Differential SGS Stress Equation Model for incompressible and compressible flows. More...

Inheritance diagram for DeardorffDiffStress< BasicTurbulenceModel >:

Collaboration diagram for DeardorffDiffStress< BasicTurbulenceModel >:

Public Types
typedef BasicTurbulenceModel::alphaField	alphaField

typedef BasicTurbulenceModel::rhoField	rhoField

typedef BasicTurbulenceModel::transportModel	transportModel

Public Types inherited from ReynoldsStress< LESModel< BasicTurbulenceModel > >
typedef LESModel< BasicTurbulenceModel > ::alphaField	alphaField

typedef LESModel< BasicTurbulenceModel > ::rhoField	rhoField

typedef LESModel< BasicTurbulenceModel > ::transportModel	transportModel

Public Types inherited from LESModel< BasicTurbulenceModel >
typedef BasicTurbulenceModel::alphaField	alphaField

typedef BasicTurbulenceModel::rhoField	rhoField

typedef BasicTurbulenceModel::transportModel	transportModel

Public Member Functions
	TypeName ("DeardorffDiffStress")

	DeardorffDiffStress (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName, const word &type=typeName)

virtual	~DeardorffDiffStress ()=default

virtual bool	read ()

virtual void	correct ()

Public Member Functions inherited from ReynoldsStress< LESModel< BasicTurbulenceModel > >
Foam::tmp< Foam::fvVectorMatrix >	DivDevRhoReff (const RhoFieldType &rho, volVectorField &U) const

	ReynoldsStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual	~ReynoldsStress ()=default

virtual tmp< volScalarField >	nut () const

virtual tmp< scalarField >	nut (const label patchi) const

virtual tmp< volScalarField >	k () const

virtual tmp< volSymmTensorField >	R () const

virtual tmp< volSymmTensorField >	devRhoReff () const

virtual tmp< volSymmTensorField >	devRhoReff (const volVectorField &U) const

virtual tmp< fvVectorMatrix >	divDevRhoReff (volVectorField &U) const

virtual tmp< fvVectorMatrix >	divDevRhoReff (const volScalarField &rho, volVectorField &U) const

virtual void	validate ()

Public Member Functions inherited from LESModel< BasicTurbulenceModel >
	TypeName ("LES")

	declareRunTimeSelectionTable (autoPtr, LESModel, dictionary,(const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName),(alpha, rho, U, alphaRhoPhi, phi, transport, propertiesName))

	LESModel (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName)

virtual	~LESModel ()=default

virtual const dictionary &	coeffDict () const

const dimensionedScalar &	Ce () const noexcept

const dimensionedScalar &	kMin () const

dimensionedScalar &	kMin ()

const volScalarField &	delta () const

virtual tmp< volScalarField >	nuEff () const

virtual tmp< scalarField >	nuEff (const label patchi) const

virtual tmp< volScalarField >	epsilon () const

virtual tmp< volScalarField >	omega () const

Protected Member Functions
virtual void	correctNut ()

Protected Member Functions inherited from ReynoldsStress< LESModel< BasicTurbulenceModel > >
void	boundNormalStress (volSymmTensorField &R) const

void	correctWallShearStress (volSymmTensorField &R) const

tmp< fvVectorMatrix >	DivDevRhoReff (const RhoFieldType &rho, volVectorField &U) const

Protected Member Functions inherited from LESModel< BasicTurbulenceModel >
virtual void	printCoeffs (const word &type)

	LESModel (const LESModel &)=delete

void	operator= (const LESModel &)=delete

Protected Attributes
dimensionedScalar	Ck_

dimensionedScalar	Cm_

dimensionedScalar	Ce_

dimensionedScalar	Cs_

Protected Attributes inherited from ReynoldsStress< LESModel< BasicTurbulenceModel > >
dimensionedScalar	couplingFactor_

volSymmTensorField	R_

volScalarField	nut_

Protected Attributes inherited from LESModel< BasicTurbulenceModel >
dictionary	LESDict_

Switch	turbulence_

Switch	printCoeffs_

dictionary	coeffDict_

dimensionedScalar	Ce_

dimensionedScalar	kMin_

dimensionedScalar	epsilonMin_

dimensionedScalar	omegaMin_

autoPtr< Foam::LESdelta >	delta_

Additional Inherited Members
Static Public Member Functions inherited from LESModel< BasicTurbulenceModel >
static autoPtr< LESModel >	New (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const transportModel &transport, const word &propertiesName=turbulenceModel::propertiesName)

Detailed Description

template<class BasicTurbulenceModel>
class Foam::LESModels::DeardorffDiffStress< BasicTurbulenceModel >

Differential SGS Stress Equation Model for incompressible and compressible flows.

Reference:

    Deardorff, J. W. (1973).
    The use of subgrid transport equations in a three-dimensional model
    of atmospheric turbulence.
    Journal of Fluids Engineering, 95(3), 429-438.

This SGS model uses a full balance equation for the SGS stress tensor to simulate the behaviour of B.

This implementation is as described in the above paper except that the triple correlation model of Donaldson is replaced with the generalized gradient diffusion model of Daly and Harlow:

    Daly, B. J., & Harlow, F. H. (1970).
    Transport equations in turbulence.
    Physics of Fluids (1958-1988), 13(11), 2634-2649.

with the default value for the coefficient Cs of 0.25 from

    Launder, B. E., Reece, G. J., & Rodi, W. (1975).
    Progress in the development of a Reynolds-stress turbulence closure.
    Journal of fluid mechanics, 68(03), 537-566.

Source files

Definition at line 81 of file DeardorffDiffStress.H.

Member Typedef Documentation

◆ alphaField

typedef BasicTurbulenceModel::alphaField alphaField

Definition at line 114 of file DeardorffDiffStress.H.

◆ rhoField

typedef BasicTurbulenceModel::rhoField rhoField

Definition at line 115 of file DeardorffDiffStress.H.

◆ transportModel

typedef BasicTurbulenceModel::transportModel transportModel

Definition at line 116 of file DeardorffDiffStress.H.

Constructor & Destructor Documentation

◆ DeardorffDiffStress()

DeardorffDiffStress	(	const alphaField &	alpha,
		const rhoField &	rho,
		const volVectorField &	U,
		const surfaceScalarField &	alphaRhoPhi,
		const surfaceScalarField &	phi,
		const transportModel &	transport,
		const word &	propertiesName = `turbulenceModel::propertiesName`,
		const word &	type = `typeName`
	)

Definition at line 50 of file DeardorffDiffStress.C.

References Foam::type().

Here is the call graph for this function:

◆ ~DeardorffDiffStress()

virtual ~DeardorffDiffStress ( )

virtualdefault

Member Function Documentation

◆ correctNut()

void correctNut

protectedvirtual

Implements ReynoldsStress< LESModel< BasicTurbulenceModel > >.

Definition at line 36 of file DeardorffDiffStress.C.

References optionList::correct(), delta, k, options::New(), and Foam::sqrt().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "DeardorffDiffStress< BasicTurbulenceModel >" )

◆ read()

bool read

virtual

Implements ReynoldsStress< LESModel< BasicTurbulenceModel > >.

Definition at line 121 of file DeardorffDiffStress.C.

References Foam::read().

Here is the call graph for this function:

◆ correct()

void correct

virtual

Implements ReynoldsStress< LESModel< BasicTurbulenceModel > >.

Definition at line 138 of file DeardorffDiffStress.C.

References Foam::constant::atomic::alpha, correct(), D, Foam::fvm::ddt(), delta, Foam::fvm::div(), epsilon, fvOptions, Foam::fvc::grad(), Foam::I, k, Foam::fvm::laplacian(), options::New(), nu, R, tmp::ref(), rho, Foam::fvm::Sp(), Foam::sqrt(), Foam::symm(), Foam::twoSymm(), and U.

Here is the call graph for this function:

Member Data Documentation

◆ Ck_

dimensionedScalar Ck_

protected

Definition at line 100 of file DeardorffDiffStress.H.

◆ Cm_

dimensionedScalar Cm_

protected

Definition at line 101 of file DeardorffDiffStress.H.

◆ Ce_

dimensionedScalar Ce_

protected

Definition at line 102 of file DeardorffDiffStress.H.

◆ Cs_

dimensionedScalar Cs_

protected

Definition at line 103 of file DeardorffDiffStress.H.

The documentation for this class was generated from the following files:

src/TurbulenceModels/turbulenceModels/LES/DeardorffDiffStress/DeardorffDiffStress.H
src/TurbulenceModels/turbulenceModels/LES/DeardorffDiffStress/DeardorffDiffStress.C
