Liquid evaporation/condensation model for solution of liquid and solid. More...

Inheritance diagram for LiquidEvapFuchsKnudsen< CloudType >:

Collaboration diagram for LiquidEvapFuchsKnudsen< CloudType >:

[legend]

Public Types
enum	activityCoeffMethodType { pUNIFAC, pHoff }

Public Types inherited from PhaseChangeModel< CloudType >
enum	enthalpyTransferType

Public Member Functions
	TypeName ("liquidEvapFuchsKnudsen")

	LiquidEvapFuchsKnudsen (const dictionary &dict, CloudType &cloud)

	LiquidEvapFuchsKnudsen (const LiquidEvapFuchsKnudsen< CloudType > &pcm)

virtual autoPtr< PhaseChangeModel< CloudType > >	clone () const

virtual	~LiquidEvapFuchsKnudsen ()=default

virtual void	calculate (const scalar dt, const label celli, const scalar Re, const scalar Pr, const scalar d, const scalar nu, const scalar rho, const scalar T, const scalar Ts, const scalar pc, const scalar Tc, const scalarField &X, const scalarField &Xsol, const scalarField &liqMass, scalarField &dMassPC) const

virtual scalar	dh (const label idc, const label idl, const scalar p, const scalar T) const

virtual scalar	Tvap (const scalarField &X) const

virtual scalar	TMax (const scalar p, const scalarField &X) const

Public Member Functions inherited from PhaseChangeModel< CloudType >
	TypeName ("phaseChangeModel")

	declareRunTimeSelectionTable (autoPtr, PhaseChangeModel, dictionary,(const dictionary &dict, CloudType &owner),(dict, owner))

	PhaseChangeModel (CloudType &owner)

	PhaseChangeModel (const dictionary &dict, CloudType &owner, const word &type)

	PhaseChangeModel (const PhaseChangeModel< CloudType > &pcm)

virtual autoPtr< PhaseChangeModel< CloudType > >	clone () const=0

virtual	~PhaseChangeModel ()=default

const enthalpyTransferType &	enthalpyTransfer () const

void	addToPhaseChangeMass (const scalar dMass)

virtual void	info (Ostream &os)

Protected Member Functions
scalar	Sh (const scalar Re, const scalar Sc) const

tmp< scalarField >	calcXc (const label celli) const

void	calcXcSolution (const scalar massliq, const scalar masssol, scalar &Xliq, scalar &Xsol) const

scalar	activityCoeff (const scalar Xliq, const scalar Ysol) const

Protected Member Functions inherited from PhaseChangeModel< CloudType >
enthalpyTransferType	wordToEnthalpyTransfer (const word &etName) const

scalar	Sh () const

Protected Attributes
activityCoeffMethodType	method_

scalar	gamma_

scalar	alpha_

const liquidMixtureProperties &	liquids_

List< word >	solution_

label	liqToCarrierMap_

label	liqToLiqMap_

label	solToSolMap_

Protected Attributes inherited from PhaseChangeModel< CloudType >
enthalpyTransferType	enthalpyTransfer_

scalar	dMass_

Additional Inherited Members
Static Public Member Functions inherited from PhaseChangeModel< CloudType >
static autoPtr< PhaseChangeModel< CloudType > >	New (const dictionary &dict, CloudType &owner)

Static Public Attributes inherited from PhaseChangeModel< CloudType >
static const wordList	enthalpyTransferTypeNames

Detailed Description

template<class CloudType>
class Foam::LiquidEvapFuchsKnudsen< CloudType >

Liquid evaporation/condensation model for solution of liquid and solid.

This model takes into account the Fuchs-Knudsen number correction, the modified Raoult's law is used to obtain the concenration of the evapora ble component on the surface and the activity coefficient is used. The correction Kelvin effect is used.

Reference:

    Xiaole Chen, Yu Feng, Wenqi Zhon, Clement Kleinstreuer.
    Numerical investigation of the interaction, transport and deposition
    of multicomponent droplets in a a simple mouth-throat model.
    Journal of Aerosol Science, 105(2017), 108-127.
    DOI:10.1016/j.jaerosci.2016.12.001

Definition at line 60 of file LiquidEvapFuchsKnudsen.H.

Member Enumeration Documentation

◆ activityCoeffMethodType

enum activityCoeffMethodType

Enumerator
pUNIFAC
pHoff

Definition at line 69 of file LiquidEvapFuchsKnudsen.H.

Constructor & Destructor Documentation

◆ LiquidEvapFuchsKnudsen() [1/2]

LiquidEvapFuchsKnudsen	(	const dictionary &	dict,
		CloudType &	cloud
	)

Definition at line 105 of file LiquidEvapFuchsKnudsen.C.

References Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::Info, and Foam::nl.

Here is the call graph for this function:

◆ LiquidEvapFuchsKnudsen() [2/2]

LiquidEvapFuchsKnudsen ( const LiquidEvapFuchsKnudsen< CloudType > & pcm )

Definition at line 170 of file LiquidEvapFuchsKnudsen.C.

◆ ~LiquidEvapFuchsKnudsen()

virtual ~LiquidEvapFuchsKnudsen ( )

virtualdefault

Member Function Documentation

◆ Sh()

Foam::scalar Sh	(	const scalar	Re,
		const scalar	Sc
	)		const

protected

Definition at line 65 of file LiquidEvapFuchsKnudsen.C.

References Foam::cbrt(), Foam::max(), Foam::pow(), and Foam::Re().

Here is the call graph for this function:

◆ calcXc()

Foam::tmp< Foam::scalarField > calcXc ( const label celli ) const

protected

Definition at line 46 of file LiquidEvapFuchsKnudsen.C.

References forAll, Foam::sum(), thermo, and Y.

Here is the call graph for this function:

◆ calcXcSolution()

void calcXcSolution	(	const scalar	massliq,
		const scalar	masssol,
		scalar &	Xliq,
		scalar &	Xsol
	)		const

protected

Definition at line 28 of file LiquidEvapFuchsKnudsen.C.

◆ activityCoeff()

Foam::scalar activityCoeff	(	const scalar	Xliq,
		const scalar	Ysol
	)		const

protected

Definition at line 76 of file LiquidEvapFuchsKnudsen.C.

References Foam::abort(), Foam::FatalError, FatalErrorInFunction, Foam::inv(), and Foam::nl.

Here is the call graph for this function:

◆ TypeName()

TypeName ( "liquidEvapFuchsKnudsen" )

◆ clone()

virtual autoPtr<PhaseChangeModel<CloudType> > clone ( ) const

inlinevirtual

Definition at line 141 of file LiquidEvapFuchsKnudsen.H.

◆ calculate()

void calculate	(	const scalar	dt,
		const label	celli,
		const scalar	Re,
		const scalar	Pr,
		const scalar	d,
		const scalar	nu,
		const scalar	rho,
		const scalar	T,
		const scalar	Ts,
		const scalar	pc,
		const scalar	Tc,
		const scalarField &	X,
		const scalarField &	Xsol,
		const scalarField &	liqMass,
		scalarField &	dMassPC
	)		const

virtual

Implements PhaseChangeModel< CloudType >.

Definition at line 190 of file LiquidEvapFuchsKnudsen.C.

References Foam::exp(), gamma, Foam::log(), Foam::max(), nu, Foam::constant::mathematical::pi(), Foam::Re(), rho, rhog(), Foam::constant::thermodynamic::RR, sigma(), Foam::sqr(), and T.

Here is the call graph for this function:

◆ dh()

Foam::scalar dh	(	const label	idc,
		const label	idl,
		const scalar	p,
		const scalar	T
	)		const

virtual

Reimplemented from PhaseChangeModel< CloudType >.

Definition at line 260 of file LiquidEvapFuchsKnudsen.C.

References Foam::abort(), Foam::FatalError, FatalErrorInFunction, p, and T.

Here is the call graph for this function:

◆ Tvap()

Foam::scalar Tvap ( const scalarField & X ) const

virtual

Reimplemented from PhaseChangeModel< CloudType >.

Definition at line 298 of file LiquidEvapFuchsKnudsen.C.

References Foam::Zero.

◆ TMax()

Foam::scalar TMax	(	const scalar	p,
		const scalarField &	X
	)		const

virtual

Reimplemented from PhaseChangeModel< CloudType >.

Definition at line 308 of file LiquidEvapFuchsKnudsen.C.

References p, and Foam::sum().

Here is the call graph for this function:

Member Data Documentation

◆ method_

activityCoeffMethodType method_

protected

Definition at line 81 of file LiquidEvapFuchsKnudsen.H.

◆ gamma_

scalar gamma_

protected

Definition at line 84 of file LiquidEvapFuchsKnudsen.H.

◆ alpha_

scalar alpha_

protected

Definition at line 87 of file LiquidEvapFuchsKnudsen.H.

◆ liquids_

const liquidMixtureProperties& liquids_

protected

Definition at line 90 of file LiquidEvapFuchsKnudsen.H.

◆ solution_

List<word> solution_

protected

Definition at line 93 of file LiquidEvapFuchsKnudsen.H.

◆ liqToCarrierMap_

label liqToCarrierMap_

protected

Definition at line 96 of file LiquidEvapFuchsKnudsen.H.

◆ liqToLiqMap_

label liqToLiqMap_

protected

Definition at line 99 of file LiquidEvapFuchsKnudsen.H.

◆ solToSolMap_

label solToSolMap_

protected

Definition at line 102 of file LiquidEvapFuchsKnudsen.H.

The documentation for this class was generated from the following files:

src/lagrangian/intermediate/submodels/Reacting/PhaseChangeModel/LiquidEvapFuchsKnudsen/LiquidEvapFuchsKnudsen.H
src/lagrangian/intermediate/submodels/Reacting/PhaseChangeModel/LiquidEvapFuchsKnudsen/LiquidEvapFuchsKnudsen.C
