SpalartAllmaras DDES turbulence model for incompressible and compressible flows. More...

Inheritance diagram for SpalartAllmarasDDES< BasicTurbulenceModel >:

Collaboration diagram for SpalartAllmarasDDES< BasicTurbulenceModel >:

Public Types
typedef BasicTurbulenceModel::alphaField	alphaField

typedef BasicTurbulenceModel::rhoField	rhoField

typedef BasicTurbulenceModel::transportModel	transportModel

Public Types inherited from SpalartAllmarasDES< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField	alphaField

typedef BasicTurbulenceModel::rhoField	rhoField

typedef BasicTurbulenceModel::transportModel	transportModel

Public Types inherited from DESModel< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField	alphaField

typedef BasicTurbulenceModel::rhoField	rhoField

typedef BasicTurbulenceModel::transportModel	transportModel

Public Types inherited from LESeddyViscosity< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField	alphaField

typedef BasicTurbulenceModel::rhoField	rhoField

typedef BasicTurbulenceModel::transportModel	transportModel

Public Types inherited from eddyViscosity< LESModel< BasicTurbulenceModel > >
typedef LESModel< BasicTurbulenceModel > ::alphaField	alphaField

typedef LESModel< BasicTurbulenceModel > ::rhoField	rhoField

typedef LESModel< BasicTurbulenceModel > ::transportModel	transportModel

Public Types inherited from linearViscousStress< LESModel< BasicTurbulenceModel > >
typedef LESModel< BasicTurbulenceModel > ::alphaField	alphaField

typedef LESModel< BasicTurbulenceModel > ::rhoField	rhoField

typedef LESModel< BasicTurbulenceModel > ::transportModel	transportModel

Public Types inherited from LESModel< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField	alphaField

typedef BasicTurbulenceModel::rhoField	rhoField

typedef BasicTurbulenceModel::transportModel	transportModel

Public Member Functions
	TypeName ("SpalartAllmarasDDES")

	SpalartAllmarasDDES (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)

virtual	~SpalartAllmarasDDES ()=default

virtual bool	read ()

Public Member Functions inherited from SpalartAllmarasDES< BasicTurbulenceModel >
	TypeName ("SpalartAllmarasDES")

	SpalartAllmarasDES (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)

virtual	~SpalartAllmarasDES ()=default

tmp< volScalarField >	DnuTildaEff () const

virtual tmp< volScalarField >	k () const

tmp< volScalarField >	nuTilda () const

virtual tmp< volScalarField >	LESRegion () const

virtual void	correct ()

Public Member Functions inherited from DESModel< BasicTurbulenceModel >
	DESModel (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName)

virtual	~DESModel ()

Public Member Functions inherited from DESModelBase
	DESModelBase ()

virtual	~DESModelBase ()=default

	ClassName ("DESModelBase")

Public Member Functions inherited from LESeddyViscosity< BasicTurbulenceModel >
	LESeddyViscosity (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName)

virtual	~LESeddyViscosity ()=default

Public Member Functions inherited from eddyViscosity< LESModel< BasicTurbulenceModel > >
	eddyViscosity (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual	~eddyViscosity ()=default

virtual tmp< volScalarField >	nut () const

virtual tmp< scalarField >	nut (const label patchi) const

virtual tmp< volScalarField >	k () const=0

virtual tmp< volSymmTensorField >	R () const

virtual void	validate ()

Public Member Functions inherited from linearViscousStress< LESModel< BasicTurbulenceModel > >
	linearViscousStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual	~linearViscousStress ()=default

virtual tmp< volSymmTensorField >	devRhoReff () const

virtual tmp< volSymmTensorField >	devRhoReff (const volVectorField &U) const

virtual tmp< fvVectorMatrix >	divDevRhoReff (volVectorField &U) const

virtual tmp< fvVectorMatrix >	divDevRhoReff (const volScalarField &rho, volVectorField &U) const

Public Member Functions inherited from LESModel< BasicTurbulenceModel >
	TypeName ("LES")

	declareRunTimeSelectionTable (autoPtr, LESModel, dictionary,(const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName),(alpha, rho, U, alphaRhoPhi, phi, transport, propertiesName))

	LESModel (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual	~LESModel ()=default

virtual const dictionary &	coeffDict () const

const dimensionedScalar &	Ce () const noexcept

const dimensionedScalar &	kMin () const

dimensionedScalar &	kMin ()

const volScalarField &	delta () const

virtual tmp< volScalarField >	nuEff () const

virtual tmp< scalarField >	nuEff (const label patchi) const

virtual tmp< volScalarField >	epsilon () const

virtual tmp< volScalarField >	omega () const

Protected Member Functions
virtual tmp< volScalarField >	dTilda (const volScalarField &chi, const volScalarField &fv1, const volTensorField &gradU) const

Protected Member Functions inherited from SpalartAllmarasDES< BasicTurbulenceModel >
tmp< volScalarField >	chi () const

tmp< volScalarField >	fv1 (const volScalarField &chi) const

tmp< volScalarField >	fv2 (const volScalarField &chi, const volScalarField &fv1) const

tmp< volScalarField >	ft2 (const volScalarField &chi) const

tmp< volScalarField >	Omega (const volTensorField &gradU) const

tmp< volScalarField >	Stilda (const volScalarField &chi, const volScalarField &fv1, const volScalarField &Omega, const volScalarField &dTilda) const

tmp< volScalarField >	r (const volScalarField &nur, const volScalarField &Omega, const volScalarField &dTilda) const

tmp< volScalarField >	fw (const volScalarField &Omega, const volScalarField &dTilda) const

tmp< volScalarField >	psi (const volScalarField &chi, const volScalarField &fv1) const

void	correctNut (const volScalarField &fv1)

virtual void	correctNut ()

Protected Member Functions inherited from LESModel< BasicTurbulenceModel >
virtual void	printCoeffs (const word &type)

	LESModel (const LESModel &)=delete

void	operator= (const LESModel &)=delete

Protected Attributes
dimensionedScalar	Cd1_

dimensionedScalar	Cd2_

Protected Attributes inherited from SpalartAllmarasDES< BasicTurbulenceModel >
dimensionedScalar	sigmaNut_

dimensionedScalar	kappa_

dimensionedScalar	Cb1_

dimensionedScalar	Cb2_

dimensionedScalar	Cw1_

dimensionedScalar	Cw2_

dimensionedScalar	Cw3_

dimensionedScalar	Cv1_

dimensionedScalar	Cs_

dimensionedScalar	CDES_

dimensionedScalar	ck_

Switch	lowReCorrection_

dimensionedScalar	Ct3_

dimensionedScalar	Ct4_

dimensionedScalar	fwStar_

volScalarField	nuTilda_

const volScalarField &	y_

Protected Attributes inherited from eddyViscosity< LESModel< BasicTurbulenceModel > >
volScalarField	nut_

Protected Attributes inherited from LESModel< BasicTurbulenceModel >
dictionary	LESDict_

Switch	turbulence_

Switch	printCoeffs_

dictionary	coeffDict_

dimensionedScalar	Ce_

dimensionedScalar	kMin_

dimensionedScalar	epsilonMin_

dimensionedScalar	omegaMin_

autoPtr< Foam::LESdelta >	delta_

Additional Inherited Members
Static Public Member Functions inherited from LESModel< BasicTurbulenceModel >
static autoPtr< LESModel >	New (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName)

Detailed Description

template<class BasicTurbulenceModel>
class Foam::LESModels::SpalartAllmarasDDES< BasicTurbulenceModel >

SpalartAllmaras DDES turbulence model for incompressible and compressible flows.

Reference:

    Spalart, P. R., Deck, S., Shur, M. L., Squires, K. D., Strelets, M. K.,
    & Travin, A. (2006).
    A new version of detached-eddy simulation, resistant to ambiguous grid
    densities.
    Theoretical and computational fluid dynamics, 20(3), 181-195.

Source files

Definition at line 63 of file SpalartAllmarasDDES.H.

Member Typedef Documentation

◆ alphaField

typedef BasicTurbulenceModel::alphaField alphaField

Definition at line 103 of file SpalartAllmarasDDES.H.

◆ rhoField

typedef BasicTurbulenceModel::rhoField rhoField

Definition at line 104 of file SpalartAllmarasDDES.H.

◆ transportModel

typedef BasicTurbulenceModel::transportModel transportModel

Definition at line 105 of file SpalartAllmarasDDES.H.

Constructor & Destructor Documentation

◆ SpalartAllmarasDDES()

SpalartAllmarasDDES	(	const alphaField &	alpha,
		const rhoField &	rho,
		const volVectorField &	U,
		const surfaceScalarField &	alphaRhoPhi,
		const surfaceScalarField &	phi,
		const transportModel &	transport,
		const word &	propertiesName = `turbulenceModel::propertiesName`,
		const word &	type = `typeName`
	)

Definition at line 102 of file SpalartAllmarasDDES.C.

References Foam::type().

Here is the call graph for this function:

◆ ~SpalartAllmarasDDES()

virtual ~SpalartAllmarasDDES ( )

virtualdefault

Member Function Documentation

◆ dTilda()

tmp< volScalarField > dTilda	(	const volScalarField &	chi,
		const volScalarField &	fv1,
		const volTensorField &	gradU
	)		const

protectedvirtual

Reimplemented from SpalartAllmarasDES< BasicTurbulenceModel >.

Definition at line 75 of file SpalartAllmarasDDES.C.

References delta, Foam::dimLength, Foam::mag(), Foam::max(), psi, and Foam::Zero.

Here is the call graph for this function:

◆ TypeName()

TypeName ( "SpalartAllmarasDDES< BasicTurbulenceModel >" )

◆ read()

bool read

virtual

Reimplemented from SpalartAllmarasDES< BasicTurbulenceModel >.

Definition at line 154 of file SpalartAllmarasDDES.C.

Member Data Documentation

◆ Cd1_

dimensionedScalar Cd1_

protected

Definition at line 86 of file SpalartAllmarasDDES.H.

◆ Cd2_

dimensionedScalar Cd2_

protected

Definition at line 87 of file SpalartAllmarasDDES.H.

The documentation for this class was generated from the following files:

src/TurbulenceModels/turbulenceModels/DES/SpalartAllmarasDDES/SpalartAllmarasDDES.H
src/TurbulenceModels/turbulenceModels/DES/SpalartAllmarasDDES/SpalartAllmarasDDES.C
