SmagorinskyZhang< BasicTurbulenceModel > Class Template Reference

The Smagorinsky SGS model including bubble-generated turbulence. More...

Inheritance diagram for SmagorinskyZhang< BasicTurbulenceModel >:

Collaboration diagram for SmagorinskyZhang< BasicTurbulenceModel >:

Public Types
typedef BasicTurbulenceModel::alphaField	alphaField
typedef BasicTurbulenceModel::rhoField	rhoField
typedef BasicTurbulenceModel::transportModel	transportModel
Public Types inherited from Smagorinsky< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField	alphaField
typedef BasicTurbulenceModel::rhoField	rhoField
typedef BasicTurbulenceModel::transportModel	transportModel
Public Types inherited from LESeddyViscosity< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField	alphaField
typedef BasicTurbulenceModel::rhoField	rhoField
typedef BasicTurbulenceModel::transportModel	transportModel
Public Types inherited from eddyViscosity< LESModel< BasicTurbulenceModel > >
typedef LESModel< BasicTurbulenceModel > ::alphaField	alphaField
typedef LESModel< BasicTurbulenceModel > ::rhoField	rhoField
typedef LESModel< BasicTurbulenceModel > ::transportModel	transportModel
Public Types inherited from linearViscousStress< LESModel< BasicTurbulenceModel > >
typedef LESModel< BasicTurbulenceModel > ::alphaField	alphaField
typedef LESModel< BasicTurbulenceModel > ::rhoField	rhoField
typedef LESModel< BasicTurbulenceModel > ::transportModel	transportModel
Public Types inherited from LESModel< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField	alphaField
typedef BasicTurbulenceModel::rhoField	rhoField
typedef BasicTurbulenceModel::transportModel	transportModel

Public Member Functions
	TypeName ("SmagorinskyZhang")
	SmagorinskyZhang (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)
virtual	~SmagorinskyZhang ()=default
virtual bool	read ()
Public Member Functions inherited from Smagorinsky< BasicTurbulenceModel >
	TypeName ("Smagorinsky")
	Smagorinsky (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)
virtual	~Smagorinsky ()=default
virtual tmp< volScalarField >	k () const
virtual void	correct ()
Public Member Functions inherited from LESeddyViscosity< BasicTurbulenceModel >
	LESeddyViscosity (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName)
virtual	~LESeddyViscosity ()=default
Public Member Functions inherited from eddyViscosity< LESModel< BasicTurbulenceModel > >
	eddyViscosity (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)
virtual	~eddyViscosity ()=default
virtual tmp< volScalarField >	nut () const
virtual tmp< scalarField >	nut (const label patchi) const
virtual tmp< volScalarField >	k () const=0
virtual tmp< volSymmTensorField >	R () const
virtual void	validate ()
Public Member Functions inherited from linearViscousStress< LESModel< BasicTurbulenceModel > >
	linearViscousStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)
virtual	~linearViscousStress ()=default
virtual tmp< volSymmTensorField >	devRhoReff () const
virtual tmp< volSymmTensorField >	devRhoReff (const volVectorField &U) const
virtual tmp< fvVectorMatrix >	divDevRhoReff (volVectorField &U) const
virtual tmp< fvVectorMatrix >	divDevRhoReff (const volScalarField &rho, volVectorField &U) const
Public Member Functions inherited from LESModel< BasicTurbulenceModel >
	TypeName ("LES")
	declareRunTimeSelectionTable (autoPtr, LESModel, dictionary,(const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName),(alpha, rho, U, alphaRhoPhi, phi, transport, propertiesName))
	LESModel (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)
virtual	~LESModel ()=default
virtual const dictionary &	coeffDict () const
const dimensionedScalar &	Ce () const noexcept
const dimensionedScalar &	kMin () const
dimensionedScalar &	kMin ()
const volScalarField &	delta () const
virtual tmp< volScalarField >	nuEff () const
virtual tmp< scalarField >	nuEff (const label patchi) const
virtual tmp< volScalarField >	epsilon () const
virtual tmp< volScalarField >	omega () const

Protected Member Functions
virtual void	correctNut ()
Protected Member Functions inherited from Smagorinsky< BasicTurbulenceModel >
tmp< volScalarField >	k (const tmp< volTensorField > &gradU) const
Protected Member Functions inherited from LESModel< BasicTurbulenceModel >
virtual void	printCoeffs (const word &type)
	LESModel (const LESModel &)=delete
void	operator= (const LESModel &)=delete

Protected Attributes
dimensionedScalar	Cmub_
Protected Attributes inherited from Smagorinsky< BasicTurbulenceModel >
dimensionedScalar	Ck_
Protected Attributes inherited from eddyViscosity< LESModel< BasicTurbulenceModel > >
volScalarField	nut_
Protected Attributes inherited from LESModel< BasicTurbulenceModel >
dictionary	LESDict_
Switch	turbulence_
Switch	printCoeffs_
dictionary	coeffDict_
dimensionedScalar	Ce_
dimensionedScalar	kMin_
dimensionedScalar	epsilonMin_
dimensionedScalar	omegaMin_
autoPtr< Foam::LESdelta >	delta_

Additional Inherited Members
Static Public Member Functions inherited from LESModel< BasicTurbulenceModel >
static autoPtr< LESModel >	New (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName)

Detailed Description

template<class BasicTurbulenceModel>
class Foam::LESModels::SmagorinskyZhang< BasicTurbulenceModel >

The Smagorinsky SGS model including bubble-generated turbulence.

Reference:

    Zhang, D., Deen, N. G., & Kuipers, J. A. M. (2006).
    Numerical simulation of the dynamic flow behavior in a bubble column:
    a study of closures for turbulence and interface forces.
    Chemical Engineering Science, 61(23), 7593-7608.

The default model coefficients are

    SmagorinskyZhangCoeffs
    {
        Ck              0.094;
        Ce              1.048;
        Cmub            0.6;
    }

Source files

• SmagorinskyZhang.H
• SmagorinskyZhang.C

Definition at line 71 of file SmagorinskyZhang.H.

Member Typedef Documentation

alphaField

typedef BasicTurbulenceModel::alphaField alphaField

Definition at line 115 of file SmagorinskyZhang.H.

rhoField

typedef BasicTurbulenceModel::rhoField rhoField

Definition at line 116 of file SmagorinskyZhang.H.

transportModel

typedef BasicTurbulenceModel::transportModel transportModel

Definition at line 117 of file SmagorinskyZhang.H.

Constructor & Destructor Documentation

SmagorinskyZhang()

SmagorinskyZhang	(	const alphaField &	alpha,
		const rhoField &	rho,
		const volVectorField &	U,
		const surfaceScalarField &	alphaRhoPhi,
		const surfaceScalarField &	phi,
		const transportModel &	transport,
		const word &	propertiesName = turbulenceModel::propertiesName,
		const word &	type = typeName
	)

Definition at line 36 of file SmagorinskyZhang.C.

References Foam::type().

Here is the call graph for this function:

~SmagorinskyZhang()

virtual ~SmagorinskyZhang ( )

virtualdefault

Member Function Documentation

correctNut()

void correctNut

protectedvirtual

Reimplemented from Smagorinsky< BasicTurbulenceModel >.

Definition at line 127 of file SmagorinskyZhang.C.

References optionList::correct(), delta, Foam::fvc::grad(), k, Foam::mag(), options::New(), and Foam::sqrt().

Here is the call graph for this function:

TypeName()

TypeName

(

"SmagorinskyZhang< BasicTurbulenceModel >"

)

read()

bool read

virtual

Reimplemented from Smagorinsky< BasicTurbulenceModel >.

Definition at line 81 of file SmagorinskyZhang.C.

Member Data Documentation

Cmub_

dimensionedScalar Cmub_

protected

Definition at line 105 of file SmagorinskyZhang.H.

---

The documentation for this class was generated from the following files:

• src/TurbulenceModels/phaseCompressible/LES/SmagorinskyZhang/SmagorinskyZhang.H
• src/TurbulenceModels/phaseCompressible/LES/SmagorinskyZhang/SmagorinskyZhang.C
