PPCG Class Reference

Preconditioned pipelined conjugate gradient solver for symmetric lduMatrices using a run-time selectable preconditioner. More...

Inheritance diagram for PPCG:

Collaboration diagram for PPCG:

Public Member Functions
	TypeName ("PPCG")
	PPCG (const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces, const dictionary &solverControls)
virtual	~PPCG ()=default
virtual solverPerformance	solve (scalarField &psi, const scalarField &source, const direction cmpt=0) const
Public Member Functions inherited from lduMatrix::solver
virtual const word &	type () const =0
	declareRunTimeSelectionTable (autoPtr, solver, symMatrix,(const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces, const dictionary &solverControls),(fieldName, matrix, interfaceBouCoeffs, interfaceIntCoeffs, interfaces, solverControls))
	declareRunTimeSelectionTable (autoPtr, solver, asymMatrix,(const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces, const dictionary &solverControls),(fieldName, matrix, interfaceBouCoeffs, interfaceIntCoeffs, interfaces, solverControls))
	solver (const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces, const dictionary &solverControls)
virtual	~solver ()=default
const word &	fieldName () const noexcept
const lduMatrix &	matrix () const noexcept
const FieldField< Field, scalar > &	interfaceBouCoeffs () const noexcept
const FieldField< Field, scalar > &	interfaceIntCoeffs () const noexcept
const lduInterfaceFieldPtrsList &	interfaces () const noexcept
virtual void	read (const dictionary &)
virtual solverPerformance	scalarSolve (solveScalarField &psi, const solveScalarField &source, const direction cmpt=0) const
solveScalarField::cmptType	normFactor (const solveScalarField &psi, const solveScalarField &source, const solveScalarField &Apsi, solveScalarField &tmpField) const

Protected Member Functions
solverPerformance	scalarSolveCG (solveScalarField &psi, const solveScalarField &source, const direction cmpt, const bool cgMode) const
Protected Member Functions inherited from lduMatrix::solver
virtual void	readControls ()

Additional Inherited Members
Static Public Member Functions inherited from lduMatrix::solver
static autoPtr< solver >	New (const word &fieldName, const lduMatrix &matrix, const FieldField< Field, scalar > &interfaceBouCoeffs, const FieldField< Field, scalar > &interfaceIntCoeffs, const lduInterfaceFieldPtrsList &interfaces, const dictionary &solverControls)
Protected Attributes inherited from lduMatrix::solver
word	fieldName_
const lduMatrix &	matrix_
const FieldField< Field, scalar > &	interfaceBouCoeffs_
const FieldField< Field, scalar > &	interfaceIntCoeffs_
lduInterfaceFieldPtrsList	interfaces_
dictionary	controlDict_
int	log_
label	minIter_
label	maxIter_
scalar	tolerance_
scalar	relTol_
profilingTrigger	profiling_
Static Protected Attributes inherited from lduMatrix::solver
static const label	defaultMaxIter_ = 1000

Detailed Description

Preconditioned pipelined conjugate gradient solver for symmetric lduMatrices using a run-time selectable preconditioner.

Reference:

    P. Ghysels, W. Vanroose.
    "Hiding global synchronization latency in the
     preconditioned Conjugate Gradient algorithm"

and implementation details from

    Paul Eller, William Gropp
    "Scalable Non-blocking Preconditioned Conjugate Gradient Methods"

Source files

• PPCG.H
• PPCG.C

Definition at line 60 of file PPCG.H.

Constructor & Destructor Documentation

PPCG()

PPCG	(	const word &	fieldName,
		const lduMatrix &	matrix,
		const FieldField< Field, scalar > &	interfaceBouCoeffs,
		const FieldField< Field, scalar > &	interfaceIntCoeffs,
		const lduInterfaceFieldPtrsList &	interfaces,
		const dictionary &	solverControls
	)

Definition at line 252 of file PPCG.C.

~PPCG()

virtual ~PPCG ( )

virtualdefault

Member Function Documentation

scalarSolveCG()

Foam::solverPerformance scalarSolveCG ( solveScalarField &  psi, const solveScalarField &  source, const direction  cmpt, const bool  cgMode  ) const

protected

Definition at line 75 of file PPCG.C.

References Foam::constant::atomic::alpha, beta(), SolverPerformance::checkConvergence(), Foam::expressions::patchExpr::debug, delta, Foam::endl(), SolverPerformance::finalResidual(), gamma, lduMatrix::preconditioner::getName(), Foam::Info, SolverPerformance::initialResidual(), n, lduMatrix::preconditioner::New(), SolverPerformance::nIterations(), p, UPstream::parRun(), psi, s, Foam::type(), and UPstream::waitRequest().

Here is the call graph for this function:

TypeName()

TypeName

(

"PPCG"

)

solve()

Foam::solverPerformance solve ( scalarField &  psi, const scalarField &  source, const direction  cmpt = 0  ) const

virtual

Implements lduMatrix::solver.

Reimplemented in PPCR.

Definition at line 276 of file PPCG.C.

References refPtr< Field< Type > >::ref().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/matrices/lduMatrix/solvers/PPCG/PPCG.H
• src/OpenFOAM/matrices/lduMatrix/solvers/PPCG/PPCG.C
