Public Types | Public Member Functions | Protected Member Functions | Protected Attributes | List of all members
kOmegaSSTDES< BasicTurbulenceModel > Class Template Reference
Turbulence models » DES turbulence

k-omega-SST DES turbulence model for incompressible and compressible flows More...

Inheritance diagram for kOmegaSSTDES< BasicTurbulenceModel >:
Inheritance graph
[legend]
Collaboration diagram for kOmegaSSTDES< BasicTurbulenceModel >:
Collaboration graph
[legend]

Public Types

typedef BasicTurbulenceModel::alphaField alphaField

typedef BasicTurbulenceModel::rhoField rhoField

typedef BasicTurbulenceModel::transportModel transportModel

- Public Types inherited from kOmegaSSTBase< DESModel< BasicTurbulenceModel > >
typedef DESModel< BasicTurbulenceModel > ::alphaField alphaField

typedef DESModel< BasicTurbulenceModel > ::rhoField rhoField

typedef DESModel< BasicTurbulenceModel > ::transportModel transportModel


Public Member Functions

 TypeName ("kOmegaSSTDES")

 kOmegaSSTDES (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)

virtual ~kOmegaSSTDES ()=default

virtual bool read ()

virtual tmp< volScalarField > LESRegion () const

- Public Member Functions inherited from kOmegaSSTBase< DESModel< BasicTurbulenceModel > >
 kOmegaSSTBase (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName)

virtual ~kOmegaSSTBase ()=default

tmp< volScalarField > DkEff (const volScalarField &F1) const

tmp< volScalarField > DomegaEff (const volScalarField &F1) const

virtual tmp< volScalarField > k () const

virtual tmp< volScalarField > omega () const

virtual void correct ()


Protected Member Functions

virtual tmp< volScalarField > CDES (const volScalarField &F1) const

virtual void correctNut (const volScalarField &S2)

virtual void correctNut ()

virtual tmp< volScalarField > dTilda (const volScalarField &magGradU, const volScalarField &CDES) const

virtual tmp< volScalarField::Internal > epsilonByk (const volScalarField &F1, const volTensorField &gradU) const

virtual tmp< volScalarField::Internal > GbyNu (const volScalarField::Internal &GbyNu0, const volScalarField::Internal &F2, const volScalarField::Internal &S2) const

- Protected Member Functions inherited from kOmegaSSTBase< DESModel< BasicTurbulenceModel > >
void setDecayControl (const dictionary &dict)

virtual tmp< volScalarField > F1 (const volScalarField &CDkOmega) const

virtual tmp< volScalarField > F2 () const

virtual tmp< volScalarField > F3 () const

virtual tmp< volScalarField > F23 () const

tmp< volScalarField > blend (const volScalarField &F1, const dimensionedScalar &psi1, const dimensionedScalar &psi2) const

tmp< volScalarField::Internal > blend (const volScalarField::Internal &F1, const dimensionedScalar &psi1, const dimensionedScalar &psi2) const

tmp< volScalarField > alphaK (const volScalarField &F1) const

tmp< volScalarField > alphaOmega (const volScalarField &F1) const

tmp< volScalarField::Internal > beta (const volScalarField::Internal &F1) const

tmp< volScalarField::Internal > gamma (const volScalarField::Internal &F1) const

virtual tmp< volScalarField::Internal > Pk (const volScalarField::Internal &G) const

virtual tmp< fvScalarMatrix > kSource () const

virtual tmp< fvScalarMatrix > omegaSource () const

virtual tmp< fvScalarMatrix > Qsas (const volScalarField::Internal &S2, const volScalarField::Internal &gamma, const volScalarField::Internal &beta) const


Protected Attributes

dimensionedScalar kappa_

dimensionedScalar CDESkom_

dimensionedScalar CDESkeps_

- Protected Attributes inherited from kOmegaSSTBase< DESModel< BasicTurbulenceModel > >
dimensionedScalar alphaK1_

dimensionedScalar alphaK2_

dimensionedScalar alphaOmega1_

dimensionedScalar alphaOmega2_

dimensionedScalar gamma1_

dimensionedScalar gamma2_

dimensionedScalar beta1_

dimensionedScalar beta2_

dimensionedScalar betaStar_

dimensionedScalar a1_

dimensionedScalar b1_

dimensionedScalar c1_

Switch F3_

const volScalarField & y_

volScalarField k_

volScalarField omega_

Switch decayControl_

dimensionedScalar kInf_

dimensionedScalar omegaInf_


Detailed Description

template<class BasicTurbulenceModel>
class Foam::LESModels::kOmegaSSTDES< BasicTurbulenceModel >

k-omega-SST DES turbulence model for incompressible and compressible flows

Reference:

    Strelets, M. (2001)
    Detached Eddy Simulation of Massively Separated Flows,
    39th AIAA Aerospace Sciences Meeting and Exhibit, Reno, NV
Note
The default values of the DES constants implemented are code-specific values calibrated for OpenFOAM using decaying isotropic turbulence, and hence deviate slightly from the values suggested in the reference publication.
Source files

Definition at line 67 of file kOmegaSSTDES.H.

Member Typedef Documentation

◆ alphaField

typedef BasicTurbulenceModel::alphaField alphaField

Definition at line 127 of file kOmegaSSTDES.H.

◆ rhoField

typedef BasicTurbulenceModel::rhoField rhoField

Definition at line 128 of file kOmegaSSTDES.H.

◆ transportModel

typedef BasicTurbulenceModel::transportModel transportModel

Definition at line 129 of file kOmegaSSTDES.H.

Constructor & Destructor Documentation

◆ kOmegaSSTDES()

kOmegaSSTDES ( const alphaField &  alpha,
const rhoField &  rho,
const volVectorField &  U,
const surfaceScalarField &  alphaRhoPhi,
const surfaceScalarField &  phi,
const transportModel &  transport,
const word &  propertiesName = turbulenceModel::propertiesName,
const word &  type = typeName
)

Definition at line 93 of file kOmegaSSTDES.C.

References Foam::type().

Here is the call graph for this function:

◆ ~kOmegaSSTDES()

virtual ~kOmegaSSTDES ( )
virtualdefault

Member Function Documentation

◆ CDES()

virtual tmp<volScalarField> CDES ( const volScalarField &  F1) const
inlineprotectedvirtual

Definition at line 94 of file kOmegaSSTDES.H.

References kOmegaSSTBase< DESModel< BasicTurbulenceModel > >::blend(), kOmegaSSTDES< BasicTurbulenceModel >::CDESkeps_, and kOmegaSSTDES< BasicTurbulenceModel >::CDESkom_.

Here is the call graph for this function:

◆ correctNut() [1/2]

void correctNut ( const volScalarField &  S2)
protectedvirtual

Reimplemented from kOmegaSSTBase< DESModel< BasicTurbulenceModel > >.

Definition at line 34 of file kOmegaSSTDES.C.

◆ correctNut() [2/2]

void correctNut
protectedvirtual

Reimplemented from kOmegaSSTBase< DESModel< BasicTurbulenceModel > >.

Definition at line 45 of file kOmegaSSTDES.C.

References Foam::fvc::grad(), Foam::magSqr(), and Foam::symm().

Here is the call graph for this function:

◆ dTilda()

tmp< volScalarField > dTilda ( const volScalarField &  magGradU,
const volScalarField &  CDES
) const
protectedvirtual

Reimplemented in kOmegaSSTIDDES< BasicTurbulenceModel >, and kOmegaSSTDDES< BasicTurbulenceModel >.

Definition at line 53 of file kOmegaSSTDES.C.

References delta, k, Foam::min(), and Foam::sqrt().

Here is the call graph for this function:

◆ epsilonByk()

tmp< volScalarField::Internal > epsilonByk ( const volScalarField &  F1,
const volTensorField &  gradU
) const
protectedvirtual

Reimplemented from kOmegaSSTBase< DESModel< BasicTurbulenceModel > >.

Definition at line 67 of file kOmegaSSTDES.C.

References F1, Foam::mag(), and Foam::sqrt().

Here is the call graph for this function:

◆ GbyNu()

tmp< volScalarField::Internal > GbyNu ( const volScalarField::Internal &  GbyNu0,
const volScalarField::Internal &  F2,
const volScalarField::Internal &  S2
) const
protectedvirtual

Reimplemented from kOmegaSSTBase< DESModel< BasicTurbulenceModel > >.

Definition at line 79 of file kOmegaSSTDES.C.

◆ TypeName()

TypeName ( "kOmegaSSTDES< BasicTurbulenceModel >"  )

◆ read()

bool read
virtual

Reimplemented from kOmegaSSTBase< DESModel< BasicTurbulenceModel > >.

Reimplemented in kOmegaSSTIDDES< BasicTurbulenceModel >, and kOmegaSSTDDES< BasicTurbulenceModel >.

Definition at line 156 of file kOmegaSSTDES.C.

References Foam::read().

Here is the call graph for this function:

◆ LESRegion()

tmp< volScalarField > LESRegion
virtual

Definition at line 172 of file kOmegaSSTDES.C.

References F1, Foam::fvc::grad(), k, Foam::mag(), Foam::neg(), IOobject::NO_READ, IOobject::NO_WRITE, Foam::sqrt(), and U.

Here is the call graph for this function:

Member Data Documentation

◆ kappa_

dimensionedScalar kappa_
protected

Definition at line 86 of file kOmegaSSTDES.H.

◆ CDESkom_

dimensionedScalar CDESkom_
protected

Definition at line 87 of file kOmegaSSTDES.H.

Referenced by kOmegaSSTDES< BasicTurbulenceModel >::CDES().

◆ CDESkeps_

dimensionedScalar CDESkeps_
protected

Definition at line 88 of file kOmegaSSTDES.H.

Referenced by kOmegaSSTDES< BasicTurbulenceModel >::CDES().

The documentation for this class was generated from the following files:
