MeshObject< Mesh, MeshObjectType, Type > Class Template Reference

Templated abstract base-class for optional mesh objects used to automate their allocation to the mesh database and the mesh-modifier event-loop. More...

Inheritance diagram for MeshObject< Mesh, MeshObjectType, Type >:

Collaboration diagram for MeshObject< Mesh, MeshObjectType, Type >:

Public Member Functions
	MeshObject (const Mesh &mesh)
virtual	~MeshObject ()=default
const Mesh &	mesh () const
virtual bool	writeData (Ostream &os) const

Static Public Member Functions
template<class... Args>
static const Type &	New (const Mesh &mesh, Args &&... args)
static bool	Delete (const Mesh &mesh)

Protected Attributes
const Mesh &	mesh_

Detailed Description

template<class Mesh, template< class > class MeshObjectType, class Type>
class Foam::MeshObject< Mesh, MeshObjectType, Type >

Templated abstract base-class for optional mesh objects used to automate their allocation to the mesh database and the mesh-modifier event-loop.

MeshObject is templated on the type of mesh it is allocated to, the type of the mesh object (TopologicalMeshObject, GeometricMeshObject, MoveableMeshObject, UpdateableMeshObject) and the type of the actual object it is created for example:

class leastSquaresVectors
:
    public MeshObject<fvMesh, MoveableMeshObject, leastSquaresVectors>
{
.
.
.
    //- Delete the least square vectors when the mesh moves
    virtual bool movePoints();
};

MeshObject types:

• TopologicalMeshObject: mesh object to be deleted on topology change
• GeometricMeshObject: mesh object to be deleted on geometry change
• MoveableMeshObject: mesh object to be updated in movePoints
• UpdateableMeshObject: mesh object to be updated in updateMesh or movePoints

Note

movePoints must be provided for MeshObjects of type MoveableMeshObject and both movePoints and updateMesh functions must exist, provided for MeshObjects of type UpdateableMeshObject.

Source files

• MeshObject.H
• MeshObject.C

Definition at line 84 of file MeshObject.H.

Constructor & Destructor Documentation

MeshObject()

MeshObject ( const Mesh &  mesh )

explicit

Definition at line 29 of file MeshObject.C.

~MeshObject()

virtual ~MeshObject ( )

virtualdefault

Member Function Documentation

New()

const Type & New ( const Mesh &  mesh, Args &&...  args  )

static

Definition at line 41 of file MeshObject.C.

Referenced by dynamicOversetFvMesh::addInterpolation(), CentredFitScheme< Type, Polynomial, Stencil >::correction(), CentredFitSnGradScheme< Type, Polynomial, Stencil >::correction(), PureUpwindFitScheme< Type, Polynomial, Stencil >::correction(), UpwindFitScheme< Type, Polynomial, Stencil >::correction(), dynamicOversetFvMesh::init(), dynamicOversetFvMesh::interpolate(), dynamicOversetFvMesh::interpolateFields(), gravity::New(), dynamicOversetFvMesh::normalisation(), LeastSquaresVectors< Stencil >::stencil(), dynamicOversetFvMesh::updateAddressing(), and dynamicOversetFvMesh::writeObject().

Here is the caller graph for this function:

Delete()

bool Delete ( const Mesh &  mesh )

static

Definition at line 75 of file MeshObject.C.

mesh()

const Mesh& mesh ( ) const

inline

Definition at line 118 of file MeshObject.H.

Referenced by faMesh::mesh(), and uniformInterpolatedDisplacementPointPatchVectorField::uniformInterpolatedDisplacementPointPatchVectorField().

Here is the caller graph for this function:

writeData()

virtual bool writeData ( Ostream &  os ) const

inlinevirtual

Definition at line 123 of file MeshObject.H.

Member Data Documentation

mesh_

const Mesh& mesh_

protected

Definition at line 92 of file MeshObject.H.

Referenced by MeshObject< fvMesh, TopologicalMeshObject, zoneCPCStencil >::mesh().

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/meshes/MeshObject/MeshObject.H
• src/OpenFOAM/meshes/MeshObject/MeshObject.C
