReduce().

Here is the call graph for this function:

faceToEdge()

Foam::label faceToEdge

Definition at line 459 of file PatchEdgeFaceWave.C.

References Foam::abort(), Foam::expressions::patchExpr::debug, Foam::endl(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::nl, Foam::Pout, and Foam::returnReduce().

Here is the call graph for this function:

iterate()

Foam::label iterate

(

const label

maxIter

)

Definition at line 584 of file PatchEdgeFaceWave.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), Foam::nl, and Foam::Pout.

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/meshTools/algorithms/PatchEdgeFaceWave/PatchEdgeFaceWave.H
• src/meshTools/algorithms/PatchEdgeFaceWave/PatchEdgeFaceWave.C
