Function object to collect the parcel mass- and mass flow rate over a set of polygons. The polygons can either be specified by sets of user- supplied points, or in a concentric circles arrangement. If a parcel is 'collected', it can be flagged to be removed from the domain using the removeCollected entry. More...

Inheritance diagram for ParticleCollector< CloudType >:

[legend]

Collaboration diagram for ParticleCollector< CloudType >:

[legend]

Public Types
enum	modeType { mtPolygon, mtConcentricCircle, mtUnknown }

Public Types inherited from CloudSubModelBase< CloudType >
typedef CloudType	cloudType

Public Member Functions
	TypeName ("particleCollector")

	ParticleCollector (const dictionary &dict, CloudType &owner, const word &modelName)

	ParticleCollector (const ParticleCollector< CloudType > &pc)

virtual autoPtr< CloudFunctionObject< CloudType > >	clone () const

virtual	~ParticleCollector ()=default

bool	resetOnWrite () const

virtual void	postMove (parcelType &p, const scalar dt, const point &position0, bool &keepParticle)

Public Member Functions inherited from CloudFunctionObject< CloudType >
	TypeName ("cloudFunctionObject")

	declareRunTimeSelectionTable (autoPtr, CloudFunctionObject, dictionary,(const dictionary &dict, CloudType &owner, const word &modelName),(dict, owner, modelName))

	CloudFunctionObject (CloudType &owner)

	CloudFunctionObject (const dictionary &dict, CloudType &owner, const word &objectType, const word &modelName)

	CloudFunctionObject (const CloudFunctionObject< CloudType > &ppm)

virtual	~CloudFunctionObject ()=default

virtual void	preEvolve (const typename parcelType::trackingData &td)

virtual void	postEvolve (const typename parcelType::trackingData &td)

virtual void	postPatch (const parcelType &p, const polyPatch &pp, bool &keepParticle)

virtual void	postFace (const parcelType &p, bool &keepParticle)

const fileName &	outputDir () const

fileName	writeTimeDir () const

Public Member Functions inherited from CloudSubModelBase< CloudType >
	CloudSubModelBase (CloudType &owner)

	CloudSubModelBase (CloudType &owner, const dictionary &dict, const word &baseName, const word &modelType, const word &dictExt="Coeffs")

	CloudSubModelBase (const word &modelName, CloudType &owner, const dictionary &dict, const word &baseName, const word &modelType)

	CloudSubModelBase (const CloudSubModelBase< CloudType > &smb)

virtual	~CloudSubModelBase ()

const CloudType &	owner () const

virtual bool	writeTime () const

virtual fileName	localPath () const

CloudType &	owner ()

virtual void	write (Ostream &os) const

Public Member Functions inherited from subModelBase
	subModelBase (dictionary &properties)

	subModelBase (dictionary &properties, const dictionary &dict, const word &baseName, const word &modelType, const word &dictExt="Coeffs")

	subModelBase (const word &modelName, dictionary &properties, const dictionary &dict, const word &baseName, const word &modelType)

	subModelBase (const subModelBase &smb)

virtual	~subModelBase ()

const word &	modelName () const

const dictionary &	dict () const

const word &	baseName () const

const word &	modelType () const

const dictionary &	coeffDict () const

const dictionary &	properties () const

virtual bool	defaultCoeffs (const bool printMsg) const

virtual bool	active () const

virtual void	cacheFields (const bool store)

template<class Type >
Type	getBaseProperty (const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
void	getBaseProperty (const word &entryName, Type &value) const

template<class Type >
void	setBaseProperty (const word &entryName, const Type &value)

bool	getModelDict (const word &entryName, dictionary &dict) const

template<class Type >
void	getModelProperty (const word &entryName, Type &value) const

template<class Type >
Type	getModelProperty (const word &entryName, const Type &defaultValue=Type(Zero)) const

template<class Type >
void	setModelProperty (const word &entryName, const Type &value)

Protected Member Functions
void	write ()

Protected Member Functions inherited from subModelBase
bool	inLine () const

Additional Inherited Members
Static Public Member Functions inherited from CloudFunctionObject< CloudType >
static autoPtr< CloudFunctionObject< CloudType > >	New (const dictionary &dict, CloudType &owner, const word &objectType, const word &modelName)

Protected Attributes inherited from CloudSubModelBase< CloudType >
CloudType &	owner_

Protected Attributes inherited from subModelBase
const word	modelName_

dictionary &	properties_

const dictionary	dict_

const word	baseName_

const word	modelType_

const dictionary	coeffDict_

Detailed Description

template<class CloudType>
class Foam::ParticleCollector< CloudType >

Function object to collect the parcel mass- and mass flow rate over a set of polygons. The polygons can either be specified by sets of user- supplied points, or in a concentric circles arrangement. If a parcel is 'collected', it can be flagged to be removed from the domain using the removeCollected entry.

Example usage:

particleCollector1
{
    type            particleCollector;

    mode            concentricCircle;
    origin          (0.05 0.025 0.005);
    radius          (0.01 0.025 0.05);
    nSector         10;
    refDir          (1 0 0);
    normal          (0 0 1);

    negateParcelsOppositeNormal no;
    removeCollected no;
    surfaceFormat   vtk;
    resetOnWrite    no;
    log             yes;
}

particleCollector2
{
    type            particleCollector;

    mode            polygon;
    polygons
    (
        (
            (0 0 0)
            (1 0 0)
            (1 1 0)
            (0 1 0)
        )
        (
            (0 0 1)
            (1 0 1)
            (1 1 1)
            (0 1 1)
        )
    );
    normal          (0 0 1);

    negateParcelsOppositeNormal no;
    removeCollected no;
    surfaceFormat   vtk;
    resetOnWrite    no;
    log             yes;
}

Source files

Definition at line 108 of file ParticleCollector.H.

Member Enumeration Documentation

◆ modeType

enum modeType

Enumerator
mtPolygon
mtConcentricCircle
mtUnknown

Definition at line 114 of file ParticleCollector.H.

Constructor & Destructor Documentation

◆ ParticleCollector() [1/2]

ParticleCollector	(	const dictionary &	dict,
		CloudType &	owner,
		const word &	modelName
	)

Definition at line 509 of file ParticleCollector.C.

References Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, forAll, Foam::mag(), Foam::mode(), and Foam::normalised().

Here is the call graph for this function:

◆ ParticleCollector() [2/2]

ParticleCollector ( const ParticleCollector< CloudType > & pc )

Definition at line 596 of file ParticleCollector.C.

◆ ~ParticleCollector()

virtual ~ParticleCollector ( )

virtualdefault

Member Function Documentation

◆ write()

void write

protectedvirtual

Reimplemented from CloudFunctionObject< CloudType >.

Definition at line 396 of file ParticleCollector.C.

References Foam::constant::atomic::alpha, beta(), Foam::expressions::patchExpr::debug, Foam::endl(), forAll, Foam::Info, mesh, Foam::New(), Foam::nl, Foam::returnReduce(), Foam::tab, Time::timeName(), dimensioned::value(), writer< Type >::write(), and Foam::Zero.

Here is the call graph for this function:

◆ TypeName()

TypeName ( "particleCollector" )

◆ clone()

virtual autoPtr<CloudFunctionObject<CloudType> > clone ( ) const

inlinevirtual

Reimplemented from CloudFunctionObject< CloudType >.

Definition at line 261 of file ParticleCollector.H.

◆ resetOnWrite()

bool resetOnWrite

inline

Definition at line 23 of file ParticleCollectorI.H.

◆ postMove()

void postMove	(	parcelType &	p,
		const scalar	dt,
		const point &	position0,
		bool &	keepParticle
	)

virtual

Reimplemented from CloudFunctionObject< CloudType >.

Definition at line 630 of file ParticleCollector.C.

References forAll, Foam::mag(), and p.

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/lagrangian/intermediate/submodels/CloudFunctionObjects/ParticleCollector/ParticleCollector.H
src/lagrangian/intermediate/submodels/CloudFunctionObjects/ParticleCollector/ParticleCollector.C
src/lagrangian/intermediate/submodels/CloudFunctionObjects/ParticleCollector/ParticleCollectorI.H
