LiquidEvaporation< CloudType > Class Template Reference

Liquid evaporation model. More...

Inheritance diagram for LiquidEvaporation< CloudType >:

Collaboration diagram for LiquidEvaporation< CloudType >:

Public Member Functions
	TypeName ("liquidEvaporation")
	LiquidEvaporation (const dictionary &dict, CloudType &cloud)
	LiquidEvaporation (const LiquidEvaporation< CloudType > &pcm)
virtual autoPtr< PhaseChangeModel< CloudType > >	clone () const
virtual	~LiquidEvaporation ()
virtual void	calculate (const scalar dt, const label celli, const scalar Re, const scalar Pr, const scalar d, const scalar nu, const scalar rho, const scalar T, const scalar Ts, const scalar pc, const scalar Tc, const scalarField &X, const scalarField &solMass, const scalarField &liqMass, scalarField &dMassPC) const
virtual scalar	dh (const label idc, const label idl, const scalar p, const scalar T) const
virtual scalar	Tvap (const scalarField &X) const
virtual scalar	TMax (const scalar p, const scalarField &X) const
Public Member Functions inherited from PhaseChangeModel< CloudType >
	TypeName ("phaseChangeModel")
	declareRunTimeSelectionTable (autoPtr, PhaseChangeModel, dictionary,(const dictionary &dict, CloudType &owner),(dict, owner))
	PhaseChangeModel (CloudType &owner)
	PhaseChangeModel (const dictionary &dict, CloudType &owner, const word &type)
	PhaseChangeModel (const PhaseChangeModel< CloudType > &pcm)
virtual autoPtr< PhaseChangeModel< CloudType > >	clone () const=0
virtual	~PhaseChangeModel ()=default
const enthalpyTransferType &	enthalpyTransfer () const
void	addToPhaseChangeMass (const scalar dMass)
virtual void	info (Ostream &os)

Protected Member Functions
scalar	Sh (const scalar Re, const scalar Sc) const
tmp< scalarField >	calcXc (const label celli) const
Protected Member Functions inherited from PhaseChangeModel< CloudType >
enthalpyTransferType	wordToEnthalpyTransfer (const word &etName) const
scalar	Sh () const

Protected Attributes
const liquidMixtureProperties &	liquids_
List< word >	activeLiquids_
List< label >	liqToCarrierMap_
List< label >	liqToLiqMap_
Protected Attributes inherited from PhaseChangeModel< CloudType >
enthalpyTransferType	enthalpyTransfer_
scalar	dMass_

Additional Inherited Members
Public Types inherited from PhaseChangeModel< CloudType >
enum	enthalpyTransferType
Static Public Member Functions inherited from PhaseChangeModel< CloudType >
static autoPtr< PhaseChangeModel< CloudType > >	New (const dictionary &dict, CloudType &owner)
Static Public Attributes inherited from PhaseChangeModel< CloudType >
static const wordList	enthalpyTransferTypeNames

Detailed Description

template<class CloudType>
class Foam::LiquidEvaporation< CloudType >

Liquid evaporation model.

• uses ideal gas assumption

Definition at line 47 of file LiquidEvaporation.H.

Constructor & Destructor Documentation

LiquidEvaporation() [1/2]

LiquidEvaporation	(	const dictionary &	dict,
		CloudType &	cloud
	)

Definition at line 64 of file LiquidEvaporation.C.

References Foam::endl(), forAll, Foam::Info, Foam::nl, and WarningInFunction.

Here is the call graph for this function:

LiquidEvaporation() [2/2]

LiquidEvaporation

(

const LiquidEvaporation< CloudType > &

pcm

)

Definition at line 106 of file LiquidEvaporation.C.

~LiquidEvaporation()

~LiquidEvaporation

virtual

Definition at line 121 of file LiquidEvaporation.C.

Member Function Documentation

Sh()

Foam::scalar Sh ( const scalar  Re, const scalar  Sc  ) const

protected

Definition at line 51 of file LiquidEvaporation.C.

References Foam::cbrt(), Foam::Re(), and Foam::sqrt().

Here is the call graph for this function:

calcXc()

Foam::tmp< Foam::scalarField > calcXc ( const label  celli ) const

protected

Definition at line 32 of file LiquidEvaporation.C.

References forAll, Foam::sum(), thermo, and Y.

Here is the call graph for this function:

TypeName()

TypeName

(

"liquidEvaporation"

)

clone()

virtual autoPtr<PhaseChangeModel<CloudType> > clone ( ) const

inlinevirtual

Definition at line 92 of file LiquidEvaporation.H.

calculate()

void calculate ( const scalar  dt, const label  celli, const scalar  Re, const scalar  Pr, const scalar  d, const scalar  nu, const scalar  rho, const scalar  T, const scalar  Ts, const scalar  pc, const scalar  Tc, const scalarField &  X, const scalarField &  solMass, const scalarField &  liqMass, scalarField &  dMassPC  ) const

virtual

Implements PhaseChangeModel< CloudType >.

Definition at line 129 of file LiquidEvaporation.C.

References Cs, Foam::expressions::patchExpr::debug, Foam::endl(), forAll, Foam::max(), nu, Foam::constant::mathematical::pi(), Foam::Re(), Foam::constant::thermodynamic::RR, Foam::sqr(), Foam::T(), and WarningInFunction.

Here is the call graph for this function:

dh()

Foam::scalar dh ( const label  idc, const label  idl, const scalar  p, const scalar  T  ) const

virtual

Reimplemented from PhaseChangeModel< CloudType >.

Definition at line 212 of file LiquidEvaporation.C.

References Foam::abort(), Foam::FatalError, FatalErrorInFunction, p, and Foam::T().

Here is the call graph for this function:

Tvap()

Foam::scalar Tvap ( const scalarField &  X ) const

virtual

Reimplemented from PhaseChangeModel< CloudType >.

Definition at line 250 of file LiquidEvaporation.C.

TMax()

Foam::scalar TMax ( const scalar  p, const scalarField &  X  ) const

virtual

Reimplemented from PhaseChangeModel< CloudType >.

Definition at line 260 of file LiquidEvaporation.C.

References p.

Member Data Documentation

liquids_

const liquidMixtureProperties& liquids_

protected

Definition at line 56 of file LiquidEvaporation.H.

activeLiquids_

List<word> activeLiquids_

protected

Definition at line 59 of file LiquidEvaporation.H.

liqToCarrierMap_

List<label> liqToCarrierMap_

protected

Definition at line 62 of file LiquidEvaporation.H.

liqToLiqMap_

List<label> liqToLiqMap_

protected

Definition at line 65 of file LiquidEvaporation.H.

---

The documentation for this class was generated from the following files:

• src/lagrangian/intermediate/submodels/Reacting/PhaseChangeModel/LiquidEvaporation/LiquidEvaporation.H
• src/lagrangian/intermediate/submodels/Reacting/PhaseChangeModel/LiquidEvaporation/LiquidEvaporation.C
