Public Types | Public Member Functions | Protected Member Functions | Protected Attributes | List of all members
kOmegaSSTIDDES< BasicTurbulenceModel > Class Template Reference
Turbulence models » DES turbulence

k-omega-SST IDDES turbulence model for incompressible and compressible flows More...

Inheritance diagram for kOmegaSSTIDDES< BasicTurbulenceModel >:
Inheritance graph
[legend]
Collaboration diagram for kOmegaSSTIDDES< BasicTurbulenceModel >:
Collaboration graph
[legend]

Public Types

typedef BasicTurbulenceModel::alphaField alphaField

typedef BasicTurbulenceModel::rhoField rhoField

typedef BasicTurbulenceModel::transportModel transportModel

- Public Types inherited from kOmegaSSTDES< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField alphaField

typedef BasicTurbulenceModel::rhoField rhoField

typedef BasicTurbulenceModel::transportModel transportModel

- Public Types inherited from kOmegaSSTBase< DESModel< BasicTurbulenceModel > >
typedef DESModel< BasicTurbulenceModel > ::alphaField alphaField

typedef DESModel< BasicTurbulenceModel > ::rhoField rhoField

typedef DESModel< BasicTurbulenceModel > ::transportModel transportModel


Public Member Functions

 TypeName ("kOmegaSSTIDDES")

 kOmegaSSTIDDES (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)

virtual ~kOmegaSSTIDDES ()=default

virtual bool read ()

- Public Member Functions inherited from kOmegaSSTDES< BasicTurbulenceModel >
 TypeName ("kOmegaSSTDES")

 kOmegaSSTDES (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)

virtual ~kOmegaSSTDES ()=default

virtual tmp< volScalarField > LESRegion () const

- Public Member Functions inherited from kOmegaSSTBase< DESModel< BasicTurbulenceModel > >
 kOmegaSSTBase (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName)

virtual ~kOmegaSSTBase ()=default

tmp< volScalarField > DkEff (const volScalarField &F1) const

tmp< volScalarField > DomegaEff (const volScalarField &F1) const

virtual tmp< volScalarField > k () const

virtual tmp< volScalarField > omega () const

virtual void correct ()


Protected Member Functions

virtual tmp< volScalarField > dTilda (const volScalarField &magGradU, const volScalarField &CDES) const

- Protected Member Functions inherited from kOmegaSSTDES< BasicTurbulenceModel >
virtual tmp< volScalarField > CDES (const volScalarField &F1) const

virtual void correctNut (const volScalarField &S2)

virtual void correctNut ()

virtual tmp< volScalarField::Internal > epsilonByk (const volScalarField &F1, const volTensorField &gradU) const

virtual tmp< volScalarField::Internal > GbyNu (const volScalarField::Internal &GbyNu0, const volScalarField::Internal &F2, const volScalarField::Internal &S2) const

- Protected Member Functions inherited from kOmegaSSTBase< DESModel< BasicTurbulenceModel > >
void setDecayControl (const dictionary &dict)

virtual tmp< volScalarField > F1 (const volScalarField &CDkOmega) const

virtual tmp< volScalarField > F2 () const

virtual tmp< volScalarField > F3 () const

virtual tmp< volScalarField > F23 () const

tmp< volScalarField > blend (const volScalarField &F1, const dimensionedScalar &psi1, const dimensionedScalar &psi2) const

tmp< volScalarField::Internal > blend (const volScalarField::Internal &F1, const dimensionedScalar &psi1, const dimensionedScalar &psi2) const

tmp< volScalarField > alphaK (const volScalarField &F1) const

tmp< volScalarField > alphaOmega (const volScalarField &F1) const

tmp< volScalarField::Internal > beta (const volScalarField::Internal &F1) const

tmp< volScalarField::Internal > gamma (const volScalarField::Internal &F1) const

virtual tmp< volScalarField::Internal > Pk (const volScalarField::Internal &G) const

virtual tmp< fvScalarMatrix > kSource () const

virtual tmp< fvScalarMatrix > omegaSource () const

virtual tmp< fvScalarMatrix > Qsas (const volScalarField::Internal &S2, const volScalarField::Internal &gamma, const volScalarField::Internal &beta) const


Protected Attributes

dimensionedScalar Cdt1_

dimensionedScalar Cdt2_

dimensionedScalar Cl_

dimensionedScalar Ct_

const IDDESDelta & IDDESDelta_

- Protected Attributes inherited from kOmegaSSTDES< BasicTurbulenceModel >
dimensionedScalar kappa_

dimensionedScalar CDESkom_

dimensionedScalar CDESkeps_

- Protected Attributes inherited from kOmegaSSTBase< DESModel< BasicTurbulenceModel > >
dimensionedScalar alphaK1_

dimensionedScalar alphaK2_

dimensionedScalar alphaOmega1_

dimensionedScalar alphaOmega2_

dimensionedScalar gamma1_

dimensionedScalar gamma2_

dimensionedScalar beta1_

dimensionedScalar beta2_

dimensionedScalar betaStar_

dimensionedScalar a1_

dimensionedScalar b1_

dimensionedScalar c1_

Switch F3_

const volScalarField & y_

volScalarField k_

volScalarField omega_

Switch decayControl_

dimensionedScalar kInf_

dimensionedScalar omegaInf_


Detailed Description

template<class BasicTurbulenceModel>
class Foam::LESModels::kOmegaSSTIDDES< BasicTurbulenceModel >

k-omega-SST IDDES turbulence model for incompressible and compressible flows

Reference:

    Gritskevich, M.S., Garbaruk, A.V., Schuetze, J., Menter, F.R. (2011)
    Development of DDES and IDDES Formulations for the k-omega
    Shear Stress Transport Model, Flow, Turbulence and Combustion,
    pp. 1-19
Source files

Definition at line 62 of file kOmegaSSTIDDES.H.

Member Typedef Documentation

◆ alphaField

typedef BasicTurbulenceModel::alphaField alphaField

Definition at line 118 of file kOmegaSSTIDDES.H.

◆ rhoField

typedef BasicTurbulenceModel::rhoField rhoField

Definition at line 119 of file kOmegaSSTIDDES.H.

◆ transportModel

typedef BasicTurbulenceModel::transportModel transportModel

Definition at line 120 of file kOmegaSSTIDDES.H.

Constructor & Destructor Documentation

◆ kOmegaSSTIDDES()

kOmegaSSTIDDES ( const alphaField &  alpha,
const rhoField &  rho,
const volVectorField &  U,
const surfaceScalarField &  alphaRhoPhi,
const surfaceScalarField &  phi,
const transportModel &  transport,
const word &  propertiesName = turbulenceModel::propertiesName,
const word &  type = typeName
)

Definition at line 159 of file kOmegaSSTIDDES.C.

References Foam::type().

Here is the call graph for this function:

◆ ~kOmegaSSTIDDES()

virtual ~kOmegaSSTIDDES ( )
virtualdefault

Member Function Documentation

◆ dTilda()

tmp< volScalarField > dTilda ( const volScalarField &  magGradU,
const volScalarField &  CDES
) const
protectedvirtual

Reimplemented from kOmegaSSTDES< BasicTurbulenceModel >.

Definition at line 117 of file kOmegaSSTIDDES.C.

References Foam::constant::atomic::alpha, delta, Foam::dimLength, Foam::exp(), k, Foam::max(), Foam::min(), Foam::neg(), Foam::pos0(), Foam::pow(), Foam::sqr(), and Foam::sqrt().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "kOmegaSSTIDDES< BasicTurbulenceModel >"  )

◆ read()

bool read
virtual

Reimplemented from kOmegaSSTDES< BasicTurbulenceModel >.

Definition at line 230 of file kOmegaSSTIDDES.C.

Member Data Documentation

◆ Cdt1_

dimensionedScalar Cdt1_
protected

Definition at line 97 of file kOmegaSSTIDDES.H.

◆ Cdt2_

dimensionedScalar Cdt2_
protected

Definition at line 98 of file kOmegaSSTIDDES.H.

◆ Cl_

dimensionedScalar Cl_
protected

Definition at line 99 of file kOmegaSSTIDDES.H.

◆ Ct_

dimensionedScalar Ct_
protected

Definition at line 100 of file kOmegaSSTIDDES.H.

◆ IDDESDelta_

const IDDESDelta& IDDESDelta_
protected

Definition at line 104 of file kOmegaSSTIDDES.H.

The documentation for this class was generated from the following files:
