WALE< BasicTurbulenceModel > Class Template Reference

The Wall-adapting local eddy-viscosity (WALE) SGS model. More...

Inheritance diagram for WALE< BasicTurbulenceModel >:

Collaboration diagram for WALE< BasicTurbulenceModel >:

Public Types
typedef BasicTurbulenceModel::alphaField	alphaField
typedef BasicTurbulenceModel::rhoField	rhoField
typedef BasicTurbulenceModel::transportModel	transportModel
Public Types inherited from LESeddyViscosity< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField	alphaField
typedef BasicTurbulenceModel::rhoField	rhoField
typedef BasicTurbulenceModel::transportModel	transportModel
Public Types inherited from eddyViscosity< LESModel< BasicTurbulenceModel > >
typedef LESModel< BasicTurbulenceModel > ::alphaField	alphaField
typedef LESModel< BasicTurbulenceModel > ::rhoField	rhoField
typedef LESModel< BasicTurbulenceModel > ::transportModel	transportModel
Public Types inherited from linearViscousStress< LESModel< BasicTurbulenceModel > >
typedef LESModel< BasicTurbulenceModel > ::alphaField	alphaField
typedef LESModel< BasicTurbulenceModel > ::rhoField	rhoField
typedef LESModel< BasicTurbulenceModel > ::transportModel	transportModel
Public Types inherited from LESModel< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField	alphaField
typedef BasicTurbulenceModel::rhoField	rhoField
typedef BasicTurbulenceModel::transportModel	transportModel

Public Member Functions
	TypeName ("WALE")
	WALE (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)
virtual	~WALE ()=default
virtual bool	read ()
virtual tmp< volScalarField >	k () const
virtual void	correct ()
Public Member Functions inherited from LESeddyViscosity< BasicTurbulenceModel >
	LESeddyViscosity (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName)
virtual	~LESeddyViscosity ()=default
Public Member Functions inherited from eddyViscosity< LESModel< BasicTurbulenceModel > >
	eddyViscosity (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)
virtual	~eddyViscosity ()=default
virtual tmp< volScalarField >	nut () const
virtual tmp< scalarField >	nut (const label patchi) const
virtual tmp< volScalarField >	k () const=0
virtual tmp< volSymmTensorField >	R () const
virtual void	validate ()
Public Member Functions inherited from linearViscousStress< LESModel< BasicTurbulenceModel > >
	linearViscousStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)
virtual	~linearViscousStress ()=default
virtual tmp< volSymmTensorField >	devRhoReff () const
virtual tmp< volSymmTensorField >	devRhoReff (const volVectorField &U) const
virtual tmp< fvVectorMatrix >	divDevRhoReff (volVectorField &U) const
virtual tmp< fvVectorMatrix >	divDevRhoReff (const volScalarField &rho, volVectorField &U) const
Public Member Functions inherited from LESModel< BasicTurbulenceModel >
	TypeName ("LES")
	declareRunTimeSelectionTable (autoPtr, LESModel, dictionary,(const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName),(alpha, rho, U, alphaRhoPhi, phi, transport, propertiesName))
	LESModel (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)
virtual	~LESModel ()=default
virtual const dictionary &	coeffDict () const
const dimensionedScalar &	Ce () const noexcept
const dimensionedScalar &	kMin () const
dimensionedScalar &	kMin ()
const volScalarField &	delta () const
virtual tmp< volScalarField >	nuEff () const
virtual tmp< scalarField >	nuEff (const label patchi) const
virtual tmp< volScalarField >	epsilon () const
virtual tmp< volScalarField >	omega () const

Protected Member Functions
tmp< volSymmTensorField >	Sd (const volTensorField &gradU) const
tmp< volScalarField >	k (const volTensorField &gradU) const
virtual void	correctNut ()
Protected Member Functions inherited from LESModel< BasicTurbulenceModel >
virtual void	printCoeffs (const word &type)
	LESModel (const LESModel &)=delete
void	operator= (const LESModel &)=delete

Protected Attributes
dimensionedScalar	Ck_
dimensionedScalar	Cw_
Protected Attributes inherited from eddyViscosity< LESModel< BasicTurbulenceModel > >
volScalarField	nut_
Protected Attributes inherited from LESModel< BasicTurbulenceModel >
dictionary	LESDict_
Switch	turbulence_
Switch	printCoeffs_
dictionary	coeffDict_
dimensionedScalar	Ce_
dimensionedScalar	kMin_
dimensionedScalar	epsilonMin_
dimensionedScalar	omegaMin_
autoPtr< Foam::LESdelta >	delta_

Additional Inherited Members
Static Public Member Functions inherited from LESModel< BasicTurbulenceModel >
static autoPtr< LESModel >	New (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName)

Detailed Description

template<class BasicTurbulenceModel>
class Foam::LESModels::WALE< BasicTurbulenceModel >

The Wall-adapting local eddy-viscosity (WALE) SGS model.

Reference:

    Nicoud, F., & Ducros, F. (1999).
    Subgrid-scale stress modelling based on the square of the velocity
    gradient tensor.
    Flow, Turbulence and Combustion, 62(3), 183-200.

The default model coefficients are

    WALECoeffs
    {
        Ck                  0.094;
        Ce                  1.048;e
        Cw                  0.325;
    }

See also

Foam::LESModels::Smagorinsky

Source files

• WALE.H
• WALE.C

Definition at line 75 of file WALE.H.

Member Typedef Documentation

alphaField

typedef BasicTurbulenceModel::alphaField alphaField

Definition at line 112 of file WALE.H.

rhoField

typedef BasicTurbulenceModel::rhoField rhoField

Definition at line 113 of file WALE.H.

transportModel

typedef BasicTurbulenceModel::transportModel transportModel

Definition at line 114 of file WALE.H.

Constructor & Destructor Documentation

WALE()

WALE	(	const alphaField &	alpha,
		const rhoField &	rho,
		const volVectorField &	U,
		const surfaceScalarField &	alphaRhoPhi,
		const surfaceScalarField &	phi,
		const transportModel &	transport,
		const word &	propertiesName = turbulenceModel::propertiesName,
		const word &	type = typeName
	)

Definition at line 99 of file WALE.C.

References Foam::type().

Here is the call graph for this function:

~WALE()

virtual ~WALE ( )

virtualdefault

Member Function Documentation

Sd()

tmp< volSymmTensorField > Sd ( const volTensorField &  gradU ) const

protected

Definition at line 36 of file WALE.C.

References Foam::dev(), and Foam::symm().

Here is the call graph for this function:

k() [1/2]

tmp< volScalarField > k ( const volTensorField &  gradU ) const

protected

Definition at line 46 of file WALE.C.

References delta, IOobject::groupName(), Foam::magSqr(), Foam::pow(), Foam::pow3(), Foam::sqr(), and Foam::symm().

Here is the call graph for this function:

correctNut()

void correctNut

protectedvirtual

Implements eddyViscosity< LESModel< BasicTurbulenceModel > >.

Definition at line 85 of file WALE.C.

References optionList::correct(), delta, Foam::fvc::grad(), k, options::New(), and Foam::sqrt().

Here is the call graph for this function:

TypeName()

TypeName

(

"WALE< BasicTurbulenceModel >"

)

read()

bool read

virtual

Reimplemented from LESeddyViscosity< BasicTurbulenceModel >.

Definition at line 152 of file WALE.C.

k() [2/2]

virtual tmp<volScalarField> k ( ) const

inlinevirtual

Definition at line 147 of file WALE.H.

References Foam::fvc::grad().

Here is the call graph for this function:

correct()

void correct

virtual

Implements eddyViscosity< LESModel< BasicTurbulenceModel > >.

Definition at line 167 of file WALE.C.

References eddyViscosity< LESModel< BasicTurbulenceModel > >::correct().

Here is the call graph for this function:

Member Data Documentation

Ck_

dimensionedScalar Ck_

protected

Definition at line 92 of file WALE.H.

Cw_

dimensionedScalar Cw_

protected

Definition at line 93 of file WALE.H.

---

The documentation for this class was generated from the following files:

• src/TurbulenceModels/turbulenceModels/LES/WALE/WALE.H
• src/TurbulenceModels/turbulenceModels/LES/WALE/WALE.C
