OFstreamCollator Class Reference

Threaded file writer. More...

Public Member Functions
	TypeName ("OFstreamCollator")
	OFstreamCollator (const off_t maxBufferSize)
	OFstreamCollator (const off_t maxBufferSize, const label comm)
virtual	~OFstreamCollator ()
bool	write (const word &objectType, const fileName &, const string &data, IOstreamOption streamOpt, const bool append, const bool useThread=true, const dictionary &headerEntries=dictionary::null)
void	waitAll ()

Detailed Description

Threaded file writer.

Collects all data from all processors and writes as single 'decomposedBlockData' file. The operation is determined by the buffer size (maxThreadFileBufferSize setting):

• local size of data is larger than buffer: receive and write processor by processor (i.e. 'scheduled'). Does not use a thread, no file size limit.
• total size of data is larger than buffer (but local is not): thread does all the collecting and writing of the processors. No file size limit.
• total size of data is less than buffer: collecting is done locally; the thread only does the writing (since the data has already been collected)

Source files

• OFstreamCollator.H
• OFstreamCollator.C

Definition at line 66 of file OFstreamCollator.H.

Constructor & Destructor Documentation

OFstreamCollator() [1/2]

OFstreamCollator ( const off_t  maxBufferSize )

explicit

Definition at line 279 of file OFstreamCollator.C.

OFstreamCollator() [2/2]

OFstreamCollator	(	const off_t	maxBufferSize,
		const label	comm
	)

Definition at line 296 of file OFstreamCollator.C.

~OFstreamCollator()

~OFstreamCollator ( )

virtual

Definition at line 317 of file OFstreamCollator.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), UPstream::freeCommunicator(), and Foam::Pout.

Here is the call graph for this function:

Member Function Documentation

TypeName()

TypeName

(

"OFstreamCollator"

)

write()

bool write	(	const word &	objectType,
		const fileName &	fName,
		const string &	data,
		IOstreamOption	streamOpt,
		const bool	append,
		const bool	useThread = true,
		const dictionary &	headerEntries = dictionary::null
	)

Definition at line 339 of file OFstreamCollator.C.

References Foam::abort(), append(), UList::cdata(), Foam::expressions::patchExpr::debug, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, decomposedBlockData::gather(), UPstream::haveThreads(), UPstream::master(), Foam::max(), UPstream::msgType(), UPstream::nonBlocking, UPstream::nRequests(), string::null, Foam::Pout, autoPtr::ptr(), UIPstream::read(), Pstream::scatter(), PtrList::set(), PtrList::setSize(), UList::size_bytes(), UPstream::waitRequests(), UOPstream::write(), and Foam::writeData().

Referenced by threadedCollatedOFstream::~threadedCollatedOFstream().

Here is the call graph for this function:

Here is the caller graph for this function:

waitAll()

void waitAll

(

)

Definition at line 578 of file OFstreamCollator.C.

References Foam::expressions::patchExpr::debug, Foam::endl(), UPstream::master(), and Foam::Pout.

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/global/fileOperations/collatedFileOperation/OFstreamCollator.H
• src/OpenFOAM/global/fileOperations/collatedFileOperation/OFstreamCollator.C
